NEC VT45 Assembly instructions

Quick Connect Guide
Remote Control Features
6 Volume ( + / – ) Buttons
Press and hold (+) to increase the volume.
Press and hold (–) to decrease the volume.
7 Picture Button
Press to display the Picture adjustment menu. Each time
this button is pressed, the highlight will move as follows:
Brightness →Contrast →Color →Hue →Sharpness → …
You can also select the Picture adjustment item by using
the select up or down button.
If no adjustments are performed within 3 seconds, the
Picture adjustment menu will disappear.
8 Freeze Button
Press to freeze a picture. Press again to resume motion.
9 Mute Button
This button turns off the image and sound. Press again to
restore the image and sound.
10 Aspect Button
Press to display the Aspect Ratio select menu.
Each time this button is pressed, the current aspect ratio
will change as follows:
Normal →Zoom →Wide Zoom →Cinema →Normal →...
You can also select the aspect ratio by using the Select
button.
If no adjustments are performed within 3 seconds, the
Aspect Ratio select menu will disappear.
11 Menu Button
Displays the menu.
12 Help Button
Provides information about the current signal and the status
of the projector.
13 Select ( ) Buttons
: Use these buttons to select the menu of the item
you wish to adjust.
: Use these buttons to change the level of a selected
menu item.
A press of the button executes the selection.
14 Enter Button
Use this button to enter your menu selection.
15 Cancel Button
Press this button to close menu.
1 Infrared Transmitter
Direct the remote control toward the remote sen-
sor on the projector cabinet.
2 Power Button
Use this button to turn your projector on and off.
NOTE: To turn off the projector, press and hold
the POWER button for a minimum of two seconds.
3 Source Buttons
Press to select an input device.
4 Auto Adjust Button
Use this button to adjust Position-H/V and Pixel
Clock/Phase for an optimal picture.
5 Magnify ( + / – ) Buttons
Use the (+) or (–) button to adjust the image size
up to 400%.
Connections
SOURCEAUTOADJUST
ON
STANDBY
STATUS
POWER
E
M
N
U
C
N
A
C
E
L
T
E
R
N
E
SELECT
VIDEO
IN
RGB OUT
S-VIDEO
IN
RGB IN
R IN
L/MONO
IN
IN
OUT
AUDIO
CONTROL
PC
RGB OUT
RGB IN
Step 2 Connect the supplied power cable.
ACIN
SOURCEAUTOADJUST
ON
STANDBY
STATUS
POWER
E
M
N
U
C
N
A
C
E
L
T
E
R
N
E
SELECT
IN
OUT
IN
IN
L/MONO
R
IN
IN
RGBOUT
RGB IN
CONTROL
PC
Step 3 Turn on the projector.
SOURCEAUTOADJUST
ON
STANDBY
STATUS
POWER
E
M
N
U
C
N
A
C
E
L
T
E
R
N
E
SELECT
Step 4 Set up the Projector.
To adjust the projector’s lens shift, focus or to zoom in and out use
the Lens Shift, Focus ring or Zoom lever on the lens.
To optimize image, press theAUTOADJUST button on the cabinet
or the remote control.
AC IN
SOURCE AUTO ADJUST
ON
STAND BY
STATUS
POWER
E
M
N
U
C
N
A
C
E
L
T
E
R
N
E
SELECT
IN
OUT
IN
IN
L/MONO
R
IN
IN
RGBOUT
RGB IN
CONTROL
PC
2
1
1
SOURCEA
UTOADJUST
ON
STANDBY
STATUS
POWER
E
M
N
U
C
N
A
C
E
L
T
E
R
N
E
SELECT
ACIN
IN
OUT
IN
IN
L/MONO
R
IN
IN
RGB OUT
RGBIN
CONTROL
PC
2
1
For older Macintosh computers, use a
commercially available pin adapter to
connect to your Macintosh’s video port.
Power down all equipment
before making connections.
Power button NOTE: To turn off the projector,
press and hold the POWER button
for a minimum of two seconds.
Using the Lens Shift
1
Grip the lens shift lever on the top and bottom.
2
Hold the lever to move the lens vertically or horizontally.
See page E-14 for Lens Shift Adjustable Range.
Adjusting the Tilt Foot
1
Press and hold the Tilt button on the front of the projector.
2
Lift the front edge of the projector to the desired height, and release the button to lock theAdjustable Tilt
Foot.
• If the projected image does not appear square to the screen then use keystone correction for proper adjustment.
Focus ring
Zoom lever
NOTE: The POWER, AUTO ADJ., MENU, SELECT, ENTER and CANCEL buttons on the remote control perform the same
functions as the corresponding buttons on the projector cabinet. The remaining buttons are on the remote control only.
VOLUME
RGB VIDEO S-VIDEO POWER
AUTO ADJ.
MAGNIFY
PICTURE FREEZE MUTE ASPECT
MENU
ENTER
HELP
CANCEL
RD-372E
1
3
4
5
7
8
11
14
6
9
10
15
12
13
2
Printed in China
7N8P0891
Step 1 Connect the supplied 15pin-15pin signal cable.
Monitor
o-vt45qcg(2).p65 01.9.12, 0:57 PM1
Black

Basic Menu
Source Select
Volume
Image Options
Projector Options
Information
Standby
Cooling down
Lamp in Nomal mode
Lamp in Eco 1 mode
Lamp in Eco 2 mode
One minute after lamp is turned on
Retrying to turn on lamp
Lamp has reached its end of life
(1000 hours or over : Normal mode)
(1500 hours or over : Eco 1 mode)
(2000 hours or over : Eco 2 mode)
Lamp life has reached its end of life
(1100 hours or over : Normal mode)
(1600 hours or over : Eco 1 mode)
(2100 hours or over : Eco 2 mode)
Lamp or filter cover error
(3 locations)
Temperature error
Fan error
Lamp error
Power/ Status Light Messages
Condition
Steady orange
Blinking green
Steady green
Steady green
Steady green
Blinking green
Steady green
Steady green
Steady orange
Steady orange
Steady orange
Steady orange
Steady orange
–
–
–
Steady orange
Steady green
Depending Lamp mode
Blinking orange
Steady red
Steady red
Blinking red
(1 sec interval)
Blinking red
(4 sec interval)
Blinking red
(8 sec interval)
Blinking red
(12 sec interval)
–
Blinks green for 60 seconds.
–
–
–
Do not turn off the projector during
this condition.
The projector retries 3 times at an
interval of 15 sec for max. 45 sec).
Message appears on screen during
thiscondition.Theprojectorreaches
its end of life. Please replace the
lamp as soon as possible.
Theprojector is instandby mode and
cannot be turned on.
Theprojector is instandby mode and
cannot be turned on.
Theprojector is instandby mode and
cannot be turned on.
Theprojector is instandby mode and
cannot be turned on.
Theprojector is instandby mode and
cannot be turned on.
Power Indicator
Status Indicator
Note
Common Problems & Solutions
Does not turn on
No picture
Image isn’t square to the screen
Picture is blurred
Image is scrolling vertically,
horizontally or both
Remote control does not work
Status indicator is lit or blinking
Cross color in RGB mode
•Check that the power cable is plugged in and that the power button on the
projector cabinet or the remote control is on.
•Ensure that the lamp cover is installed correctly. See page E-36.
•Check to see if the projector has overheated or the lamp usage exceeds 1100
hours (2100 hours in Eco 2 mode and 1600 hours in Eco 1 mode). If there is
insufficient ventilation around the projector or if the room where you’re presenting
is particularly warm, move the projector to a cooler location.
•Use the menu to select your source (Video, S-Video or RGB). See page E-29.
•Ensure your cables are connected properly.
•Use menus to adjust the brightness and contrast. See page E-29.
•Remove the lens cap.
•Reset the settings or adjustments to factory preset levels using the Factory
Default on the Image Options Menu. See page E-31.
•Reposition the projector to improve its angle to the screen. See page E-14.
•Use the Keystone on the Image Options Menu to correct the trapezoid distortion.
See page E-29.
•Adjust the focus. See page E-23.
•Reposition the projector to improve its angle to the screen. See page E-14.
•Ensure that the distance between the projector and screen is within the
adjustment range of the lens. See page E-15.
•Use menus or Source button on the remote control or the cabinet to select the
source you want to input.
•Install new batteries. See page E-13.
•Make sure there are no obstacles between you and the projector.
•Stand within 22 feet (7 m) of the projector. See page E-13.
•See the Power/ Status Light messages.
•IfAutoAdjust is off, turn it on. IfAutoAdjust is on, turn it off and balance the image
with the Position and Clock Adjust on the Advanced Options Menu. See page
E-31.
Problem Check These Items
Basic Menu
Normal/Eco1/Eco 2
RGB
Video
S-Video
Menu
Setup
*This setting is optional. you need the optional presentation
remote control (PR51KIT).
Source Select
Projector Options
Brghtness
Contrast
Color
Hue
Sharpness
Image Options
Menu
Menu Mode
Language
Source Display
No Input Display
Volume Bar
Keystone Bar *
FilterClean Message
Menu Display Time
setup
Orientation
Cinema Position
Background
Page 1 (Source Index/Input Terminal/Horizontal Frequency/Vertical Frequency/Sync
Polarity)
Page 2 (Signal Type/Video Type/Sync Type/Interlace)
Page 3 (Remaining Lamp Time/Lamp Hour Meter/Projector Usage)
Keystone
Lamp Mode
Factory Default
DesktopFront/Ceiling Rear/
DesktopRear/Ceiling Front
Top/Center/Bottom
Blue/Black/Logo
Basic/Advanced
English/German/French/
Italian/Spanish/Swedish/
Japanese
On/Off
On/Off
On/Off
On/Off
On/Off
Manual/Auto 5 sec/Auto 15
sec/Auto 45 sec
Volume
All Data/Current Signal
Troubleshooting
