1. GENERAL
This section provides information on the NEC PASOLINK 7-38 GHz 2/4/
8/16 x2 MB and/or 2 x10/100Base-T(X) LAN signals transmission
digital microwave radio system. Included herein are system configuration,
system performance, RF channel assignment, and alarm and control.

ROI-S04604 SYSTEM CONFIGURATION
2-1
2. SYSTEM CONFIGURATION
This system consists of TRP-[ ]G-[ ] Transmitter-Receiver (Outdoor Unit
(ODU)) (see Fig. 2-1) and MDP-[ ]MB-[ ] Modulator-Demodulator
(Indoor Unit (IDU)) (see Fig. 2-2 and Fig. 2-3 ).
The [ ]GHz (2/4/8/16 x2 MB) MB digital radio system is used to
communicate from 2 to 16 data streams at 2.048 Mbps and/or up to 2
channels 10BASE-T/100BASE-TX LAN signals between two stations.
The system block diagrams of 2/4/8/16 x2 MB systems are shown in Fig.
2-4 and Fig. 2-5.
Fig. 2-1 Outline of ODU
FOR 7-38 GHz BAND ODU
FG
IFL
MON
RX LEV

SYSTEM CONFIGURATION ROI-S04604
2-2
Fig. 2-2 Front View of the IDUs in 1+0 System
TRAFFIC IN/OUT (CH1 to CH8) ALM/AUX ALM OW/DSC/ASC LA PORT
NMS/RA
TRAFFIC IN/OUT (CH9 to CH16)
NMS LANWS/SC LANPORT1 PORT2
100M 100M CALL
RESET
MAINT
IDUODU
SELV
−
PWR
FUSE (7.5A)
EOW
PASOLINK
+
TRAFFIC IN/OUT (CH1 to CH4) ALM/AUX ALM OW/DSC/ASC LA PORT
NMS/RA
NMS LANSC LANPORT1 PORT2
100M 100M CALL
RESET
MAINT
IDUODU
SELV
−
PWR
FUSE (7.5A)
EOW
PASOLINK
+
TRAFFIC IN/OUT (CH1 to CH8) ALM/AUX ALM OW/DSC/ASC LA PORT
NMS/RA
TRAFFIC IN/OUT (CH9 to CH16)
NMS LANWS/SC LAN
CALL
RESET
MAINT
IDUODU
SELV
−
PWR
FUSE (7.5A)
EOW
PASOLINK
+
TRAFFIC IN/OUT (CH1 to CH4) ALM/AUX ALM OW/DSC/ASC LA PORT
NMS/RA
NMS LANSC LAN
CALL
RESET
MAINT
IDUODU
SELV
−
PWR
FUSE (7.5A)
EOW
PASOLINK
+
(a) 4 ×2MB Fix Rate Composition
(b) 4 ×2MB Fix Rate with LAN Interface Composition
(c) 2/4/8/16 ×2MB Free Rate Composition
(d) 2/4/8/16 ×2MB Free Rate with LAN Interface Composition
IF
IN/OUT
IF
IN/OUT
IF
IN/OUT
IF
IN/OUT

ROI-S04604 SYSTEM CONFIGURATION
2-3
Fig. 2-3 Front View of the IDUs in 1+1 System
RESET IDU
ODU
PWR
PASOLINK
MAINT
SELV
−+
RESET IDU
ODU
PWR
PASOLINK
MAINT
SELV
−+
PASOLINK
IF
LA PORT
LA PORT
TRAFFIC IN/OUT (CH1 to CH8) ALM OW/DSC/ASC LA PORT
NMS/RA
CALL
OPR
AUX ALM
RESET IDU
ODU
FUSE (7.5A) PWR
FUSE (7.5A)
EOW
NMS LANSC LAN
RX RX TXTX
OPR ALM
SEL
No.1
No.2
1
2
−
WARNING
-43V OUTPUT
TURN OF F POWER
BEFOREDISCONNECTING
IFCABLE
!
PASOLINK
MAINT
SELV
−+
PASOLINK
RESET
RESET IDU
ODU
PWR
PASOLINK
MAINT
SELV
−+
IN/OUT
IF
WARNING
-43VOUTPUT
TURNOFFPOWER
BEFOREDISCONNECTING
IFCABLE
!
IN/OUT
LA PORT
LA PORT
TRAFFIC IN/OUT (CH1 to CH8) ALM OW/DSC/ASC LA PORT
NMS/RA
CALL
OPR
AUX ALM
RESET IDU
ODU
FUSE (7.5A) PWR
FUSE (7.5A)
EOW
NMS LANSC LAN
RX RX TXTX
OPR ALM
SEL
No.1
No.2
1
2
−
PASOLINK
MAINT
SELV
−+
PASOLINK
RESET
RESET IDU
ODU
PWR
PASOLINK
MAINT
SELV
−+
PORT1 PORT2
100M 100M
IF
WARNING
-43VOUTPUT
TURNOFFPOWER
BEFOREDISCONNECTING
IFCABLE
!
IN/OUT
IF
WARNING
-43V OUTPUT
TURNOFFPOWER
BEFORE DISCONNECTING
IFCABLE
!
IN/OUT
LA PORT
LA PORT
TRAFFIC IN/OUT (CH1 to CH8) ALM OW/DSC/ASC LA PORT
NMS/RA
CALL
OPR
AUX ALM
FUSE (7.5A)
FUSE (7.5A)
EOW
NMS LANSC LAN
RX RX TXTX
OPR ALM
SEL
No.1
No.2
1
2
−
PASOLINK
RESET
RESET IDU
ODU
PWR
PASOLINK
MAINT
SELV
−+
TRAFFIC IN/OUT (CH9 to CH16)
IF
WARNING
-43VOUTPUT
TURNOFFPOWER
BEFOREDISCONNECTING
IFCABLE
!
IN/OUT
IF
WARNING
-43VOUTPUT
TURNOFFPOWER
BEFOREDISCONNECTING
IFCABLE
!
IN/OUT
LA PORT
LA PORT
TRAFFIC IN/OUT (CH1 to CH8) ALM OW/DSC/ASC LA PORT
NMS/RA
CALL
OPR
AUX ALM
RESET IDU
ODU
FUSE (7.5A) PWR
FUSE (7.5A)
EOW
NMS LANSC LAN
RX RX TXTX
OPR ALM
SEL
No.1
No.2
1
2
−
PASOLINK
MAINT
SELV
−+
RESET
PORT1 PORT2
100M 100M
IF
WARNING
-43V OUTPUT
TURN OFFPOWER
BEFOREDISCONNECTING
IFCABLE
!
IN/OUT
IF
WARNING
-43V OUTPUT
TURNOFFPOWER
BEFOREDISCONNECTING
IFCABLE
!
IN/OUT
TRAFFIC IN/OUT (CH9 to CH16)
(a) 4 ×2MB Fix Rate Composition
(b) 4 ×2MB Fix Rate with LAN Interface Composition
(c) 2/4/8/16 ×2MB Free Rate Composition
(d) 2/4/8/16 ×2MB Free Rate with LAN Interface Composition

ROI-S04604 SYSTEM PERFORMANCE
3-1
3. SYSTEM PERFORMANCE
The system performance is listed in Table 3-1.
Table 3-1 Performance Characteristics
ITEM 7 GHz 8 GHz 13 GHz 15 GHz 18 GHz 23 GHz 26 GHz 38 GHz GUARANTEED
Frequency
Range [ GHz] 7.125- 7.725 7.900- 8.500 12.75- 13.25 14.5- 15.35 17.7- 19.7 21.2- 23.6 24.5- 26.5 37.0- 39.5
Frequency
Plan ITU-R F.385-6 F.386-6 Annex 4 F.497-6 F.636-3 F.595-7 F.637-3 F.748-4 F.749-2
Channel
Separation 3.5 MHz (4MB) / 7 MHz (8 MB) / 14 MHz (17 MB; 13.75 MHz also for 18 GHz) / 28 MHz (34 MB; 27.5 MHz also for 18 GHz)
RF TX/RX
Spacing [MHz] 154 161 126 266 266 315 420
490
728
340
1008
1010
1560
1008
1200
1232
1008 1260
Output Power at
Antenna Port
[dBm] +27 +25 +23 +23 +23 +20 +15 ±1.5 dB
(ATT=0)
Threshold Level
(dBm measured
at antenna port)
BER=10-3 4 MB -93.5 -93.5 -93.5 -92.5 -91.5 -91.0 -90.5 +2.5 dB
8 MB -90.5 -90.5 -90.5 -89.5 -88.5 -88.0 -87.5 +2.5 dB
17 MB -87.5 -87.5 -87.5 -86.5 -85.5 -85.0 -84.5 +2.5 dB
34 MB -84.5 -84.5 -84.5 -83.5 -82.5 -82.0 -81.5 +2.5 dB
BER=10-6 4 MB -90.0 -90.0 -90.0 -89.0 -88.0 -87.5 -87.0 +2.5 dB
8 MB -87.0 -87.0 -87.0 -86.0 -85.0 -84.5 -84.0 +2.5 dB
17 MB -84.0 -84.0 -84.0 -83.0 -82.0 -81.5 -81.0 +2.5 dB
34 MB -81.0 -81.0 -81.0 -80.0 -79.0 -78.5 -78.0 +2.5 dB
System gain
(dBm measured
at ant. port)
BER=10-3 4 MB 120.5 118.5 116.5 115.5 114.5 111.0 105.5 -4.0 dB
8 MB 117.5 115.5 113.5 112.5 111.5 108.0 102.5 -4.0 dB
17 MB 114.5 112.5 110.5 109.5 108.5 105.0 99.5 -4.0 dB
34 MB 111.5 109.5 107.5 106.5 105.5 102.0 96.5 -4.0 dB
BER=10-6 4 MB 117.0 115.0 113.0 112.0 111.0 107.5 102.0 -4.0 dB
8 MB 114.0 112.0 110.0 109.0 108.0 104.5 99.0 -4.0 dB
17 MB 111.0 109.0 107.0 106.0 105.0 101.5 96.0 -4.0 dB
34 MB 108.0 106.0 104.0 103.0 102.0 98.5 93.0 -4.0 dB

SYSTEM PERFORMANCE ROI-S04604
3-2
2 pages
Note: * The range of DC power input depends on system requirement.
Frequency
Agility (MHz
without changing
filters)
63 42 56 56-100 252 280
Data signal
interface
Bit rate: 2.048 Mbps ±50 ppm (2 ×2 MB/4 ×2 MB/8 ×2 MB/16 ×2 MB system)
Level: Meets specification of ITU-T G.703
Code format: High density bipolar-3 (HDB-3)
Impedance: 75 ohms, unbalanced
120 ohms, balanced
Electro magnetic
compatibility
(EMC)
• ODU/IDU: ETS300385
Class B
Power
requirement*: +20 to +60 / -20 to -60 V DC
Power
consumption
4 MB system:
8 MB system:
17 MB system:
34 MB system:
Approx. 50 watts (without optional module)
Approx. 60 watts (equipped with optional module)
Approx. 50 watts (without optional module)
Approx. 60 watts (equipped with optional module)
Approx. 52 watts (without optional module)
Approx. 62 watts (equipped with optional module)
Approx. 55 watts (without optional module)
Approx. 66 watts (equipped with optional module)
Table 3-1 Performance Characteristics (Cont’d)
ITEM 7 GHz 8 GHz 13 GHz 15 GHz 18 GHz 23 GHz 26 GHz 38 GHz GUARANTEED

GENERAL ROI-S02775
1-6
1.2 Equipment Performance
The performance characteristics of the IDU are listed in Table 1-1.
Table 1-1 Performance Characteristics of IDU
Data signal interface (between IDU and DTE)
Bit rate: • 2.048 Mbps ±50 ppm (2 MBx2/2 MB x4/2 MB x
8/2 MB x16 system)
• 8.448 Mbps ±30 ppm (8 MBx1 system)
• 34.368 Mbps ±20 ppm (34 MBx1 system)
Level: Meets specifications of ITU-T G.703
Code format: High density bipolar-3 (HDB-3)
Impedance: 75 ohms, unbalanced or
120 ohms, balanced
Modulation method: 4-phase shift keying (4 PSK) system
Demodulation method: Quasi-coherent detection
IF signal interface (between IDU and ODU)
Signal frequency
TX: 850 MHz
RX: 70 MHz
Signal level
IF output: −5 dBm, nominal
IF input: −15 to 0 dBm (at , RX IN), varies with cable length
(maximum cable length (8D-FB): l=300 m)
Impedance: 50 ohms, unbalanced
Insertion loss: 15 dB at 70 MHz (l=300 m)
45 dB at 850 MHz (l=300 m)
Orderwire frequency
Output: 468 kHz, amplitude modulation (AM)
Input: 450 kHz, AM
Power supply: −43 V DC (through) at IF IN/OUT
Control/Monitor signal frequency: 10 MHz, amplitude shift keying (ASK) (at IF IN/OUT)

ROI-S02775 GENERAL
1-7
Table 1-1 Performance Characteristics of IDU (Cont’d)
Analog service channel (ASC) signal interface
Frequency: 0.3 to 3.4 kHz
Impedance: 600 ohms
Digital service channel (DSC) signal interface
Bit rate: • 64 kbps (G703/V.11)
• 9.6 kbps (asynchronous)
Level: RS-232, RS-422 or RS-485 (9.6k)
Meet specifications of ITU-T G.703/V.11 (64k)
Wayside (WS) signal interface
Bit rate: 2.048 Mbps
Level: Meet specifications of ITU-T G.703
Dimensions
•2MBx2/2 MB x4/2 MB x8/
2 MB x16 (for 120 ohms interface)/
8 MB x1/34 MB x1 fixed bit rate
system/2 MB x2/4/8 bit rate free
system/2 MB x2/4/8/16 bit rate free
system for 120 ohms interface: 482 wide ×44 high × 240 deep (mm)
•2 ΜΒ x16 fixed bit rate (for 75
ohms nterface) system/2 MB x2/4/8/
16 bit rate free system for 75 ohms
interface: 482 wide ×66 high × 240 deep (mm)
Weight
•2MBx2/2 ΜΒ × 4/2 ΜΒ × 8/
2 ΜΒ x16 (for 120 ohms interface)/
8 ΜΒ x1/34 ΜΒ x1 system: Approx. 4 kg (including all options)
•2 ΜΒ x16 (for 75 ohms interface)
system: Approx. 5 kg (including all options)
Environmental temperature range
Operation: 0°C to +50°C
Storage: −30°C to +70°C

ROI-S04605 GENERAL
1-3
1.2 Equipment Performance
The performance characteristics of the ODU are listed in Table 1-2 and
radio frequency assignment is provided in para. 5.1.
Table 1-2 Performance Characteristics
ITEM 7 GHz 8 GHz 13 GHz 15 GHz 18 GHz 23 GHz 26 GHz 38 GHz GUARANTEED
Frequency Range
[ GHz] 7.125- 7.725 7.900- 8.500 12.75- 13.25 14.5- 15.35 17.7- 19.7 21.2- 23.6 24.5- 26.5 37.0- 39.5
Frequency Plan ITU-
RF.385-6 F.386-6 Annex4 F.497-6 F.636-3 F.595-7 F.637-3 F.748-4 F.749-2
Channel Separation 3.5 MHz (4 MB) / 7 MHz (8 MB) / 14 MHz (17 MB; 13.75 MHz also for 18 GHz) /
28 MHz (34 MB; 27.5 MHz also for 18 GHz)
RF TX/RX Spacing
[MHz] 154
161 126 266 266 315 420
490
728
340
1008
1010
1560
1008
1200
1232
1008 1260
Output Power
at Antenna Port
(dBm)
+27 +25 +23 +23 +23 +20 +15 ±1.5 dB
(ATT=0)
Power Control 0 to 30 dB, in 1 dB steps, variable ±1.0 dB
Frequency Stability ±5 ppm ±10 ppm
Receiver Noise
Figure 4.5 dB 4.5 dB 4.5 dB 4.5 dB 5.5 dB 6.5 dB 7.0 dB 7.5 dB +1.5 dB
Maximum Input
Level -15 dBm (No ERROR)
IF signal interface
(between IDU and
ODU)
Signal frequency
TX: 850 MHz
RX: 70 MHz
Signal level
Input: -52 to -3 dBm for 7-38 GHz, varies with cable length
(maximum cable length: L=300 m/8D-FB)
Output: 0 dBm, nominal
Orderwire
frequency
Output: 468 kHz, AM
Input: 450 kHz, AM
DC component -43 V DC

GENERAL ROI-S04605
1-4
4 pages
Notes: *1 For direct mounting type ODU, the RF IN/OUT port used is
NEC special flange, not PBR flange.
Control/Monitor
signal frequency 10 MHz, ASK (at IF IN/OUT)
Impedance 50 ohms, unbalanced
Type of RF IN/OUT
Portion *1 N-Female PBR - 140 PBR - 220 PBR -260 PBR - 320
Dimensions: 236 wide ×236 high ×113 deep (mm)
Weight: Approx. 4.5 kg Approx. 4 kg
Environmental
temperature range
Operation -33°C to +50°C
Storage -40°C to +70°C
Table 1-2 Performance Characteristics (Cont’d)
ITEM 7 GHz 8 GHz 13 GHz 15 GHz 18 GHz 23 GHz 26 GHz 38 GHz GUARANTEED

ROI-S04604 RADIO FREQUENCY ASSIGNMENT
4-1
4. RADIO FREQUENCY ASSIGNMENT
Radio frequencies for Pasolink [ ] GHz 4/8/17/34 MB digital radio system
are as follows:
• 7 GHz band: 7.125 to 7.725 GHz
• 8 GHz band: 7.900 to 8.500 GHz
• 13 GHz band: 12.75 to 13.25 GHz
• 15 GHz band: 14.5 to 15.35 GHz
• 18 GHz band: 17.7 to 19.7 GHz
• 23 GHz band: 21.2 to 23.6 GHz
• 26 GHz band: 24.5 to 26.5 GHz
• 38 GHz band: 37.0 to 39.5 GHz
For details, refer to Appendix "Frequency Allocation Table" in TRP
equipment (ODU) description (Section II).

ALARM AND CONTROL
The simplified alarm and control functions are described in accordance
with the alarm indication and reporting, and network management.
Alarm Indication and Reporting
Alarm indication and reporting function are provided with the IDU. Alarm
signals initiated by detection circuits on the ODU are sent to the IDU.
Therefore the alarm indicator for the ODU is located on the front panel of
the IDU. The alarm indication for the IDU is also indicated by the
corresponding alarm indicator on the IDU. When the equipment is
operating normally, the alarm indicators on the IDU stay unlit. When an
abnormal condition occurs, the related alarm indicator is lit and a remote
alarm report is made

FUNCTIONAL OPERATION ROI-S04488
2-28 28 pages
Table 2-3 Alarm Indication and Reporting
DETECTING
CIRCUIT ALARM CONDITION ALARM INITIATED LED INDICATION
ON IDU REMOTE ALARM REPORT *1
INTFC
AIS signal is sent AIS SEND — IDU*2 —
AIS (all logic “1”) is received AIS RCVD — —
Input data stream is lost INPUT LOSS TX ALM ( )
IDU
TX ALM ( )
Transmitter clock is lost TX CLK LOSS TX ALM ( ) TX ALM ( )
Receiver clock is lost RX CLK LOSS RX ALM ( ) RX ALM ( )
Output data stream is lost OUTPUT LOSS RX ALM ( ) RX ALM ( )
Setting error of traffic channel assignment for usage CHANNEL USAGE ERROR TX ALM ( ) TX ALM ( )
SW BOARD TX 1/2 CLK is lost TX IN CLK LOSS1/2 TX ALM 1/2 TX ALM 1/2
RX1/2 CLK is lost RX IN CLK LOSS1/2 RX ALM1/2 RX ALM 1/2
LAN INTFC FE link down, selectable FE LINK DOWN LINK LAN INTFC ALM
WS INTFC
Wayside input data stream is lost WS INPUT LOSS TX ALM ( )
IDU*3
TX ALM ( )
Wayside AIS is received WS AIS RCVD TX ALM ( ) TX ALM ( )
Wayside output data stream is lost WS OUTPUT LOSS RX ALM ( ) RX ALM ( )
Wayside AIS is transmitted WS AIS SEND RX ALM ( ) RX ALM ( )
WS INTFC Wayside channel usage error, selectable WS CHANNEL USAGE TX ALM ( )
IDU
TX ALM ( )
DPU Output data stream or master clock signal is lost at the DPU (TX) circuit TX DPU ALM TX ALM ( ) TX ALM ( )
MOD VCO synchronization is lost at the MOD circuit MOD ALM TX ALM ( )
DEM Carrier synchronization is lost DEM ALM RX ALM ( ) RX ALM ( )
IF input signal is lost DEM ALM RX ALM ( ) RX ALM ( )
DPU
Frame synchronization is lost at the DPU (RX) F SYNC ALM RX ALM ( ) RX ALM ( )
BER is worse than preset value (1 x10−3)HIGH BER ALM RX ALM ( ) RX ALM, ( ) BER ALM
BER is worse than preset value (1 x10−6)LOW BER ALM RX ALM ( ) RX ALM ( ), BER ALM
BER is worse than preset value (1 x10−3, 1 x10−4, 1 x10−5or 1 x10−6, selectable) BER ALM RX ALM ( ) RX ALM ( ), BER ALM
CPU communication error between IDU and ODU OPR ALM TX ALM ( )
RX ALM ( ) TX ALM( ) RX ALM ( )
ODU
Transmitter RF power decreases 3 dB from normal TX PWR ALM TX ALM ( )
ODU
TX ALM ( )
Receiver input level decreases from squelch level at ODU RX LEV ALM RX ALM ( ) RX ALM ( )
APC loop of local oscillator for transmitter or first local oscillator for receiver unlocks at ODU APC 1 ALM TX ALM ( )
RX ALM ( ) TX ALM ( ) RX ALM ( )
APC loop of second local oscillator for receiver unlocks at ODU APC 2 ALM TX ALM ( )
RX ALM ( ) TX ALM ( ) RX ALM ( )
IF signal from the IDU is lost at ODU IF INPUT ALM TX ALM ( ) TX ALM ( )
—
When the equipment is set to the Maintenance condition by PC. MAINT ALM MAINT MAINT ALM
When the equipment is set to the following condition by PC.
• FE loopback control condition
• NE loopback control condition
• MOD CW condition
• MUTE (TX output power) condition
• BER ALM >> AIS (off)
— MAINT ( ) —
SW BOARD OPR SEL No.1-No.2 switch is set to No.1 or No.2 position. MAINT ALM MAINT ( ) MAINT ALM

ODU Description and Operation
1- General
The IDU has the following two types for each 1+0 and 1+1 systems.
• Fixed bit rate type (for 4 × 2MB and optional 2 × 10/100 BASET(X))
• Free bit rate type (for 2/4/8/16 × 2MB and optional 2 × 10/100 BASE-T(X))
2- Equipment Composition
A- 1+0 IDU
Idu Description and Operation
IDU Description and Operation

B- 1+1 IDU

3. FUNCTIONAL OPERATION
This section describes functional operation of the transmit line
equalization, transmit digital processing, modulation, demodulation,
receive digital processing, receive line equalization, analog service
channel signal transmission, 9.6k digital service channel transmission,
alarm signal transmission, wayside signal transmission, 64k digital service
channel transmission, LAN signal transmission, and alarm and control in
that order for the IDU.
The IDU provides four signal transmission systems; 2 x 2 MB, 4 x 2 MB,
8 x 2 MB and 16 x 2 MB in 1+0 and 1+1 configuration as shown in Fig 2-
1 and Fig 2-2 Functional Block Diagram.

ROI-S04488 FUNCTIONAL OPERATION
2-3/4
Fig. 2-1 Functional Block Diagram of IDU (1/3)
CH1 IN
CH2 IN
CH1 OUT
CH2 OUT
4 x 2 MB
SYSTEM
8 x 2 MB
SYSTEM
16 x 2 MB
SYSTEM
TRANS
TRANS
TRANS
TRANS
PLS
B-U
AIS
U-B
LOOPBACK
CONV
CONV
MON DET CKT
LOOPBACK
CKT
AIS CTRL
AIS CTRL
PLS MON
OUTPUT LOSS 1-2
PLS AIS
MON DET
CH3 IN
CH4 IN
CH3 OUT
CH4 OUT
TRANS
TRANS
TRANS
TRANS
B-U
U-B
CONV
CONV
PLS MON
AIS CTRL
AIS CTRL
LOOPBACK
CKT
LOOPBACK
CKT
1/8
MEM
MEM
MEM
MEM
MEM
MEM
MEM
MEM
MUX
DEMUX
FE LB CTRL 1-4
FE LB ANS 1-4
P-S CONV
TX CLK LOSS
RX CLK LOSS
S-P CONV
CLK MON
CLK MON
OUTPUT LOSS 1-2
OUTPUT LOSS 3-4
AIS RCVD 3-4
INPUT LOSS 3-4
FE LB CTRL 1-4
FE LB ANS 1-4
NE LB ANS 1-4
AIS RCVD 1-2
INPUT LOSS 1-2 SERIAL ALM
SERIAL DATA
P-S
CONV
S-P
CONV
FE LB CTRL 1-4
NE LB CTRL 1-4
a
b
t
s
q
v
u
j
i
r
c
d
k
l
e
f
m
n
o
p
g
h
CH5 IN
CH6 IN
CH5 OUT
CH6 OUT
CH7 IN
CH8 IN
CH7 OUT
CH8 OUT
CH9 IN
CH10 IN
CH9 OUT
CH10 OUT
CH11 IN
CH12 IN
CH11 OUT
CH12 OUT
CH13 IN
CH14 IN
CH13 OUT
CH14 OUT
CH15 IN
CH16 IN
CH15 OUT
CH16 OUT
(CH13 - CH16)
(CH5 - CH8)
(SAME AS ABOVE)
(CH9 - CH12)
(SAME AS ABOVE)
TX FPLS
TX CLK
RX CLK
RX FPLS
16M CLK
AIS CTRL
F SYNC ALM
INPUT LOSS 1-2
AIS RCVD 1-2
INPUT LOSS 3-4
AIS RCVD 3-4
From/To
FIG. 2-1 (2/3)
y
w
x
INTFC (CH1 - CH4)
TIM GEN z
2 x 2 MB
SYSTEM
