UGR16-30W-60SQ, UGR16-30W-120/30
LED Light Panel
Installation Instructions:
This installation must be carried out by an electrician. Please read these instructions carefully
before installation. Leave a copy for the user/maintenance engineer for future reference.
Safety:
This is a mains powered product. Before installation, maintenance or cleaning please ensures
the power supply is isolated.
Maintenance:
a. Please ensure the fitting has cooled down prior to performing maintenance on this
product.
b. If the product is not damaged in transport, it is supplied ready to use.
c. Clean using a dry cloth. No detergent or water to be used.
Notes:
Voltage input: AC220-240V/50/60Hz, using the newest high efficiency constant current driver.
Anti-electromagnetic interference, no mercury, no lead. Before using, please confirm that
this product has not been damaged during transit.
Please keep packing material and small accessories far away from children. Avoid the eyes
sighting the LED light-emitting area directly.
Please keep products and packing away the open fire or high temperature goods.
The fixture must not be modified. And modification will void the warranty and can make the
product dangerous.
Please note the recommended clearance from the rear heat sink to any flammable materials is
0.2m. Under no circumstance should any insulation or similar be laid onto the fitting.
Application:
Hotel, meeting room, factory or office, residence or public facilities, commercial use, school,
hospital and other environments.
LED panel light for indoor using only.

Free Call
Website
Email
1800 909 306
nedlandsgroup.com.au
[email protected]
A&K Investments (Australia) Pty Ltd T/A Nedlands Group ABN 95 164 389 762
VIC Office Unit 1 / 181 Proximity Drive, Sunshine West VIC 3020 WA Office Unit 3 / 5 Edison Circuit, Forrestdale, WA, 6112
Installation Steps:
A. Built in Style:
1. Take off Ceiling plaster tile. 2. Connect the Wire.
3. Fix the panel Light on into the
ceiling screens.
4. After stabilizing the panel light,
turn on the power ready to use.
B . Ceiling style
1. Fix the panel frame directly, no
screws are needed.
2. Fix the ceiling frame into the
ceiling or wall.
3. Fix the panel light on the ceiling
frame.
4. After steady the panel light, you can
connect the electric current to use.
C Pendant style
1. Take off the cassette and install
the screw cassette.
2. Fix the cassette onto the ceiling.
3. Lock the Line controler into the
cassette.
4. Adjust the length of the iron line
well and the connect the power
supply, then you can power.
Module
replacement
1. Turn off the power, take off the LED
panel light.
2. Replace the LED module like the
phots. Fixed it with clasp.
3. Fix the panel light on the ceiling
frame.
