NEFF C29DR1X.0 User manual

neff -home.com
Steamer
User manual and installation
instructions
C29DR1X.0

en Safety
2
Futher information and explanations are available online:
Table of contents
INFORMATION FOR USE
1 Safety...................................................................2
2 Avoiding material damage..................................4
3 Environmental protection and saving en-
ergy ......................................................................4
4 Familiarising yourself with your appliance .......5
5 Operating modes ................................................6
6 Accessories.........................................................7
7 Before using for the first time ............................8
8 Basic operation .................................................10
9 Time-setting options.........................................11
10 Steam programs................................................13
11 Favourites..........................................................14
12 Childproof lock..................................................15
13 Basic settings....................................................15
14 HomeConnect ..................................................16
15 Cleaning and servicing.....................................18
16 Troubleshooting................................................23
17 Disposal.............................................................25
18 How it works......................................................25
19 Customer Service..............................................38
20 Information regarding Free and Open
Source Software................................................38
21 Declaration of Conformity ................................39
22 INSTALLATION INSTRUCTIONS ......................39
22.1 General installation instructions......................39
1 Safety
Observe the following safety instructions.
1.1 General information
¡Read this instruction manual carefully.
¡Keep the instruction manual and the
product information safe for future refer-
ence or for the next owner.
¡Do not connect the appliance if it has been
damaged in transit.
1.2 Intended use
This appliance is designed only to be built
into kitchen units. Read the special installation
instructions.
Only a licensed professional may connect ap-
pliances without plugs. Damage caused by in-
correct connection is not covered under the
warranty.
Only use this appliance:
¡To prepare meals and drinks.
¡in private households and in enclosed
spaces in a domestic environment.
¡up to an altitude of max. 2000m above
sea level.
1.3 Restriction on user group
This appliance may be used by children aged
8 or over and by people who have reduced
physical, sensory or mental abilities or inad-
equate experience and/or knowledge,
provided that they are supervised or have
been instructed on how to use the appliance
safely and have understood the resulting
dangers.
Do not let children play with the appliance.
Children must not perform cleaning or user
maintenance unless they are at least 15 years
old and are being supervised.
Keep children under the age of 8 years away
from the appliance and power cable.
1.4 Safe use
Follow these instructions when using a steam
function.
Always place accessories in the cooking com-
partment the right way round.
→"Accessories", Page7

Safety en
3
WARNING‒Risk of burns!
The appliance and its parts that can be
touched become hot during use.
▶Caution should be exercised here in order
to avoid touching heating elements.
▶Young children under 8 years of age must
be kept away from the appliance.
▶Never touch the ventilation openings.
Accessories and cookware get very hot.
▶Always use oven gloves to remove ac-
cessories or cookware from the cooking
compartment.
WARNING‒Risk of scalding!
The accessible parts of the appliance become
hot during operation.
▶Never touch these hot parts.
▶Keep children at a safe distance.
Hot steam may escape when you open the
appliance door. Steam may not be visible, de-
pending on the temperature.
▶When opening the door, do not stand too
close to the appliance.
▶Open the appliance door carefully.
▶Keep children at a safe distance.
If there is water in the cooking compartment
when it is hot, this may create hot steam.
▶Never pour water into the cooking compart-
ment when the cooking compartment is
hot.
The water in the evaporator dish is still hot
even after the appliance has been switched
off.
▶Never empty the evaporator dish immedi-
ately after switching off the appliance.
▶Allow the appliance to cool down before
cleaning.
Hot liquid may spill over the sides of the ac-
cessory when it is removed from the cooking
compartment.
▶Remove hot accessories with care and al-
ways wear oven gloves.
WARNING‒Risk of injury!
Scratched glass in the appliance door may
develop into a crack.
▶Do not use any harsh or abrasive cleaners
or sharp metal scrapers to clean the glass
on the oven door, as they may scratch the
surface.
WARNING‒Risk of fire!
Due to the hot surfaces, vapours from flam-
mable liquids may catch fire in the cooking
compartment (explosion). The appliance door
may spring open. Hot steam and jets of flame
may escape.
▶Do not pour flammable liquids (e.g. alco-
holic drinks) into the water tank.
▶Only fill the water tank with water or with
the descaling solution we have recommen-
ded.
WARNING‒Risk of electric shock!
Incorrect repairs are dangerous.
▶Repairs to the appliance should only be
carried out by trained specialist staff.
▶Only use genuine spare parts when repair-
ing the appliance.
▶If the power cord of this appliance is dam-
aged, it must be replaced by trained spe-
cialist staff.
If the insulation of the power cord is dam-
aged, this is dangerous.
▶Never let the power cord come into contact
with hot appliance parts or heat sources.
▶Never let the power cord come into contact
with sharp points or edges.
▶Never kink, crush or modify the power
cord.
An ingress of moisture can cause an electric
shock.
▶Do not use steam- or high-pressure clean-
ers to clean the appliance.
If the appliance or the power cord is dam-
aged, this is dangerous.
▶Never operate a damaged appliance.
▶Never pull on the power cord to unplug the
appliance. Always unplug the appliance at
the mains.
▶If the appliance or the power cord is dam-
aged, immediately unplug the power cord
or switch off the fuse in the fuse box.
▶Call customer services. →Page38
WARNING‒Risk of suffocation!
Children may put packaging material over
their heads or wrap themselves up in it and
suffocate.
▶Keep packaging material away from chil-
dren.
▶Do not let children play with packaging ma-
terial.

en Avoiding material damage
4
Children may breathe in or swallow small
parts, causing them to suffocate.
▶Keep small parts away from children.
▶Do not let children play with small parts.
2 Avoiding material damage
ATTENTION!
Silicone bakeware is not suitable for operation with
steam.
▶Cookware must be heat- and steam-resistant.
Using cookware with rust spots may cause corrosion in
the cooking compartment. Even the smallest spots of
rust can cause corrosion.
▶Do not use cookware with rust spots.
Dripping liquids make the cooking compartment floor
dirty.
▶When steaming with a perforated cooking container,
always insert the solid cooking container under-
neath. This will catch any liquid that drips down.
If descaling solution comes into contact with the control
panel or other delicate surfaces, it will damage them.
▶Remove descaling solution immediately with water.
Cleaning the water tank in the dishwasher will damage
it.
▶Do not clean the water tank in the dishwasher.
▶Clean the water tank with a soft cloth and standard
washing-up liquid.
With certain models, accessories may scratch the door
pane when closing the appliance door.
▶Always push accessories fully into the cooking com-
partment.
Sitting or placing objects on the appliance door may
damage it.
▶Do not place, hang or support objects on the appli-
ance door.
▶Do not place cookware or accessories on the appli-
ance door.
If the seal is very dirty, the appliance door will no
longer close properly during operation. This may dam-
age the front of adjacent kitchen units.
▶Keep the seal clean at all times.
▶Never operate the appliance if the seal is damaged
or missing.
The prolonged presence of moisture in the cooking
compartment leads to corrosion.
▶Allow the cooking compartment to dry after use.
▶Do not keep moist food in the cooking compartment
for a long time with the door closed.
▶Do not store food in the cooking compartment.
Improper care may lead to corrosion in the cooking
compartment.
▶Observe the care and cleaning instructions.
▶Once the appliance has cooled down, remove any
dirt from the cooking compartment.
Carrying the appliance by the door handle could break
it. The door handle cannot support the weight of the
appliance.
▶Do not carry or hold the appliance by the door
handle.
A build-up of heat damages the appliance.
▶Never place accessories, foil, greaseproof paper or
ovenware on the cooking compartment floor.
▶Never cover the cooking compartment floor with any
type of foil.
▶Keep the cooking compartment floor and the evap-
orator tray clear.
▶Always place the cookware in a perforated cooking
container.
Hot water in the water tank may damage the steam
system.
▶Only fill the water tank with cold water.
3 Environmental protection and saving energy
3.1 Disposing of packaging
The packaging materials are environmentally compat-
ible and can be recycled.
▶Sort the individual components by type and dispose
of them separately.
3.2 Saving energy
If you follow these instructions, your appliance will use
less power.
Only preheat the appliance if the recipe or the recom-
mended settings →Page25 tell you to do so.
¡Not preheating the appliance can reduce the en-
ergy used by up to 20%.
Open the appliance door as little as possible during
operation.
¡This maintains the temperature in the cooking com-
partment and eliminates the need for the appliance
to reheat.
Cook food on multiple levels at the same time. Put the
food with the longest cooking time in first.
¡If you are preparing the food at the same time,
shorten the operating time.
Note:
The appliance requires:
¡A maximum of2W in networked standby mode
¡A maximum of 0.5W in non-networked standby
mode with the display switched off

Familiarising yourself with your appliance en
5
4 Familiarising yourself with your appliance
4.1 Control panel
You can use the control panel to configure all functions of your appliance and to obtain information about the operat-
ing status.
On certain models, specific details such as colour and shape may differ from those pictured.
1
2 2
1
Display
The display shows the current settings, options
or notifications.
2
Buttons
You can use the buttons to directly set various
functions.
4.2 Display
You can configure all the functions on your appliance
via the display.
The main menu provides an overview of your appli-
ance's functions.
Navigating
Direction Use
Navigate to the left Swipe right on the display
with your finger
Navigate to the right Swipe left on the display
with your finger
Setting values
To adjust a setting, touch the appropriate place on the
display with your finger. The settings area appears on
the display. Swipe left or right over this settings area on
the display with your finger until the required setting is
magnified.
Values Use
Increase Swipe right on the display with your
finger
Decrease Swipe left on the display with your
finger
4.3 Buttons
The buttons are touch-sensitive areas. To select a function, press the corresponding button.
Symbol Name Use
On/Off Switch the appliance on or off
Back Navigate back
Left arrow Decreases the adjustment values

en Operating modes
6
Symbol Name Use
Right arrow Increases the adjustment values
Start/stop Start or pause the appliance
Timer Set the timer
4.4 Cooking compartment
The functions in the cooking compartment make your
appliance easier to use.
Interior lighting
When you open the appliance door, the light in the
cooking compartment switches on. If the appliance
door remains open for longer than 18minutes, the light
switches off again.
In most operating modes, the interior lighting switches
on as soon as operation starts. The interior lighting
switches off again when the operation stops.
You can specify whether you want the interior lighting
to switch on during operation in the basic settings.
→Page15
Cooling fan
The cooling fan switches on and off as required. The
hot air escapes above the door.
ATTENTION!
Covering the ventilation slots will cause the appliance
to overheat.
▶Do not cover the ventilation slots.
To cool the cooking compartment more quickly after
operation, the cooling fan continues to run for a certain
period afterwards.
You can specify how long the cooling fan should con-
tinue to run by going to the basic settings.
Shelf positions
The shelf positions are numbered from bottom to top.
A B
A
Evaporator dish
B
Water tank in the water tank recess
4.5 Appliance door
If you open the appliance door while the appliance is in
operation, this pauses operation. If you close the appli-
ance door, operation resumes automatically.
Tip:For optimal cooking results, open the door as in-
frequently as possible during steaming.
5 Operating modes
The menu is divided into different operating modes.
Operating
mode
Use
Steaming Set and start the appropriate type of
steam heating.
→"Basic operation", Page10
Dishes Cook food with steam.
→"Steam programs", Page13
Cleaning Descale the water system.
Basic settings Adjust the basic settings.
→"Basic settings", Page15
Favourites Use your own saved settings.
HomeConnect
With HomeConnect, you can connect and remotely
control the oven with a mobile device, and use the full
functionality of the appliance.
Depending on the appliance type, additional or more
comprehensive functions are available for your appli-
ance with the HomeConnect app. You can find more
information about this in the app.
→"HomeConnect ", Page16
5.1 Types of steam heating
This is where you can find an overview of the types of steam heating. You will find recommendations for using the
types of steam heating.
When you select a type of steam heating, the appliance suggests a suitable temperature. You can use these values
or change them within the specified range.

Accessories en
7
Symbol Name Temperature Use
Steaming 30-100°C For blanching and steaming:
¡Vegetables
¡Fish
¡Side dishes
Juice fruit.
Reheating 80-100°C Suitable for plated meals.
The steam type of heating gently warms cooked food.
The steam ensures that the food does not dry out.
Dough proofing 30-50°C Suitable for yeast dough.
The yeast dough proves more quickly than at room tem-
perature. The surface of the dough does not dry out.
Defrosting 30-60°C Suitable for fruit and vegetables.
The steam type of heating uses moisture to transfer the
heat to the food, gently warming it without impairing its
quality. The food does not dry out or lose its shape.
Sous-vide 50-95°C Cooking food in a vacuum at low temperatures between
50 and 95°C and in 100% steam: Suitable for meat,
fish, vegetables and desserts.
A vacuum-sealing machine is used to heat-seal the food
in special air-tight, heat-resistant cooking bags. The pro-
tective envelope retains the nutrients and flavours.
5.2 Residual heat indicator
When the appliance is switched off, the display uses
the message "Residual heat low" to show the residual
heat in the cooking compartment. The message disap-
pears at approximately 60°C.
6 Accessories
Use original accessories. These have been made espe-
cially for your appliance.
Note:Accessories may become deformed if they get
hot. Deformation has no effect on function. As the ac-
cessory cools down, it will regain its original shape.
The accessories supplied may differ depending on the
appliance model.
Accessories Properties Use
Steam container, solid, size
L
¡Boil rice, pulses or cereals
¡Catch dripping liquid, e.g. when steaming
Perforated steam container,
size L
¡Steam whole fish or larger quantities of
vegetables
¡Juice large quantities of berries
6.1 Locking function
The locking function prevents the accessories from tilt-
ing when they are pulled out.
You can pull out the accessories approximately halfway
without them tipping. The accessories must be inserted
into the cooking compartment correctly for the tilt pro-
tection to work properly.
6.2 Inserting the steaming tray
ATTENTION!
A build-up of heat damages the appliance.
▶Never place accessories, foil, greaseproof paper or
ovenware on the cooking compartment floor.
▶Never cover the cooking compartment floor with any
type of foil.
▶Keep the cooking compartment floor and the evap-
orator tray clear.
▶Always place the cookware in a perforated cooking
container.

en Before using for the first time
8
1. Rotate the steaming tray such that the latching
cutout is towards the rear and its shape is point-
ing upwards.
2. Do not push the steaming tray beyond the recess
⁠.
3. Take hold of the steaming tray in the middle to in-
sert it.
6.3 Other accessories
You can purchase other accessories from our after-
sales service, specialist retailers or online.
You will find a comprehensive range of products for
your appliance in our brochures and online:
www.neff-international.com
Accessories vary from one appliance to another. When
purchasing accessories, always quote the exact
product number (E no.) of your appliance.
You can find out which accessories are available for
your appliance in our online shop or from our after-
sales service.
7 Before using for the first time
Configure the settings for initial start-up. Clean the appliance and accessories.
7.1 Before using for the first time
Before using the appliance for the first time, ask your
water supplier about the hardness of your tap water. To
ensure that the appliance can reliably remind you to
descale it when required, you must set your water hard-
ness range correctly.
ATTENTION!
If the wrong water hardness has been set, the appli-
ance cannot remind you to descale it at the right time.
▶Set the water hardness correctly.
Using unsuitable liquids may damage the appliance.
▶Do not use highly chlorinated tap water (>40 mg/l)
or other liquids.
▶Only use cold, fresh tap water, softened water or
non-carbonated mineral water.
Notes
¡If you are using mineral water, set the water hard-
ness range to "very hard". If you are using mineral
water, you must only use non-carbonated mineral
water.
¡If your tap water is very hard, we recommend that
you use softened water. If you are using only
softened water, set the "softened" water hardness
range.
Setting Water hardness in
mmol/l
German hardness °dH French hardness °fH
0 (softened)1---
1 (soft) Up to 1.5 Up to 8.4 Up to 15
2 (medium) 1.5-2.5 8.4-14 15-25
1Only set this if you will be using solely softened water.
2Also set for mineral water. Only use non-carbonated mineral water.

Before using for the first time en
9
Setting Water hardness in
mmol/l
German hardness °dH French hardness °fH
3 (hard) 2.5-3.8 14-21.3 25-38
4 (very hard)2Over 3.8 Over 21.3 Over 38
1Only set this if you will be using solely softened water.
2Also set for mineral water. Only use non-carbonated mineral water.
7.2 Initial use
After connecting the appliance to the power supply,
you must configure the settings for its initial start-up. It
may take a few minutes for the settings to appear on
the display.
Notes
¡You can adjust the settings at any time in the basic
settings.
→"Basic settings", Page15
¡You can also use HomeConnect to configure the
settings. When your appliance is connected, follow
the instructions in the app.
→"HomeConnect ", Page16
Setting the language
Requirement:The appliance is connected to the power
supply.
1. Press to switch the appliance on.
2. Use the ⁠ or ⁠button to select the language.
3. Press the required language.
4. Press to confirm the language.
Setting up HomeConnect
Note:You can skip HomeConnect set-up by pressing
"Later". Next, set the clock.
1. Press "Connect" to set up HomeConnect.
→"HomeConnect ", Page16
2. Make all other settings for initial start-up in the
HomeConnect app.
Setting the time
1. Use or to select the hours.
2. Press the minutes.
3. Use ⁠ or ⁠to select the minutes.
4. Press to confirm the time.
Setting the date
1. Use or to select the year.
2. Press the month.
3. Use or to select the month.
4. Press the day.
5. Use or to select the day.
6. Press to confirm the date.
Setting the water hardness
1. Use or to select the water hardness range.
2. Press to confirm the water hardness range.
3. Press "OK" to end the initial start-up.
4. Open and close the appliance door once.
aThe appliance will perform a self-test, after which it
will be ready to use.
aThe initial start-up is now complete.
7.3 Calibrating and cleaning the appliance
before using it for the first time
Calibrate the appliance and clean the cooking compart-
ment and accessories before using it to prepare food
for the first time.
Note:The boiling point of water depends on the air
pressure. During calibration, the appliance self-adjusts
during the first steam operation to the pressure ratio at
the installation location.
Do not open the appliance door while calibration is in
progress, as this will cancel the calibration process
and it must be restarted.
Requirement:The cooking compartment is cold or at
room temperature.
1. Remove the product information and the accessor-
ies from the cooking compartment. Remove any
leftover packaging, such as polystyrene pellets, and
any adhesive tape that is in or on the appliance.
2. Wipe the smooth surfaces in the cooking compart-
ment with a soft, damp cloth.
3. Press to switch the appliance on.
4. Fill the water tank.
→"Filling the water tank", Page10
5. Apply the following settings:
Type of heating Steaming
Temperature 100°C
Duration 20 minutes
→"Basic operation", Page10
6. Start the operation.
‒Ventilate the kitchen while the appliance is heat-
ing.
aCalibration starts. This creates a lot of steam.
aWhen the time has elapsed, a signal sounds. A noti-
fication appears on the display confirming that the
operation has finished.
7. Allow the appliance to cool down and then dry the
cooking compartment floor thoroughly.
8. Once the appliance has cooled down, clean all sur-
faces in the cooking compartment with a detergent
solution and a dish cloth.
9. Empty the water tank and dry the cooking compart-
ment.
→"After using the Steam function", Page11
Note:Following a power cut, the calibrated settings are
retained.
To adjust the appliance to a new installation location
after moving house, reset the basic settings to the fact-
ory settings. Restart the calibration process.
7.4 Cleaning the accessories
▶Clean the accessory using soapy water and a dish
cloth.

en Basic operation
10
8 Basic operation
8.1 Switching on the appliance
▶Press to switch the appliance on.
Notes
¡In the basic settings, you can specify whether the
display shows the main menu or another function
when the appliance is switched on.
→"Basic settings", Page15
¡If you do not perform any actions on the appliance
for an extended period, it will automatically switch it-
self off.
8.2 Switching off the appliance
Switch your appliance off when you are not using it.
The appliance will switch itself off automatically if it is
not used for a certain period of time.
▶Press to switch the appliance off.
aThe appliance switches off. Any functions currently
in progress are cancelled.
aThe time or residual heat indicator appears on the
display.
Notes
¡The residual heat indicator will appear on the dis-
play while the cooking compartment is still hot.
¡The cooling fan will continue to run until the cooking
compartment has cooled down.
8.3 Residual heat indicator
After you have switched off the appliance, the residual
heat indicator will appear on the display.
Display Temperature
Residual heat low Between 60 and 100°C
8.4 Filling the water tank
The water tank is located next to the cooking compart-
ment. You will need to fill the water tank before starting
any operation that uses steam.
WARNING‒Risk of scalding!
Hot steam may escape when you open the appliance
door. Steam may not be visible, depending on the tem-
perature.
▶When opening the door, do not stand too close to
the appliance.
▶Open the appliance door carefully.
▶Keep children at a safe distance.
The water in the evaporator dish is still hot even after
the appliance has been switched off.
▶Never empty the evaporator dish immediately after
switching off the appliance.
▶Allow the appliance to cool down before cleaning.
When you open the appliance door, hot water may flow
out of the appliance.
▶When opening the door, do not stand too close to
the appliance.
▶Open the appliance door carefully.
▶Keep children away from the appliance.
▶If the evaporator dish overflows, do not pour more
water into the water tank.
ATTENTION!
Using unsuitable liquids may damage the appliance.
▶Do not use highly chlorinated tap water (>40 mg/l)
or other liquids.
▶Only use cold, fresh tap water, softened water or
non-carbonated mineral water.
Requirement:The water hardness range is set cor-
rectly.
1. Open the appliance door.
2. Remove the water tank from the tank recess.
3. Open the tank cover.
4. Fill the water tank with cold water up to the max.
mark.
5. Close the tank lid.
6. Insert the full water tank back into the tank recess.

Time-setting options en
11
7. Check that the water tank is flush with the water
tank recess.
8. Close the appliance door.
8.5 Refilling the water tank
If the water tank runs dry during operation, steaming
will be paused.
1. Open the appliance door carefully.
2. Remove the water tank from the tank recess.
3. Fill the water tank with water.
4. Insert the full water tank back into the tank recess.
5. Close the appliance door.
8.6 Setting the type of heating and
temperature
1. Press to switch the appliance on.
2. Press "Steam".
3. Scroll through the types of heating using or ⁠.
4. Press the type of heating that you want to use.
5. Press "Temperature".
6. Use or to select the temperature.
7. Press to confirm the setting.
Also available to select:
– Duration →Page12
– Ready at →Page12
– Information
8. Press to start the operation.
aThe cooking time appears on the display.
aYou can see the cooking time counting down.
9. When the food is ready, use to switch the appli-
ance off.
8.7 Changing the temperature
You can also change the temperature or level once you
have started the appliance.
1. Press "Temperature".
2. Use ⁠ or ⁠to change the temperature.
3. Press to confirm the setting.
aThe temperature is changed.
8.8 Changing the type of heating
If you switch to a different type of heating, the appli-
ance will reset all the settings.
1. Press to pause operation.
2. Press to switch to the types of heating.
3. Scroll through the types of heating using or ⁠.
4. Press the type of heating that you want to use.
5. Adjust the temperature or level, if required.
6. Press to start the operation.
8.9 Pausing operation
1. Press ⁠.
2. Press again to resume operation.
8.10 “Fill water tank” message
If you select a type of heating and the water tank is
only half full, the appliance displays the message "Fill
water tank".
If the water tank contains sufficient water for cooking,
start the appliance.
If the water tank does not contain sufficient water for
cooking, fill the water tank.
→"Filling the water tank", Page10
8.11 After using the Steam function
When you use the appliance, moisture and food rem-
nants remain in the cooking compartment afterwards.
Dry and clean the appliance after each use. Empty the
water tank.
After using the Steam function
1. Dry the cooking compartment.
→"Drying the cooking compartment", Page19
2. Empty the water tank.
→"Emptying the water tank", Page19
9 Time-setting options
Your appliance has different time-setting options, with
which you can control its operation.
Time-setting
option
Use
Timer You can set the timer to run inde-
pendently of the appliance during op-
eration. The timer does not affect the
appliance.
Time-setting
option
Use
Cooking
time
Once the set duration has elapsed,
the appliance stops heating automat-
ically.
Ready at Along with the duration, you can set
the time at which you want the oper-
ation to end. The appliance starts up
automatically so that the operation
finishes at the required time.

en Time-setting options
12
9.1 Timer
You can set the timer regardless of whether the appli-
ance is on or off.
Setting the timer
1. Press ⁠.
2. Press Hours, Minutes or Seconds.
3. Use or to select the timer duration.
4. Press to confirm the setting.
a lights up red. The timer counts down.
aOnce the timer duration has elapsed, an audible sig-
nal sounds.
5. Press any button to end the audible signal.
Changing the timer
1. Press ⁠.
2. Press ⁠.
3. Press Hours, Minutes or Seconds.
4. Use or to change the timer duration.
5. Press to confirm the setting.
Cancelling the timer
1. Press ⁠.
2. Press to reset the timer duration.
3. Press to close the timer.
9.2 Cooking time
Once the set duration has elapsed, the appliance stops
heating automatically. You can only use the cooking
time in conjunction with a type of heating.
Setting the cooking time
1. Set a type of heating and a temperature.
2. Press "Cooking time".
3. Press Hours or Minutes.
4. Use ⁠ or ⁠to select the cooking time.
5. Press to confirm the setting.
6. Press to start operation with a cooking time.
aThe cooking time appears on the display. The cook-
ing time counts down.
aWhen the time has elapsed, a signal sounds.
7. Press any button to end the audible signal.
Changing the cooking time
1. Press ⁠.
2. Press "Cooking time".
3. Use ⁠ or ⁠to change the cooking time.
4. Press to confirm the setting.
Cancelling the cooking time
1. Press ⁠.
2. Press "Cooking time".
3. Reset the cooking time using ⁠.
4. Press to confirm the setting.
9.3 Delayed start/"Ready at" time
With this function, the appliance automatically switches
itself on, and then switches itself off at the preselected
end time. To enable it to do this, you set the cooking
time (duration) and specify when you want your food to
be ready. You can only use the delayed start function
in conjunction with a heating function.
Setting the "Ready at" time for delayed starts
Notes
¡Do not leave food that spoils easily in the cooking
compartment for too long.
¡You cannot use the delayed start function with every
type of heating.
1. Place the food into the cooking compartment and
close the appliance door.
2. Set a type of heating and a temperature.
3. Press "Cooking time".
4. Press Hours or Minutes.
5. Use ⁠ or ⁠to select the cooking time.
6. Press to confirm the setting.
7. Press "Ready at".
aThe time at which your food will be ready will ap-
pear on the display.
8. Use the ⁠button to select the required end time.
9. Press to confirm the setting.
10. Press to confirm the delayed start.
aThe appliance will start at the appropriate time.
aWhen the time has elapsed, a signal sounds.
11. Press any button to end the audible signal.
Changing the "Ready at" time for delayed starts
1. Press ⁠.
2. Press "Ready at".
3. Use or to change the end time.
4. Press to confirm the setting.
5. Press to confirm the delayed start.
Cancelling the "Ready at" time for delayed starts
1. Press ⁠.
2. Press "Ready at".
3. Use to reset the end time.
4. Press to confirm the setting.
aThe end time corresponds to the current time plus
the set cooking time.
aThe operation starts with the set cooking time.
Note:If you want to continue the operation without a
cooking time, cancel the cooking time.
→"Cancelling the cooking time", Page12

Steam programs en
13
10 Steam programs
You can cook food very easily using the various pro-
grams. The program applies the most suitable settings.
10.1 Selecting a program
WARNING‒Risk of scalding!
Hot steam may escape when you open the appliance
door. Steam may not be visible, depending on the tem-
perature.
▶When opening the door, do not stand too close to
the appliance.
▶Open the appliance door carefully.
▶Keep children at a safe distance.
1. Use ⁠ or ⁠ to select "Steam programmes" ⁠.
2. Navigate to the next row.
3. Use or to select the required steam programme.
4. Navigate to the next row.
5. Use to start the steam programme.
aOnce the set cooking time has elapsed, a signal
sounds and the appliance stops heating.
6. Once the cooking time has elapsed:
‒Press to end the signal early
‒For some dishes, you can extend the cooking
time if necessary.
‒When the dish is ready, press to switch the ap-
pliance off.
10.2 Setting a later end time
You can set a later end time for certain dishes.
Requirements
¡A dish is selected.
¡Operation has not begun.
1. Press ⁠.
2. Use or to adjust the end time.
3. Press to start the operation.
aThe start time will appear on the display. The appli-
ance is in standby mode.
aOnce the start time has been reached, the appli-
ance will start heating and the cooking time will start
counting down.
aOnce the cooking time has elapsed, an audible sig-
nal will sound. The time shown on the display will be
zero.
Note:You cannot change the end time later on.
10.3 Extending the cooking time
For some dishes, you can extend the cooking time
once the set cooking time has elapsed. You can do
this as often as required.
1. Press "Extend cooking time".
aA cooking time appears on the display.
2. If required, use or to change the cooking time.
3. Press to start the operation.
aThe appliance starts to heat and the time counts
down.
aWhen the time has elapsed, a signal sounds. The
appliance stops heating. The notification for extend-
ing the cooking time appears again.
4. Once the cooking time has elapsed:
‒Press the ⁠button to silence the audible signal
before it is due to end
‒If you want to extend the cooking time again,
press ⁠.
‒When the dish is ready, press to switch the ap-
pliance off.
10.4 Cancelling operation
▶Press to delete all settings.
aThe appliance will then stop. You can configure new
settings.
10.5 Overview of the steam programs
You can find out which individual dishes are available
to you on the appliance when you call up the operating
mode.
The dishes are sorted by category and food.
¡"Steamed chicken breast fillet"
¡"Fish, whole, steam"
¡"Fish fillet, fresh, steamed"
¡"Mixed vegetables, frozen"
¡"Unpeeled boiled potatoes"
¡"Basmati rice"
¡"Brown rice"
¡"Couscous"
¡"Steam cauliflower florets"
¡"Steam broccoli florets"
¡"Steam green beans"
¡"Sliced carrots, steamed"
¡"Lentils"
¡"Eggs, hard-boiled"
¡"Eggs, soft-boiled"
¡"Rice pudding"
¡"Fruit compote"
¡"Yoghurt in glass jars"
¡"Sterilise bottles"
¡"Reheat side dishes"
10.6 Overview of the sous-vide steam
programmes
You can find out which individual dishes are available
to you on the appliance when you call up the operating
mode.
The dishes are sorted by category and food.
The designation "SV" means that it is a sous-vide dish.
¡"Beef or veal steak, SV"
¡"Fillet of beef or veal, SV"
¡"Fillet of pork, SV"
¡"Saddle of lamb, SV"
¡"Duck breast, SV"
¡"Chicken breast fillet, SV"
¡"Fish fillet, SV"
¡"Scallops, SV"
¡"Prawns, SV"
¡"Green asparagus, SV"
¡"Pumpkin, SV"
¡"Tomatoes, SV"
¡"Apple slices, SV"
¡"Pineapple slices, SV"

en Favourites
14
¡"Custard, SV"
10.7 Cooking instructions for dishes
Follow the instructions shown on your appliance. Pro-
ceed in accordance with this information when you are
cooking dishes.
¡All programmes are designed for cooking on one
level. Cooking times may vary depending on the
quantity and quality of the ingredients.
¡Observe the tips for sous-vide cooking.
→"Sous-vide cooking", Page32
Amount/weight
¡Do not fill the food more than 4cm deep in the ac-
cessory.
¡Do not exceed the recommended maximum weight.
Accessory/cookware
¡Note the information about the accessories in the
recommended settings.
→"How it works", Page25
¡When cooking food in the perforated steaming tray,
insert the unperforated steaming tray below it in po-
sition 1. This will catch any liquid that drips down.
Cereal products or lentils
Weigh the food and add the correct ratio of water:
¡Basmati rice 1:1.5
¡Couscous 1:1
¡Brown rice 1:1.5
¡Lentils 1:2
¡Stir cereal products after cooking so that the re-
maining water is more quickly absorbed.
Fish
¡Grease the perforated steaming tray.
¡Do not place fish or fish fillets on top of each other.
¡Select fish or fish fillets that are as similar in size as
possible.
¡Enter the weight of the heaviest fish.
Eggs
¡Pierce eggs before cooking.
¡Do not place eggs on top of each other.
Chicken breast
¡Do not place chicken breasts on top of each other.
Vegetables
¡Do not season vegetables until after cooking.
¡Do not use frozen products that are covered with a
thick layer of ice. Remove any ice on the food.
¡Always distribute the food evenly in the cookware. It
will not cook evenly if the food is piled up to varying
heights.
Making yoghurt
1. Heat the milk to 90°C on the hob.
If you are using long-life milk, 40°C is sufficient.
2. Allow the milk to cool to 40°C.
3. Mix 150g of chilled yoghurt into the milk.
4. Pour the mixture into cups or small jars and cover
with cling film.
5. Place the cups or jars onto a steaming tray.
6. Observe the information in the overview of dishes
and start the programme.
7. After making the yoghurt, leave it to cool in the refri-
gerator.
Making rice pudding
1. Weigh the rice.
2. Add 2.5 times the amount of milk.
3. Pour the rice and milk into the accessory until you
have a mixture that is no more than 2.5cm deep.
4. Observe the information in the overview of dishes
and start the programme.
5. Stir the rice after cooking.
aThe rice pudding will absorb the remaining milk.
Making fruit compote
The programme is only suitable for fruits with stones
and pips.
1. Weigh the fruit.
2. Add approx. 1/3 of the amount of water.
3. Add sugar and spices to taste.
4. Observe the information in the overview of dishes
and start the programme.
Sterilising bottles
You can use your appliance to sterilise bottles. The
process is equivalent to normal sterilisation by boiling.
1. Clean the bottles with a bottle brush immediately
after use.
2. Wash the bottles in the dishwasher.
3. Place the bottles into the perforated steaming tray
such that they do not touch one another.
4. Observe the information in the overview of dishes
and start the programme.
5. Dry the bottles with a clean cloth.
11 Favourites
In the "Favourites", you can save your settings and use
these again.
Notes
¡Depending on the appliance type/software status,
you must first download this function to your appli-
ance. You can find more information in the
HomeConnect app.
¡You can start the favourites on the appliance or us-
ing the HomeConnect app. All other functions are
available via the HomeConnect app.
11.1 Saving favourites
You can save up to 10 different functions as your fa-
vourites.
▶To save a function as a favourite, you must use the
HomeConnect app. When your appliance is con-
nected, follow the instructions in the app.

Childproof lock en
15
11.2 Selecting favourites
If you have saved favourites, you can use these to set
the operation.
1. Press "Favourites" in the menu.
2. Press the required favourite.
3. If required, you can change the settings.
4. Press to start the operation.
aThe setting values are shown on the display.
11.3 Changing favourites
You can change, sort or delete your saved favourites at
any time.
▶To change the favourites, you must use the
HomeConnect app. When your appliance is con-
nected, follow the instructions in the app.
12 Childproof lock
You can secure your appliance to prevent children
from accidentally switching it on or changing the set-
tings.
12.1 Activating the childproof lock
The childproof lock can be activated regardless of
whether the appliance is on or off.
▶Press and hold for approx. 4seconds to activate
the childproof lock.
aA confirmation notification appears on the display.
aThe control panel is now locked. The appliance can
only be switched off using ⁠.
aWhen the appliance is switched on, lights up.
When the appliance is switched off, does not
light up.
12.2 Deactivating the childproof lock
You can deactivate the childproof lock at any time.
▶Press and hold "Unlock" for approx. 4seconds to
deactivate the childproof lock.
13 Basic settings
You can configure the basic settings for your appliance
to meet your needs.
13.1 Overview of the basic settings
Here you can find an overview of the basic settings
and factory settings. The basic settings depend on the
features of your appliance.
You can find more information about the individual ba-
sic settings on the display using ⁠.
Basic settings Selection
Language See selection on the appliance
HomeConnect Connect the oven to a mobile end
device and remotely control it. Home
Connect →Page16
Time Time in 24-hour format
Date Date in the format DD.MM.YYYY
Display Selection
Brightness ¡Levels 1, 2, 3, 4 and 51
Standby
screen
¡On for a limited time
¡On (this setting increases energy
consumption)
¡Off1
Clock ¡Digital + date1
¡Digital
¡Analogue + date
Alignment ¡Align the display horizontally and
vertically
1Factory setting (may vary according to model)
Tone Selection
Button tone ¡On1
¡Off
Signal tone ¡Very short duration
¡Short duration
¡Medium duration1
¡Long duration
1Factory setting (may vary according to model)
Appliance set-
tings
Selection
Fan run-on
time
¡Minimum
¡Recommended1
¡Long
¡Very long
Lighting ¡On when cooking and opening
the door 1
¡Only when the door is opened
¡Always off
Water hard-
ness
¡4 (very hard)1
¡3 (hard)
¡2 (medium)
¡1 (soft)
¡0 (softened)
1Factory setting (may vary according to model)
Personalisa-
tion
Selection
Brand logo ¡Display1
¡Do not display
1Factory setting (may vary according to model)

en HomeConnect
16
Personalisa-
tion
Selection
Operation after
switch-on
¡Main menu1
¡Steaming
¡Dishes
¡Favourites
Regional
dishes
¡All1
¡European dishes
¡British dishes
Childproof
lock
¡Keylock only1
¡Deactivated
1Factory setting (may vary according to model)
Factory set-
tings
Selection
Factory set-
tings
¡Restore
Appliance in-
formation
Appliance information
13.2 Changing basic settings
1. Press to switch the appliance on.
2. Press "Basic settings".
3. Use or to scroll through the basic settings or cat-
egories.
4. Press the required basic setting or category.
‒Press the required basic setting in a category.
5. Swipe left or right to select the required setting.
6. Press to confirm the change.
If does not appear, the change is applied imme-
diately.
7. To change other basic settings, use to return to
the basic settings.
14 HomeConnect
This appliance is network-capable. Connecting your ap-
pliance to a mobile device lets you control its functions
via the HomeConnect app, adjust its basic settings
and monitor its operating status.
The HomeConnect services are not available in every
country. The availability of the HomeConnect function
depends on the availability of HomeConnect services
in your country. You can find information about this at:
www.home-connect.com.
The HomeConnect app guides you through the entire
login process. Follow the instructions in the HomeCon-
nect app to configure the settings.
Tips
¡Please consult the documents supplied by
HomeConnect.
¡Please also follow the instructions in the HomeCon-
nect app.
Notes
¡Please note the safety precautions in this instruction
manual and make sure that they are also observed
when operating the appliance via the HomeCon-
nect app.
→"Safety", Page2
¡Operating the appliance on the appliance itself al-
ways takes priority. During this time it is not possible
to operate the appliance using the HomeConnect
app.
¡In networked standby mode, the appliance requires
a maximum of2W.
14.1 Setting up HomeConnect
Requirements
¡The appliance is connected to the power supply and
is switched on.
¡You have a mobile device with a current version of
the iOS or Android operating system, e.g. a smart-
phone.
¡The mobile device and the appliance are within
range of your home network's Wi-Fi signal.
1. Download the HomeConnect app.
2. Open the HomeConnect app and scan the follow-
ing QR code.
3. Follow the instructions in the HomeConnect app.
14.2 HomeConnect settings
You can adjust the HomeConnect settings and network settings in your appliance's basic settings.
Which settings the display shows will depend on whether HomeConnect has been set up and whether the appliance
is connected to your home network.

HomeConnect en
17
Basic setting Possible settings Explanation
Home Connect as-
sistant
Start the assistant
Disconnect
You can connect your appliance to the Home Connect app via
the Home Connect assistant.
Note:If you are using the Home Connect assistant for the first
time, only the "Start assistant" setting is available.
Wi-Fi On
Off
You can use the Wi-Fi to switch off the network connection for
your appliance. When you have connected successfully once,
you can deactivate the Wi-Fi and not lose your detailed data.
As soon as you activate Wi-Fi again, the appliance connects
automatically.
Note:In networked standby mode, the appliance requires a
maximum of 2W.
Remote control status Monitoring
Manual remote start
Permanent remote start
During monitoring, you can only view the operating status of
the appliance in the app.
For manual remote start, you must activate the remote start
each time before you can start the appliance via the app. If
you open the appliance door within 15minutes of activating
remote start or of the operation ending, remote start is deactiv-
ated.
For permanent remote start, you can start and operate the ap-
pliance remotely at any time. If you often operate the appliance
remotely, it is helpful to set the remote start to "Permanent".
14.3 Operating the appliance with the
HomeConnect app
You can use the HomeConnect app to set and start
the appliance remotely.
WARNING‒Risk of fire!
Combustible objects that are left in the cooking com-
partment may catch fire.
▶Never store combustible objects in the cooking
compartment.
▶If smoke is emitted, the appliance must be switched
off or the plug must be pulled out and the door
must be held closed in order to stifle any flames.
Requirements
¡The appliance is switched on.
¡The appliance is connected to the home network
and to the HomeConnectapp.
¡In order to be able to set the appliance via the app,
the manual or permanent remote start must be se-
lected in the "Remote control status" basic setting.
1. To activate remote start, press ⁠.
2. Configure a setting in the HomeConnectapp and
send it to the appliance.
Notes
¡If you open the appliance door within 15minutes
of activating remote start or of the operation end-
ing, the manual remote start is deactivated.
¡When you start the oven using the controls on
the appliance itself, the remote start function is
activated automatically. You can use the
HomeConnectapp to adjust the settings or start
a new programme.
14.4 Software update
Your appliance's software can be updated using the
software update function, e.g. for the purposes of op-
timisation, troubleshooting or security updates.
To do this, you must be a registered HomeCon-
nectuser, have installed the app on your mobile device
and be connected to the HomeConnectserver.
As soon as a software update is available, you will be
informed via the HomeConnectapp and will be able to
start the software update via the app. Once the update
has been successfully downloaded, you can start in-
stalling it via the HomeConnectapp if you are in your
WLAN home network (Wi-Fi). The HomeConnectapp
will inform you once installation is successful.
Notes
¡You can continue to use your appliance as normal
while updates are downloading. Depending on your
personal settings in the app, software updates can
also be set to download automatically.
¡We recommend that you install security updates as
soon as possible.
¡Installation takes a few minutes. You cannot use
your appliance during installation.
14.5 Remote diagnostics
Customer Service can use Remote Diagnostics to ac-
cess your appliance if you contact them, have your ap-
pliance connected to the HomeConnect server and if
Remote Diagnostics is available in the country in which
you are using the appliance.
Tip:For further information and details about the avail-
ability of Remote Diagnostics in your country, please
visit the service/support section of your local website:
www.home-connect.com.

en Cleaning and servicing
18
14.6 Data protection
Please see the information on data protection.
The first time your appliance is registered on a home
network connected to the Internet, your appliance will
transmit the following types of data to the
HomeConnect server (initial registration):
¡Unique appliance identification (consisting of appli-
ance codes as well as the MAC address of the Wi-Fi
communication module installed).
¡Security certificate of the Wi-Fi communication mod-
ule (to ensure a secure data connection).
¡The current software and hardware version of your
appliance.
¡Status of any previous reset to factory settings.
This initial registration prepares the HomeConnect
functions for use and is only required when you want to
use the HomeConnect functions for the first time.
Note:Please note that the HomeConnect functions
can only be utilised with the HomeConnect app. In-
formation on data protection can be retrieved in the
HomeConnect app.
15 Cleaning and servicing
To keep your appliance working efficiently for a long time, it is important to clean and maintain it carefully.
15.1 Cleaning agents
Only use cleaning agents that are suitable for the differ-
ent surfaces on your appliance.
WARNING‒Risk of electric shock!
An ingress of moisture can cause an electric shock.
▶Do not use steam- or high-pressure cleaners to
clean the appliance.
ATTENTION!
Unsuitable cleaning products may damage the sur-
faces of the appliance.
▶Do not use harsh or abrasive detergents.
▶Do not use oven cleaner.
▶Do not use limescale remover on the door handle or
control panel, as it may leave permanent staining.
▶Do not use corrosive or harsh cleaning products or
products containing chlorine.
▶Salts are very corrosive and can cause rusting. Re-
move the remnants of any acidic sauces or salted
food from the cooking compartment immediately
once it has cooled.
▶Do not use cleaning products with a high alcohol
content.
▶Do not use hard scouring pads or cleaning
sponges.
Appliance front
Surface Cleaning agent Information
Stainless steel Soapy water
Special stainless steel cleaner
After cleaning the surface, dry it with a soft
cloth.
To prevent corrosion, remove any patches of
limescale, grease, starch or albumin (e.g.
egg white) from stainless steel surfaces im-
mediately.
Appliance interior
Cooking compartment with evap-
orator dish
Hot soapy water
Vinegar solution
Use the cleaning sponge provided or a soft
washing-up brush to clean the cooking com-
partment and evaporator dish with hot, soapy
water or a vinegar solution.
Accessories Hot soapy water
Vinegar solution
Soak accessories in hot, soapy water and
then clean with a brush or washing-up
sponge.
Alternatively, accessories can be cleaned in
the dishwasher.
If an accessory is exhibiting significant dis-
colouration, clean it with a vinegar solution.
Water tank Soapy water Do not clean the water tank in the dish-
washer.
Tank recess Wipe dry after every use.
Seal in the water tank lid Wipe dry after every use.

Cleaning and servicing en
19
Appliance door
Door panels Glass cleaner After cleaning the surface, dry it with a soft
cloth.
Door seal Hot soapy water
15.2 Microfibre cloth
The microfibre cloth removes liquids and grease.
This microfibre cloth has a honeycomb structure and is
suitable for cleaning delicate surfaces such as the
following:
¡Glass
¡Glass ceramic
¡Stainless steel
¡Aluminium
You can buy the microfibre cloth from customer ser-
vice, from specialist retailers or online.
15.3 Cleaning sponge
Use the absorbent cleaning sponge only for cleaning
the cooking compartment and for removing residual
water from the evaporator dish.
Wash the cleaning sponge thoroughly before use.
You can wash the cleaning sponge in the washing ma-
chine using a hot wash program.
You can buy the cleaning sponge from customer ser-
vice, from specialist retailers or online.
15.4 Drying the cooking compartment
WARNING‒Risk of scalding!
Hot steam may escape when you open the appliance
door. Steam may not be visible, depending on the tem-
perature.
▶When opening the door, do not stand too close to
the appliance.
▶Open the appliance door carefully.
▶Keep children at a safe distance.
The water in the evaporator dish is still hot even after
the appliance has been switched off.
▶Never empty the evaporator dish immediately after
switching off the appliance.
▶Allow the appliance to cool down before cleaning.
1. Leave the appliance door ajar until the appliance
has cooled down.
2. Clean any food remnants from the cooking compart-
ment.
3. Once it has cooled down, wipe down the cooking
compartment and the evaporator dish with the
cleaning sponge, and dry thoroughly with a soft
cloth.
4. If condensation has formed on the front panels, dry
them.
15.5 Emptying the water tank
ATTENTION!
Drying the water tank in the hot cooking compartment
leads to damage to the water tank.
▶Do not dry the water tank in the hot cooking com-
partment.
Cleaning the water tank in the dishwasher will damage
it.
▶Do not clean the water tank in the dishwasher.
▶Clean the water tank with a soft cloth and standard
washing-up liquid.
1. Open the appliance door.
2. Remove the water tank and empty out the remaining
water.
3. Dry the seal in the tank lid and the tank recess in
the appliance.
4. Slot the water tank back into the water tank recess.
5. Close the appliance door.
15.6 Descaling
To ensure that your appliance continues to operate cor-
rectly, it must be descaled regularly. How often you
need to descale your appliance depends on the hard-
ness of the water used.
Notes
¡If you press while the descaling process is in pro-
gress, the process stops and the appliance shuts
down. When you switch the appliance back on, you
will need to rinse it twice in order to remove any re-
maining descaling solution. During the second rinse
cycle, the appliance is locked against being used
for other applications.
¡The appliance indicates when only another 5 or
fewer steam-assisted operations are possible. If you
do not carry out descaling, you can no longer set
any operation with steam.
Step Duration
Descaling →Page19 Approx. 34min
First rinse cycle 2min
Second rinse cycle 2min
Starting the descaling process
It takes approx. 30minutes to descale your appliance.
ATTENTION!
The length of time for which the descaler is left to work
is based on the recommended, liquid descaler. Other
descalers may damage the appliance.
▶Only use the liquid descaler recommended by us
for the descaling programme.
If descaling solution comes into contact with the control
panel or other delicate surfaces, it will damage them.
▶Remove descaling solution immediately with water.
1. Mix 300ml water with 60ml liquid descaler to
make a descaling solution.
2. Remove the water tank.
3. Fill the water tank with the descaling solution.
4. Slide the water tank all the way into the appliance.
5. Close the appliance door.
6. Press
7. Select "Cleaning".
8. Press ⁠.

en Cleaning and servicing
20
Running the rinse cycle
1. Remove the descaling solution from the evaporator
dish using the cleaning sponge provided and then
thoroughly rinse the cleaning sponge with water.
2. Remove the water tank and rinse it thoroughly.
3. Fill the water tank with water and then slide it back
into the appliance.
4. Close the appliance door.
aThe appliance rinses itself for 4 minutes.
5. Open the appliance door.
6. Remove the remaining water from the evaporator
dish using the cleaning sponge.
7. Proceed to the second rinse cycle.
8. Remove the water tank and empty out the remaining
water.
9. Thoroughly rinse the water tank and fill it with fresh
water.
10. Reinsert the water tank.
11. Close the appliance door.
12. Press ⁠.
aThe appliance rinses itself for 2 minutes.
13. Remove the remaining water from the evaporator
dish using the cleaning sponge.
14. Wipe down the cooking compartment using the
cleaning sponge and then dry with a soft cloth.
15. Switch off the appliance.
aThe appliance is ready for use again.
15.7 Appliance door
To clean or remove the door panels, you can detach
the appliance door.
The appliance's door hinges each have a locking lever.
When the locking levers are closed, the appliance door
is secured in place. The appliance door cannot be re-
moved when it is secured like this.
When the locking levers are open, the hinges are se-
cured and cannot snap shut.
Detaching the appliance door
WARNING‒Risk of injury!
Components inside the appliance door may have sharp
edges.
▶Wear protective gloves.
The hinges on the appliance door move when the door
is opened and closed, which could trap your fingers.
▶Keep your hands away from the hinges.
1. Open the appliance door fully.
2. WARNING‒Risk of injury!
When the hinges are not secured, they can snap
shut with great force.
▶Make sure that the locking levers are always
either fully closed or (when detaching the oven
door) fully open.
Open the locking levers on the left- and right-hand
hinges.
Locking levers opened
The hinge is now se-
cured and cannot snap
shut.
Locking levers closed
The appliance door is
secured and cannot be
detached.
aThe locking levers are open. The hinges are now se-
cured and cannot snap shut.
