NELLY SECURITY TVI User manual

Digital Video Recorder
Quick Start Guide

Digital Video Recorder Quick Start Guide
1
TABLE OF CONTENTS
Chapter 1Description of Panels ......................................................................................................................6
1.1 Front Panel ......................................................................................................................................6
1.2 Rear Panel .......................................................................................................................................7
Chapter 2Installation and Connections..........................................................................................................9
2.1 DVR Installation..............................................................................................................................9
2.2 Hard Disk Installation......................................................................................................................9
2.3 RS-485 and Controller Connection................................................................................................ 11
2.4 HDD Storage Calculation Chart.................................................................................................... 12
Chapter 3Menu Operation............................................................................................................................13
3.1 Menu Structure..............................................................................................................................13
3.2 Startup and Shutdown.................................................................................................................... 13
3.3 Activating Your Device .................................................................................................................14
3.4 Login and Logout..........................................................................................................................15
User Login .......................................................................................................................................15
User Logout .....................................................................................................................................16
3.5 Configuring the Signal Input.........................................................................................................17
3.6 Using the Setup Wizard.................................................................................................................18
3.7 Network Settings...........................................................................................................................19
3.8 Adding IP Cameras........................................................................................................................ 20
3.9 Live View...................................................................................................................................... 21
3.10 Recording Settings.........................................................................................................................21
3.11 Playback ........................................................................................................................................ 22
Chapter 4Accessing by Web Browser...........................................................................................................24

Digital Video Recorder Quick Start Guide
2
Quick Start Guide
This Manual is applicable to TVI HD Digital Video Recorder (DVR).
The Manual includes instructions for using and managing the product. Pictures, charts, images and all other
information hereinafter are for description and explanation only. The information contained in the Manual is
subject to change, without notice, due to firmware updates or other reasons. Please find the latest version in the
company website
Please use this user manual under the guidance of professionals.
Legal Disclaimer
REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE
WHOLLY AT YOUR OWN RISKS. OUR COMPANY SHALL NOT TAKE ANY RESPONSIBILITES FOR
ABNORMAL OPERATION, PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER
ATTACK, HACKER ATTACK, VIRUS INSPECTION, OR OTHER INTERNET SECURITY RISKS;
HOWEVER, OUR COMPANY WILL PROVIDE TIMELY TECHNICAL SUPPORT IF REQUIRED.
SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL RELEVANT LAWS IN YOUR
JURISDICTION BEFORE USING THIS PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS
THE APPLICABLE LAW. OUR COMPANY SHALL NOT BE LIABLE IN THE EVENT THAT THIS
PRODUCT IS USED WITH ILLEGITIMATE PURPOSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE
LATER PREVAILS.

Digital Video Recorder Quick Start Guide
3
Regulatory Information
FCC Information
Please take attention that changes or modification not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may
cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be required to correct the interference at his own expense.
FCC Conditions
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired operation.
EU Conformity Statement
This product and - if applicable - the supplied accessories too are marked with "CE" and comply
therefore with the applicable harmonized European standards listed under the EMC Directive
2014/30/EU, the LVD Directive 2014/35/EU, the RoHS Directive 2011/65/EU.
2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted
municipal waste in the European Union. For proper recycling, return this product to your local
supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection
points. For more information see: www.recyclethis.info
2006/66/EC (battery directive): This product contains a battery that cannot be disposed of as unsorted
municipal waste in the European Union. See the product documentation for specific battery
information. The battery is marked with this symbol, which may include lettering to indicate
cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling, return the battery to your supplier or to a
designated collection point. For more information see: www.recyclethis.info
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (A)/NMB-3(A) standards requirements.

Digital Video Recorder Quick Start Guide
4
Safety Instruction
These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss.
The precaution measure is divided into “Warnings” and “Cautions”
Warnings: Serious injury or death may occur if any of the warnings are neglected.
Cautions: Injury or equipment damage may occur if any of the cautions are neglected.
Warnings
Proper configuration of all passwords and other security settings is the responsibility of the installer
and/or end-user.
In the use of the product, you must be in strict compliance with the electrical safety regulations of the
nation and region. Please refer to technical specifications for detailed information.
Input voltage should meet both the SELV (Safety Extra Low Voltage) and the Limited Power Source
with 100~240 VAC or 12 VDC according to the IEC60950-1 standard. Please refer to technical
specifications for detailed information.
Do not connect several devices to one power adapter as adapter overload may cause over-heating or a
fire hazard.
Please make sure that the plug is firmly connected to the power socket.
If smoke, odor or noise rise from the device, turn off the power at once and unplug the power cable, and
then please contact the service center.
Preventive and Cautionary Tips
Before connecting and operating your device, please be advised of the following tips:
Ensure unit is installed in a well-ventilated, dust-free environment.
Unit is designed for indoor use only.
Keep all liquids away from the device.
Ensure environmental conditions meet factory specifications.
Ensure unit is properly secured to a rack or shelf. Major shocks or jolts to the unit as a result of dropping
it may cause damage to the sensitive electronics within the unit.
Use the device in conjunction with an UPS if possible.
Power down the unit before connecting and disconnecting accessories and peripherals.
A factory recommended HDD should be used for this device.
Improper use or replacement of the battery may result in hazard of explosion. Replace with the same or
equivalent type only. Dispose of used batteries according to the instructions provided by the battery
manufacturer.
Warnings
Follow these
safeguards to prevent serious
injury or death.
Cautions Follow these precautions
to prevent potential injury or
material damage.

Digital Video Recorder Quick Start Guide
5
Applicable Models
This manual is applicable to the TVI DVR series.
Symbol Conventions
The symbols that may be found in this document are defined as follows.
Symbol Description
Indicates a potentially hazardous situation, which if not avoided,
could result in equipment damage, data loss, performance
degradation, or unexpected results.
Provides additional information to emphasize or supplement
important points of the main text.

Digital Video Recorder Quick Start Guide
6
Chapter 1 Description of Panels
1.1 Front Panel
Figure 1. 1 Front Panel 2
Table 1. 1 Description of Front Panel 2
No.
Name
Function Description
1
POWER
Turns yellow when the device s running.
STATUS Flickers red when data is being read from or written to HDD, and
turns yellow when the SHIFT function is realized.
Tx/RxFlickers
yellow when network connection is functioning
properly.
2 Composite
Keys
SHIFT Switches between the numeric or letter input and functions of the
composite keys.
1/MENU Enters numeral “1”;
Accesses the main menu interface.
2/ABC/F1
Enters numeral “2”;
Enters letters “ABC”;
Uses the F1 button to select all items in a list field;
Turns on/off PTZ light in PTZ Control mode, and use it to zoom
out the image;
Switches between main and spot video output in live view or
playback mode.
3/DEF/F2
Enters numeral “3”;
Enters letters “DEF”;
Uses the F2 button to change the tab pages;
Zooms in the image in PTZ control mode.
4/GHI/ESC
Enters numeral “4”;
Enters letters “GHI”;
Exits and back to the previous menu.
5/JKL/EDIT
Enters numeral “5”;
Enters letters “JKL”;
Deletes characters before cursor;
Checks the checkbox and select the ON/OFF switch;
Starts/stops record clipping in playback.
6/MNO/PLAY
Enters numeral “6”;

Digital Video Recorder Quick Start Guide
7
No.
Name
Function Description
Enters letters “MNO”;
Accesses to playback interface in Playback mode.
7/PQRS/REC
Enters numeral “7”;
Enters letters “PQRS”;
Accesses to manual record interface;
Manually enables/disables record.
8/TUV/PTZ
Enters numeral “8”;
Enters letters “TUV”;
Accesses PTZ control interface.
9/WXYZ/PREV
Enters numeral “9”;
Enters letters “WXYZ”;
Multi-channel display in live view.
0/A
Enters numeral “0”;
Shifts the input methods in the editing text field. (Upper and
lowercase, alphabet, symbols or numeric input).
3
DIRECTION
Navigates between different fields and items in menus.
Uses the Up and Down buttons to speed up and slow down the
playing of video files in Playback mode.
The Left and Right but
ton will select the next and previous
record files.
Cycles through channels in Live View mode.
Controls the movement of the PTZ camera in PTZ control mode.
ENTER
Confirms selection in any of the menu modes.
Checks the checkbox.
Plays or pauses the playing of video files in Playback mode.
Advances the video by a single frame in single-frame Playback
mode.
Stops/starts auto switch in Auto-switch mode.
4 USB Interface Universal Serial Bus (USB) ports for additional devices such as
USB mouse and USB Hard Disk Drive (HDD).
5
IR Receiver
Receiver for IR remote control.
1.2 Rear Panel
The rear panel vaires according to different models. Please refer to the actual product. The following figure is for
reference only.

Digital Video Recorder Quick Start Guide
8
Figure 1. 2 Rear Panel
Table 1. 2 Description of Front Panel
No.
Item
Description
1
VIDEO IN
BNC interface for TVI and analog video input.
2
AUDIO IN
RCA connector
3
AUDIO OUT
RCA connector.
4 VGA DB15 connector for VGA output. Display local video output and
menu.
5
HDMI
HDMI video output connector.
6
USB
Universal Serial Bus (USB) ports for additional devices
7
Network Interface
Connector for network
8
RS-485
Half-duplex connector for RS-485 devices.
9
Power Supply
12VDC power supply.
10
Power Switch
Switch for turning on/off the device.
11
GND
Ground (needs to be connected when NVR starts up).
12
VIDEO OUT
BNC connector for video output.
13
GND
Ground (needs to be connected when NVR starts up).
14 Alarm Interface
Connector for alarm input.
Connector for alarm output.

Digital Video Recorder Quick Start Guide
9
Chapter 2 Installation and Connections
2.1 DVR Installation
During the installation of the DVR:
1. Use brackets for rack mounting.
2. Ensure there is ample room for audio and video cables.
3. When installing cables, ensure that the bend radius of the cables are no less than five times than its diameter.
4. Connect both the alarm and RS-485 cable.
5. Allow at least 2cm (≈0.75-inch) of space between racks mounted devices.
6. Ensure the DVR is grounded.
7. Environmental temperature should be within the range of -10º C to 55º C, 14º F to 131º F.
8. Environmental humidity should be within the range of 10% to 90%.
2.2 Hard Disk Installation
Before you start:
Before installing a hard disk drive (HDD), please make sure the power is disconnected from the DVR. A factory
recommended HDD should be used for this installation.
One or two SATA hard disks can be installed depending on different models.
Tools Required: Screwdriver.
As the installation steps of HDD are similar among different models, here we take the steps of one model as the
example.
Steps:
1. Remove the cover from the DVR by unfastening the screws on the back and side.
Figure 2. 1 Remove the Cover
2. Connect one end of the data cable to the motherboard of DVR and the other end to the HDD.

Digital Video Recorder Quick Start Guide
10
Figure 2. 2 Connect the Data Cable
3. Connect the power cable to the HDD.
Figure 2. 3 Connect the Power Cable
4. Place the HDD on the bottom of the device and then fasten the screws on the bottom to fix the HDD.
Figure 2. 4 Install the HDD
5. Re-install the cover of the DVR and fasten screws.

Digital Video Recorder Quick Start Guide
11
2.3 RS-485 and Controller Connection
Typical Connection :
Figure 2. 5 Controller Connection A
To connect PTZ to the DVR:
1. Disconnect pluggable block from the RS-485 terminal block.
2. Press and hold the orange part of the pluggable block; insert signal cables into slots and release the orange
part. Ensure signal cables are in tight.
3. Connect A+ on PTZ to D+ on terminal block and B- on controller to D- on terminal block. Fasten stop
screws.
4. Connect pluggable block back into terminal block.
Make sure both the controller and DVR are grounded.

Digital Video Recorder Quick Start Guide
12
2.4 HDD Storage Calculation Chart
The following chart shows an estimation of storage space used based on recording at one channel for an hour at a
fixed bit rate.
Bit Rate
Storage Used
96K
42M
128K
56M
160K
70M
192K
84M
224K
98M
256K
112M
320K
140M
384K
168M
448K
196M
512K
225M
640K
281M
768K
337M
896K
393M
1024K
450M
1280K
562M
1536K
675M
1792K
787M
2048K
900M
4096K
1.76G
8192K
3.52G
16384K
7.03G
Please note that supplied values for storage space used are just for reference. Storage space used is estimated by
formulas and may have some deviation from actual value.

Digital Video Recorder Quick Start Guide
13
Chapter 3 Menu Operation
3.1 Menu Structure
The menu structure varies according to different models.
Menu
Export Manual HDD Camera
Maintenance
Shutdown
Record
Configuration
Playback
Normal Record General Schedule Camera General System Info Logout
Event Advanced Parameters OSD Network Log
Information Shutdown
Advanced Image
Import/
Export
Reboot
Holiday PTZ Upgrade
Motion
Live View
Default
Privacy Mask
Exceptions
Net Detect
Video
Tampering
User
Video Loss
HDD Detect
Alarm
VCA
Normal
Event
Tag
Smart
Sub-periods
External
File
VCA Search
Behavior
Search
Face Search
People
Counting
Heat Map
Alarm
Manual Video
Quality
Diagnostics
Video Quality
Diagnostics
Figure 3. 1 Menu Structure
3.2 Startup and Shutdown
Proper startup and shutdown procedures are crucial to expanding the life of the DVR.
To start your DVR:
1. Check the power supply is plugged into an electrical outlet. It is HIGHLY recommended that an
Uninterruptible Power Supply (UPS) be used in conjunction with the device. The Power button) on the front
panel should be red, indicating the device is receiving the power.
2. Press the POWER button on the front panel. The Power LED should turn blue. The unit will begin to start.

Digital Video Recorder Quick Start Guide
14
After the device starts up, the wizard will guide you through the initial settings, including modifying
password, date and time settings, network settings, HDD initializing, and recording.
To shut down the DVR:
1. Enter the Shutdown menu.
Menu > Shutdown
Figure 3. 2 Shutdown
2. Select the Shutdown button.
3. Click the Yes button.
3.3 Activating Your Device
Purpose:
For the first-time access, you need to activate the device by setting an admin password. No operation is allowed
before activation. You can also activate the device via Web Browser, SADP or client software.
Steps:
1. Input the same password in the text field of Create New Password and Confirm New Password.
Figure 3. 3 Set Admin Password
STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong
password of your own choosing (using a minimum of 8 characters, including upper case letters,
lower case letters, numbers, and special characters) in order to increase the security of your
product. And we recommend you reset your password regularly, especially in the high security
system, resetting the password monthly or weekly can better protect your product.
2. Click OK to save the password and activate the device.

Digital Video Recorder Quick Start Guide
15
For the old version device, if you upgrade it to the new version, the following dialog box will pop up once the
device starts up. You can click YES and follow the wizard to set a strong password.
Figure 3. 4 Warning of Weak Password
3.4 Login and Logout
User Login
Purpose:
You have to log in to the device before operating the menu and other functions.
Steps:
1. Select the User Name in the dropdown list.
Figure 3. 5 Login
2. Input Password.
3. Click OK to log in.
In the Login interface, for the admin, if you have entered the wrong password for 7 times, the account will be
locked for 60 seconds. For the operator, if you have entered the wrong password for 5 times, the account will be
locked for 60 seconds.

Digital Video Recorder Quick Start Guide
16
Figure 3. 6 User Account Protection for the Admin
Figure 3. 7 User Account Protection for the Operator
User Logout
Purpose:
After logging out, the monitor turns to the live view mode and if you want to perform any operations, you need to
enter user name and password log in again.
Steps:
1. Enter the Shutdown menu.
Menu > Shutdown
Figure 3. 8 Logout
2. Click Logout.

Digital Video Recorder Quick Start Guide
17
After you have logged out the system, menu operation on the screen is invalid. It is required to input a user name
and password to unlock the system.
3.5 Configuring the Signal Input
After the startup and login, the device system enters the Wizard for configuring the signal input.
Steps:
1. Check the checkbox to select different signal input types: TVI/CVBS, AHD, and IP.
2. Click Apply to save the settings.
Figure 3. 9 Configure Signal Input Type
You can also click Menu > Camera > Signal Input Status to configure the signal input.
Steps:
1. Enter the Signal Input Status interface.
Menu > Camera > Signal Input Status
2. Check the checkbox to select different signal input types: TVI/CVBS, AHD or IP (For E series DVR, there is
no signal input configuration interface.).

Digital Video Recorder Quick Start Guide
18
Figure 3. 10 Configure Signal Input Type
3. Click Apply to save the settings.
For this series DVR, each two video channels are grouped in sequence, e.g., CH01 and CH02, CH03 and
CH04..., and each two channels in the same group must be connected with the same type of video source
selected on GUI. For example, when the TVI/CVBS signal mode is selected, then either TVI or CVBS signal
input can be connected to the channels in the same group; and when the AHD signal mode is selected, only
the AHD signal input can be connected.
The default TVI/CVBS signal input type also supports the auto detection of 3MP signal. Each two types of
the signals can be mixed randomly.
In the live view interface, when there is no video signal of the analog channel, the corresponding connectable
video signal type message can be displayed on the screen.
The IP channels will not be displayed on the interface and you can view the max. IP camera accessible
number in the Max. IP Camera Access text field.
3.6 Using the Setup Wizard
The Setup Wizard can walk you through some important settings of the device. By default, the Setup Wizard starts
once the device has loaded.
Check the checkbox to enable Setup Wizard when device starts. Click Next to continue the setup wizard. Follow
the guide of the Setup Wizard to configure the system resolution, system date/time, network settings, HDD
management, record settings, etc.

Digital Video Recorder Quick Start Guide
19
Figure 3. 11 Wizard
3.7 Network Settings
Purpose:
Network settings must be properly configured before you operate DVR over network.
Steps:
1. Enter the Network Settings interface.
Menu > Configuration > Network
Figure 3. 12 Network Settings
1 self-adaptive 10M/100M/1000M network interface or 1 self-adaptive 10M/100Mbps network interface provided
for other models. .
2. Select the General tab.
3. In the General Settings interface, you can configure the following settings: NIC Type, IPv4 Address, IPv4
Gateway, MTU and DNS Server.
If the DHCP server is available, you can check the checkbox of DHCP to automatically obtain an IP address
and other network settings from that server.
4. After having configured the general settings, click the Apply button to save the settings.
