1.0 Keys required
Cash Box Base Front Door: Key A with Black Key
Sleeve.
SST Kiosk LCD Screen Door: Key T0001 with white
Key Sleeve.
Puloon Cash Dispenser: Key Dae Ro / 02
QUICK START GUIDE
CAUTION: Servicing of this product or unit is to
be performed by trained service personnel only.
15302 Betmakers SST_Cash Kiosk Quick Start Guide_ECN6501 Page 4 of 14
2.0 Unpacking the Kiosk
Remove the strapping from the SST Cash Kiosk
carton.
Caution: The strapping is under tension and can flick
when cut.
Carefully lift the carton off the Pallet.
Remove the documentation from the packaging and
retain for future reference.
The removal of the green protective film from the LCD
Screen, plastic Swipe Cover covers, Base Plate &
clear protective film from the NFC are to be completed
at the end of the installation process to avoid damage.
Open Cash Box Base Front Door using Key A with
Black Key Sleeve.
QUICK START GUIDE
CAUTION: Servicing of this product or unit is to
be performed by trained service personnel only.
15302 Betmakers SST_Cash Kiosk Quick Start Guide_ECN6501 Page 5 of 14
2.0 Unpacking the Kiosk (continued)
Remove the Cash Kiosk Base from the Pallet.
2x Coach Bolts are fastened through the front of the
Kiosk retaining the Base Plate to the Pallet.
The UPS may require repositioning to allow access to
the Coach Bolt. If required, peel the UPS from the
Velcro holding to the Base Plate.
Remove 1x Coach Bolt from the LH Side of the Base
Plate with a 13mm Open End Ring Spanner.
Discard Bolt.
Return the UPS back to its original position & press
down to adhere to the Velcro.
Step 2: Unlock and open the Dispenser Internal Lock
Door by unlocking the Lock on the RH Side using the
Key A provided.
Remove 1x Coach Bolt from the RH Side of the Base
Plate with a 13mm Open End Ring Spanner.
Discard Bolt.
Close the Dispenser Internal Lock Door & Cash Box
Base Front Door using Key A with Black Key Sleeve.
QUICK START GUIDE
CAUTION: Servicing of this product or unit is to
be performed by trained service personnel only.
Coach Bolt fixing
shown.
UPS
Coach Bolt fixing
shown.
15302 Betmakers SST_Cash Kiosk Quick Start Guide_ECN6501 Page 6 of 14
2.0 Unpacking the Kiosk (continued)
THE REMOVAL OF THE SST CASH
KIOSK REQUIRES A FORKLIFT OR
SIMILAR TO REMOVE IT FROM THE
PALLET.
DO NOT ATTEMPT TO REMOVE
WITHOUT APPROPRIATE LIFTING
EQUIPMENT.
SST CASH KIOSK BASE WEIGHT
= 280Kg / 617lbs
Remove the SST Cash Kiosk from Pallet and locate to
the designated area.
Remove green protective film from Base Plate.
QUICK START GUIDE
CAUTION: Servicing of this product or unit is to
be performed by trained service personnel only.
15302 Betmakers SST_Cash Kiosk Quick Start Guide_ECN6501 Page 7 of 14
3.0 Power up the Kiosk
Power, Network ports are accessed from the LH side
of the unit.
The Kiosk is intended to be used in a location having
equipotential bonding (such as a restricted access
area) and is connected to power using an earthed IEC
cable supplied.
Verification of the protective earthing connection of the
socket-outlet to be performed by a skilled person.
Plug the Power lead into power point.
Plug in the Network cable into position shown.
Unlock and open the LCD Screen Door and Lower
Door by unlocking the Lock at the Right-hand side of
the Kiosk using Key T0001 with White Key Sleeve
provided.
This provides access to the Kiosk power switch.
Switch unit from O →I (note: components removed for
clarity).
Stage 1: Push in green tray and close Lower Door.
Stage 2: Close & lock the LCD Screen Door via the
Lock at the Right-hand side of the Kiosk using Key
T0001 with White Key Sleeve provided.
QUICK START GUIDE
CAUTION: Servicing of this product or unit is to
be performed by trained service personnel only.
Stage 1
Stage 2
15302 Betmakers SST_Cash Kiosk Quick Start Guide_ECN6501 Page 8 of 14
4.0 Power up the Kiosk (continued)
Open Cash Box Base Front Door using Key A with
Black Key Sleeve to access the UPS located on the LH
side of the Kiosk.
Press & hold the UPS Power button until a “beep” is
heard.
A light on the UPS will continually illuminate indicating
that the UPS is on.
Close the Dispenser Internal Lock Door using Key A
with Black Key Sleeve.
QUICK START GUIDE
CAUTION: Servicing of this product or unit is to
be performed by trained service personnel only.
15302 Betmakers SST_Cash Kiosk Quick Start Guide_ECN6501 Page 9 of 14
4.0 Loading printer paper
Unlock and open the LCD Screen Door and Lower
Door by unlocking the Lock at the Right-hand side of
the Kiosk using Key T0001 with White Key Sleeve
provided.
This provides access to the Kiosk internals.
To access the printer paper tray, pull out the green tray
towards the operator.
Remove the paper spindle from the Packaging Kit.
Slide the paper roll onto the paper spindle and install
into roller supports.
Paper feeds into Printer from top of roll.
Ensure paper roll coated surface is fed into the printer
face up.
Stage 1: Push in green tray and close Lower Door.
Stage 2: Close & lock the LCD Screen Door via the
Lock at the Right-hand side of the Kiosk using Key
T0001 with White Key Sleeve provided.
QUICK START GUIDE
CAUTION: Servicing of this product or unit is to
be performed by trained service personnel only.
Stage 1
Stage 2
15302 Betmakers SST_Cash Kiosk Quick Start Guide_ECN6501 Page 10 of 14
5.0 Location of Modem and inserting SIM Card
To access the Modem, unlock and open the LCD
Screen Door by unlocking the Lock at the Right-hand
side of the Kiosk using Key T0001 with White Key
Sleeve provided.
The Modem is in the Main Frame against the rear wall.
Insert SIM Card into Modem from the rear in the
orientation shown.
Modem
QUICK START GUIDE
CAUTION: Servicing of this product or unit is to
be performed by trained service personnel only.
15302 Betmakers SST_Cash Kiosk Quick Start Guide_ECN6501 Page 11 of 14
6.0 Monitor adjustment
To access the LCD Screen Monitor adjustment
buttons, unlock and open the LCD Screen Door by
unlocking the Lock at the Right-hand side of the Kiosk
using Key T0001 with White Key Sleeve provided.
The LCD Screen Adjustment buttons are located
behind the rear cover.
Select “Menu”button.
Navigate settings following the Menu.
The Monitor Adjustment Menu will disappear after
approx. 10 seconds.
Reselect “Menu: button to continue process.
Menu
QUICK START GUIDE
CAUTION: Servicing of this product or unit is to
be performed by trained service personnel only.
15302 Betmakers SST_Cash Kiosk Quick Start Guide_ECN6501 Page 12 of 14
7.0 Access to the Puloon Dispenser
The Puloon Cash Dispenser is in RH side of the
Cabinet Main Frame.
Unlock and open the Door Fascia by unlocking the
Lock on the LH Side using Key A with Black Key
Sleeve provided.
Unlock and open the Dispenser Internal Lock Door
by unlocking the Lock on the RH Side using the
Key A with Black Key Sleeve provided.
The Puloon Cash Dispenser has 4x Cash Trays.
They can be removed individually by pressing the
green button & pulling the handle.
Unlock and open the Puloon Cash Dispenser Cash
Tray by unlocking the Lock using the Key Dae Ro /
02 provided.
QUICK START GUIDE
CAUTION: Servicing of this product or unit is to
be performed by trained service personnel only.
15302 Betmakers SST_Cash Kiosk Quick Start Guide_ECN6501 Page 13 of 14
8.0 Instructions for Puloon Dispenser test software
Step 1:
Find and open UCDM V1.74 application
Step 2:
Using device manager determine the COM port the cash dispenser is connected to (1-10).
Step 3:
Select the communication port number and click the OPEN button to connect device. The OPEN button will
be turned to CLOSE when it is connected normally with the display on the left side (like the red dotted box)
Without communication success, no function can work, and the red dotted box displays the communication
status.
QUICK START GUIDE
CAUTION: Servicing of this product or unit is to
be performed by trained service personnel only.
15302 Betmakers SST_Cash Kiosk Quick Start Guide_ECN6501 Page 14 of 14
8.0 Instructions for Puloon Dispenser test software (continued)
Step 4:
Dispensing notes (Operation).
Input the requested amount for dispensing into the blanks on Request Type. Then DISPENSE is pressed
and the requested quantity of note will be dispensed.
If an error is occurred, UCDM will stop, and the error codes will be displayed on the pop-up window.
The only commands that are necessary to know are:
Present- The dispensed notes by DISPENSE are stacked in the specific area before delivering to the
customer. Then PRESENT enables to present the dispensed and stacked notes to the customer.
Retract- In case the customer does not take the presented banknotes within the designated time,
RETRACT could be used for returning the notes back to Reject Cassette. Also, even after dispensing
banknotes (before presenting), it enables all the stacked notes to be rejected to the Reject Cassette.
Purge- This command moves all notes on the path to the Reject Cassette and initializes UCDM with
clearing all the errors.
QUICK START GUIDE
CAUTION: Servicing of this product or unit is to
be performed by trained service personnel only.
