NeoQi Flamingo User manual

NEOQI®
Flamingo
ENG

2

3
Thank you for choosing NeoQi®

4
Main features in NeoQi®Flamingo
Ergonomic design
Every part of cocoon is made to suit
your special needs to relax.
Sensor buttons
Functions can be activated by gentle
touch of a button.
Creativity
You can combine between several
possibilities to have a small SPA.

5
Main features in NeoQi®Flamingo
Steam
cleanses the skin and
improves its structure
(elasticity, color),
increases the recep-
tiveness of the skin to
active ingredients
contained in cosmetic
products.
Infrared radiation
provides deep, safe and
revitalizing warming of all
organs and tissues,
improves the metabolism,
stimulates sweating,
removes toxins from the
body.
Vichy shower
resembling a heavy rain,
provides gentle massage
of reflex zones, improves
blood circulation and has
lymphatic drainage action,
affects the nervous system
in a positive way.
Vibrating table
improves and stimulates
regeneration processes,
helps to eliminate waste
products, has a positive
effect on the neuro-
muscular system.
LED light
represents the active
energy that impacts on
our psycho-emotional
processes.
Music system
specially composed
music accompaniment
that has a positive
impact the perception of
the treatment.

6
Table of Content
PRECONDITIONS. SET UP.
QUALITY REPORT 11
PRECONDITIONS FOR INSTALLATION 15
ELECTRIC CONNECTION 19
WATER CONNECTIONS 19
MAINTENANCE 21
OTHER TECHNICAL DETAILS 21
TERMS OF WARRANTY 22
INTRODUCTION. CAUTIONS.
INTRODUCTION 29
PHILOSOPHY OF NEOQI®30
IMPORTANT CAUTIONS AND USER SAFETY INFORMATION 31
HEALTH PRECAUTIONS 32
GETTING STARTED. USING YOUR COCOON.
BASIC COMPONENTS OF YOUR COCOON 37
FUNCTIONS ON CONTROL PANEL A(UPPER PART OF EQUIPMENT) 39
WARM-UP SESSION 39
STEAM SAUNA 41
AROMATHERAPY 42
INFRARED SAUNA 43
44
45
48
48
FACE FAN
VICHY SHOWER
TIMER
HAND SHOWER
Bluetooth Audio 49

7
TREATMENTS. ТHERAPIES. AFFECTS.
STEAM SAUNA 53
AROMATHERAPY 55
INFRARED SAUNA 56
HYDROFUSION 60
VICHY SHOWER 61
VIBROMASSAGE 62
CHROMOTHERAPY 64
MUSIC THERAPY 66

8

9
ASASASSSASAAAAAAA
1
Preconditions.
Set up.

10

11
QUALITY REPORT
NeoQi Energy Cocoon
Serial Number: _
Pre shipment inspection Pre usage inspection
Date: ________________
Physical aspects
body surfaces ________________
components ________________
technical condition ________________
Functional test
control panels ________________
steam sauna ________________
infrared sauna ________________
Vichy shower ________________
vibrating table ________________
face fan ________________
hand shower ________________
MP3-player ________________
LED lamps ________________
Checked by: _______________ ________________
Before starting to use the unit, please fill out this form and fax or mail it back to NeoQi AS.
Ph:[phone] Fax:[phone] Add: Piirimäe 15, Tänassilma, Saku vald 76406, Estonia

12

13

NeoQi AS.
Piirimäe 15, Tänassilma SERVICE REQUEST
76406 Saku vald DATE:
Estonia NUMBER:
Ph. [phone]
DISTRIBUTOR´S NAME: CUSTOMER´S NAME:
Equimpent’s Serial Number: Harmony Flamingo:
Date Equipment Received:
Date Equipment Delivered:
Date Equipment Started operating:
Date Problem Occurred:
Problem Report:
Person Reporting……………………….

14

15

NeoQi AS.
Piirimäe 15, Tänassilma SERVICE REQUEST
76406 Saku vald DATE:
Estonia NUMBER:
Ph. [phone]
DISTRIBUTOR´S NAME: CUSTOMER´S NAME:
Equimpent’s Serial Number: Harmony Flamingo:
Date Equipment Received:
Date Equipment Delivered:
Date Equipment Started operating:
Date Problem Occurred:
Problem Report:
Person Reporting……………………….

16

17
Preconditions for Installation
Room
Equipment is designed for use in indoor
conditions. The room, where the equipment
is used should be moisture proof.
Ventilation is recommended, as in the
working regime the machine creates
humidity.
It is recommended to have a general drain
on a floor.
For installation of Flamingo the room must
be at least 2500 mm high and 2500 mm
wide.
On the illustration areas A and B are the
best suitable places for connections (Figure
1).
Doorway must be wide at least 80 cm.
Power
Power cord material at least 3 x 2,5 mm²
copper crosscut. Power cord should be
connected into the moisture proof junction
box which is located on the equipment
frame.
Maximum power consumption for equipment
at a time is 4,4kW.
Protective device current in front of
equipment feeder not less than 20A. Refer
to area (A) on illustration (Figure 1).
Water
WATER CONNECTION
2 water pressure hoses are required one for
hot, another for cold water with one ending
being ½ threaded. Refer to area (inside area
B on illustration) on illustration (Figure 1)
Length of hoses depend upon the distance
from the water inlets.
Steam generator do not work without warm
water inlet.
DRAINAGE
Drainage connection on the floor should be
at least Ø 32 mm;
Water drainage hose should be of Ø 32 mm
Length of drainage hose depending on the
distance from drainage opening on the
ground (inside area B on illustration)(Figure
1).

18
2300 mm
945 mm
Figure 1
Figure 2

19
Electric Connection
Electric installations of NeoQi® Harmony
Flamingo should be carried out by qualified
specialists or official representative of
NeoQi® AS.
NeoQi® Harmony Flamingo is CLASS 1
EQUIPMENT in which protection against
electric shock does not rely on BASIC
INSULATION only, but which includes an
additional safety precaution, which implies
that the EQUIPMENT must be connected to a
protective earth conductor in a fixed wiring,
in such a way that accessible metal parts
cannot become live in the event of a failure
of the basic insulation.
NeoQi® Harmony Flamingo belongs to the
group of TYPE B EQUIPMENT, which provides
a degree of protection against electric shock,
which implies:
-allowable leakage current (10 mA);
-reliability of the protective earth connection.
NeoQi® Harmony Flamingo cannot be used
if the air contains FLAMMABLE ANAESTHETIC
MIXTURE WITH AIR or WITH OXYGEN OR
NITROUS OXIDE.
Water Connections
The installation of warm and cold water
inlets and drainage connections of NeoQi®
Harmony equipment should be carried out
by qualified specialist or official
representative of NeoQi® AS.
For proper functioning of the equipment only
clean tap water should be used. In case the
tap water contains high percentage of
abrasive substances or rust, it is
recommended to install a water filter.

20
Initial Warm-Up Session
Turn on the device by pressing main ON/OFF
button.
Close the hood of the equipment and switch
on the steam sauna (STEAM) function from
the upper control panel. The following icon
will appear on the screen in a small frame.
Select the maximum steam temperature by
pressing +/- buttons until the steam icon
appears in the frame. Set temperature to
48º. The timer will automatically set itself to
30 minutes.
After the steam session has stopped, switch
on the infrared sauna (INFRARED) function
from upper control panel. The following icon.
Now turn on the first program of the Vichy
shower (VICHY SHOWER) for 5 minutes.
In case any of the functions will not operate
please contact the local dealer.
