Neousys Technology Nuvo-8034 Series User manual

Neousys Technology Inc.
Nuvo-8034 Series
User Manual
Revision 1.4

Table of Contents
Table of Contents
Table of Contents...................................................................................................................2
Legal Information...................................................................................................................4
Contact Information...............................................................................................................5
Declaration of Conformity.....................................................................................................5
Copyright Notice ....................................................................................................................6
Safety Precautions.................................................................................................................7
Hot Surface Warning..............................................................................................................7
Battery Warning......................................................................................................................7
Service and Maintenance......................................................................................................8
ESD Precautions....................................................................................................................8
Restricted Access Location..................................................................................................8
About This Manual.................................................................................................................9
1 Introduction
1.1 Product Specifications.............................................................................................11
1.1.1 Nuvo-8034 Specifications.................................................................................11
1.2 Nuvo-8034 Dimension..............................................................................................13
1.2.1 Nuvo-8034 I/O Panel View................................................................................13
1.2.2 Nuvo-8034 Side Panel View.............................................................................14
1.2.3 Nuvo-8034 Top View.........................................................................................15
1.2.4 Nuvo-8034 Rear View.......................................................................................16
1.2.5 Nuvo-8034 Wall-mount Bracket Dimension ......................................................17
2System Overview
2.1 Nuvo-8034 Packing List...........................................................................................18
2.2 External I/O Panel.....................................................................................................19
2.2.1 Power Button ....................................................................................................21
2.2.2 4-pole 3.5mm Speaker-out/ Microphone-in Jack...............................................22
2.2.3 DisplayPort........................................................................................................23
2.2.4 Reset Button.....................................................................................................24
2.2.5 LED Indicators ..................................................................................................25
2.2.6 DVI Port............................................................................................................26
2.2.7 VGA Port...........................................................................................................27
2.2.8 USB3.1 Gen 2 Port...........................................................................................28
2.2.9 Gigabit Ethernet Port ........................................................................................29
2.2.10 USB3.1 Gen 1 Port...........................................................................................30
2.2.11 COM Port..........................................................................................................31
2.2.12 Hot-swappable 2.5” External HDD/ SSD Slot....................................................32
2.2.13 3-pin Terminal Block..........................................................................................33
2.2.14 Isolated Digital Input/ Output.............................................................................34
2.3 Internal I/O Functions...............................................................................................36
2.3.1 SODIMM DRAM Slot ........................................................................................36
2.3.2 Dual Mode mSATA/ mini-PCIe Socket & Pin Definition.....................................37
2.3.3 M.2 2242 (B Key), Dual-SIM Card Slot & Pin Definition....................................39
2.3.4 SATA Ports........................................................................................................41
2.3.5 Status LED Output & Remote On/ Off Control and Pin Definition.....................42
2.3.6 M.2 2280 (M Key) Slot for NVMe SSD or OptaneTM Memory............................44
2.3.7 Internal USB Port on Extension Board..............................................................46
2.3.8 COM Port 3 and 4.............................................................................................47
3System Installation
3.1 Disassembling the System......................................................................................50
3.2 Installing Internal Components...............................................................................55
3.2.1 CPU Installation Procedure...............................................................................55
3.2.2 DDR4 SO-DIMM Installation.............................................................................58

Table of Contents
3
3.2.3 mPCIe Module, Mini-SIM (2FF) Card andAntennae Installation.......................60
3.2.4 M.2 2242 (B Key) Module and Micro-SIM (3FF) Card Installation.....................62
3.2.5 M.2 (M Key) 2280 NVMe SSD or Intel®OptaneTM Memory Installation ............64
3.2.6 PCIe/ PCI Card Installation...............................................................................66
3.2.7HDD/ SSD Installation.......................................................................................68
3.2.8 Ethernet Port Panel Screw Holes......................................................................70
3.3 Installing the System Enclosure .............................................................................71
3.4Wall-mount Bracket Installation..............................................................................74
3.5 Powering On the System .........................................................................................76
3.5.1 Powering On Using the Power Button...............................................................76
3.5.2 Powering On Using Wake-on-LAN....................................................................77
4System Configuration
4.1 BIOS Settings ...........................................................................................................79
4.1.1 COM Port Configuration....................................................................................80
4.1.2 COM Port High Speed Mode............................................................................81
4.1.3 Primary Display.................................................................................................82
4.1.4 SATA Configuration...........................................................................................83
4.1.5 Fan Control Configuration.................................................................................85
4.1.6 TPMAvailability.................................................................................................90
4.1.7 Power On After Power Failure Option...............................................................91
4.1.8 Power & Performance (CPU SKU Power Configuration)..................................92
4.1.9 Wake on LAN Option ........................................................................................93
4.1.10 Boot Menu ........................................................................................................94
4.1.11 Boot Type (Legacy/ UEFI).................................................................................96
4.1.12 Position New Boot Device.................................................................................97
4.1.13 Watchdog Timer for Booting..............................................................................98
4.2 AMT Configuration...................................................................................................99
4.3 RAID Configuration................................................................................................100
4.3.1 Legacy Mode RAID Configuration...................................................................100
4.3.2 UEFI Mode RAID Configuration......................................................................106
5OS Support and Driver Installation
5.1 Operating System Compatibility...........................................................................116
5.2 Driver Installation...................................................................................................117
5.2.1 Install Drivers Automatically............................................................................117
5.2.2 Install Drivers Manually...................................................................................118
5.3 Driver Installation for Watchdog Timer Control...................................................119
5.4 Intel®OptaneTM Memory BIOS Setup and Driver Installation..............................120
Appendix A Using WDT & DIO
WDT and DIO Library Installation.....................................................................................130
WDT Functions...................................................................................................................132
InitWDT................................................................................................................................132
SetWDT ...............................................................................................................................132
StartWDT.............................................................................................................................133
ResetWDT ...........................................................................................................................133
StopWDT .............................................................................................................................133

Legal Information
Legal Information
All Neousys Technology Inc. products shall be subject to the latest Standard
Warranty Policy
Neousys Technology Inc. may modify, update or upgrade the software, firmware or
any accompanying user documentation without any prior notice. Neousys
Technology Inc. will provide access to these new software, firmware or
documentation releases from download sections of our website or through our
service partners.
Before installing any software, applications or components provided by a third party,
customer should ensure that they are compatible and interoperable with Neousys
Technology Inc. product by checking in advance with Neousys Technology Inc..
Customer is solely responsible for ensuring the compatibility and interoperability of
the third party’s products. Customer is further solely responsible for ensuring its
systems, software, and data are adequately backed up as a precaution against
possible failures, alternation, or loss.
For questions in regards to hardware/ software compatibility, customers should
contact Neousys Technology Inc. sales representative or technical support.
To the extent permitted by applicable laws, Neousys Technology Inc. shall NOT be
responsible for any interoperability or compatibility issues that may arise when (1)
products, software, or options not certified and supported; (2) configurations not
certified and supported are used; (3) parts intended for one system is installed in
another system of different make or model.

Contact Information/ Declaration of Conformity
Contact Information
Headquarters
(Taipei, Taiwan)
Neousys Technology Inc.
15F, No.868-3, Zhongzheng Rd., Zhonghe Dist., New Taipei City, 23586, Taiwan
Tel: [phone] Fax: [phone] Email, Website
Americas
(Illinois, USA)
Neousys Technology America Inc.
3384 CommercialAvenue, Northbrook, IL 60062, USA
Tel: [phone]Email, Website
China Neousys Technology (China) Ltd.
Room 612, Building 32, Guiping Road 680, Shanghai
Tel: [phone]Email, Website
Declaration of Conformity
FCC This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user will
be required to correct the interference at own expense.
CE The product(s) described in this manual complies with all applicable European
Union (CE) directives if it has a CE marking. For computer systems to remain
CE compliant, only CE-
compliant parts may be used. Maintaining CE
compliance also requires proper cable and cabling techniques.

Copyright Notice
Copyright Notice
All rights reserved. This publication may not be reproduced, transmitted,
transcribed, stored in a retrieval system, or translated into any language or
computer language, in any form or by any means, electronic, mechanical,
magnetic, optical, chemical, manual or otherwise, without the prior written
consent of Neousys Technology, Inc.
Disclaimer This manual is intended to be used as an informative guide only and is subject
to change without prior notice. It does not represent commitment from Neousys
Technology Inc. Neousys Technology Inc. shall not be liable for any direct,
indirect, special, incidental, or consequential damages arising from the use of
the product or documentation, nor for any infringement on third party rights.
Patents and
Trademarks
Neousys, the Neousys logo, Expansion Cassette, MezIOTM are registered
patents and trademarks of Neousys Technology, Inc.
Windows is a registered trademark of Microsoft Corporation.
Intel®, Core™ are registered trademarks of Intel Corporation
NVIDIA®is a registered trademark of NVIDIA Corporation
All other names, brands, products or services are trademarks or registered
trademarks of their respective owners.

Safety Precautions
Safety Precautions
Read these instructions carefully before you install, operate, or transport the system.
Install the system or DIN rail associated with, at a sturdy location
Install the power socket outlet near the system where it is easily accessible
Secure each system module(s) using its retaining screws
Place power cords and other connection cables away from foot traffic. Do not
place items over power cords and make sure they do not rest against data cables
Shutdown, disconnect all cables from the system and ground yourself before
touching internal modules
Ensure that the correct power range is being used before powering the device
Should a module fail, arrange for a replacement as soon as possible to minimize
down-time
By means of a power cord connected to a socket-outlet with earthing connection
This product is intended to be supplied by a Listed Power Adapter or DC power
source, rated 24Vdc, 16A, Tma 60 degree C and 5000m altitude during operation.
If further assistance is required, please contact Neousys Technology
If the system is not going to be used for a long time, disconnect it from mains
(power socket) to avoid transient over-voltage
Hot Surface Warning
HOT SURFACE. DO NOT
TOUCH. “ATTENTION: Surface chaude. Ne
pas toucher.”
WARNING!
Components/ parts inside the
equipment may be hot to touch!
Please wait one-half hour after
switching off before handling parts.
Battery Warning
Batteries are at risk of exploding if incorrectly
installed
Do not attempt to recharge, force open, or heat the
battery
Replace the battery only with the same or equivalent
type recommended by the manufacturer

Service and Maintenance/ ESD Precautions
Service and Maintenance
ONLY qualified personnel should service the system
Shutdown the system, disconnect the power cord and all other connections
before servicing the system
When replacing/ installing additional components (expansion card, memory
module, etc.), insert them as gently as possible while assuring proper
connector engagement
ESD Precautions
Handle add-on module, motherboard by their retention screws or the module’s
frame/ heat sink. Avoid touching the PCB circuit board or add-on module
connector pins
Use a grounded wrist strap and an anti-static work pad to discharge static
electricity when installing or maintaining the system
Avoid dust, debris, carpets, plastic, vinyl and 8tyrofoam in your work area.
Do not remove any module or component from its anti-static bag before
installation
Restricted Access Location
The controller is intended for installation only in the certain environment where both
these condition apply:
Access can only be gained by SERVICE PERSONS or by USERS who have
been instructed about the reasons for the restrictions applied to the location
and about any precautions that shall be taken
Access is through the use of a TOOL or lock and key, or other means of
security, and is controlled by the authority responsible for the location.

About This Manual
About This Manual
This manual introduces Neousys Nuvo-8034 featuring Intel®Xeon, 9th/ 8th Gen
Core™ I octa/ hexa core 65W/ 35W LGA1151 processors and dual graphics cards.
The system features two x16 PCIe, two x8 PCIe and three PCI slots for legacy
expansion cards. The system is ideal for industrial applications such as machine
vision, automation and data analytics.
The guide also demonstrates the system’s installation procedures.
Revision History
Version Date Description
1.0 Mar. 2020 Initial release
1.1 May. 2020 Updated COM port specifications, antenna aperture and AMT
port illustrations
1.2 Oct. 2020 Updated CPU/ motherboard installation procedure
1.3 Feb. 2021 Updated COM ports 3 and 4 connection and pin definition on the
daughter board
1.4 Mar. 2021 Updated recommended WDT_DIO driver version
Updated DIO connector pin definition

Nuvo-8034
10
1 Introduction
Nuvo-8034 is based on the one-for-all concept featuring meets the I/O expansions that meet
the demands of industrial automation and system integrators for machine vision, automation,
and AI applications. Nuvo-8034 is the first box-PC to offer seven expansion slots that include
two x16 PCIe, two x8 PCIe and three PCI slots, in just half the volume of a typical 4U, 19”
industrial computer. Along with Xeon®E or Intel 9th/ 8th-Gen Core desktop processor and
workstation-grade Intel C246 chipset, it delivers state-of-the-art processing power among
off-the-shelf box-PCs and rack-mount IPCs. More than that, with Neousys’ distinctive power
design, Nuvo-8034 is able to power a single 180W NVIDIA GPU, to fuel teraFLOPS
performance for deep learning-based vision inspection applications.
External I/O wise, Nuvo-8034
has eight USB 3.1 Gen2/ Gen1
ports with screw-lock, two Gigabit
Ethernet ports, four COM ports
and 8-CH isolated DI plus 8-CH
isolated DO for general machine
automation usage. It also has two
front-accessible, hot-swappable
2.5" SATA tray with RAID 0/ 1
support. Internally it supports an
M.2 NVMe SSD and up to 128
GB DDR4 memory for the
ultimate system performance.
In addition, by supporting an 180W GPU, it’s now possible to leverage cutting-edge deep
learning methodologies to complement complicated vision inspection systems. We believe
Nuvo-8034 is the universal platform fulfilling all demands of machine automation and vision
inspection, both now and in the future.”

Nuvo-8034
11
1.1 Product Specifications
1.1.1 Nuvo-8034 Specifications
System Core
Processor
Supporting Intel® Xeon® E and 9th/ 8th Gen Core i CPU (LGA1151 socket)
Intel® Xeon® Processor E-2278GE (8C/ 16T)
Intel® Xeon® Processor E-2278GEL (8C/ 16T)
Intel® Xeon® Processor E-2176G
Intel® Core™ i7-9700E/ i7-9700TE/ i7-8700/ i7-8700T
Intel® Core™ i5-9500E/ i5-9500TE/ i5-8500/ i5-8500T
Intel® Core™ i3-9100E/ i3-9100TE/ i3-8100/ i3-8100T
Chipset Intel® C246 Platform Controller Hub
Graphics Independent GPU via x16 (@ x8 signal) PEG port, or integrated Intel® UHD graphics
630
Memory Up to 128 GB ECC/ non-ECC DDR4 2133 SDRAM (four SODIMM slots)
AMT Supports AMT 12.0
TPM Supports TPM 2.0
I/O Interface
Ethernet 1x Gigabit Ethernet port by Intel® I219-LM
1x Gigabit Ethernet port by Intel® I210-IT
Native Video
1x VGAconnector, supporting 1920 x 1200 resolution
1x DVI-D connector, supporting 1920 x 1200 resolution
1x DisplayPort connector, supporting 4096 x 2304 resolution
Serial Port 2x software-programmable RS-232/ 422/ 485 ports (COM1/ COM2)
2x RS-232 ports (COM3/ COM4)
USB3.1 4x USB 3.1 Gen2 (10 Gbps) ports
4x USB 3.1 Gen1 (5 Gbps) ports
USB2.0 1x USB 2.0 ports (internal for dongle use)
Audio 1x 3.5mm jack for mic-in and speaker-out
Storage Interface
SATA 2x hot-swappable HDD trays for 2.5” HDD/ SSD installation (support RAID 0/1)
M.2 1x M.2 2280 M key socket (PCIe Gen3 x4) for NVMe SSD or Intel® Optane™ memory
mSATA 2x full-size mSATA port (mux with mini-PCIe)
Expansion Bus
PCI Express 2x PCIe x16 slot@Gen3, 8-lanes
2x PCIe x8 slots@Gen3, 4-lanes

Nuvo-8034
12
* If the CPU is operating at 65W mode, the highest operating temperature shall be limited to 50°C and
thermal throttling may occur when sustained full-loading applied. Users can configure CPU power in
BIOS to obtain higher operating temperature.
** For sub-zero operating temperature, a wide temperature HDD drive or Solid State Disk (SSD) is
required.
PCI 3x 33MHz/ 32-bit 5V PCI slots
M.2 1x M.2 2242 B key socket supporting dual SIM mode with selected M.2 LTE module
Mini-PCIe 1x full-size mini PCI Express socket with internal SIM socket (mux. With mSATA)
Power Supply
DC Input 1x 3-pin pluggable terminal block for 8~35V DC input
1x 3-pin pluggable terminal block for remote control
Mechanical
Dimension 259 mm (W) x 280 mm (D) x 198 mm (H)
Weight ~ 7Kg
Mounting Wall-mount brackets
Environmental
Operating
temperature -25°C ~ 60°C */ **
Storage
temperature -40°C ~85°C
Humidity 10%~90% , non-condensing
Vibration Operating, MIL-STD-810G, Method 514.6, Category 4
Shock Operating, MIL-STD-810G, Method 516.6, Procedure I, Table 516.6-II
EMC CE/ FCC Class A, according to EN 55032 & EN 55024

Nuvo-8034
13
1.2 Nuvo-8034 Dimension
NOTE
All measurements are in millimeters (mm).
1.2.1 Nuvo-8034 I/O Panel View

Nuvo-8034
14
1.2.2 Nuvo-8034 Side Panel View

Nuvo-8034
15
1.2.3 Nuvo-8034 Top View

Nuvo-8034
16
1.2.4 Nuvo-8034 Rear View

Nuvo-8034
17
1.2.5 Nuvo-8034 Wall-mount Bracket Dimension

Nuvo-8034
18
2 System Overview
Upon receiving and unpacking your Nuvo-8034 system, please check immediately if the
package contains all the items listed in the following table. If any item(s) are missing or
damaged, please contact your local dealer or Neousys Technology.
2.1 Nuvo-8034 Packing List
System
Pack Nuvo-8034 Qty
1 Nuvo-8034 system
(If you ordered CPU/ RAM/ HDD, please verify these items) 1
2
Accessory box, which contains
CPU bracket
Neousys drivers & utilities DVD
Wall-mount bracket
Hex key
3-pin power terminal block
Screw pack
1
1
2
2
2
1

Nuvo-8034
19
2.2 External I/O Panel
The Nuvo-8034 I/O panel features USB3.1 Gen2/ Gen1, DisplayPort, DVI, VGA, dual Ethernet,
COM ports, dual 2.5” external slots, DIO.
No. Item Description
1 Power button Use this button to turn on or shutdown the system.
2
4-pole 3.5mm
speaker-out/
microphone-in
jack
3.5mm jack for speaker-out or microphone-input.
3 DisplayPort Support display resolutions up to 4096 x 2304. Compatible with
HDMI/ DVI via respective adapter/ cable (resolution may vary).
4 Reset button Use this button to manual reset the system.
5 LED indicator
From top to bottom, the four system LEDs are PWR (system
power), HDD (hard disk drive), WDT (watchdog timer) and IGN
(ignition control).
6 DVI port DVI-D output supports resolution up to 1920x1200@60Hz and is
compatible with other digital connections via an adapter.
7 VGA port VGA output supports resolution up to 1920x1200@60Hz
8 USB3.1 Gen 2 port (SuperSpeed+) offers up to 10Gbps, twice the
USB 3.1 Gen2

Nuvo-8034
20
port bandwidth over existing SuperSpeed USB3.1 Gen. 1 connection. It
is also backwards compatible with USB3.0 and USB2.0
9 GbE port 1x Gigabit Ethernet port by Intel® I219-LM
1x Gigabit Ethernet port by Intel® I210-IT
10 USB 3.1 Gen1
port USB3.1 Gen 1 offers up to 5Gbps of data-throughput performance
11 COM port The software-selectable RS-232/422/485 ports. The operation
mode of COM1 and COM2 can be set in BIOS.
12 x16 PCIe slot x16 PCIe @ Gen3, 8-lanes expansion slot
13 x8 PCIe slot x8 PCIe @ Gen3, 4-lanes expansion slot
14 PCI slot 33MHz/ 32-bit 5V PCI slot
15
3-pin terminal
block (DC/ remote
on/ off control)
Compatible with DC power input from 8~35V DC allows for external
switch extension when the system is placed inside a cabinet
16 Isolated DIO The DIO port provides 8x isolated digital input and 8x isolate output
channels.
17
External 2.5” drive
tray (indicated in
red)
Two 2.5” hot-swappable drive trays for 2.5” HDD or SSD
