Neousys Technology NRU-51V+ Series User manual

Neousys Technology Inc.
NRU-51V+/ NRU-51V Series
User Manual
Revision 1.0

Table of Content
Table of Contents
Table of Contents...................................................................................................................2
Legal Information...................................................................................................................4
Contact Information...............................................................................................................5
Declaration of Conformity.....................................................................................................5
Copyright Notice....................................................................................................................6
Safety Precautions.................................................................................................................7
Battery Warning......................................................................................................................7
Service and Maintenance ......................................................................................................8
ESD Precautions....................................................................................................................8
Restricted Access Location ..................................................................................................8
About This Manual.................................................................................................................9
1Introduction
1.1 NRU-51V+ (JON8/ 16) Series Specifications ..........................................................11
1.2 NRU-51V (NX8/ 16) Series Specifications...............................................................13
1.3 Dimension of NRU-51V Series.................................................................................15
1.3.1 Front Panel View...............................................................................................15
1.3.2 Side Panel View................................................................................................15
1.3.3 Rear Panel View...............................................................................................16
1.3.4 Bottom View......................................................................................................16
1.3.5 Fan Kit Dimensions...........................................................................................17
2System Overview
2.1 NRU-51V Packing List..............................................................................................18
2.2 NRU-51V Series Front Panel....................................................................................19
2.2.1 3-pin Terminal Block for DC and Ignition Control..............................................20
2.2.2 Force Recovery Button.....................................................................................20
2.2.3 Micro SIM Slot...................................................................................................21
2.2.4 DisplayPort........................................................................................................21
2.2.5 USB3.2 Gen1 Ports ..........................................................................................22
2.2.6 CAN bus Port....................................................................................................23
2.2.7 MicroUSB Port..................................................................................................24
2.2.8 COM Port..........................................................................................................25
2.2.9 System Status LEDs.........................................................................................26
2.2.10 Power Button ....................................................................................................26
2.3 NRU-51V Series DIO Panel ......................................................................................27
2.3.1 DIO & GPS PPS Port........................................................................................28
2.3.2 FAKRA Z Connector..........................................................................................29
2.3.3 10Gb Ethernet Port...........................................................................................30
2.3.4 1Gb Ethernet Port.............................................................................................31
2.3.5 Grounding Point................................................................................................32
2.4 Internal I/O.................................................................................................................33
2.4.1 M.2 B Key 2242/ 3042/ 3052 & SIM Slot...........................................................33
2.4.2 mini-PCIe Slots for NRU-51V+..........................................................................35
2.4.3 mini-PCIe Slots for NRU-51V............................................................................37
2.4.4 DIP Switch for COM Port Configuration............................................................40
3System Installation
3.1 Disassembling the System Enclosure....................................................................42
3.2 Installing Internal Components...............................................................................43
3.2.1 M.2 B Key 2242/ 3042/ 3052 & SIM Card Installation.......................................43
3.2.2 mini-PCIe Module Installation ...........................................................................45
3.3 Fan Kit Installation ...................................................................................................47
3.4 Installing the System Enclosure .............................................................................49
3.5 Wall Mount Installation ............................................................................................50

Table of Content
3
3.6 Powering On the System.........................................................................................52
3.6.1 Powering On Using the Power Button...............................................................52
4Ignition Power Control
4.1 Principles of Ignition Power Control.......................................................................53
4.1.1 Additional Features of Ignition Power Control...................................................54
4.1.2 Wiring Ignition Signal........................................................................................55
4.1.3 Operation Modes of Ignition Power Control......................................................56
5Reflashing the NRU System
6Software Reminder

Legal Information
Legal Information
All Neousys Technology Inc. products shall be subject to the latest Standard
Warranty Policy
Neousys Technology Inc. may modify, update or upgrade the software,
firmware or any accompanying user documentation without any prior notice.
Neousys Technology Inc. will provide access to these new software, firmware
or documentation releases from download sections of our website or through
our service partners.
Before installing any software, applications or components provided by a third
party, customer should ensure that they are compatible and interoperable with
Neousys Technology Inc. product by checking in advance with Neousys
Technology Inc.. Customer is solely responsible for ensuring the compatibility
and interoperability of the third party’s products. Customer is further solely
responsible for ensuring its systems, software, and data are adequately backed
up as a precaution against possible failures, alternation, or loss.
For questions in regards to hardware/ software compatibility, customers should
contact Neousys Technology Inc. sales representative or technical support.
To the extent permitted by applicable laws, Neousys Technology Inc. shall NOT
be responsible for any interoperability or compatibility issues that may arise
when (1) products, software, or options not certified and supported; (2)
configurations not certified and supported are used; (3) parts intended for one
system is installed in another system of different make or model.

Contact Information/ Declaration of Conformity
Contact Information
Headquarters
(Taipei, Taiwan)
Neousys Technology Inc.
15F, No.868-3, Zhongzheng Rd., Zhonghe Dist., New Taipei City, 23586, Taiwan
Tel: [phone] Fax: [phone] Email, Website
Americas
(Illinois, USA)
Neousys Technology America Inc.
3384 Commercial Avenue, Northbrook, IL 60062, USA
Tel: [phone] Email, Website
China
Neousys Technology China Co., Ltd.
Room 612, Building 32, Guiping Road 680, Shanghai
Tel: [phone] Email, Website
Declaration of Conformity
FCC
This equipment has been testedand found to comply withthe limits
for a Class A digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment
in a residential area is likely to cause harmful interference in which
case the user will be required to correct the interference at own
expense.
CE
The product(s) described in this manual complies with all
applicable European Union (CE) directives if it has a CE marking.
For computer systems to remain CE compliant, only CE-compliant
parts may be used. Maintaining CE compliance also requires
proper cable and cabling techniques.

Copyright Notice
Copyright Notice
All rights reserved. This publication may not be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated
into any language or computer language, in any form or by any
means, electronic, mechanical, magnetic, optical, chemical,
manual or otherwise, without the prior written consent of Neousys
Technology, Inc.
Disclaimer
This manual is intended to be used as an informative guide only
and is subject to change without prior notice. It does not represent
commitment from Neousys Technology Inc. Neousys Technology
Inc. shall not be liable for any direct, indirect, special, incidental, or
consequential damages arising from the use of the product or
documentation, nor for any infringement on third party rights.
Patents and
Trademarks
Neousys, the Neousys logo, Expansion Cassette, MezIOTM are
registered patents and trademarks of Neousys Technology, Inc.
Windows is a registered trademark of Microsoft Corporation.
AMD, Ryzen™are registered trademarks of Advanced Micro Devices, Inc
All other names, brands, products or services are trademarks or
registered trademarks of their respective owners.

Safety Precautions
Safety Precautions
⚫Read these instructions carefully before you install, operate, or transport the
system.
⚫Install the system or DIN rail associated with, at a sturdy location
⚫Install the power socket outlet near the system where it is easily accessible
⚫Secure each system module(s) using its retaining screws
⚫Place power cords and other connection cables away from foot traffic. Do not
place items over power cords and make sure they do not rest against data
cables
⚫Shutdown, disconnect all cables from the system and ground yourself before
touching internal modules
⚫Ensure that the correct power range is being used before powering the device
⚫Should a module fail, arrange for a replacement as soon as possible to minimize
down-time
⚫By means of a power cord connected to a socket-outlet with earthing connection
⚫This product is intended to be supplied by a Listed Power Adapter or DC power
source, rated up to 5000m altitude operation. If further assistance is required,
please contact Neousys Technology
⚫If the system is not going to be used for a long time, disconnect it from mains
(power socket) to avoid transient over-voltage
Battery Warning
⚫Batteries are at risk of exploding if incorrectly installed.
⚫Do not attempt to recharge, force open, or heat the battery.
⚫Replace the battery only with the same or equivalent type
recommended by the manufacturer.

Service and Maintenance/ ESD Precautions
Service and Maintenance
⚫ONLY qualified personnel should service the system
⚫Shutdown the system, disconnect the power cord and all other connections
before servicing the system
⚫When replacing/ installing additional components (expansion card, memory
module, etc.), insert them as gently as possible while assuring proper
connector engagement
ESD Precautions
⚫Handle add-on module, motherboard by their retention screws or the module’s
frame/ heat sink. Avoid touching the PCB circuit board or add-on module
connector pins
⚫Use a grounded wrist strap and an anti-static work pad to discharge static
electricity when installing or maintaining the system
⚫Avoid dust, debris, carpets, plastic, vinyl and
8
tyrofoam in your work area.
⚫Do not remove any module or component from its anti-static bag before
installation
Restricted Access Location
The controller is intended for installation only in certain environments
where both of the following conditions apply:
⚫Access can only be gained by QUALIFIED SERVICE PERSONNEL who have
been instructed on the reasons for restrictions applied to the location and any
precautions that shall be taken
⚫Access is through the use of a TOOL, lock and key, or other means of security,
and is controlled by the authority responsible for the location

NRU-51V Series
9
About This Manual
This manual introduces and demonstrates installation procedures of Neousys
NRU-51V series systems featuring NVIDIA Jetson AGX Orin/ Xavier platform. The
manual also demonstrates the system’s general installation procedures.
Revision History
Version
Date
Description
1.0
Jan. 2024
Initial release

NRU-51V Series
10
1 Introduction
NRU-51V series is a rugged Jetson Orin™NX/ Xavier™NX computer supporting GMSL2
cameras that can act either as a sensor hub or a perception unit for ADAS, teleoperation,
autonomous mobile robots, and autonomous vehicles.
By supporting GMSL2 automotive cameras, they enable NRU-51V+ with greater vision
capability by taking advantage of advanced features such as IP67 waterproof, high dynamic
range (120dB HDR), auto white balance (AWB), and LED flicker mitigation (LFM). NRU-51V+
can obtain high quality images with minimal latency regardless of lighting conditions, from
bright sunny days to pitch-black nights. Moreover, it has a unique synchronization mechanism
capable of acquiring images from four GMSL2 cameras simultaneously within microseconds
channel-to-channel skew. It can further accept GPS PPS signal to align image data with LIDAR
or synchronize cameras on other systems.
Thanks to the great power efficiency of NVIDIA® Jetson Orin NX™NX SOM, NRU-51V+
delivers 100 TOPS inference performance in its 25W power package. Users can transfer raw
camera images through its built-in 10GBASE-T Ethernet to another GPU server for perception
processing, but also leverage its significant TOPS for real-time object or ROI detection. For
teleoperation applications, users can utilize its hardware H.264/265 video codec, to encode
video streams from four GMSL2 cameras in real-time and transmit the live video feed to a
driver at a remote location via 5G telecommunication with minimum latency.
The combination of GMSL2 interface and Jetson Orin™NX makes NRU-51V+ much more than
just a simple edge AI computer. With greater vision brought by automotive cameras plus I/O
interfaces such as 10GbE, CAN 2.0, and M.2 for 5G broadband, NRU-51V+ plays a central role
in a moving platform, as a sensor hub for ADAS, a perception unit for AGV/ AMR, or a
teleoperation controller for off-highway vehicles.

NRU-51V Series
11
1.1 NRU-51V+ (JON8/ 16) Series Specifications
System Core
Processor
NVIDIA®Jetson Orin™NX system-on-module (SOM), comprising NVIDIA®Ampere
GPU and ARM Cortex CPU
Memory
NRU-51V+ (JON8) 8GB LPDDR5 @ 3200 MHz on SOM
NRU-51+ (JON16) 16GB LPDDR5 @ 3200 MHz on SOM
eMMC
Not applicable
Bundled JetPack
JetPack 5.1.1
Panel I/O Interface
GMSL camera
4x GMSL2 FAKRA Z connectors, supporting 4x 1920 x 1080 @ 30 FPS camera input
Ethernet port
1x 10GBASE-T 10GbE port with screw-lock
1x 1GBASE-T 1GbE port with screw-lock
USB
2x USB3.2 Gen1 ports (total 5 Gbps shared with M.2 B key)
1x micro USB (OTG only)
Video Port
1x DisplayPort, supporting 3840 x 2160 at 60Hz
Serial Port
1x hardware configurable RS-232/422/485 port
CAN bus
1x isolated CAN bus 2.0 port
Isolated DIO
1x GPS PPS input, 3-CH isolated DI and 4-CH isolated DO
Ground Terminal
1x M4 ground terminal for chassis ESD shielding
Internal I/O Interface
Mini PCI Express
1x full-size mini PCI Express socket (PCIe + USB 2.0) for WiFi, NVMe storage
1x full-size mini PCI Express socket (USB 2.0) for GNSS, V2X, or CAN modules
M.2
1x 3042/3052 M.2 B key (USB3.2 Gen 1 + USB 2.0) for 4G/5G module with dual SIM
support (1x front-accessible, 1x internal)
Power Supply
DC Input
1x 3-pin pluggable terminal block for 8V to 35V DC input and ignition power control (V+/
GND/ IGN)

NRU-51V Series
12
Mechanical
Dimension
173 mm (W) x 144 mm (D) x 60 mm (H)
Weight
1.4 kg
Mounting
Wall-mount bracket (optional)
Environmental
Operating
Temperature
-25°C to 60°C fanless operation (15W TDP mode) *
-25°C to 70°C fanless operation (15W TDP mode, without 10GbE transmission) *
-25°C to 70°C with optional fan kit (15W TDP mode) *
Storage
Temperature
-40°C to 85°C
Humidity
10% to 90%, non-condensing
Vibration
Operating, MIL-STD-810H, Method 514.8, Category 4
Shock
Operating, MIL-STD-810H, Method 516.8, Procedure I
EMC
CE/FCC Class A, according to EN 55032 & EN 55035
* For sub-zero and over 60°C operating temperature, a wide temperature Solid State Disk (SSD)
is required.

NRU-51V Series
13
1.2 NRU-51V (NX8/ 16) Series Specifications
System Core
Processor
NVIDIA®Jetson Orin™NX system-on-module (SOM), comprising NVIDIA®Volta GPU
and Carmel CPU
Memory
Xavier NX 8GB LPDDR4x @ 1600 MHz on SOM
Xavier NX 16GB LPDDR4x @ 1866 MHz on SOM
eMMC
16GB MMC 5.1 on SoM
Bundled JetPack
JetPack 4.6.1
Panel I/O Interface
Ethernet port
4x Gigabit ports with screw-lock, share 1 Gbps total bandwidth
PoE Capability
In compliant with IEEE 802.3bt PoE++ Type 3 and Type 4 PSE, maximum 90W output
on single PoE++ port compatible with 802.3at (PoE+) and 802.3af (PoE) PD
USB
2x USB3.2 Gen1 ports (total 5 Gbps shared with M.2 B key)
Video Port
1x DisplayPort, supporting 3840x2160 at 60Hz
Serial Port
1x hardware configurable RS-232/422/485 port
CAN bus
1x isolated CAN 2.0 port
Isolated DIO
1x GPS PPS input, 3-CH isolated DI and 4-CH isolated DO
Ground Terminal
1x M4 ground terminal for chassis ESD shielding
Internal I/O Interface
Mini PCI Express
1x full-size mini PCI Express socket (PCIe + USB 2.0) for WiFi, NVMe storage
1x full-size mini PCI Express socket (USB 2.0) for GNSS, V2X, or CAN modules
M.2
1x 3042/3052 M.2 B key (USB3.2 Gen 1 + USB 2.0) for 4G/5G module with dual SIM
support (1x front-accessible, 1x internal)
Power Supply
DC Input
1x 3-pin pluggable terminal block for 8V to 35V DC input and ignition power control (V+/
GND/ IGN)

NRU-51V Series
14
Mechanical
Dimension
173 mm (W) x 144 mm (D) x 60 mm (H)
Weight
1.4 kg
Mounting
Wall-mount bracket (optional)
Environmental
Operating
Temperature
-25°C to 60°C fanless operation (15W TDP mode) *
-25°C to 70°C fanless operation (15W TDP mode, without 10GbE transmission) *
-25°C to 70°C with optional fan kit (15W TDP mode) *
Storage
Temperature
-40°C to 85°C
Humidity
10% to 90%, non-condensing
Vibration
Operating, MIL-STD-810H, Method 514.8, Category 4
Shock
Operating, MIL-STD-810H, Method 516.8, Procedure I
EMC
CE/FCC Class A, according to EN 55032 & EN 55035
* For sub-zero and over 60°C operating temperature, a wide temperature Solid State Disk (SSD)
is required.

NRU-51V Series
15
1.3 Dimension of NRU-51V Series
NOTE
NRU-51V and NRU-51V+ share the same dimensions. All measurements are in millimeters
(mm).
1.3.1 Front Panel View
1.3.2 Side Panel View

NRU-51V Series
16
1.3.3 Rear Panel View
1.3.4 Bottom View

NRU-51V Series
17
1.3.5 Fan Kit Dimensions
NOTE
Fan kit is an optional accessory.

NRU-51V Series
18
2 System Overview
Upon receiving and unpacking your NRU-51V series systems, please check immediately if the
package contains all the items listed in the following table. If any item(s) are missing or damaged,
please contact your local dealer or Neousys Technology.
2.1 NRU-51V Packing List
Item
Description
Qty
1
NRU-51V series system
(If you ordered SSD/ HDD or add-on module, please verify these items)
1
2
Accessory box, which contains
⚫3-pin power terminal block
⚫Standoff, M3-5, H6.5, L4 for M.2 3042/ 3052 B key module
⚫Screw pack
1
1
1

NRU-51V Series
19
2.2 NRU-51V Series Front Panel
The front panel of the system features rich I/O ports, it has a 3-pin terminal block for DC input,
microSD slot, DisplayPort, USB3.2 Gen1 (USB3.0), CAN bus, COM, system status LEDs and a
power button.
No.
Item
Description
1
3-pin terminal block
(DC/ ignition
control)
Compatible with DC power input from 8~35V, the terminal block is
also used for ignition signal input
2
Force recovery
button
Use for system recovery or system reflash purposes
3
MicroSD slot
Front accessible MicroSD slot is a reserved slot and is not
functional
4
Micro SIM slot
The slot is coupled with M.2 B key for LTE/ 5G NR
5
DisplayPort output
The DisplayPort is a high-resolution graphics output supporting up
to 3840 x 2160 @ 60Hz
6
USB3.2 Gen1 port
USB3.2 Gen1 port, up to 5 Gbit/s data transfer bandwidth
7
CAN bus port
Compatible with both industrial and in-vehicle applications, it
supports CAN2.0A and CAN2.0B up to 1Mbps
8
micro-USB port
The micro-USB port is reserved for system reflash purposes
9
COM port
For communicating with external devices
10
System status LED
Three system LEDs, ignition control (IGN), (OS), and power
(PWR)
11
Power button
Use this button to turn on or shutdown the system

NRU-51V Series
20
2.2.1 3-pin Terminal Block for DC and Ignition Control
The system allows an 8 to 35V DC power input from via a 3-pin pluggable terminal
block. The screw clamping mechanism is a reliable way to wire DC power. In
addition to DC power, this terminal block also accepts ignition signal input (IGN).
WARNING
Please make sure the voltage of DC power is correct before you connect it to the system.
Supplying a voltage over 35V will damage the system.
2.2.2 Force Recovery Button
The force recovery button is reserved for engineering or system reflash
purposes.
