Nescafe Tama User manual

Recommended with NESCAFÉ GOLD.
Experience the full range today.*
USER MANUAL

Recommended with NESCAFÉ GOLD.
Experience the full range today.*
www.nescafe.co.th
We recommend using NESCAFÉ GOLD coee which is suited and tested for the NESCAFÉ GOLD BLEND Barista
system.
Fine powdered coee (for example NESCAFÉ Red Cup) is not recommended to be used in the NESCAFÉ GOLD
BLEND Barista system as it will result in blockage issues.
NESCAFÉ GOLD
BLEND
A premium blend of Arabica
beans that are golden roasted
to perfection. Delivers a smooth
cup with juicy aromas.
*All NESCAFÉ GOLD products are suitable for use and have been tested for the NESCAFÉ GOLD BLEND Barista system.

TABLE OF CONTENTS 
SAFETY PRECAUTIONS..................................................................................................2-3
MACHINE OVERVIEW..................................................................................................... 4-5
FIRST TIME USE & INITIAL RINSING ............................................................................. 6
REFILLING WITH COFFEE .................................................................................................7
PREPARING BEVERAGES.............................................................................................. 8-9
INDIVIDUAL ADJUSTMENTS TO YOUR PERSONAL TASTE ...............................10
CLEANING - OVERVIEW OF THE PARTS.................................................................... 11
RECOMMENDED WEEKLY CLEANING........................................................................ 12
CLEANING DRAWER & MIXING CHAMBER......................................................... 13-14
CLEANING DRIP TRAY, TANKS & DOSING UNIT............................................... 15-16
DESCALING.......................................................................................................................17-18
GREEN & ORANGE LIGHT SIGNALS............................................................................19
RED LIGHT SIGNALS.................................................................................................. 20-22
TROUBLESHOOTING ................................................................................................. 23-24
FREQUENTLY ASKED QUESTIONS............................................................................. 25
SPARE PARTS.......................................................................................................................26

2 of 26 3 of 26
SAFETY PRECAUTIONS 1/2
When using electrical appliances, basic safety precautions should
always be observed, including the following:
These instructions are to ensure you use this
electric product safely and prevent you and
other users from the risk of damage or hazard.
Please read and follow carefully all indicated
“Warnings” and instructions.
“Warnings”: failure to follow these warnings
may result in death or severe injury.
Warnings:
•In case of an emergency remove plug from
power socket immediately.
•Do not place hands underneath the hot water
jet or outlet during the preparation of the
beverage (danger of burning). Never leave
the appliance while making a beverage.
•Ensure electrical plugs are clean and free of
dust. It can cause an electric shock, short
circuit or fire.
•Never touch cable or plug with wet hands.
Do not unplug by pulling the cable. In case of
damage, do not use the appliance. In order
to avoid danger, arrange repairs and/or
replacement of power cable by our Hotline
only.
•Do not damage, destroy, remodel, bend, pull
or twist the plug forcedly. The plug can be
damaged and cause fire or electric shock by
placing heavy objects on it, taking it apart or
modifying it.
•Always put a cup underneath the outlets
when rinsing the machine.
Advised usage:
•Mains voltage used must be the same as the
details on the rating plate. Insert the plug in
a socket which is properly wired. When using
an extension cable, do not put many loads
in one outlet. It can result in fire caused by
abnormal heat. In the event that the plug
and cable get hot, stop using the machine
immediately (do not use the machine abroad).
•The manufacturer is not liable for damage
caused by improper use of the machine or
failure to comply with the instructions of this
manual. Such damages are also not covered
by the warranty.
•Children should be supervised to ensure that
they do not play with the appliance.
•This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities,
or lack of experience and knowledge,
unless they have been given supervision or
instruction concerning use of the appliance
by a person responsible for their safety.
•This appliance is intended to be used in
household and similar applications such as:
- Staff kitchen areas in shops, offices and
other working environments;
- Farm houses;
- By clients in hotels, motels and other
residential type environments;
- Bed and breakfast type environments.
•Always use the appliance on a flat, stable, heat
resistant surface away from sources of heat
or water splashes. Do not place cable close
to heat, sharp edges, etc. Do not allow cable
to dangle (risk of tripping up).

3 of 26
SAFETY PRECAUTIONS 2/2
•Do not use the machine near fire or place it
on hot surfaces (e.g. on top of electric hot
plate). It can cause a fire.
•Do not put a load on the machine. When in
use do not squeeze the machine in between
two shelves nor place it in a cabinet. This
could lead to damage.
•Do not use the machine if it is not operating
perfectly or if there is evidence of damage. In
such cases inform our Hotline.
•Unplug the cable when the machine is not in
use to avoid the risk of injury, burn, electric
shock, electric leak or fire caused by dielectric
degradation.
•Do not insert any foreign object in the mixing
chamber.
•Do not put anything (hot water, milk, alcohol,
etc) other than potable water in the water
tank. It can block or clog the inside of the
machine and cause failure. We recommend
the usage of soft water.
•Do not put too much water in the water tank
as it will spill over the power connection to
the machine. The water tank must be filled
when detached from the machine.
•Do not leave water in the water tank when
the machine is not used over a long period of
time. The water can become contaminated.
Use fresh water every time you use the
machine.
•Clean machine periodically according to
instructions in chapter “CLEANING”.
•When cleaning the machine, unplug the
machine and let it cool down. Do not clean
the machine while it is still hot. You can burn
yourself.
•Do not wash the plug or the cable with water
nor leave them in liquid, such as cleanser. It
can cause a failure.
•The appliance must not be immersed in water.
•The machine’s cover is equipped with a
permanent magnet. Avoid placing appliances
and objects that can be damaged by
magnetism close to cover, e. g. credit cards,
USB drives and other data devices, video
tapes, television and computer monitors with
picture tubes, mechanical clocks, hearing
aids and loud speakers.
•Patients with pacemakers or defibrillators:
Do not approach the cover directly over the
pacemaker or defibrillator.
Further instructions:
•Drawer can only be inserted when the mixing
chamber is inserted and locked.
•In some situations the machine requires a
rinsing cycle. Before operating again, put a
cup underneath the outlets.
We recommend using NESCAFÉ GOLD
coffee which is suited and tested for the
NESCAFÉ GOLD BLEND Barista system.
Agglomerated soluble spray dried coffee
powder (for instance NESCAFÉ Red Cup),
roast and ground coffee, are not designed for
use in this coffee machine. Upon use of those
coffee types, the system will be blocked or
damaged.

4 of 26 5 of 26
1
2
1
2
MACHINE OVERVIEW 1/2
Milk
measuring cup
5 °C - 35 °C
~3.4 kg
A = 178 mm
B = 319 mm
C = 285 mm
A
C
B
max. 15 bar 1 L
220-240 V 50-60 Hz 1500 W
A
C
B
12
Top coverWater tank
Drip tray
Water tank
connection part
(Do not touch!)
Use drip tray to place your cups for coee prepara-
tion. Remove drip tray when using a big mug.

5 of 26
NESCAFÉ
container
Dosing unit
High velocity
hot water jet
Drawer
Cap
MACHINE OVERVIEW 2/2
For cleaning pull down on
the lock handle and remove
mixing chamber
see page 13
5 °C - 35 °C
~3.4 kg
A = 178 mm
B = 319 mm
C = 285 mm
A
C
B
max. 15 bar 1 L
220-240 V 50-60 Hz 1500 W
A
C
B
Coee box User interface
Menu icons
see page 8
Power button
(ON/OFF)
Drawer & Inner parts
Rinsing light
Cleaning light
No water
indicator light

7 of 266 of 26 7 of 26
FIRST TIME USE AND INITIAL RINSING
Rinsing starts.
Wait until it stops.
6
6
After rinsing is completed, all icons
will turn steady green. Machine is
now ready for use.
6
7
Switch machine on. Power button
starts blinking green while machine is
heating up for approx. 25 seconds.
Power button and Espresso icon light
steady green.
Touch Espresso icon.
6
46 5
~25 sec
ON
Plug the machine only into mains
voltage of 220-240 V / 50-60 Hz.
Remove the water tank.
Put drinking water in the tank.
Never put any liquid other than
drinking water in the tank!
6
16 2
1
2
Re-attach the water tank to the main
body. Place a container with a capaci-
ty of at least 250 ml under the coee
outlet.
6
3
6
i
Before using the machine for the
first time:
• Initial rinse must be done.
• Perform a rinse with water tank
filled to maximum level (ap-
prox. 1 L). Preferably use soft
water.
REFILLING WITH COFFEE
6
i
For light cleaning or if machine
is left unused for more than 2
days, please
• Empty, rinse, and replenish the
water tank
• Touch and hold the Lungo
icon THEN the power button
simultaneously for 5 seconds
• Go to for initial rinse.

7 of 267 of 26
FIRST TIME USE AND INITIAL RINSING REFILLING WITH COFFEE
Place coee box as shown and
remove cap.
Remove coee box.
7
2
12
Press the top cover and open it.
7
17 3
Fill coee box with suitable coee
(see indication below).
7
4
Close top cover.
7
7
Re-attach coee box cap. Insert coee box back to machine. The
logo faces forwards. If you have
diculty to insert back coee box,
please refer to section TROUBLE-
SHOOTING on page 24.
7
57 6
Click!
Click!
7
i
Coee powder is adversely aected by high temperatures and humidity. Please store it in a sealed
container in a cool and dry location. Also, the coee powder in the coee tank should be used in
good time, preferably within one month.
We recommend using NESCAFÉ GOLD coee which is
suited and tested for the NESCAFÉ GOLD BLEND Barista
system. Alternatively, other freeze-dried coee options can
also be used.
•Maximum filling volume for coee tank: 150 g
Fine powdered coee is not recommended to be used in
the NESCAFÉ GOLD BLEND Barista system as it will result
in blockage issues.

8 of 26 9 of 26
PREPARING BEVERAGES 1/2
Latte Macchiato
Suggested cup size: 300 ml
Power button (ON/OFF)
Menu icons
Espresso
Suggested cup size: 100 ml
Hot water function
for cup preheating
Lungo
Suggested cup size: 200 ml
Americano
Suggested cup size: 250 ml
Cappuccino
Suggested cup size: 300 ml
Touch the desired menu icon.
8
2
When selected menu icon stops
flashing your coee is ready. All
lights are steady green. Enjoy your
coee. CAUTION! Your coee will
be hot!
8
4
Place a cup. Remove drip tray when
using a big mug.
8
1
The selected menu icon flashes. The ex-
traction starts and stops automatically.
To stop the extraction partway through,
touch selected menu icon again and
wait until light stops flashing. Neverthe-
less some coee will continue to flow
as long as the icon is flashing.
8
3
Black coee options
Espresso
Lungo
Americano
To heat up the cup before preparing
coee touch Cappuccino and Ameri-
cano icon simultaneously.
CAUTION! Hot water will flow out!
Afterwards throw away water and
continue with step 1.
8
i

9 of 26
MILK
PREPARING BEVERAGES 1/2 PREPARING BEVERAGES 2/2
Pour milk* into the supplied measur-
ing cup:
- Latte Macchiato: 60 ml
- Cappuccino: 50 ml
9
1
Pour milk into the cup.
9
2
The selected menu icon starts flash-
ing.
Touch the desired menu icon.
9
49 5
Place a cup. Remove drip tray when
using a Latte Macchiato glass.
9
3
When selected menu icon stops
flashing your coee is ready. All
lights are steady green. Enjoy your
coee. CAUTION! Your coee will
be hot!
9
7
Hot water/coee extraction starts and
stops automatically.
To stop the extraction partway through,
touch selected menu icon again and
wait until light stops flashing. Neverthe-
less some coee will continue to flow
as long as the icon is flashing.
9
6
Milk coee options
Latte Macchiato
Cappuccino
To heat up the cup before preparing
coee touch Cappuccino and Ameri-
cano icon simultaneously.
CAUTION! Hot water will flow out!
Afterwards throw away water and
continue with step 1.
9
i
* NESCAFÉ recommends to use milk
with at least 3% fat.

11 of 2610 of 26 11 of 26
INDIVIDUAL ADJUSTMENTS TO YOUR PERSONAL TASTE
 
When the selected menu icon starts
flashing green you can adjust the
amount of hot water.
10
3
The power button light changes to
orange. The selected menu icon lights
green. Coee extraction starts.
Put a cup in place. Touch and hold the
menu icon for the beverage you wish
to adjust for 5 seconds.
+/−
When the beverage reaches the
desired amount touch the menu icon
to stop. If you do not touch machine
will stop at the maximum water
level!
10
4
10
110 2
5 sec
10
i
Resetting initial beverage recipes
① Connect the power plug.
② Check that the power is OFF.
③ Touch and hold the Cappuccino
icon THEN the power button
simultaneously.
④ Release the icons when all the
icon lights start flashing fast in
green.
⑤ Machine is now back to factory
settings.
⑥ Initial rinsing must be performed
(see page 6).
• After changing the setting, the new
setting remains the same until you
modify it again (even if the machine is
unplugged).
• When a small cup is used, the
coee may overflow the cup if you
set the amount of hot water too high.
• To adjust to a new amount of
hot water, repeat the above
procedure (the current setting
will be overwritten).
Note: For Latte Macchiato &
Cappuccino, cup parameter
can not be adjusted manually.
To adjust volume, please follow procedure below:
You can adjust the strength of the coee by changing the amount of hot water:
Espresso
type coee Latte
Macchiato
Cappuccino
Lungo
type coee
Americano
type coee
Minimum Standard Maximum
~40 ml
~70 ml
~100 ml
~60 ml
~140 ml
~200 ml
~120 ml
~210 ml
~300 ml

11 of 2611 of 26
INDIVIDUAL ADJUSTMENTS TO YOUR PERSONAL TASTE CLEANING - OVERVIEW OF THE PARTS
Cleaning is to be performed when refilling coee (see page 12). Regular maintenance of
the machine ensures a better in-cup quality and a longer machine lifetime.
Rinsing OK - recommended every week Do not rinse!
Water tank connection part
Water tank Coee box cap
Coee box
If you touch the protrusion
on the bottom of tank when
it has water in it, the water
may spill from the tank.
Do not touch the protrusion
(connection part) on the
bottom of the water tank.
CAUTION!
Drawer
Drip grid
Drip tray
Slider cover
(green) Mixing
chamber mesh
Mixing
chamber
Lower disk
No. 2
Dosing unit
housing
No. 3
Upper disk
No. 1
Rinsing OK - recommended every week

12 of 26 13 of 26
CLEANING DRAWER & MIXING CHAMBER 1/2RECOMMENDED WEEKLY CLEANING
Remove coee box.
12
3
12
Push on the top cover and open it.
12
2
Check if coee box is empty:
If empty, please complete cleaning
procedure on pages 15-16 for deep
cleaning of dosing unit and coee box.
If not go ahead with recommended
weekly cleaning procedure.
12
1
Turn over coee box.
12
4
Turn lower disk No. 2 in the direction
of the “OPEN” arrow until you hear a
“Click”.
Remove lower disk No. 2, clean it with
hot water and dry it completely.
12
512 6
Clean both openings of the dosing
unit housing with a dry cloth.
12 12
7 9
Before reassembling make sure
that all parts are completely dry.
Place lower disk No. 2 back on
dosing unit housing. Turn it in the
direction of the “CLOSE” arrow
until you hear a “Click”.
12
8
Click!
Click!
Lower disk
No. 2
Insert coee box back to machine.
The logo faces forwards.
Click!
CAUTION! Do not put any of the parts into the dishwasher!

13 of 26
CLEANING DRAWER & MIXING CHAMBER 1/2
Switch machine o.
Disconnect plug from socket.
Pull out the drawer.
13
113 2
Press down the blue lock handle.
13
3
Press the slider cover inwards from
the both sides and pull it out. Some-
times the residue hardens, making it
a little bit dicult to remove.
Release the lock under the mixing
chamber.
13
513 6
Check that the lock handle is down.
Remove the mixing chamber.
13
4
OFF!
Rinse drawer and slider cover under
hot water. Wipe with a soft damp cloth.
Soak mixing chamber in hot water
for at least 2 minutes. If coee is still
adhered, scrape it o gently.
13
713 8
Dry away moisture.
13
9
min.
2 minutes
CAUTION! Do not put any of the parts into the dishwasher!
(Weekly cleaning recommended)

14 of 26 15 of 26
CLEANING DRAWER & MIXING CHAMBER 2/2
Push down lever until you hear a
“Click”.
14
11
In case mesh has been removed:
Check orientation of the mesh (the
mesh has a top and a bottom side).
14
12
Align arrows on slider cover and
main body. Press the slider cover in
until you hear a “Click”.
Make sure that step 11 has been
correctly followed. Push mixing
chamber into the main body. Ensure
it is fully inserted.
14
14 14 15
Pull up blue handle to lock mixing
chamber.
Slide drawer in until you feel the
“Click”.
14
16 14 17
Check the holes inside the mixing
chamber: If the holes are blocked with
coee, rinse again with hot water.
14
10
Push mesh into original position.
Ensure it is fully inserted.
Check
inside! To p
Bottom
14
13
Click!
Click!
Click!
Click!
CLEANING DRIP TRAY, TANKS & DOSING UNIT 1/2
CAUTION! Do not put any of the parts into the dishwasher!
(Weekly cleaning recommended)

14 of 26 15 of 26
Switch machine o.
Disconnect plug from socket.
Rinse drip tray with hot water and
clean it with a brush.
CLEANING DRIP TRAY, TANKS & DOSING UNIT 1/2
15
115 2
Rinse and clean water tank. After-
wards refill with fresh, potable water
and insert it to machine.
15
3
Turn over the dosing unit and re-
move the upper disk No. 1.
Using the thumbs turn in the direc-
tion of the “OPEN” arrow until you
hear a “Click”.
15
515 6
Put your fingers into the openings
and remove lower disk No. 2.
Check whether all three parts are
there.
15
715 8
Lower disk
No. 2
Upper disk
No. 1
Dosing unit housing
No. 3
Make sure that coee box is empty.
Turn the dosing unit clockwise and
remove it from the coee box.
15
4
No. 3
No. 1
Wipe away the dirt with a soft damp
cloth. Soak disk No. 1 and disk No. 2 in
hot water.
15
9
OFF!
Click!
CAUTION! Do not put any of the parts into the dishwasher!
(At least monthly cleaning recommended)

16 of 26 17 of 26
Put coee box back on dosing unit.
16
15
With the dosing unit held steady
at the bottom, close by turning the
coee box clockwise until it stops.
16
16
Remove coee box cap.
16
10
Clean cap with a soft damp cloth.
Do not clean the coee box with
flowing water!
16
11
Turn over the dosing unit housing
and align the triangular portions on
the dosing unit housing No. 3 and
upper disk No. 1.
16
14
No. 1
No. 3
CLEANING DRIP TRAY, TANKS & DOSING UNIT 2/2
Rinse and dry parts carefully before
reassembling! Ideally let it dry for
one night. Do not use a hair dryer -
deformation may result!
16
i
Align marks ▼ No. 3 with No. 2 and
fit together. The label “No. 3” gets
visible.
Using the thumbs of both hands turn
the lower disk No. 2 in the direction
of the “CLOSE” arrow until you hear
a “Click”.
No.3
16
12 16 13
No.2
No.3 Click!
CAUTION! Do not put any of the parts into the dishwasher!
(At least monthly cleaning recommended)

17 of 26
DESCALING 1/2
17
117 3
Dissolve 125 ml of descaling agent* per
500 ml of cold water.
Do not use hot water!
*Durgol® recommended to use for descaling agent
Pour descaling solution into water
tank. Insert water tank to machine.
125 mL
Remove drip tray. Place a container with
a capacity of at least 500 ml under the
coee outlet. Take water tank out.
17
2
min.
500 ml
17
417
6
17
5
Espresso icon and power button ligh-
ts up steady green. Touch Espresso
icon to start descaling process (icon
starts flashing green).
Descaling solution is discharged:
First from high velocity hot water jet,
then from coee outlet. Throw away
water from container.
To enter the descaling mode, start
with machine o, then press on
Espresso icon & power button for
7seconds. All menu icons start flash-
ing. Release the icons.
7 sec
If you don’t descale your machine according to the following recommendations issues and
even break down could happen. We recommend to descale your machine depending on water
hardness and consumption but at least twice a year (see table below).
Water hardness Descaling after ... cups
Hard water 300 ppm 250 cups
Medium 180 ppm 500 cups
Soft 80 ppm 750 cups
●Read instructions and safety infor-
mation on packaging of descaling
agent.
●Do not wash surface of machine
using descaling agent.

19 of 2618 of 26 19 of 26
DESCALING 2/2
18
718
9
Wait 5 minutes to let the descaling
solution work. Touch Espresso icon
to start again descaling process
(icon starts flashing green).
Wait another 5 minutes to let descal-
ing solution work. Throw away water
from container. Carefully rinse water
tank.
5 min 5 min
18
8
Descaling solution is discharged:
First from high velocity hot water jet,
then from coee outlet.
18
10
18
15
min.
500ml
Place a container with a capacity of at
least 500 ml under the coee outlet.
Put drinking water in the tank. Insert
water tank to machine.
Throw away water from container.
Carefully rinse water tank. Fill up
water tank with drinking water. Insert
water tank back to machine.
18
11
Touch Espresso icon to start rinsing
process (icon starts flashing green).
18
12
Water is first discharged from the
high velocity hot water jet and then
from the coee outlet. Throw away
water from container.
18
13
When Espresso icon stops flashing,
touch Espresso icon again to start
second rinsing cycle (icon starts
flashing green).
18
14
Water is first discharged from the
high velocity hot water jet and then
from the coee outlet.
iTo quit the descaling mode, turn o the machine.
