Net Optics 10 GigaBit Media Converter Tap User manual

Installation Guide for
10 GigaBit Media Converter
Doc PUBFMCXFPU, Rev. 3, 01/07

10 GigaBit Media Converter
Contents
Introduction.....................................................1
KeyFeatures....................................................2
AboutthisGuide.................................................3
UnpackingandInspection..........................................3
ProductDiagrams................................................4
InstallingtheMediaConverter......................................5
InstallingaConversionKit.........................................5
10 GigaBit Ethernet Connection Distances . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Specications ...................................................7
Limitations on Warranty and Liability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

10 GigaBit Media Converter
PLEASE READ THESE LEGAL NOTICES CAREFULLY.
By using a Net Optics 10 GigaBit Media Converter you agree to the terms and conditions of usage set
forth by Net Optics, Inc.
No licenses, express or implied, are granted with respect to any of the technology described in this
manual. Net Optics retains all intellectual property rights associated with the technology described in
this manual. This manual is intended to assist application in installing Net Optics products into your
network.
Trademarks and Copyrights
© 2010 by Net Optics, Inc. Net Optics® is a registered trademark of Net Optics, Inc. Additional com-
pany and product names may be trademarks or registered trademarks of the individual companies and
are respectfully acknowledged.
Additional Information
Net Optics, Inc. reserves the right to make changes in specications and other information contained
in this document without prior notice. Every effort has been made to ensure that the information in this
document is accurate.

10 GigaBit Media Converter
1
Introduction
Net Optics 10 GigaBit Converters are optimized, high-performance media
converters for connecting dissimilar 10 GigaBit devices and links. Deploy these
bidirectional media converters individually to connect SR and LR ber devices,
or in pairs at each end of long-distance ber links. These Converters are the per-
fect solution for dispersed networks where media conversion is required between
multimode segments separated by long distances.
Fast and Versatile
The 10 GigaBit Converters support seamless media conversion at 10 Gbps over
link distances up to 65 meters with 50/125 multimode SR ber and up to 10
kilometers with singlemode LR ber. These Converters feature XFP module
connectors for quick reconguration and redeployment.
Long Link Reliability
To control jitter over long optical links, the Converter features Clock and Data
Recovery (CDR). CDR ensures that the overall jitter budget is not exceeded
when deploying converter pairs with long ber links.
Simple and Reliable
Media conversion is a snap since all network and monitoring cables neces-
sary for plug-and-play deployment are included with the Tap. For extra uptime
protection, Net Optics Converters offer redundant power connections. Should the
primary power source fail, the Converter automatically switches to the backup
power source with no trafc interruption.

10 GigaBit Media Converter
2
Key Features
Secure Technology
• Optimized and tested for 10 GigaBit ber networks
• Provides transparent conversion at 10 Gbps without data stream interference
or introducing a point of failure
• Clock and Data Recovery (CDR) control overall jitter when deploying con-
verter pairs
• Redundant power ensures link uptime
• Compatible with all LR singlemode ber and SR multimode ber
• Fully IEEE 802.3ae compliant
• Fully RoHS compliant
Ease of Use
• LED indicators show link status and redundant power
• XFP connectors (ordered separately) support easy reconguration and
redeployment
• Optional 19-inch rack frame holds three Converters
• Tested and compatible with all major manufacturers’ monitoring devices, in-
cluding protocol analyzers, probes, and intrusion detection/prevention systems
Support
• Net Optics offers free technical support throughout the lifetime of your
purchase. Our technical support team is available from 8 am to 5 pm Pa-
cic Time, Monday through Friday at [phone] and via email at
[email protected]. FAQs are also available on Net Optics website at
www.netoptics.com.

10 GigaBit Media Converter
3
About this Guide
This guide covers the installation and use of the following models:
Part Number Description
FMC-XFP 10 GigaBit Converter
Unpacking and Inspection
Unpack the 10 GigaBit Media Converter, verify that you have all components by
checking the Packing List against goods received.
The 10 GigaBit Media Converter ships with the following:
• 2 Power supplies
• 2 Network cables
• 1 Installation Guide
You may have also ordered a panel for rack mounting the Converter and an
extended warranty. If any part is missing or damaged, immediately contact Net
Optics Customer Service at 1 408.737.7777.
If you need to change the interface on the Converter, Net Optics offers conver-
sion kits that include the XFP and corresponding cable.
The conversion kits are:
XFPKT-50SR 10GBase-SR XFP Conversion Kit 50µm
XFPKT-SR 10GBase-SR XFP Conversion Kit
XFPKT-LR 10GBase-LR XFP Conversion Kit
XFP kits are ordered separately. For more information, contact Net Optics Cus-
tomer Service, 1 408.737.777.

10 GigaBit Media Converter
4
1
2
B
A
®
10 GigaBit Converter
www.netoptics.com
AB
LINK
SR XFP Connector LR XFP Connector
Product Diagram
Figure 1: FMC-LR/50SR Front Panel

10 GigaBit Media Converter
5
Installing the Media Converter
The Converter has two LC XFP connectors labeled according to media type. If
you have any doubt, you can verify connector type by removing the XFP and
reading the label on the bottom of the XFP.
Warning: The intended use of this product is in systems that contain lasers.
DANGER: Invisible Laser Radiation when open or when operating with ber
disconnected. AVOID DIRECT EXPOSURE TO THE BEAM. Never operate
unit with a broken ber or with a ber connector disconnected.
To install the Converter:
1. If you are rack mounting the Converter, install the panel in the rack with the
four thumbscrews provided.
2. Insert the Converter into one of the available slots and secure it to the panel by
tightening the thumbscrews.
3. Using the supplied cables, connect the Converter ports to the corresponding
devices.
4. Connect the redundant power supplies to separate power sources and then to
the converter.
5. Secure the DC power connectors with the connector clips.
6. Check the Power LEDs to verify that the Converter is receiving power.
7. Check the Link LEDs to verify that the link has been established.
Installing a Conversion Kit
The conversion kits include the XFP and matching cable. Remove power from
the Converter before installing the conversion kit.
To change the XFP:
1. Remove the cable and lower the wire clip to release the old XFP.
2. With the clip in the lowered position, pull gently on the clip to free the XFP.
3. Insert the new XFP until you hear it click into place.
4. Connect the approriate cable and check the Link LEDs.

10 GigaBit Media Converter
6
10 GigaBit Ethernet Connection Distances
10GB-SR (850 nm laser)
Fiber Core
Diameter Type
Fiber
Bandwidth
Mhz/km
Distance
62.5 µm Multimode 160 Mhz/km 26 m
62.5 µm Multimode 200 Mhz/km 33 m
50.0 µm Multimode 400 Mhz/km 66 m
50.0 µm Multimode 500 Mhz/km 83 m
50.0 µm Multimode 2007 Mhz/km 300 m
10GB-LR (1310 nm laser)
Fiber Core
Diameter Type
Fiber
Bandwidth
Mhz/km
Distance
8.5 µm Singlemode n/a up to 10 Km

10 GigaBit Media Converter
7
Specications
Environmental
Operating Temperature: 0˚C to 40˚C
Storage Temperature: -10˚C to 70˚C
Relative Humidity: 10% min, 95% max, non-condensing
Mechanical
Dimensions: 1.0” high x 5.3” deep x 2.9” wide
Power
Power Supply: Input: 100-240 VAC, 0.6A, 50-60 Hz
(AC100-125V~30VA, 50-60 Hz, for Japan)
Output: 5V, 2A (5V, 2.4A for UK and Japan)
Certications
Fully RoHS compliant
Optical Interface
Laser Class
Class I, eye-safe, laser emitter type. These Class I Lasers conform to the
applicable requirements per US 21 CFR (J) and EN 60825-1, also UL 1950
applications.
SR Fiber Optic Interface:
Fiber Type: Multimode Corning 50µm or 62.5µm, wavelength 850nm
Connector: XFP (ordered separately)
Optical Transmitter Wavelength: 850 nm nominal
Output Power: -7.3 dBm min, -1.0 dBm max
Optical Receiver Input Sensitivity: -7.5 dBm
LR Fiber Optic Interface:
Fiber Type: Singlemode Corning 8.5µm, wavelength 1310/1550 nm
Connector: XFP (ordered separately)
Optical Transmitter Wavelength: 1310 nm nominal
Output Power: -6.0 dB min, -.5 dB max
Optical Receiver Input Sensitivity: -10.0 dBm

10 GigaBit Media Converter
8
Connectors
FMC-XFP
(2) XFP hot-pluggable
XFP Conversion Kits (ordered separately)
XFPKT-50SR 10GBase-SR XFP Conversion Kit 50µm
XFPKT-SR 10GBase-SR XFP Conversion Kit
XFPKT-LR 10GBase-LR XFP Conversion Kit

10 GigaBit Media Converter
9
Limitations on Warranty and Liability
Net Optics offers a limited warranty for all its products. IN NO EVENT SHALL NET OPTICS, INC.
BE LIABLE FOR ANY DAMAGES INCURRED BY THE USE OF THE PRODUCTS (INCLUDING
BOTH HARDWARE AND SOFTWARE) DESCRIBED IN THIS MANUAL, OR BY ANY DEFECT
OR INACCURACY IN THIS MANUAL ITSELF. THIS INCLUDES BUT IS NOT LIMITED TO
LOST PROFITS, LOST SAVINGS, AND ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES
ARISING FROM THE USE OR INABILITY TO USE THIS PRODUCT, even if Net Optics has been
advised of the possibility of such damages. Some states do not allow the exclusion or limitation of
implied warranties or liability for incidental or consequential damages, so the above limitation or exclu-
sion may not apply to you.
Net Optics, Inc. warrants this GigaBit Media Converter to be in good working order for a period of ONE
YEAR from the date of purchase from Net Optics or an authorized Net Optics reseller.
Should the unit fail anytime during the said ONE YEAR period, Net Optics will, at its discretion, repair
or replace the product. This warranty is limited to defects in workmanship and materials and does not
cover damage from accident, disaster, misuse, abuse or unauthorized modications.
If you have a problem and require service, please call the number listed at the end of this section and
speak with our technical service personnel. They may provide you with an RMA number, which must
accompany any returned product. Return the product in its original shipping container (or equivalent)
insured and with proof of purchase.
THE WARRANTY AND REMEDIES SET FORTH ABOVE ARE EXCLUSIVE AND IN LIEU OF
ALL OTHERS, EXPRESS OR IMPLIED. No Net Optics reseller, agent, or employee is authorized to
make any modication, extension, or addition to this warranty.
Net Optics is always open to any comments or suggestions you may have about its products and/or this
manual.
Send correspondence to
Net Optics, Inc.
5303 Betsy Ross Drive
Santa Clara, CA 95054 USA
Telephone: [phone]
Fax: [phone]
Email: [email protected]
Internet: www.netoptics.com
All Rights Reserved. Printed in the U.S.A. No part of this publication may be reproduced, transmitted,
transcribed, stored in a retrieval system, or translated into any language or computer language, in any
form, by any means, without prior written consent of Net Optics, Inc., with the following exceptions:
Any person is authorized to store documentation on a single computer for personal use only and that the
documentation contains Net Optics’ copyright notice.
