NetCommWireless
1.2Gbps Powerline Kit
with Gigabit Port
QUICK START GUIDE
NP1201
NetComm
Wireless

THANKS FOR PURCHASING
NETCOMM WIRELESS
This quick start guide is designed to get you up and running quickly
with your new device. More advanced set up instructions can be found
in the user guide which can be downloaded from
www.netcommwireless.com

SETTING UP YOUR
POWERLINE ADAPTERS
The powerline adapters you have purchased are paired and ready
for use out of the box. All that is required is to correctly connect
them. Follow these instructions to connect them:
1. Connect one end of the supplied Ethernet cable into a LAN Ethernet
port of your modem/router.

1.2Gbps Powerline Kit with Gigabit Port - NP1201
2. Connect the other end of the cable into one of the
Powerline adapters.
3. Plug the Powerline adapter into a wall power socket near the
modem/router.
NOTE: For best performance plug your Powerline adapters directly into the wall.
Only connect to a powerboard as a last resort as this will reduce performance.

NetComm
Wireless
4. If desired, plug other electrical equipment into the Powerline
adapter’s AC pass-through socket.
5. Plug the other Powerline adapter into a wall socket near the equipment
that requires network access. Connect the other supplied Ethernet
cable from the Powerline adapter to the device that requires network
access, e.g. PC, set-top box, gaming console, or Blu-Ray player.
When the Powerline adapters are rst plugged in to the wall sockets,
they take a short time to locate and synchronise with each other. When
synchronised, the Powerline LED on both adapters turns on and they
are ready to use.

LEDS
What can the LEDs tell me?
The Powerline LED changes colour depending on the speed of your
data transfer.
LED Status Description
On
Fastest possible connection speed. Powerline
adapter is connected to the Powerline
network.
On Faster connection speed. Powerline adapter
is connected to the Powerline network.
On Fast connection speed. Powerline adatper is
connected to the Powerline network.
Off
The Powerline adapter is not connected to a
Powerline network. This could be due to there
being no network in range or the unit could
not nd another paired unit on the power line.
On An Ethernet device is connected via the
Ethernet port of the Powerline adapter.
Off No device connected to the Ethernet port of
the Powerline adapter.
On Powerline adapter is connected to a powered
wall socket.
Blinking The Powerline adapter is pairing.
Off Powerline adapter is not powered on.

BUTTONS
Reset Button
Press and hold the reset button for less than 3 seconds to factory reset
the powerline adapter. All LEDs ash once to indicate that the adapter will
perform a factory reset.
Security Button
The Security button is used to create or join a powerline network. See the
Adding another powerline adapter section for more detail.

1.2Gbps Powerline Kit with Gigabit Port - NP1201
QSG-00073 rev2
ADDING ANOTHER POWERLINE
ADAPTER
You can add additional NetComm Wireless powerline adapters to your
powerline network. Follow these instructions to add a new adapter to
an existing network:
1. Plug the new powerline adapter into a wall socket.
2. Hold down the Security button on one of the existing (paired) devices
for 2 seconds, then hold the Security button on the new powerline
adapter for 2 seconds.
3. Hold the Security button on the existing device for 2 seconds.
Both adapters will be able to communicate with each other.
