Neteon EF23-1-Fm-SC-2 Manual

Industrial Ethernet to Fiber Media Convertor
Hardware Installation Guide
Version 1.2
Updated in April, 2015
Introduction Inside the Package
Product Description
EF23 Series
Tel: [phone]
Fax: [phone]
www.atop.com.tw
P/N:89900403G
EF23 Series
10/100 Base-T(X) to 100Base-FX Media Converters
EF23G Series
1000Base-T to 1000Base-X Media Converters
Atop Technologies, Inc.
Thank you for choosing the Atop Industrial DIN-Rail Ethernet to Fiber Media
Converter. The EF23/EF23G Series provide industrial grade media conver-
sion between 10/100Base-T(X) and 100Base-FX (SC connector); and
1000Base-T and 1000BASE-X(SC connector or SFP).
This Guide covers Five product models:
EF23 Series
■EF23-1-Fm-SC-2:
Fast Ethernet 10/100Base-T(X) to 100Base-FX Media Converter with
extended operating temperature.
Include 1 10/100Mbps RJ45 and 1 100Mbps Multi-mode Optical Fiber.
■EF23-1-Fs-SC-30:
Fast Ethernet 10/100Base-T(X) to 100Base-FX Media Converter with
extended operating temperature.
Include 1 10/100Mbps RJ45 and 1 100Mbps Single-mode Optical Fiber.
EF23G Series
■EF23-1G-1Fm-SC-550M:
Gigabit Ethernet 1000Base-T to 1000Base-X Media Converter with extended
operating temperature.
Include 1 1000Mbps RJ45 and 1 1000M Multi-mode Optical Fiber.
■EF23-1G-1Fs-SC-10:
Gigabit Ethernet 1000Base-T to 1000Base-X Media Converter with extended
operating temperature.
Include 1 1000Mbps RJ45 and 1 1000Mbps Single-mode Optical Fiber.
■EF23-1G-1SFP:
Gigabit Ethernet 1000Base-T to 1000Base-X Media Converter with extended
operating temperature.
Include 1 1000Mbps RJ45 and 1 1000Mbps SFP slot.
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received; including interference
that may cause undesired operation.
■ Main Product
■ Atop EF23/EF23G industrial Ethernet Media Converter x1
■ Standard accessories
■ 3-pin Terminal Block (2ESDVM-03P) x1
Atop P/N: 50706701G
■ RJ-45 Port Plugs x1
Atop P/N: 3990012G
■ Hardware Installation Guide (Warranty card is include) x1
Atop P/N: 89900403G
Optional Accessories
■ 3-pin Terminal Block(2ESDVM-03P )
Atop P/N: 50706701G
■ Adapter : 3-pin Terminal block (5.08 mm) power adaptor,
100-240VAC input, 1.25A @ 12VDC output, US plug
Atop P/N: 70100000000027G
■ Adapter : 3-pin Terminal block (5.08 mm) power adaptor,
100-240VAC input, 1.25A @ 12VDC output, EU plug
Atop P/N: 70100000000028G
Hardware Installation
■ Electrical
Step 1: Unpack the Media Converter, check
to make sure no external damages.
Step 2: Connect the power adapter/supply (6-48VDC);
It is normal to see the PWR indicator on.
Step 3: Connect the RJ-45 port to your Ethernet device.
Step 4: Connect the fiber optical port from EF23 to
another EF23 or a switch. Make sure you
connect the cable’s Tx to Rx and Rx to Tx.
At this point, you should see the
FX_LINK/ACT LED indicator on.
Step 5: Now check to make sure your Ethernet device can access the
network.
■ Mechanical
Media Converters are equipped with a DIN-Rail bracket attached onto the
rear panel. Follow the steps below to fasten the Media Converter to the
DIN-Rail.
Step 1: Tilt the unit slightly backwards.
Step 2: Fit the unit over top the DIN-Rail.
Step 3: Push downwards and against the DIN-Rail for locking.
Step 4: Check that the unit is locked into position.
1. TX Port: 10/100 Base-T(X)
2. Green: PWR SPD LED
3. Green: TX_LINK/ACT TX_FDX/COL LED
4. Green: FX_LINK/ACT FX_FDX/COL LED
5. FX Port: 100 Base-FX (SC Connector)
EF23G Series
1. TX Port: 1000 Base-T
2. Green: ACT TX_LINK
3. Green: PWR FX_FDX/COL LED
4. FX Port: 1000 Base-X
(SC Connector or SFP Solt)
EF23 Series DIP Switch Definition
* SPEED is only for TX
* LFP: Link Fault Pass-through
* This table only applies to EF23 series
WARNING:
Disconnect the power and allow to cool 5 minutes before touching.
Never install or work on electrical or cabling during periods of
lighting activity. Never connect or disconnect power when hazard-
ous gases are present.
Caution:
CLASS 1 LASER PRODUCT. Do not stare into the laser! DIP Switch
1
2
3
4
5
Mode
TX_DUPLEX_MODE
FX_DUPLEX_MODE
SPEED_MODE
LFP
Auto Negotiation
OFF
Full(default)
Full(default)
100M(default)
Disable(default)
Enable(default)
ON
Half
Half
10M
Enable
Disable

3-pin Terminal Block for power input
Mechanical dimensions(unit=mm)
Front view-EF23 Series
Back view Side view and Panel Mounting View
Front view-EF23G Series
Top view-EF23 Series Top view-EF23G Series
─
7 6 5 4 3 2 1 6 5 4 3 2 1
EF23 Series EF23G Series
Pin Assignment of Network Connections
10/100/1000Base-T(X) Ethernet Port Connection
10/100BASE-T(X)
Pin
Signal
1
Tx+
2
Tx-
3
Rx+
4
─
5
─
6
Rx-
7
─
8
─
1. Grounding screw
2. LOCK
3. Frame Ground
4. V-
5. V+
6. LOCK
7. DIP Switch
1. Grounding screw
2. LOCK
3. Frame Ground
4. V-
5. V+
6. LOCK
LED
PWR
SPEED (SPD)
TX_LINK\ACT
TX_FDX\COL
FX_LINK\ACT
FX_FDX\COL
Color
Green
Green
Green
Green
Green
Green
State
On
Off
On
Off
On
Off
Blinking
On
Off
Blinking
On
Off
Blinking
On
Off
Blinking
Description
System is powered on
System is not powered on
TX port is running at 100Mbps
TX port is running at 10Mbps
TX port is connected
TX port is disconnected
Data is transmitting on this port
TX port is transmitting in full duplex mode
TX port is transmitting in half duplex mode
TX port is transmitting in half duplex mode
and collision has occurred
FX port is connected
FX port is disconnected
Data is transmitting on this port
FX port is transmitting in full duplex mode
FX port is transmitting in half duplex mode
FX port is transmitting in half duplex mode
and collision has occurred
1000BASE-T
Pin
Signal
1
BI_DA+
2
BI_DA-
3
BI_DB+
4
BI_DC+
5
BI_DC-
6
BI_DB-
7
BI_DD+
8
DI_DD-
EF23G Series LED Indicators
LED
ACT
TX_LINK\ACT
PWR
FX_LINK\ACT
Color
Green
Green
Green
Green
State
Blinking
On
Off
Blinking
On
Off
On
Off
Blinking
Description
Data is transmitting on both TX and FX ports
TX port is connected
TX port is disconnected
Data is transmitting on this port
System is powered on
System is not powered on
FX port is connected
FX port is disconnected
FX port is transmitting in half duplex mode
and collision has occurred
