Introduction
Checklist
Check the contents of your package for following parts:
MCR200-1T-1TW
5V DC/ 2AAC-to-DC Power Adapter x1
RJ-11 Telephone Line x1
User’s Manual x1
If any of these items are missing or damaged, please contact your dealer
immediately, if possible, retain the carton including the original packing
material, and use them against to repack the product in case there is a
need to return it to us for repair.
Ethernet over VDSL2 Bridge Description
UTC's state-of-the-art Ethernet-over-VDSL2 products are based on two
core networking technologies: Ethernet and VDSL2 (Very-high-data-rate
Digital Subscriber Line 2). This technology offers the absolute fastest
possible data transmission speeds over existing copper telephone lines or
coaxial cables without the need for rewiring.
The MCR200-1T-1TW Ethernet Over VDSL2 Converter has a switching
architecture with RJ-45 10/100Mbps Ethernet port and one asymmetric or
symmetric Ethernet over VDSL port (Asymmetric means upstream and
downstream rate are not the same and Symmetric means upstream and
downstream rate are similar) – the VDSL port can be RJ-11 connector
MCR200-1T-1TW. The MCR200-1T-1TW can be set to Central Office (CO)
or Customer Premises Equipment (CPE) mode via a DIP switch. When
MCR200-1T-1TW is connected with other MCR200-1T-1TW devices, the
performance will up to 100/55Mbps for asymmetric data rate within 200m
and up to 25/4Mbps for asymmetric data rate at 1.6km.

IFS MCR200-1T-1TW User Guide 3
The UTC VDSL2 Converter provides a much cheaper replacement and
smooth migration for existing Long Reach Ethernet (LRE) networks.
The cable specifications of the connection are listed as following:
■ 10Base-T, Category 3, 4 or 5 UTP
■ 100Base-TX, Category 5, 5e or 6 UTP
■ Ethernet over VDSL2, Twisted-pair telephone wires
The two drawings pictures are typical applications diagrams for the
Ethernet over VDSL2 Converter.
Slave device (CPE) must connect to Master device
(CO) through the telephone wire or coaxial cable. It
is not allow connecting like Master to Master or
Slave to Slave. To define the MCR200-1T-1TW to
CO or CPE, please refer to “MODE DIP Switch” on
page 9 for more detail.

4 IFS MCR200-1T-1TW User Guide
Key Features
The Ethernet Over VDSL2 Converter provides the following key features:
■ Cost-effective VDSL2 CO / CPE bridge solution
■ One box design, CO / CPE selectable via DIP Switch
■ Defines Asymmetric (Band Plan 998) and Symmetric band plans for the
transmission of Upstream and Downstream signals
■ Complies with IEEE 802.3, IEEE 802.3u and IEEE 802.3x standards
■ DMT (Discrete Multi-Tone) line coding
■ Half Duplex Back Pressure and IEEE 802.3x Full Duplex Pause Frame Flow
Control
■ Built-in POTS splitter to share voice and data
■ Voice and data communication can be shared on the existing telephone wire
simultaneously
■ Support up to 1536 bytes packet size, 802.1Q VLAN tag transparent
■ VDSL2 Stand-Alone transceiver for simple bridge modem application
■ Selectable Target Band Plan and Target SNR Margin
■ Support extensive LED indicators for network diagnostics

IFS MCR200-1T-1TW User Guide 5
Specifications
Product MCR200-1T-1TW
Hardware Specification
10/100
Base-
TX 1 x RJ-45, Auto-negotiation Auto-MDI/MDI-X
VDSL 1 x RJ-11, female Phone Jack
Ports
PHONE 1 x RJ-11, Built-in splitters for POTS connection
DIP Switch 4 position DIP switch
Functionality
•CO / CPE mode select
•Selectable fast and interleaved mode
•Selectable target Band Plan
•Selectable target SNR mode
Encoding
•VDSL-DMT
- ITU-T G.993.1 VDSL
- ITU-T G.997.1
- ITU-T G.993.2 VDSL2 (Profile 17a Support)
One Power
3 for RJ-11/VDSL2
LED Indicators 2 for RJ-45 10/100Base-TX port
Ethernet •10Base-T: 2-pair UTP Cat.3,4,5 up to 100m (328ft)
•100Base-TX: 2-pair UTP Cat.5, 5e, 6 up to 100m
(328ft)
Cabling
VDSL Twisted-pair telephone wires (AWG24 or better) up
to 1.6km

6 IFS MCR200-1T-1TW User Guide
Specifications Continued:
Asymmetric Mode
200m -> 100/55Mbps
400m -> 90/50Mbps
600m -> 70/40Mbps
800m -> 60/25Mbps
1000m -> 45/15Mbps
1200m -> 35/10Mbps
1400m -> 30/6Mbps
1600m -> 25/4Mbps
Symmetric Mode
Performance*
(Down Stream /
Up Stream)
200m -> 100/100Mbps
400m -> 90/95Mbps
600m -> 70/70Mbps
800m -> 55/50Mbps
1000m -> 45/35Mbps
1200m -> 30/25Mbps
1400m -> 25/20Mbps
1600m -> 20/15Mbps
Power
Requirement 5V DC, 2A
Operating
Temperature 0~50ºC
Storage
Temperature -10~70ºC
Operating
Humidity 10% to 90%, relative humidity, non-condensing
Storage Humidity 10% to 90%, relative humidity, non-condensing
Standard Conformance
Regulation
Compliance FCC Part 15 Class A, CE
Standards
Compliance
IEEE 802.3 10Base-T
IEEE 802.3u 100Base-TX
IEEE 802.3x Full Duplex Pause frame Flow Control
ITU-T
。 G.997.1
。 G.993.1 VDSL
。 G.993.2 VDSL2 (Profile 17a)
* The actual data rate will vary on the quality of the copper wire and
environment factors.

IFS MCR200-1T-1TW User Guide 7
Hardware Description
The MCR200-1T-1TW provides 2 RJ-11 ports for voice connection (like
telephone) and for network line connection.
The MCR200-1T-1TW also provides 1 RJ-45 port with two different running
speeds –10Mbps and 100Mbps. It can distinguish the speed of an
incoming connection automatically.
This section describes the hardware features of the Ethernet over VDSL2
Converter. For easier control of the converter, familiarize yourself with its
display indicators and ports. Front panel illustrations in this chapter display
the unit LED indicators. Before connecting any network device to the
converter, read this chapter carefully.
Front Panel
The units’ front panel provides a simple interface monitoring the Ethernet
over VDSL2 Converter.
■ MCR200-1T-1TW Front Panel
Figure 1: MCR200-1T-1TW front panel

8 IFS MCR200-1T-1TW User Guide
LED indicators for MCR200-1T-1TW
The rich diagnostic LEDs on the front panel can provide the operating
status of individual port and whole system.
■ System
LED Color Function
Light Power ON
PWR Green
Off Power OFF
■ VDSL
LED Color Function
Light Indicate that the VDSL link is
established.
Fast Blink Indicate that the VDSL link is at training
status (about 10 seconds).
LNK/ACT Green
Slow Blink Indicate that the VDSL link is at idle
status.
CO Green Light Indicate the VDSL Bridge is running at
CO mode.
CPE Green Light Indicate the VDSL Bridge is running at
CPE mode.
■ 10/100Base-TX Port
LED Color Function
Light Indicate that the port is Link Up.
Blink Indicate that the Converter is actively
sending or receiving data over that port.
LNK/ACT Green
Off Indicate that the port is Link Down.
Light Indicate that the port is operating at
100Mbps.
100 Green Off Indicate that the port is Link Down or
10Mbps.
2CO Green Light Indicate the VDSL Bridge is running at CO
mode.
CPE Green Light Indicate the VDSL Bridge is running at CPE
mode.

IFS MCR200-1T-1TW User Guide 9
■ 10/100Base-TX Port
LED Color Function
Light Indicate that the port is link up.
Blink Indicate that the Converter is actively
sending or receiving data over that port.
LNK/ACT Green
Off Indicate that the port is link down.
The Rear Panel
The rear panel of the Ethernet over VDSL2 Converter is shown as below.
Figure 2: MCR200=1T-1TW rear panel
MODE DIP Switch
The Ethernet over VDSL2 Converter provides 4 selective transmission
modes. By switching the transmission modes, you can obtain a best
transmission mode to suit with phone line quality or distance of
connectivity. The following is the summary table of transmission setting,
bandwidth and distance extensibility tested for AWG 24 (0.5mm) twisted-
pair without noise and cross talk.

10 IFS MCR200-1T-1TW User Guide
DIP-1 DIP-2 DIP-3 DIP-4
Mode Channel Band
Plan SNR
OFF CO Interleave Symm 9dB
ON
(default) CPE Fast Asymm 6dB
CO / CPE
CO (Central Office) – the Master device mode, usually the CO device
will be located at the data center of ISP or enterprise to link to the
backbone.
CPE (Customer Premises Equipment) – the Slave device mode, usually
the CPE device will be located at branch office, home or remote side as
the long reach data receiver. The CPE can be connected to the PC, IP
Camera or Wireless Access Point and etc network devices.
When the Ethernet Over VDSL2 Converter is operating in CPE
mode, the DIP switch 2,3,4 is disabled.
Fast and Interleave mode
Fast mode guarantees a minimum end to end latency less than 1 ms.
Interleaved mode provides impulse noises protection with a duration
less than 250 us. Interleaved mode has a maximum end to end latency
of 10m sec.
Band Plan
User can switch the Band Plan either Symmetric or Asymmetric by their
own. When Symmetric is selected that provides better upstream
performance, when Asymmetric is selected that provides better
downstream performance. Refer to table above for details.
Target SNR (Signal Noise Ratio) Margin
When fixed SNR margin is selected, the system will maintain the SNR
margin at 9 dB across all usable loop length.
By default setting, the four DIP switch at “ON” position and
operate as “CPE”. For operate as “CO”, please adjust the DIP 1
switch to “OFF” position. Adjust other DIP switch setting to fill
different network application demand.
Please power off the Ethernet over VDSL2 Converter before making any
transmission mode adjustment.

IFS MCR200-1T-1TW User Guide 11
DC Power Jack
MCR200-1T-1TW requires 5V DC power input. It will conform to the
bundled AC adapter. If you have the issue to make the power connection,
please contact your local sales representative.
1. The device is a power-required device, it means, it will not
work till it is powered. If your networks should active all the
time, please consider using UPS (Uninterrupted Power
Supply) for your device. It will prevent you from network data
loss or network downtime.
2. In some area, installing a surge suppression device may also
help to protect your Ethernet Over VDSL2 Converter from
being damaged by unregulated surge or current to the
Ethernet over VDSL2 Converter or the power adapter.

12 IFS MCR200-1T-1TW User Guide
Installation
Install Ethernet over VDSL2 Converter
The Ethernet over VDSL2 Converter does not require any software
configuration. Users can immediately use any feature of this product simply
by attached the cables and plug power on. There is some key limitation on
the Ethernet over VDSL2 Converter. Please check the following items:
MCR200-1T-1TW: The device is used for Point-to-Point connection only
(Master device to Slave device) and has equipped with 2 RJ-11 connectors
for VDSL port. One for voice device connection (like telephone) and the other
one for network link connection.
Depending on the quality of telephone line, the maximum distance of one
VDSL segment is 1.6km (6561ft) with AWG 24 telephone wires.
* The MC251-4P/1CXT and MC250-4T/1CXT can utilize standard
telephone (POTS) type cable for transmission of Ethernet/IP data. It is
not designed for transmitting Ethernet data on a PBX system or
public switch telephone network (PSTN).
MCR200-1T-1TW LAN to LAN connection
Two sets of the Ethernet over VDSL2 Converters could be used to link two
local Area networks that are located in different place. Through the normal
telephone line, it could setup a 100/55Mbps asymmetric backbone, but one
Ethernet over VDSL2 Converter must be Master (CO mode) and the other
one is Slave (CPE mode).

IFS MCR200-1T-1TW User Guide 13
Figure 3: MCR200-1T-1TW LAN to LAN connection
Connecting the MCR200-1T-1TW
Connecting Standalone PC
Refer to the following procedures to setup the MCR200-1T-1TW to a
standalone PC.
1. Set the MCR200-1T-1TW to be CO or CPE mode from the DIP switch at
the rear panel.
2. Power on the MCR200-1T-1TW by connecting its power source.
3. Power LED will illuminate.
Connect VDSL line from another VDSL device to VDSL port of
4. The MCR200-1T-1TW.
5. LNK LED will blink to illuminate.
6. Connect telephone to the PHONE port.
7. Connect Ethernet port to PC Network Interface Card (NIC) via regular Cat.
5, 5e or 6 cable.
Figure 3-4: Connecting Standalone PC

14 IFS MCR200-1T-1TW User Guide
Connecting Multiple PCs to an Ethernet LAN
Refer to the following procedures to setup the MCR200-1T-1TW to an
Ethernet LAN.
1. Set the MCR200-1T-1TW to be CO or CPE mode from the DIP switch at
the rear panel.
2. Power on the MCR200-1T-1TW by connecting its power source.
3. Power LED will illuminate.
4. Connect VDSL line from another VDSL device to VDSL port of
the MCR200-1T-1TW. LNK LED will illuminate.
5. Connect telephone to the PHONE port.
6. MCR200-1T-1TW: Connect Ethernet port to Ethernet Switch (or Broadband
Router) via regular Cat. 5, 5e or 6 cables.
Figure 3-5: Connecting Multiple PCs to an Ethernet LAN
Please refer to your Ethernet device User’s
Manual for the device’s set up information.

IFS MCR200-1T-1TW User Guide 15
Chassis Installation and Rack Mounting
(MCR200-1T-1TW)
To install the Ethernet over VDSL2 Converter in a MCR300 19-inch
Converter Chassis with standard rack, follow the instructions described
below.
Step 1: Place your MCR200-1T-1TW on a hard flat surface, with the front
panel positioned towards your front side.
Step 2: Carefully slide in the module until it is fully and firmly fitted into the
slot of the converter chassis.
Figure 3-8: Insert a VDSL2 converter into an available slot
Step 3: Attach a rack-mount bracket to each side of the Converter Chassis
with supplied screws attached to the package.
Step 4: After the brackets are attached to the Converter Chassis, use
suitable screws to securely attach the brackets to the rack.
Step 5: Proceed with the steps 4 and steps 5 of session Stand-alone
Installation to connect the network cabling and supply power to your
Converter Chassis
You must use the screws supplied with the
mounting brackets. Damage caused to the parts by
using incorrect screws would invalidate your
warranty.

16 IFS MCR200-1T-1TW User Guide
Power Information
The power jack of MCR200-1T-1TW is with 2.5mm in the central post and
required +5VDC power input. It will conform to the bundled AC-DC adapter
and Planet’s Media Chassis. If you have encountered the issue to make
the power connection, please contact your local sales representative.
Please keep the AC-DC adapter as spare parts when your MCR200-1T-
1TW is installed into a Media Chassis.
2.5mm
DC Receptacle 2.5mm
+5V for each slot
For Media Chassis DC receptacle is 2.5mm wide that
conforms to and matches the VDSL2 Converter 2.5mm DC
jack's central post. Do not install any improper devices in
Media Chassis

IFS MCR200-1T-1TW User Guide 17
Troubleshooting
SYMPTOM: VDSL LNK LED does not light after wire is connected to the
VDSL port.
CHECKPOINT:
1. Verify the length of the wire connected between two MCR200-1T-1TW is not
more than 2.0km. Please also try to adjust the DIP switch of MCR200-1T-
1TW to other SNR mode.
2. Please note you must use one MCR200-1T-1TW with CO mode and the other
MCR200-1T-1TW with CPE mode, connect to each other to make it work.
SYMPTOM: TP LED does not light after cable is connected to the port.
CHECKPOINT:
1. Verify you are using the Cat.5, 5e or 6 cables with RJ-45 connector to
connect to the port.
2. If your device (like LAN card) supports to Auto-Negotiation, please try to
modify at a fixed speed of your device by manually.
3. Check the converter and the connected device’s power are ON or OFF.
4. Check the port’s cable is firmly seated in its connectors in the switch and in
the associated device.
5. Check the connecting cable is good.
Check the power adapters are functional, including the connecting device.
