Powerline AV Ethernet
Adapter Data Sheet
XAV101
Extend Your Network Using Electrical Outlets
• Turn any electrical power outlet into a high-speed Internet and home network connection1
• Easily connect TiVo®, Slingbox™, game consoles, or TVs
• Fast enough to stream HD video
• Plug and play: just plug into a wall outlet, no setup required
Features
• Turns any electrical power outlet into an Ethernet network connection
• Delivers fast 200 Mbps speed†
• Secure your Powerline AV network by just pushing a button
• For use with both wired and wireless routers and gateways
• Simply plug one XAV101 into your router1
• Connect a desktop, notebook PC, gaming console, NETGEAR ReadyNAS™, Slingbox™,
a DVR or NETGEAR Print Server (PS121)
• 128-bit AES data encryption ensures privacy and security
• Red, yellow, green status LEDs indicate maximum data rate
• Supports Windows® Vista™
• HomePlug AV compatible
24/7
TECHNICAL
SUPPORT*
1-888-NETGEAR (638-4327)
Email: [email protected]
Plug-and-play connection of
a Powerline Network1, 2
POWERLINE
AV
200
Mbps
Up to
Push button
to secure
network
Broadband
modem
Router
200 Mbps Powerline
Network Adapter
(XAV101)
200 Mbps Powerline
Network Adapter
(XAV101)
Set-top box
Gaming
console
TV
Home Office
Living Room
or
or

4500 Great America Parkway
Santa Clara, CA 95054 USA
1-888-NETGEAR (638-4327)
E-mail: [email protected]
www.NETGEAR.com
System Requirements
For device connection: Available RJ-45 –
Ethernet port
Automatic push button security works –
with all platforms, does not require CD
To manually modify encryption and set-–
tings using CD: Microsoft® Windows®
Vista™, 2000 or XP
Network Ports
One 10/100 Mbps Ethernet port–
One 200 Mbps– † Powerline AV interface
Power Supply
100-240V @ 50-60 Hz–
LEDs
Power–
Status–
Ethernet–
Environmental Specications
Operating temperature: 0º-40 ºC –
(32º-104 ºF)
Operating relative humidity: –
10% to 90% non-condensing
Physical Specications
Dimensions: 98 x 72 x 40 mm –
(3.86 x 2.83 x 1.57 in)
Weight: 0.18 kg (0.4 lb)–
Electromagnetic Emissions
FCC Part 15 Class B–
CE–
C-Tick–
Power and Safety Regulations
UL Certied–
Typical Coverage
Up to 5000 square foot home– †
Warranty
NETGEAR 1-year Warranty–
Package Contents
Powerline AV Ethernet Adapter –
(XAV101)
1.51 m (5 ft) Ethernet cable–
Installation guide–
Setup CD–
Warranty card–
Support and information card–
NETGEAR Related Products
Network: –
– RangeMax™ NEXT Wireless-N Router
(WNR834B)
– RangeMax™ Wireless Router
WPN824)
– Super-G® Wireless Router (WGT624)
– Wireless-G Router (WGR614)
– RangeMax™ NEXT Wireless-N Access
Point (WN802T)
– RangeMax™ Wireless Access Point
WPN802)
– Open Source Wireless-G Router
KWGR614)
– Wireless-G Access Point (WG602)
– Web Safe 4-port Router (RP614)
Printer –
– USB Print Server (PS121)
Storage–
– ReadyNAS NV+ (RND4XXX)
– Storage Central Turbo (SC101T)
Multimedia Players–
– Digital Entertainer HD (EVA8000)
Powerline AV Ethernet Adapter XAV101
© 2008 NETGEAR, Inc. NETGEAR, the NETGEAR Logo, NETGEAR Digital Entertainer Logo, Connect with Innovation, FrontView, IntelliFi,
PowerShift, ProSafe, RAIDar, RAIDiator, X-RAID, RangeMax, ReadyNAS and Smart Wizard are trademarks of NETGEAR, Inc. in the United
States and/or other countries. Other brand names mentioned herein are for identification purposes only and may be trademarks of their
respective holder (s). Information is subject to change without notice. All rights reserved.
*Free basic installation support provided for 90 days from date of purchase. Advanced product features and configurations are not
included in free basic installation support; optional premium support available.
†Actual data throughput will vary. Network conditions and environmental factors, including volume of network traffic, building material and
construction, and network overhead, lower actual data throughput rate.
D-XAV101-0
1 Requires use of a HomePlug AV-compatible Powerline device (one (1) XAV101 device included).
2XAV101 will coexist, but is not compatible nor interoperable with NETGEAR’s Homeplug 1.0 products including XE102, XE103, XE104,
XEPS103, XET1001, and WGX102 products and UPA products, HDX101 and HDX111.
Outlets must be electrically connected in order for Powerline devices to provide a network connection between them.
