)NSTALLATION'UIDE
XFP GBIC Module AXM751
The 10 Gigabit small form-factor pluggable (XFP) module provides a
full-duplex 10G bps Ethernet link on NETGEAR managed switches.
The switch will automatically detect the AXM751, so you can simply
plug it into an available module slot.
The module can be inserted or removed while the switch is operational.
Installing a AXM751 Module
Insert the module firmly into the slot that supports the XFP interface.
Make sure the optical cable you use is multi-mode LC to LC duplex
cable.
Removing a AXM751 Module
Release the module latch by pulling down the handle bar across the
module, and pull the module out of the module slot.
Specifications
Standard IEEE 802.3ae
10GBase LR
Dimensions (HxWxD) 0.33” x 0.72” x 3.07”
(8.5mm x 18.35mm x 78.0 mm)
Weight 0.1 lb (47g)
Operating Temperature 32- 158 F (0-70c)
Storage Temperature 32-185 F (0-85c)
Operative relative humidity 104 (40c) and 90%
Operating Distance 33m (62um OM1 cable)
82m (50um OM2 cable)
220m (50um OM3 cable)
Connectors LC MM for 62.5um fiber cable
LC MM for 50um fiber cable
Power Consumption 0.95w (max: 1.37w)
MTBF 1154739 hr (135 years)
Safety Certification UL 1950
CSA 22.2 No. 950
