NETGEAR GS728TXS Manual

350 East Plumeria Drive
San Jose, CA 95134
USA
March 2013
202-11201-01
v1.1
GS728TXS/GS752TXS
Smart Switch
Hardware Installation Guide

2
GS728TXS/GS752TXS Smart Switch
Support
Thank you for selecting NETGEAR products.
After installing your device, locate the serial number on the label of your product and use it to register your product
at https://my.netgear.com. You must register your product before you can use NETGEAR telephone support.
NETGEAR recommends registering your product through the NETGEAR website. For product updates and web
support, visit http://support.netgear.com
Phone (US & Canada only): 1-888-NETGEAR.
Phone (Other Countries): Check the list of phone numbers at
http://support.netgear.com/general/contact/default.aspx
Trademarks
NETGEAR, the NETGEAR logo, and Connect with Innovation are trademarks and/or registered trademarks of
NETGEAR, Inc. and/or its subsidiaries in the United States and/or other countries. Information is subject to change
without notice. © NETGEAR, Inc. All rights reserved.
Revision History
Publication Part Number Version Publish Date Comments
202-11201-01 v1.1 March 2013 First publication

Contents | 3
Contents
Chapter 1 Introduction
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Stacking. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Chapter 2 Physical Description
GS728TXS Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
GS728TXS Front Panel and Back Panel Configuration . . . . . . . . . . . . 11
LED Designations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Device Hardware Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
GS752TXS Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
GS752TXS Front Panel and Back Panel Configuration . . . . . . . . . . . . 14
LED Designations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Device Hardware Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Chapter 3 Applications
Desktop Switching . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Backbone Switching . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Chapter 4 Installation
Step 1: Prepare the Site . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Step 2: Install the Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Install the Switch on a Flat Surface . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Install the Switch in a Rack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Step 3: Check the Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Step 4: Connect Devices to the Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Step 5: Install an SFP Transceiver Module . . . . . . . . . . . . . . . . . . . . . . . . 24
Step 6: Install Device as Standalone or Stack Master. . . . . . . . . . . . . . . . 25
Step 7: Apply AC Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Step 8: Manage the Switch Using a Web Browser or the Smart Control Center Utility
26
Appendix A Troubleshooting
Troubleshooting Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Additional Troubleshooting Suggestions . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Network Adapter Cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

4
GS728TXS/GS752TXS Smart Switch
Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Switch Integrity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Autonegotiation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Appendix B Technical Specifications
Network Protocol and Standards Compatibility . . . . . . . . . . . . . . . . . . . . . 32
Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
GS728TXS Smart Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
GS752TXS Smart Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
LEDs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Performance Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Physical Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Environmental Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Electromagnetic Emissions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Appendix C Notification of Compliance

5
1
1. Introduction
Congratulations on the purchase of your NETGEAR®ProSafeTM GS728TXS/GS752TXS Smart
Switch! Your GS728TX/GS752TXS Smart Switch is a state-of-the-art, high-performance,
IEEE-compliant network solution designed for users who require many ports and want the power
of Gigabit connectivity to eliminate bottlenecks, boost performance, and increase productivity.
There are either 24 (GS728TXS) or 48 (GS752TXS) twisted-pair ports on the front panel of the
switch that support nonstop 10/100/1000 networks. The front panel also has 4 SFP+ ports that
support 1000M and 10G optical modules or up to two stacking modules. To simplify installation,
the switch is shipped ready for use out of the box.
This installation guide describes how to install and power on the smart switch. The information in
this manual is intended for readers with intermediate computer and Internet skills.
This chapter serves as an introduction to the smart switch and includes the following sections:
•Overview
•Features
•Package Contents

6
GS728TXS/GS752TXS Smart Switch
Overview
The NETGEAR GS728TXS/GS752TXS Smart Switch provides either 24 (GS728TXS) or 48
(GS752TXS) twisted-pair ports that support nonstop 10/100/1000M networks. The switch
also has four built-in enhanced small form factor pluggable (SFP+) GBIC slots that support
1000M and 10G optical modules or up to two stacking modules.
Using these Gigabit slots, you can create high-speed connections to a server or network
backbone. For example, you can:
•Connect switches to each other with high-speed links
•Link to high-speed servers
•Provide 10/100/1000M copper and 1000M/10G fiber connectivity
•Connect up to six switches in a stack to create a high-port-capacity solution with a single
point of administration
The smart switch also provides the benefit of administrative management with a complete
package of features for the observation, configuration, and control of the network. You can
use the simple and intuitive web-based graphical user interface (GUI) to view and use the
switch’s many capabilities. The switch’s management features include configuration for port
and switch information, VLAN for traffic control, port trunking for increased bandwidth, and
Class of Service (CoS) for prioritizing traffic. These features provide better understanding and
control of the network. Initial discovery of the switch on the network requires the Smart
Control Center program, a utility that runs on a Windows computer.
The smart switch can be freestanding, stacked with other switches, or rack-mounted in a
wiring closet or equipment room. It is IEEE-compliant and offers low latency for high-speed
networking. All ports can automatically negotiate to the highest speed which makes the
switch ideal for environments that have a mix of Ethernet, Fast Ethernet, Gigabit Ethernet, or
10-Gigabit Ethernet devices. All RJ-45 ports operate in half-duplex or full-duplex mode. The
maximum segment length is 328 feet (100 meters) over Category 5 unshielded twisted-pair
(UTP) cable.
Features
The following lists the key features of the smart switch:
•24 (GS728TXS) or 48 (GS752TXS) 10/100/1000-Mbps autosensing Gigabit Ethernet
switching ports.
•4 dedicated 1000M/10G SFP+ fiber ports.
•Full NETGEAR Smart Switch functionality.
•Full compatibility with IEEE standards:
-IEEE 802.3i (10BASE-T)
-IEEE 802.3u (100BASE-TX)
-IEEE 802.3ab (1000BASE-T)

7
GS728TXS/GS752TXS Smart Switch
-IEEE 802.3z (1000BASE-x)
-IEEE 802.3 Clause 49 (10GBASE-LR and 10GBASE-SR)
-IEEE802.aq (10GBASE-LRM)
-IEEE802.3ae (10GBASE Ethernet)
-IEEE802.3az (Energy Efficient Ethernet)
-IEEE 802.3x (Full-duplex flow control)
•AutoSensing and autonegotiating capabilities for all ports.
•Auto Uplink™ on all ports to make the right connection.
•Automatic address learning function to build the packet-forwarding information table. The
table contains up to 16K Media Access Control (MAC) addresses.
•Store-and-forward transmission to remove bad packets from the network.
•Full-duplex IEEE 802.3x pause frame flow control.
•Active flow control to minimize packet loss and frame drops.
•Half-duplex backpressure control.
•Per port LEDs and power LED.
•Internal open frame power supply.
•Standard NETGEAR 7xx series chassis (1U high).
•NETGEAR Green product series power-saving features:
-Automatic power consumption adjustment based on the RJ-45 cable length
(GS752TXS only)
-Per port automatic power down when the port link is down.
Stacking
A stack can be controlled and managed from a single unit called the master unit. Any other
unit member of the stack is called a stack slave member.
In particular, firmware can be downloaded from the stack master to the other units in the
stack.
A unit serving as stack master runs the fully operational software of a switch. In addition, it
runs the master part of the distributed switching application that configures and manages all
other units in the stack. Generally, the master operates the remote slave’s low-level drivers,
through the distributed switching application part that is running in the context of the slave.
During stacking setup, the switches autoselect one device as the stacking master. All other
devices are named as slave stack members and assigned unique unit IDs. One of the slave
units is designated as the backup master. The backup master acts as a slave stack master,
but can become a stack master if the stack master fails. In the default configuration, the
master and backup master are assigned unit IDs of 1 and 2, respectively. The administrator
can use the web interface to configure different ID assignments. The stack master provides a
single point of control and management as well as a single interface in which to control and
manage the stack.

8
GS728TXS/GS752TXS Smart Switch
Switch software is downloaded separately for each stack member. However, all units in the
stack must be running the same software version.
A stack unit can operate in one of the following modes:
•A standalone unit runs as a general switch. The standalone unit does not run the stacking
application until it is connected to a stack.
•The master unit manages the entire stack, and is responsible for the entire stack
configuration. All protocols run in the context of the master unit. It updates and
synchronizes the backup master.
•A master-backup unit runs as a slave unit as described earlier, and in addition, it
continuously monitors the existence and operation of the stack master. If the master unit
fails, the master-backup unit assumes the stack-master role (switchover).
•A slave unit runs only a slave version of the distributed switching algorithm, which allows
the applications running on the master unit’s CPU to control and manage the resources of
the slave unit.
A stack can contain a mix of up to six GS728TXS and GS752TXS switches.
Package Contents
The following figure shows the package contents of the smart switch. (The figure shows the
GS752TXS Smart Switch; however, the GS728TXS Smart Switch has the same package
contents.)
Green=Link at 1G
Yellow=Link at 10/
100M
Power
Reset
ID
Fan
Stack
Master
Facto ry
Defaults
12345678910 11 13 15 17 19 21
12 2214 16 18 20 23 25 27 29 31 33 24 3426 28 30 32 35 37 39 41 43 45 47 36 38 40 42 44 46 48
GS752TXS
50F
49F
Green=10G Link Yellow=1G
Blink=ACT
SFP
+
52F
51F
Link/Act Mode —
Figure 1. Package contents

9
GS728TXS/GS752TXS Smart Switch
Verify that the package contains the following:
•GS728TXS/GS752TXS Smart Switch
•Rubber footpads for tabletop installation
•Rack-mounting kits
•Power cord
•Installation guide
•Smart switch resource CD with NETGEAR Smart Control Center and user’s manual
If any item is missing or damaged, contact the place of purchase immediately.

10
2
2. Physical Description
This chapter describes the GS728TXS/GS752TXS Smart Switch hardware features. Topics
include:
•GS728TXS Description
•GS752TXS Description

11
GS728TXS/GS752TXS Smart Switch
GS728TXS Description
This section describes the smart switch hardware features.
GS728TXS Front Panel and Back Panel Configuration
The GS728TXS has 24 10/100/1000-Mbps copper ports and 4 dedicated
1000 Mbps/10 Gbps SFP+ fiber ports. Up to 2 fiber ports (port 27 and 28) at a time can be
used as stacking ports.
Each port is capable of sensing the line speed and negotiating the duplex mode with the link
partner automatically.
Green=Link at 1G
Yellow=Link at 10/
100M
Power
Reset
ID
Fan
Stack
Master
Fact ory
Defaults
12345678910 11 13 15 17 19 21
12 2214 16 18 20 23 24
GS728TXS
25F
Green=10G Link Yellow=1G
Blink=ACT
SFP
+
27F
Link/Act Mode —
28F26F
Power, Fan, and
Link/Speed/ACT LEDs
10/100/1000 Ethernet ports
1000M/10G
SFP ports
Reset button
Stack Master LEDs
Factory
Defaults button
Stack ID LED
The following figure illustrates the front panel of the smart switch.
Figure 2. GS728TXS front panel
The front panel contains the following:
•24 RJ-45 connectors for 10/100/1000-Mbps autosensing Gigabit Ethernet switching
ports.
•Four dedicated 1000 Mbps/10Gbps SFP+ Gigabit Ethernet switching ports. Up to two of
these ports (ports 27 and 28) can alternatively be used as stacking ports.
•Reset button to restart the device.
•Recessed Factory Defaults button to restore the device back to the factory defaults.
•Link, Speed, and Activity LEDs for each port.
•Power, Fan, Stack Master, and Stack ID LEDs.
The following figure illustrates the smart switch back panel.

Power connector
Kensington Lock™ slot
12
GS728TXS/GS752TXS Smart Switch
Figure 3. GS728TXS back panel
The back panel contains a power connector.
LED Designations
This section describes the LEDs on the smart switch.
Port LEDs
The following table describes the RJ-45 and dedicated SFP port LED designations. Each
RJ-45 port has one LED.
Table 1. Port LEDs
LED Designation
Link/Speed/ACT LED mode for
copper ports 1 to 24
•Off. No link is established.
•Solid green. A valid 1000-Mbps link is established.
•Blinking green. The port is transmitting or receiving packets at
1000 Mbps.
•Solid yellow. A valid 10/100-Mbps link is established.
•Blinking yellow. The port is transmitting or receiving packets
at 10/100 Mbps.
Link/ACT LED for SFP+ ports
25 to 28
•Off. No SFP+ module link is established.
•Solid green. A valid 10-Gbps link is established.
•Blinking green. The port is transmitting or receiving packets
at 10 Gbps.
•Solid yellow. A valid 1000-Mbps link is established.
•Blinking yellow. The port is transmitting or receiving packets at
1000 Mbps.
Each SFP port has its own LED.

13
GS728TXS/GS752TXS Smart Switch
System LEDs
The following table describes the system LED designations.
Table 2. System LEDs
LED Designation
Power •Solid green. The device is powered on; runtime code is operating.
•Solid yellow. The device is booting up.
•Off. Power is not supplied to the device.
Fan •Solid yellow. The fan has failed.
•Off. The fan is operating normally.
Stack Master LED •Solid green. The switch acts as a master unit in a stack of GS7XXTXS series
switches.
•Off. The switch acts as a slave in a stack of GS7XXTXS series switches, or the
stack is operating in standalone mode.
Stack ID Displays the stack ID, from 1 to 6.
Device Hardware Interfaces
This section describes the hardware interfaces on the smart switch.
RJ-45 Ports
RJ-45 ports are AutoSensing ports. When you insert a cable into an RJ-45 port, the switch
automatically ascertains the maximum speed (10, 100, or 1000 Mbps) and duplex mode
(half-duplex or full-duplex) of the attached device. All ports support only an unshielded
twisted-pair (UTP) cable terminated with an 8-pin RJ-45 plug.
To simplify the procedure for attaching devices, all RJ-45 ports support Auto Uplink. This
technology allows attaching devices to the RJ-45 ports with either straight-through or
crossover cables. When you insert a cable into the switch’s RJ-45 port, the switch
automatically:
•Senses whether the cable is a straight-through or crossover cable.
•Determines whether the link to the attached device requires a “normal” connection (such
as when you are connecting the port to a computer) or an uplink connection (such as
when you are connecting the port to a router, switch, or hub).
•Automatically configures the RJ-45 port to enable communications with the attached
device. The Auto Uplink technology compensates for setting uplink connections, while
eliminating concern about whether to use crossover or straight-through cables when you
attach devices.

14
GS728TXS/GS752TXS Smart Switch
SFP+ Ports
To enable you to have fiber connections on your network, four SFP+ ports (25 through 28)
accommodate standard 1000M and 10G SFP+ transceiver modules, which are sold
separately.
The SFP+ ports can alternatively be used to connect the switch to a stack. Up to two ports
(ports 27 and 28) can be used at a time as stacking ports.
Reset Button
The smart switch has a Reset button on the front panel to allow you to manually reboot the
switch. This action is equivalent to powering the unit off and back on. The last saved
configuration is loaded into the switch as it resets. To use the Reset button, insert a device
such as a straightened paper clip into the opening to press the recessed button. The front
panel LEDs should turn off and light again as the switch performs its power-on self-test
(POST).
Factory Defaults Button
The smart switch has a Factory Defaults button on the front panel so that you can remove the
current configuration and return the device to its factory settings. When you enable the
Factory Defaults button, all settings including the password, VLAN settings, and port
configurations are removed. To use the Factory Defaults button, insert a device such as a
straightened paper clip into the opening to press the recessed button for over 2 seconds.
Note: Switches that are part of stack will retain the stacking configuration.
GS752TXS Description
This section describes the smart switch hardware features.
GS752TXS Front Panel and Back Panel Configuration
The GS752TXS has 48 10/100/1000-Mbps copper ports and 4 dedicated
1000 Mbps/10 Gbps SFP+ fiber ports. Up to 2 fiber ports (port 51 and 52) at a time can be
used as stacking ports.
Each port is capable of sensing the line speed and negotiating the duplex mode with the link
partner automatically.
The following figure illustrates the front panel of the NETGEAR GS752TXS Smart Switch.

Green=Link at 1G
Yellow=Link at 10/
100M
Power
Reset
ID
Fan
Stack
Master
Fact ory
Defaults
12345678910 11 13 15 17 19 21
12 2214 16 18 20 23 25 27 29 31 33 24 3426 28 30 32 35 37 39 41 43 45 47 36 38 40 42 44 46 48
GS752TXS
50F
49F
Green=10G Link Yellow=1G
Blink=ACT
SFP
+
52F
51F
Link/Act Mode —
Power, Fan, and
Link/Speed/ACT LEDs
10/100/1000 Ethernet ports
1000M/10G
SFP ports
Reset button
Stack Master LEDs
Factory
Defaults button
Stack ID LED
15
GS728TXS/GS752TXS Smart Switch
Figure 4. GS752TXS front panel
The front panel contains the following:
•48 RJ-45 connectors for 10/100/1000-Mbps autosensing Gigabit Ethernet switching
ports.
•Four dedicated 1000 Mbps/10Gbps SFP+ Gigabit Ethernet switching ports. Up to two of
these ports (ports 51 and 52) can alternatively be used as stacking ports.
•Reset button to restart the device.
•Recessed Factory Default button to restore the device back to the factory defaults.
•Link, Speed, and ACT LEDs for each port.
•Power, Fan, Stack Master, and Stack ID LEDs.
The following figure illustrates the smart switch back panel.
Power connector
Kensington Lock™ slot
Figure 5. Back panel
The back panel contains a power connector.
LED Designations
This section describes the LEDs on the smart switch.

16
GS728TXS/GS752TXS Smart Switch
Port LEDs
The following table describes the RJ-45 and dedicated SFP port LED designations. Each
RJ-45 port has one LED.
Table 3. Port LEDs
LED Designation
Link/Speed/ACT LED mode for
copper ports 1 to 48
•Off. No link is established.
•Solid green. A valid 1000-Mbps link is established.
• Blinking green. The port is transmitting or receiving packets at
1000Mbps.
•Solid yellow. A valid 10/100-Mbps link is established.
•Blinking yellow. The port is transmitting or receiving packets
at 10/100 Mbps.
Link/ACT LED for SFP+ ports
49 to 52
•Off. No SFP+ module link is established.
•Solid green. A valid 10-Gbps link is established.
•Blinking green. The port is transmitting or receiving packets
at 10 Gbps.
•Solid yellow. A valid 1000-Mbps link is established.
•Blinking yellow. The port is transmitting or receiving packets at
1000 Mbps.
Each SFP port has its own LED.
System LEDs
The following table describes the system LED designations.
Table 4. System LEDs
LED Designation
Power •Solid green. The device is powered on; runtime code is operating.
•Solid yellow. The device is booting up.
•Off. Power is not supplied to the device.
Fan •Solid yellow. The fan has failed.
•Off. The fan is operating normally.
Stack Master LED •Solid green. The switch acts as a master unit in a stack of GS7XXTXS series
switches.
•Off. The switch acts as a slave in a stack of GS7XXTXS series switches, or the
stack is operating in standalone mode.
Stack ID Displays the stack ID, from 1 to 6.
Device Hardware Interfaces
This section describes the hardware interfaces on the smart switch.

17
GS728TXS/GS752TXS Smart Switch
RJ-45 Ports
RJ-45 ports are AutoSensing ports. When you insert a cable into an RJ-45 port, the switch
automatically ascertains the maximum speed (10, 100, or 1000 Mbps) and duplex mode
(half-duplex or full-duplex) of the attached device. All ports support only an unshielded
twisted-pair (UTP) cable terminated with an 8-pin RJ-45 plug.
To simplify the procedure for attaching devices, all RJ-45 ports support Auto Uplink. This
technology allows attaching devices to the RJ-45 ports with either straight-through or
crossover cables. When you insert a cable into the switch’s RJ-45 port, the switch
automatically:
•Senses whether the cable is a straight-through or crossover cable.
•Determines whether the link to the attached device requires a “normal” connection (such
as when you are connecting the port to a computer) or an uplink connection (such as
when you are connecting the port to a router, switch, or hub).
•Automatically configures the RJ-45 port to enable communications with the attached
device. The Auto Uplink technology compensates for setting uplink connections, while
eliminating concern about whether to use crossover or straight-through cables when you
attach devices.
SFP+ Ports
To enable you to have fiber connections on your network, four SFP+ ports (49 through 52)
accommodate standard 1000M and 10G SFP+ transceiver modules, which are sold
separately.
The SFP+ ports can alternatively be used to connect the switch to a stack. Up to two ports
(ports 51 and 52) can be used at a time as stacking ports.
Reset Button
The smart switch has a Reset button on the front panel to allow you to manually reboot the
switch. This action is equivalent to powering the unit off and back on. The last saved
configuration is loaded into the switch as it resets. To use the Reset button, insert a device
such as a straightened paper clip into the opening to press the recessed button. The front
panel LEDs turn off and light again as the switch performs its power-on self-test (POST).
Factory Defaults Button
The smart switch has a Factory Defaults button on the front panel so that you can remove the
current configuration and return the device to its factory settings. When you press the Factory
Defaults button, all settings including the password, VLAN settings, and port configurations
are removed. To use the Factory Defaults button, insert a device such as a straightened
paper clip into the opening to press the recessed button for over 2 seconds.
Note: Switches that are part of stack will retain the stacking configuration.

18
3
3. Applications
Your GS728TXS/GS752TXS Smart Switch is designed to provide flexibility in configuring your
network connections. It can be used as your only network traffic-distribution device or with
10 Mbps, 100 Mbps, 1000 Mbps, and 10-Gbps hubs and switches. Topics include:
•Desktop Switching
•Backbone Switching

19
GS728TXS/GS752TXS Smart Switch
Desktop Switching
The smart switch can be used as a desktop switch to build a small network that enables
users to have 1000-Mbps access to a file server. With full duplex enabled, the switch port
connected to the server or computer can provide 2000 Mbps throughput. If a 10-Gbps
module is used to connect the switch to the file server in full-duplex operation, then the server
can provide up to 20 Gbps throughput. (The figure shows the GS752TXS Smart Switch;
however, the GS728TXS Smart Switch can also be used for desktop switching.)
Green=Linkat 1G
Yellow=Linkat 10/
100M
Power
Reset
ID
Fan
Stack
Master
Factory
Defaults
12345678910 11 13 15 17 19 21
12 2214 16 18 20 23 25 27 29 31 33 24 3426 28 30 32 35 37 39 41 43 45 47 36 38 40 42 44 46 48
GS752TXS
50F
49F
Green=10GLink Yellow=1G
Blink=ACT
SFP
+
52F
51F
Link/ActMode —
`` ` `
Figure 6. Desktop switching
Backbone Switching
You can use the smart switch as a backbone switch in a small network that gives users
high-speed access to servers and other network devices. (The figure shows the GS752TXS
Smart Switch; however, the GS728TXS Smart Switch can also be used for backbone
switching.)

Green=Linkat 1G
Yellow=Linkat 10/
100M
Power
Reset
ID
Fan
Stack
Master
Factory
Defaults
12345678910 11 13 15 17 19 21
12 2214 16 18 20 23 25 27 29 31 33 24 3426 28 30 32 35 37 39 41 43 45 47 36 38 40 42 44 46 48
GS752TXS
50F
49F
Green=10GLink Yellow=1G
Blink=ACT
SFP
+
52F
51F
Link/ActMode —
` `
```
Model FS728TP
Model GS108T
GS728TXS/GS752TXS
20
GS728TXS/GS752TXS Smart Switch
Figure 7. Backbone switching
