NETGEAR MS510TX Manual

8-Port Multi-Gigabit
Smart Managed Pro Switch
with two 10G Ports
Hardware Installation Guide
Models MS510TX and MS510TXPP
June 2017
202-11763-01
350 E. Plumeria Drive
San Jose, CA 95134
USA

Support
Thank you for purchasing this NETGEAR product.You can visit www.netgear.com/support to register your
product, get help, access the latest downloads and user manuals, and join our community.We recommend that
you use only official NETGEAR support resources.
Conformity
For the current EU Declaration of Conformity, visit http://kb.netgear.com/app/answers/detail/a_id/11621.
Compliance
For regulatory compliance information, visit http://www.netgear.com/about/regulatory.
See the regulatory compliance document before connecting the power supply.
Trademarks
©NETGEAR, Inc., NETGEAR, and the NETGEAR Logo are trademarks of NETGEAR, Inc.Any non-NETGEAR
trademarks are used for reference purposes only.
2
8-Port Multi-Gigabit Smart Managed Pro Switch with two 10G Ports

Contents
Chapter 1 Introduction
Overview................................................................................................................5
Features.................................................................................................................5
Safety Instructions and Warnings..........................................................................7
Chapter 2 Hardware Overview
Hardware Description..........................................................................................10
Front Panel......................................................................................................10
Back Panel......................................................................................................12
LEDs...............................................................................................................12
Switch Hardware Interfaces.................................................................................15
RJ-45 Ports for 10/100/1000M and 2.5G/5G/10G BASE-T Ethernet
Connectivity.....................................................................................................15
SFP+ Port for Fiber Connectivity.....................................................................16
Reset Button...................................................................................................16
Factory Defaults Button...................................................................................17
USB Port.........................................................................................................17
Chapter 3 Applications
Multispeed Backbone Switching..........................................................................19
2.5G Network Storage and Redundancy.............................................................19
Multispeed PoE+ Access Points..........................................................................20
Chapter 4 Installation
Step 1: Prepare the Site.......................................................................................23
Step 2: Protect Against Electrostatic Discharge...................................................23
Step 3: Unpack the Switch...................................................................................24
Step 4: Install the Switch......................................................................................25
Install the Switch in a Rack.............................................................................25
Install the Switch on a Flat Surface.................................................................26
Optional Step 5: Install an SFP Transceiver Module............................................26
Step 6: Connect Devices to the Switch................................................................27
Step 7: Check the Installation..............................................................................27
Step 8: Apply Power and Check the LEDs...........................................................28
Step 9: Manage the Switch..................................................................................28
Chapter 5Troubleshooting
Troubleshooting Chart..........................................................................................30
PoE Troubleshooting Suggestions.......................................................................30
Additional Troubleshooting Suggestions..............................................................31
3

1
Introduction
This hardware installation guide is for the following NETGEAR switch models:
•8-Port Multi-Gigabit Smart Managed Pro Switch with two 10G Ports, Model MS510TX
•8-Port Multi-Gigabit Smart Managed Pro Switch with PoE+ and two 10G Ports, Model MS510TXPP
The switch provides four multispeed Gigabit Ethernet and four 1G Ethernet RJ-45 copper ports with one dedicated
10G RJ-45 copper uplink port and one dedicated SFP+ fiber uplink port that supports 10G and 1G.Two of the
four multispeed ports support 5G, 2.5G, and 1G.The other two multispeed ports support 2.5G and 1G. (The
10G RJ-45 copper uplink port also supports 5G, 2.5G and 1G.)
Model MS510TXPP supports Power over Ethernet plus (PoE+) on all four multispeed ports and four 1G ports
so that you can let the switch provide power to PoE-capable devices such as WiFi access points,VoIP phones,
and IP security cameras.Model MS510TXPP can supply up to 30W PoE+ (IEEE 802.3at) to each port, with a
maximum PoE power budget of 180W across all active PoE+ ports.
This hardware installation guide complements the installation guide that came with your switch.The resource
CD that came with your switch includes software and additional documentation and support resources.
This chapter serves as an introduction to the switch and includes the following sections:
•Overview
•Features
•Safety Instructions and Warnings
For more information about the topics that are covered in this manual, visit the support website
at support.netgear.com.
Note
For technical specifications, see the data sheet at
netgear.com/business/products/switches/managed. For switch documentation, see the
resource CD in the product package or visit downloadcenter.netgear.com.
Note
4

Overview
The switch provides two multispeed gigabit copper ports that support 5G, 2.5G, and 1G; another two
multispeed gigabit copper ports that support 2.5G and 1G; four 1G RJ-45 copper ports;one dedicated 10G
copper uplink port (which also supports 5G, 2.5G and 1G); and one dedicated SFP+ fiber uplink port that
supports 10G and 1G. All copper ports use RJ-45 connectors.
The SFP+ port requires a standard small form-factor pluggable (SFP) gigabit interface converter (GBIC,
also referred to as a transceiver module), which is sold separately from the switch.The switch integrates
78 Gbps full-duplex, nonblocking switch fabric for high-performance workgroups.
The PoE model supports PoE+ on all copper ports (except for the 10G uplink port) with a maximum PoE
power budget of 180W across all active PoE+ ports.
For information about application examples, see Applications on page 18.Note
The switch provides administrative management options that let you configure, monitor, and control the
network.Using the web browser–based management interface, you can configure the switch and the network,
including the ports, the managementVLAN,VLANs for traffic control, link aggregation for increased bandwidth,
Quality of Service (QoS) for prioritizing traffic, and network security.
Initial discovery of the switch on the network requires the Smart Control Center program, which runs on a
Windows-based computer and is included on the resource CD.If you do not use aWindows-based computer,
get the IP address of the switch from the DHCP server in the network or use an IP scanner utility.
After discovery, you can configure the switch using the web management interface for advanced setup and
configuration of features, or the Smart Control Center program for very basic setup.For more information,
see the user manual, which you can download from downloadcenter.netgear.com.
You can install the switch freestanding or rack mounted in a wiring closet or equipment room.The switch
is IEEE compliant and offers low latency. All ports can automatically negotiate to the highest speed, which
makes the switch very suitable for a mixed environment with multispeed Gigabit Ethernet, Gigabit Ethernet,
and Fast Ethernet.
Forspeeds of10Gbps andhigherspeeds,use Category 6(Cat 6) cablesterminated with RJ-45connectors;
for speeds from 5 Gbps to 10 Gbps, use Cat 5e cables terminated with RJ-45 connectors; and for speeds
from 10 Mbps to 5 Gbps, including 2.5 Gbps, use Cat 5e or higher-rated Ethernet cables terminated with
RJ-45 connectors.
Features
The switch supports the following key hardware features:
•Two 5G Ethernet ports (which also support 2.5G and 1G).
•Two 2.5G Ethernet ports (which also support 1G).
•Four 1G Ethernet ports.
•1 dedicated 10G Ethernet uplink port (which also supports 5G, 2.5G and 1G).
•1 dedicated SFP+ fiber uplink port capable of 10G.(The port also supports 1G.)
•1 USB port for configuration and firmware backup and upgrade.
Introduction
5
8-Port Multi-Gigabit Smart Managed Pro Switch with two 10G Ports

•PoE support (model MS510TXPP):
-8 PoE+ (802.3at) ports
-Total PoE power budget of 180W for the switch
•MAC table size of 16K.
•Variable-speed fan that can lower the noise level during low temperatures.
•Acoustic noise is equal to or less than 30 dBA at 25°C.
•78 Gbps full-duplex, nonblocking switch fabric.
•Includes 19-inch rack-mount kit for rack installation.
•Full compatibility with IEEE standards:
-IEEE 802.3 Ethernet
-IEEE 802.3u 100BASE-T
-IEEE 802.3z Gigabit Ethernet 1000BASE-SX/LX
-IEEE 802.3bz NBASE-T and MGBASE-T
-IEEE 802.3an (10GBASE-T)
-IEEE 802.3ae 10-Gigabit Ethernet over fiber (10GBASE-SR, 10GBASE-LR)
-IEEE 802.3ab 1000BASE-T
-IEEE 802.3i 10BASE-T
-IEEE 802.1Q VLAN tagging
-IEEE 802.3x Full-duplex flow control
-IEEE 802.3ad Link aggregation (LAG with LACP)
-IEEE 802.1ab LLDP
-IEEE 802.1p Class of Service (QoS)
-IEEE 802.1D Spanning Tree Protocol (STP)
-IEEE 802.1s Multiple Spanning Tree Protocol (MSTP)
-IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)
-IEEE 802.1x RADIUS network access control
-IEEE 802.3az Energy Efficient Ethernet (EEE)
-IEEE 802.1af (PoE)
-IEEE 802.1at (PoE+)
•AutoSensing and autonegotiating capabilities for all ports.
•Auto Uplink™technology is supported on all ports.
•Automatic address learning function to build the packet-forwarding information table.The table contains
up to 16K Media Access Control (MAC) addresses.
•Store-and-forward transmission to remove bad packets from the network.
Introduction
6
8-Port Multi-Gigabit Smart Managed Pro Switch with two 10G Ports

•Active flow control to minimize packet loss and frame drops.
•Half-duplex backpressure control.
•Per-port status LEDs and system status LEDs.
•NETGEAR green power-saving features:
-Energy efficiency mode that fully conforms to the IEEE802.3az standard
-Per-port automatic change to a lower power mode when the port link is down
Safety Instructions andWarnings
Use the following safety guidelines to ensure your own personal safety and to help protect your system from
potential damage.
To reduce the risk of bodily injury, electrical shock, fire, and damage to the equipment, observe the following
precautions:
•This product is designed for indoor use only in a temperature-controlled (0–50°C) and humidity-controlled
(90 percent maximum relative humidity, noncondensing) environment.
Any device that is located outdoors and connected to this product must be properly grounded and surge
protected.
To the extend permissible by applicable law, failure to follow these guidelines could result in damage
to your NETGEAR product, which might not be covered by NETGEAR’s warranty.
•Observe and follow service markings:
-Do not service any product except as explained in your system documentation.
-Opening or removing covers that are marked with the triangular symbol with a lightning bolt can
expose you to electrical shock.We recommend that only a trained technician services components
inside these compartments.
•If any of the following conditions occur, unplug the product from the electrical outlet and replace the part
or contact your trained service provider:
-The power cable, extension cable, or plug is damaged.
-An object fell into the product.
-The product was exposed to water.
-The product was dropped or damaged.
-The product does not operate correctly when you follow the operating instructions.
•Keep your system away from radiators and heat sources.Also, do not block cooling vents.
•Do not spill food or liquids on your system components, and never operate the product in a wet
environment.If the system gets wet, see the appropriate section in your troubleshooting guide, or contact
your trained service provider.
•Do not push any objects into the openings of your system.Doing so can cause fire or electric shock by
shorting out interior components.
Introduction
7
8-Port Multi-Gigabit Smart Managed Pro Switch with two 10G Ports

•Use the product only with approved equipment.
•Allow the product to cool before removing covers or touching internal components.
•Operate the product only from the type of external power source indicated on the electrical ratings label.
If you are not sure of the type of power source required, consult your service provider or local power
company.
•To avoid damaging your system, be sure that the voltage selection switch (if provided) on the power
supply is set to match the power at your location:
-115V, 60 Hz in most of North and South America and some Far Eastern countries such as South
Korea and Taiwan
-100V, 50 Hz in eastern Japan and 100V, 60 Hz in western Japan
-230V, 50 Hz in most of Europe, the Middle East, and the Far East
•Be sure that attached devices are electrically rated to operate with the power available in your location.
•Use only approved power cables.If you were not provided with a power cable for your system or for
any AC-powered option intended for your system, purchase a power cable approved for your country.
The power cable must be rated for the product and for the voltage and current marked on the product
electrical ratings label.The voltage and current rating of the cable must be greater than the ratings
marked on the product.
•To help prevent electric shock, plug the system and peripheral power cables into properly grounded
electrical outlets.
•The peripheral power cables are equipped with three-prong plugs to help ensure proper grounding.Do
not use adapter plugs or remove the grounding prong from a cable.If you must use an extension cable,
use a three-wire cable with properly grounded plugs.
•Observe extension cable and power strip ratings.Make sure that the total ampere rating of all products
plugged into the extension cable or power strip does not exceed 80 percent of the ampere ratings limit
for the extension cable or power strip.
•To help protect your system from sudden, transient increases and decreases in electrical power, use a
surge suppressor, line conditioner, or uninterruptible power supply (UPS).
•Position system cables and power cables carefully. Route cables so that they cannot be stepped on or
tripped over. Be sure that nothing rests on any cables.
•Do not modify power cables or plugs. Consult a licensed electrician or your power company for site
modifications.
•Always follow your local and national wiring rules.
Introduction
8
8-Port Multi-Gigabit Smart Managed Pro Switch with two 10G Ports

2
Hardware Overview
This chapter describes the switch hardware features.
The chapter includes the following sections:
•Hardware Description
•Switch Hardware Interfaces
9

Hardware Description
This section describes the switch hardware features.
Front Panel
Model MS510TX provides four 1G ports, two 2.5G ports, two 5G ports, one 10G port, and one SFP+ port.
Model MS510TXPP is a PoE+ model that provides four 1G PoE+ ports, two 2.5G PoE+ ports, two 5G PoE+
ports, one 10G port, and one SFP+ port.
The following figure shows the front panel of model MS510TX.
Figure 1. Front panel model MS510TX
Table 1. Front panel components model MS510TX
DescriptionNumber
Power LED and Fan LED (see LEDs on page 12).1
Recessed Reset button (see Reset Button on page 16).2
Recessed Factory Defaults button (see Factory Defaults Button on page 17).3
Ports 1, 2, 3, and 4: Four independent 10/100/1000BASE-T RJ-45 ports, each with an LED that
functions as the combined link, speed, and activity LED (see LEDs on page 12).
4
Ports 5 and 6:Two independent 2.5GBASE-T RJ-45 ports (also supporting 100/1000BASE-T), each
with an LED that functions as the combined link, speed, and activity LED (see LEDs on page 12).
5
Port 7 and 8:Two independent 2.5G/5GBASE-T RJ-45 ports (also supporting 100/1000BASE-T),
each with an LED that functions as the combined link, speed, and activity LED (see LEDs on page
12).
6
Port 9: One independent 2.5G/5G/10GBASE-T RJ-45 port (also supporting 100/1000BASE-T) with a
left LED that functions as the combined link, speed, and activity LED (see LEDs on page 12).
7
Port 10: One independent SFP+ port in which you can install transceiver modules (see SFP+ Port for
Fiber Connectivity on page 16).
8
Hardware Overview
10
8-Port Multi-Gigabit Smart Managed Pro Switch with two 10G Ports

Table 1. Front panel components model MS510TX (Continued)
DescriptionNumber
Two LEDs for Port 10.These LEDs indicate link, speed, and activity (see LEDs on page 12).9
USB 2.0 port (see USB Port on page 17).10
The following figure shows the front panel of model MS510TXPP.
Figure 2. Front panel model MS510TXPP
Table 2. Front panel components model MS510TXPP
DescriptionNumber
Power LED, Fan LED, and PoE Max LED (see LEDs on page 12).1
Recessed Reset button (see Reset Button on page 16).2
Recessed Factory Defaults button (see Factory Defaults Button on page 17).3
Ports 1, 2, 3, and 4: Four independent 10/100/1000BASE-T RJ-45 PoE+ ports, each with a left LED
that functions as the combined link, speed, and activity LED; and a right LED that provides PoE
information (see LEDs on page 12).
4
Ports 5 and 6:Two independent 2.5GBASE-T RJ-45 PoE+ ports (also supporting 100/1000BASE-T),
each with a left LED that functions as the combined link, speed, and activity LED; and a right LED
that provides PoE information (see LEDs on page 12).
5
Port 7 and 8:Two independent 2.5G/5GBASE-T RJ-45 PoE+ ports (also supporting 100/1000BASE-T),
each with a left LED that functions as the combined link, speed, and activity LED; and a right LED
that provides PoE information (see LEDs on page 12).
6
Port 9: One independent 2.5G/5G/10GBASE-T RJ-45 port (also supporting 100/1000BASE-T) with a
left LED that functions as the combined link, speed, and activity LED (see LEDs on page 12).
7
Port 10: One independent SFP+ port in which you can install transceiver modules (see SFP+ Port for
Fiber Connectivity on page 16).
8
Hardware Overview
11
8-Port Multi-Gigabit Smart Managed Pro Switch with two 10G Ports

Table 2. Front panel components model MS510TXPP (Continued)
DescriptionNumber
Two LEDs for Port 10.These LEDs indicate link, speed, and activity (see LEDs on page 12).9
USB 2.0 port (see USB Port on page 17).10
Back Panel
The switch integrates a fixed, internal power supply unit (PSU).
The back panel contains a Kensington lock slot, a console port that is not for customer use (it is for NETGEAR
technical support only), and the AC power connector.
Figure 3. Back panel
LEDs
This section describes the LED designations of the switch.
The following table describes the LEDs on the front panel of model MS510TX.Ports 1–9 come with a single
LED each. Port 10 comes with two LEDs.
Table 3. LEDs on the front panel of model MS510TX
DescriptionLED
Solid green.The device is powered on.
Solid yellow.The device is booting.
Off. Power is not supplied to the device.
Power LED
Solid green.The fan is operating normally.
Solid yellow.A problem occurred with the fan.
Fan LED
Off. No link is established.
Solid green. A valid 1000 Mbps link is established.
Blinking green.The port is transmitting or receiving packets at 1000 Mbps.
Solid yellow.A valid 10 Mbps or 100 Mbps link is established.
Blinking yellow.The port is transmitting or receiving packets at 10 Mbps or
100 Mbps.
1G Ports 1–4 LEDs
Link, speed, and activity
Hardware Overview
12
8-Port Multi-Gigabit Smart Managed Pro Switch with two 10G Ports

Table 3. LEDs on the front panel of model MS510TX (Continued)
DescriptionLED
Off. No link is established.
Solid green. A valid 2.5 Gbps link is established.
Blinking green.The port is transmitting or receiving packets at 2.5 Gbps.
Solid yellow.A valid 100 Mbps or 1000 Mbps link is established.
Blinking yellow.The port is transmitting or receiving packets at 100 Mbps or
1000 Mbps.
2.5GPorts 5 and6 LEDs
Link, speed, and activity
Off. No link is established.
Solid green. A valid 2.5 Gbps or 5 Gbps link is established.
Blinking green.The port is transmitting or receiving packets at 2.5 Gbps or 5 Gbps.
Solid yellow.A valid 100 Mbps or 1000 Mbps link is established.
Blinking yellow.The port is transmitting or receiving packets at 100 Mbps or
1000 Mbps.
5G Ports 7 and 8 LEDs
Link, speed, and activity
Off. No link is established.
Solid green. A valid 10 Gbps link is established.
Blinking green.The port is transmitting or receiving packets at 10 Gbps.
Solid yellow.A valid 5 Gbps, 2.5 Gbps, 1000 Mbps, or 100 Mbps link is established.
Blinking yellow.The port is transmitting or receiving packets at 5 Gbps, 2.5 Gbps,
1000 Mbps, or 100 Mbps.
10G Port 9, LED
Link, speed, and activity
Off. No SFP+ module link is established on the fiber port.
Left LED solid green.The fiber port established a valid 10 Gbps link.
Left LED blinking green.The fiber port is transmitting or receiving packets at
10 Gbps.
Right LED solid yellow.The fiber port established a valid 1 Gbps link.
Right LED blinking yellow.The fiber port is transmitting or receiving packets at
1 Gbps.
SFP+ Port 10, LEDs
Link, speed, and activity
The following table describes the LEDs on the front panel of model MS510TXPP. Ports 1–8 come with a
left LED and a right LED each. Port 9 comes with a single LED. Port 10 comes with two LEDs.
Table 4. LEDs on the front panel of model MS510TXPP
DescriptionLED
Solid green.The device is powered on.
Solid yellow.The device is booting.
Off. Power is not supplied to the device.
Power LED
Solid green.The fan is operating normally.
Solid yellow.A problem occurred with the fan.
Fan LED
Hardware Overview
13
8-Port Multi-Gigabit Smart Managed Pro Switch with two 10G Ports

Table 4. LEDs on the front panel of model MS510TXPP (Continued)
DescriptionLED
Off. More than 7W of PoE power is available.
Solid yellow.Less than 7W of PoE power is available.
Blinking yellow.The PoE Max LED was active in the previous two minutes.
PoE Max LED
Off. No link is established.
Solid green. A valid 1000 Mbps link is established.
Blinking green.The port is transmitting or receiving packets at 1000 Mbps.
Solid yellow.A valid 10 Mbps or 100 Mbps link is established.
Blinking yellow.The port is transmitting or receiving packets at 10 Mbps or 100 Mbps.
1G Ports 1–4, Left LEDs
Link, speed, and activity
Off.The port is not delivering PoE.
Solid green.The port is delivering PoE.
Solid yellow.A PoE fault occurred. For more information, see PoE Troubleshooting
Suggestions on page 30.
1G Ports 1–4, Right
LEDs
PoE status
Off. No link is established.
Solid green. A valid 2.5 Gbps link is established.
Blinking green.The port is transmitting or receiving packets at 2.5 Gbps.
Solid yellow.A valid 100 Mbps or 1000 Mbps link is established.
Blinking yellow.The port is transmitting or receiving packets at 100 Mbps or
1000 Mbps.
2.5G Ports 5 and 6, Left
LEDs
Link, speed, and activity
Off.The port is not delivering PoE.
Solid green.The port is delivering PoE.
Solid yellow.A PoE fault occurred. For more information, see PoE Troubleshooting
Suggestions on page 30.
2.5G Ports 5 and 6,
Right LEDs
PoE status
Off. No link is established.
Solid green. A valid 2.5 Gbps or 5 Gbps link is established.
Blinking green.The port is transmitting or receiving packets at 2.5 Gbps or 5 Gbps.
Solid yellow.A valid 100 Mbps or 1000 Mbps link is established.
Blinking yellow.The port is transmitting or receiving packets at 100 Mbps or
1000 Mbps.
5G Ports 7 and 8, Left
LEDs
Link, speed, and activity
Off.The port is not delivering PoE.
Solid green.The port is delivering PoE.
Solid yellow.A PoE fault occurred. For more information, see PoE Troubleshooting
Suggestions on page 30.
5G Ports 7 and 8, Right
LEDs
PoE status
Hardware Overview
14
8-Port Multi-Gigabit Smart Managed Pro Switch with two 10G Ports

Table 4. LEDs on the front panel of model MS510TXPP (Continued)
DescriptionLED
Off. No link is established.
Solid green. A valid 10 Gbps link is established.
Blinking green.The port is transmitting or receiving packets at 10 Gbps.
Solid yellow.A valid 5 Gbps, 2.5 Gbps, 1000 Mbps, or 100 Mbps link is established.
Blinking yellow.The port is transmitting or receiving packets at 5 Gbps, 2.5 Gbps,
1000 Mbps, or 100 Mbps.
10G Port 9, LED
Link, speed, and activity
Off. No SFP+ module link is established on the fiber port.
Left LED solid green.The fiber port established a valid 10 Gbps link.
Left LED blinking green.The fiber port is transmitting or receiving packets at
10 Gbps.
Right LED solid yellow.The fiber port established a valid 1 Gbps link.
Right LED blinking yellow.The fiber port is transmitting or receiving packets at
1 Gbps.
SFP+ Port 10, LEDs
Link, speed, and activity
Switch Hardware Interfaces
The following sections describe the hardware interfaces on the switch.
RJ-45 Ports for 10/100/1000M and 2.5G/5G/10G BASE-T Ethernet
Connectivity
All RJ-45 copper ports support autosensing.When you insert a cable into an RJ-45 port, the switch
automatically ascertains the maximum speed. Depending on the port, the switch can autodetect 10 Mbps,
100 Mbps, or 1 Gbps and duplex mode (half-duplex or full-duplex), or 2.5 Gbps, 5 Gbps, or 10 Gbps of the
attached device.All ports support Ethernet cables that are terminated with 8-pin RJ-45 connectors.The
following table describes the network cables that you can use for the switch connections and the speeds
that these cables can support.
Table 5. Network cables and supported speeds
Supported SpeedsCableType
Speeds from 10 Mbps to 5 Gbps, including 2.5 GbpsCategory 5 (Cat 5)
Speeds from 5 Gbps to 10 GbpsCategory 5e (Cat 5e)
Speeds of 10 Gbps and higher speedsCategory 6 (Cat 6)
To simplify the procedure for attaching devices, all RJ-45 ports support Auto Uplink technology.This
technology allows attaching devices to the RJ-45 ports with either straight-through or crossover cables.
Hardware Overview
15
8-Port Multi-Gigabit Smart Managed Pro Switch with two 10G Ports

When you insert a cable into the switch’s RJ-45 port, the switch automatically performs the following actions:
•Senses whether the cable is a straight-through or crossover cable.
•Determines whether the link to the attached device requires a normal connection (such as when you
are connecting the port to a computer) or an uplink connection (such as when you are connecting the
port to a router, switch, or hub).
•Automatically configures the RJ-45 port to enable communications with the attached device.The Auto
Uplink technology compensates for setting uplink connections while eliminating concern about whether
to use crossover or straight-through cables when you attach devices.
For model MS510TXPP, copper ports 1 through 8 also support Power over Ethernet (PoE+).
SFP+ Port for Fiber Connectivity
To enable fiber connections on the switch, SFP+ fiber ports accommodate standard small form-factor
pluggable (SFP) gigabit interface converters (GBICs, also referred to as transceiver modules) for fiber
connectivity. GBICs are sold separately from the switch.
The switch supports the NETGEAR SFP and SFP+ transceiver modules and cables that are listed in the
following table.
Table 6. Supported SFP and SFP+ transceiver modules and cables
DescriptionModelSpeed and Medium
SFP Transceiver 1000BASE-SXAGM731F1G Ethernet short-reach fiber
SFP Transceiver 1000BASE-LXAGM732F1G Ethernet long-reach fiber
SFP Transceiver 1000BASE-TAGM7341G Ethernet copper
SFP+ Transceiver 10GBASE-SRAXM76110G Ethernet short-reach fiber
SFP+ Transceiver 10GBASE-LRAXM76210G Ethernet long-reach fiber
SFP+ Direct Attach Cable (DAC), 1 meterAXC76110G Ethernet
SFP+ Direct Attach Cable (DAC), 3 metersAXC76310G Ethernet
For more information about NETGEAR SFP and SFP+ transceiver modules and cables, visit
netgear.com/business/products/switches/modules-accessories.
Reset Button
The switch provides a Reset button on the front panel so that you can reboot the switch. Save the
configuration before you press the Reset button.
To reboot the switch:
1. Insert a device such as a straightened paper clip into the opening.
2. Press the recessed Reset button.
Hardware Overview
16
8-Port Multi-Gigabit Smart Managed Pro Switch with two 10G Ports

The switch reboots.
Factory Defaults Button
To return the switch to its factory default settings:
1. Insert a device such as a straightened paper clip into the opening.
2. Press the recessed Factory Defaults button for more than three seconds.
The switch reboots and returns to its factory default settings.
USB Port
The switch provides one USB 2.0 port that lets you upgrade firmware from a disk and back up the configuration
to a storage device.
A device that you attach to the USB port must comply with the following requirements:
•The USB device must support USB 2.0.
•The USB device must support the FAT32 file type.The NTFS file type is not supported.
Hardware Overview
17
8-Port Multi-Gigabit Smart Managed Pro Switch with two 10G Ports

3
Applications
The switch is designed to provide flexibility in configuring multispeed network connections.This chapter shows
application examples with 5G, 2.5G, and 1G connections and, for model MS510TXPP, multispeed PoE+
connections.
The chapter includes the following sections:
•Multispeed Backbone Switching
•2.5G Network Storage and Redundancy
•Multispeed PoE+ Access Points
18

Multispeed Backbone Switching
You can use the switch as a multispeed backbone switch in a network that serves network components
such as high-speed servers, a 2.5G NAS, 2.5G (gaming) computers, and 1G computers.
Figure 4. Multi-speed backbone switching
DescriptionLine Color
1G connection to a computerBlack
2.5G connection to a computer with a 2.5G network card, 2.5G connection to a
2.5G NAS, or 5G connection to a high-speed server
Blue
10G uplink to a network router that is connected to the InternetRed
2.5G Network Storage and Redundancy
You can use the switches to provide 2.5G connections and redundancy between 2.5G ReadyNAS storage
platforms and 2.5G or 5G connections to virtual machines or servers.
Applications
19
8-Port Multi-Gigabit Smart Managed Pro Switch with two 10G Ports

Figure 5. High-speed network storage switching in a redundant configuration
DescriptionLine Color
2.5G connection to a 2.5G NAS and to a redundant 2.5G NASRed
2.5G connection to a 2.5G NAS and to a redundant 2.5G NASYellow
2.5G or 5G connection to a virtual machine or server and to a redundant virtual
machine or server
Blue
2.5G or 5G connection to a virtual machine or server and to a redundant virtual
machine or server
Green
Multispeed PoE+ Access Points
Model MS510TXPP supports 8 PoE+ ports.The switch can supply up to 30W PoE+ (IEEE 802.3at) to each
port up to its total maximum PoE power budget of 180W across all active PoE+ ports.
Supplied power is prioritized according to the port order, up to the total power budget of the device.Port 1
receives the highest PoE priority, while port 8 is relegated to the lowest PoE priority.
If the power requirements for attached devices exceed the total power budget of the switch, the PoE power
to the device on the highest-numbered active PoE port is disabled to make sure that the devices connected
to the higher-priority, lower-numbered PoE ports are supported first.
Although a device is listed as an 802.3at PoE+-powered or 802.3af PoE-powered
device, it might not require the maximum power limit that is specified by its IEEE
standard. Many devices require less power, allowing all 8 PoE+ ports to be active
simultaneously when the devices correctly report their PoE class to the switch.
Note
Applications
20
8-Port Multi-Gigabit Smart Managed Pro Switch with two 10G Ports
