NETGEAR ProSafe Plus User manual

202-10524-02
February 2010
NETGEAR, Inc.
350 East Plumeria Drive
San Jose, CA 95134
ProSafe®Plus Switch
Configuration Utility User
Guide

ii
1.0 February 2010
© 2010 by NETGEAR, Inc. All rights reserved.
Trademarks
NETGEAR and Auto Uplink are trademarks or registered trademarks of NETGEAR, Inc..
Microsoft, Windows, and Windows NT are registered trademarks of Microsoft Corporation.
Other brand and product names are registered trademarks or trademarks of their respective holders.
Statement of Conditions
In the interest of improving internal design, operational function, and/or reliability, NETGEAR reserves the right to
make changes to the products described in this document without notice.
Product and Publication Details
Model Number: ProSafe® Plus Switches
Publication Date: February 2010
Product Family: ProSafe® Plus Switch
Product Name: ProSafe® Plus Switch Configuration Utility
Home or Business Product: Business
Language: English
Publication Part Number: 202-10524-02
Publication Version Number: 1.0

iii
v1.0, September 2009
Contents
Chapter 1
Getting Started
Installing the Utility ..........................................................................................................1-1
Overview of Utility Features ............................................................................................1-1
Uninstalling the Utility .....................................................................................................1-4
Discovering Switches .....................................................................................................1-5
Overview of Utility Features ............................................................................................1-6
Switch Settings .........................................................................................................1-7
Default Settings ........................................................................................................1-7
Chapter 2
System Configuration
System Features ............................................................................................................2-2
Status .............................................................................................................................2-2
Switch Selection .......................................................................................................2-2
Switch Information ....................................................................................................2-3
DHCP Mode Selection .............................................................................................2-3
Manually Setting the IP Address Information ...........................................................2-4
Maintenance ...................................................................................................................2-4
Change Password ....................................................................................................2-4
Device Reboot ..........................................................................................................2-4
Reset Factory Defaults .............................................................................................2-5
Firmware Upgrade ...................................................................................................2-5
Monitoring .......................................................................................................................2-5
Port Statistics ...........................................................................................................2-5
Port Mirroring ...........................................................................................................2-5
Cable Test ................................................................................................................2-6

iv
v1.0, September 2009
Chapter 3
Virtual LAN Configuration
Port Based Configuration ...............................................................................................3-1
Basic Port Based Configuration ...............................................................................3-1
Advanced Port Based Configuration ........................................................................3-2
802.1Q Based Configuration ..........................................................................................3-2
Basic 802.1Q Based Configuration ..........................................................................3-2
Advanced 802.1Q Based Configuration ...................................................................3-2
VLAN Configuration ...........................................................................................3-3
VLAN Membership ............................................................................................3-3
Port PVID ...........................................................................................................3-4
Port Tagging ......................................................................................................3-4
Chapter 4
Quality of Service Configuration
QoS Global Configuration ...............................................................................................4-2
Port Based Priority ...................................................................................................4-2
802.1p Based Priority ...............................................................................................4-3
Rate Limiting ...................................................................................................................4-4
Broadcast Filtering ..........................................................................................................4-4
Chapter 5
Help
Online Help .....................................................................................................................5-1
User Guide ...............................................................................................................5-1
Support Information ..................................................................................................5-1
About the Utility ...............................................................................................................5-2

i
v1.0, February 2010
About This Manual
The ProSafe® Plus Switch Configuration Utility User Guide describes how to use the Switch
Configuration Utility. The information in this manual is intended for readers with intermediate
computer and internet skills.
Conventions, Formats, Scope, and Audience
The conventions, formats, and scope of this manual are described in the following paragraphs:
•Typographical Conventions.This manual uses the following typographical conventions
•Formats.This manual uses the following formats to highlight special messages:
Note: Product updates are available on the NETGEAR website at http://
kbserver.netgear.com.
Italic Emphasis, books, CDs, file and server names, extensions
Bold User input, IP addresses, GUI screen text
Fixed Command prompt, text, code
italic URL links
Note: This format is used to highlight information of importance or special interest.
Tip: This format is used to highlight a procedure that will save time or resources.

1.0 February 2010
ii
•Scope.This manual is written for the switch utility according to these specifications:
This document provides examples of the use of the management utility in a typical network.
•Audience. Use this guide if you have at least intermediate computer and internet skills and are
responsible for configuring and operating a network with ProSafe®Plus switches.
To obtain the greatest benefit from this guide, you should have a basic knowledge of
networking concepts.
Additional Documentation
Before proceeding, read the Installation Guides for the ProSafe®Plus Switches used in your
network. These documents may be found at: http://www.NETGEAR.com.
How to Print This Manual
Your computer must have the free Adobe Acrobat reader installed in order to view and print PDF
files. The Acrobat reader is available on the Adobe Web site at
http://www.adobe.com.
Revision History
Product ProSafe®Plus Switch Configuration Utility
Manual Publication Date February 2010
Tip: If your printer supports printing two pages on a single sheet of paper, you can
save paper and printer ink by selecting this feature.
Part Number Version
Number Description
202-10524-02 1.0 ProSafe®Plus Switch Configuration Utility User Guide

1-1
v1.0, February 2010
Chapter 1
Getting Started
In order to make use of the enhanced features on ProSafe®Plus switches you can install and use the
ProSafe®Plus Switch Configuration Utility. The utility is on the Resource CD shipped with ProSafe®Plus
switches.
Installing the Utility
If an earlier version of the utility is already present on the PC, it will be replaced by the newer version.
Newer versions of the utility are backwards compatible and support all previously released ProSafe® Plus
switches. If the version of the utility you are trying to install is older than the one already installed on the PC,
the installation will not be performed.
If you have not already installed the utility, install it now. To install the utility:
1. Insert the switch Resource CD into the PC that you want to use to manage your switches. The Resource
CD home page will display.
Note: The utility must be installed on a PC in the network containing the switches to be managed
and is only supported on MS Windows.
Note: You can install the utility on any Windows PC(s) connected to the network containing the
switches to be managed.

ProSafe®Plus Switch Configuration Utility User Guide
1-2 Getting Started
v1.0, February 2010
2. Resource CD pages and the installation guide for the switch can be displayed in several languages. A
pull down menu for language selection is in the upper right corner of the Resource CD home screen.
3. Click on Install ProSafe®Plus Utility to install the utility program on your PC.

ProSafe®Plus Switch Configuration Utility User Guide
Getting Started 1-3
v1.0, February 2010
Note: If the Resource CD home page does not display, your PC may have the Autorun feature disabled. You
can enable your PC’s Autorun feature or use the PC’s file manager to navigate to the CD and double
click on Autorun.exe.
Note: The name of the utility may vary slightly for different ProSafe® Plus switch models.
The utility uses two network programs, WinPcap and Adobe AIR to process network commands. If not
already installed on your PC, these two programs will also be installed. They will be placed in your program
directory.
4. Click Install Utility. This will create a NetGear subdirectory under the \Program Files directory on
your PC. Installation then copies the utility program into the \Program Files\NetGear\ProSafe Plus
Utility directory and places a utility icon ( ) on the PC desktop.
5. The WinPcap and Adobe AIR programs can be used by other network applications and may already be
installed on your PC. If so, a message will be displayed asking if you want to reinstall WinPcap. Click
Cancel unless you think the installed WinPcap is an older version or might be corrupted. Clicking
Cancel will end the WinPcap portion of installation and will continue installing the remaining
components.
6. If the Adobe AIR program is already installed, an already installed message will be displayed. Clicking
Close will end the Adobe AIR portion of installation.
7. When the InstallShield Wizard Complete screen displays you can check a box to launch the utility
following installation. If you do not want to launch the utility at this time, just click Finish.
8. Installation is complete. If you checked the “Launch following installation” box, the utility will
automatically start. If not, you can launch the utility by clicking on the utility icon on your desktop.
Autorun

ProSafe®Plus Switch Configuration Utility User Guide
1-4 Getting Started
v1.0, February 2010
Uninstalling the Utility
To uninstall the utility:
1. Use your PC’s Add or Remove Programs command, Start > Control Panel > Add or Remove
Programs.
2. Select ProSafe Plus Utility and click Change/Remove.
3. When you are asked if you want to completely remove the selected application, click Yes.
4. You can also remove the WinPcap and AIR programs if they are not needed by another program.
.

ProSafe®Plus Switch Configuration Utility User Guide
Getting Started 1-5
v1.0, February 2010
Discovering Switches
When the utility is launched, it immediately searches the network for ProSafe®Plus switches.
Note: Local PC firewall applications such as Symantec Endpoint Protection can prevent the utility from
communicating with the switches. If the utility is unable to discover your switches and you are using a
local firewall, you will need to turn off the firewall function in order for discovery to work.
Within a few seconds the utility will discover and list all ProSafe®Plus switches in your network or in the
same broadcast domain. Discovery will continue through the network until blocked by a router or firewall.
The discovered switches are displayed as shown below.
You can now select a switch to configure or display status.
Note: At this point you can select an alternate language for the Utility user interface. Click on the Select
Language pull down menu and click on the desired language. You will be asked to restart the Utility
to enable the selected language.

ProSafe®Plus Switch Configuration Utility User Guide
1-6 Getting Started
v1.0, February 2010
Overview of Utility Features
The utility configures switch features and provides status and support information. The features are arranged
on tabs as shown in the following figure:
System (General Configuration and Information)
Status - indicates which switches are present and if they are operational. If your switch supports the switch
information feature you can display additional information such as IP Address, Subnet Mask, and Gateway
Address.
Maintenance - allows you to change administrator password, reboot the switch, reset to factory default
settings, and if your switch supports it, upgrade switch firmware.
Monitoring - displays port statistics (packets sent or received), tests cable connections, and allows you to
mirror ports.
VLAN (Virtual LAN networks)
Port Based - allows you to assign ports to virtual networks.
802.1Q - allows you to create virtual networks using 802.1Q criteria.
QoS (Quality of Service)
Port based - allows you to assign communication priorities to ports.
802.1p based - uses communication priorities from 802.1p tags in the data.
Rate Limit - allows you to set maximum data rates for ports.
Broadcast Filtering - protects your network from broadcast packet storms that can interfere with the
processing of normal data.
Help
Online Help - online access to technical support information and this manual.
About - version information.

ProSafe®Plus Switch Configuration Utility User Guide
Getting Started 1-7
v1.0, February 2010
Note: It is possible that you can make port settings that will block further access to the switch you are
configuring. If this occurs you can reset the switch manually to restore access. Your previous settings
will be lost.
Switch Settings
The features on each tab are explained in the following chapters:
Chapter 2 System Configuration - describes general management features
Chapter 3 Virtual LAN Configuration - describes how to create and configure VLAN groups
Chapter 4 Quality of Service (QoS) - describes how to set data priorities using Global Configuration, Rate
Limiting, and Broadcast filtering
Chapter 5 Help - describes how to get online support information

ProSafe®Plus Switch Configuration Utility User Guide
1-8 Getting Started
v1.0, February 2010
Default Settings
All of the ProSafe® Plus Switch features have default settings. You do not need to configure any settings in
order to use the ProSafe®Plus switches.
The following table lists the default values for switch settings. Shaded features are not configurable on all
switches.
Table 1-1. Feature Default Values
Tab Menu Feature Default Value
System
Status
Switch Selection No switch selected
Names All names blank
Passwords “password” for all switches
Switch Information
DHCP Mode Enabled
IP Address 192.168.0.239
Subnet Mask 255.255.255.0
Gateway Address 192.168.0.254
Maintenance
Change Password All fields blank
Device Reboot Unchecked
Factory Default Unchecked
Firmware Upgrade Filename blank
Monitoring
Port Statistics 0
Mirroring Disabled
Cable Tester OK or No Cable for each port

ProSafe®Plus Switch Configuration Utility User Guide
Getting Started 1-9
v1.0, February 2010
VLAN
Port Based
Basic Disabled
Advanced Disabled
802.1Q
Basic Disabled
Advanced Disabled
QoS
QoS
Global Configuration
QoS Mode Port based
Port Priority Low priority for each port
Rate Limit
Ingress No limit
Egress No limit
Broadcast Filtering Disabled
Help
Online Help
Support -
User Guide -
About the Utility About the Utility -
Table 1-1. Feature Default Values
Tab Menu Feature Default Value

ProSafe®Plus Switch Configuration Utility User Guide
1-10 Getting Started
v1.0, February 2010

2-1
v1.0, February 2010
Chapter 2
System Configuration
The System tab lets you select a switch to manage, display general information about the switch, perform
basic switch maintenance, and monitor data flow through the switch.
System features are:
Status - indicates which switches are present and if they are operational.
Maintenance - allows you to change administrator password, reboot the switch, reset to factory default
settings and if the feature is available on the selected switch, upgrade switch firmware.
Monitoring - displays port statistics (packets sent or received), tests cable connections, and allows you to
mirror ports.
All of the features have default settings. You do not need to configure any settings in order to use the
ProSafe®Plus switches. Refer to “Default Settings” on page 1-8 for a list of default system settings.

ProSafe®Plus Switch Configuration Utility User Guide
2-2 System Configuration
v1.0, February 2010
System Features
Table 2-1 lists features available on the System tab.
The Switch Selection remains in effect until you select a different switch or quit the utility.
Status
The Status menu allows you to select a switch and display switch information.
Switch Selection
In order to use any of the System tab features you must first select a switch. Click on the radio button for the
desired switch. You will be asked to enter the password for the selected switch. The default password for all
switches is “password”. When you enter the switch password and click on Login, the port status for the
switch will be displayed. You can then select Switch Information for additional switch status, or select
Maintenance, or Monitoring for other switch features. When you select a switch, the Status menu displays
the status (up or down) of the ports on the switch and the speed of the device connected to the port. The
switch automatically senses the speed of the device connected to each port.
Table 2-1. System Tab Features
Feature Description
Status
Switch Selection Selects a switch to configure
Switch Information Displays general information for the selected switch
Maintenance
Change Password Changes password for the selected switch
Device Reboot Restarts the selected switch using configured settings
Factory Default Restarts the selected switch with factory default settings
Firmware Upgrade Updates the selected switch with a firmware update saved on the PC
Monitoring
Port Statistics Displays port network traffic for the selected switch
Mirroring Allows a port to receive data sent to another port
Cable Tester Checks cable connections for the ports of the selected switch

ProSafe®Plus Switch Configuration Utility User Guide
System Configuration 2-3
v1.0, February 2010
You can assign a name to the selected switch by entering the name in the Switch Name field.The switch
name can be up to 20 characters. The switch is updated with a new name when you press the Enter key
before leaving the Switch Name field.
Switch Information
The Switch Information feature displays additional information about the selected switch. This information
will vary depending on the model of the selected switch. If the selected switch supports the Switch
Information feature, you can use it to display or configure the IP Address, Subnet Mask, and Gateway
Address.
DHCP Mode Selection
The Switch Information screen contains a field for DHCP (Dynamic Host Configuration Protocol) Mode
selection. When you enable this setting the switch will obtain a network IP address from a DHCP server in
the network. Each time the switch is powered on or reset, it will request an IP address from a DHCP Server
in the Network. This is called a Dynamic IP address. If there is no DHCP server in the network, a timeout
message will be displayed. If the switch fails to retrieve an IP address from a DHCP server, a default IP
address of 192.168.0.239 will be entered.
To enable DHCP operation:
1. Select System >Switch Information. The Switch Information screen will display.

ProSafe®Plus Switch Configuration Utility User Guide
2-4 System Configuration
v1.0, February 2010
2. Click the list arrow in the DHCP Mode list box.
3. Select Enable then click Apply.
The IP Address, Subnet Mask, and Gateway Address fields will be disabled (greyed out).
To disable DHCP address assignment, repeat the previous procedure and select Disable. When you click
Apply, you will able to manually enter IP Address, Subnet Mask, and Gateway Address information.
Manually Setting the IP Address Information
You can manually enter IP address and subnet mask values for the switch as well as the address of the
Gateway device to be used by the switch.
To define an IP interface information:
1. Click System > Status > Switch Information. The Switch Information screen displays.
2. Select Disable for the DHCP Mode. The IP Address, Subnet Mask, and Gateway Address fields will
be enabled.
3. Enter the IP Address, Subnet Mask, and if available Gateway Address and click Apply.
Maintenance
The Maintenance feature allows you to change the password for the selected switch, perform a device
reboot, reset the switch to its factory default settings, or upgrade the switch firmware.
Change Password
To change the password for a switch:
1. Select System > Maintenance. The Maintenance menu and Change Password feature will display.
2. Enter the old password (default is “password”) and the new password.
3. Click Apply.
Device Reboot
Warning: Rebooting the switch will briefly disrupt network traffic through the switch.
To reboot the selected switch:
1. Select System > Maintenance > Device Reboot. The Device Reboot dialog will display.
2. Check the box in the Device Reboot dialog.
3. Click Apply.
