NETO M-PANEL User manual

User Manual
Please read instructions carefully

M-PANEL
2
CONTENTS
03 Overview
03 Included Parts
03 Safety Information
04 Description
04 Features
05 Set Up
05 Power
05 Data
05 Rigging
06 Operation
06 Control Panel
08 DMX Personalities
17 Technical Specs
18 Contact Us

3
NETO
INCLUDED ITEMS
• M-Panel
• PowerCon
• Warranty Information
• User Manual
Please inspect package for missing or damaged items and notify NETO
Lighting as soon as possible to receive replacements.
SAFETY INFORMATION
Do not attempt service on unit. Product should only be serviced by qualied
techs. Please respect local laws and regulations governing installation.
• Never look directly into light source in order to prevent injury.
• Always disconnect from the main power source before performing any
type of service.
• Always use a grounded circuit.
• Fixture housing may be very hot while operating. Do not touch the xture
barehanded during its use.
• Always disconnect from main power source and allow 15 minutes to cool
before attempting any type of service.
• Do not plug in when unit is cold. Unit must be at room temperature.
• Product weighs X amount. Ensure rigging used is rated to hold such
weight.
• Make sure there are no ammable materials near the unit while operating
in order to prevent a re hazard.
• Only supply the unit with rated voltages.
• Do not connect xture to a dimmer pack.
• If you notice any damages, do not attempt to operate.
• If malfunctioning, disconnect from main power source immediately.
Contact NETO Lighting.
• Do not operate if ambient temperature reaches over 40° C.
• Not intended for use outdoors or in moisture.
Contact NETO Lighting for all support and technical questions.

M-PANEL
4
DESCRIPTION
The NETO Lighting M-Panel is a versatile 5x5 4-in-1 LCD pixel matrix mounted
on a yoke with innite pan and tilt.
• Art-Net input and output for easier cabling
• Fast and responsive motors for precision control that is always on time
• Large screen display for easy control
• -25 15 Watt RGBW LEDS
• Strong, durable design, ideal for transportation
FEATURES
• 5° lens
• RGBW LED 15w
• Eect macros
• Pre-programmed letters and symbols macros
• Network DMX via Art-Net
• 121, 38, 36, 20 Channel
• Innite pan 16-bit
• Innite tilt 16-bit

5
NETO
SET UP
1 Power
The M-Panel is equipped with an auto-ranging power factor corrected
switch-mode power supply. 100-240 VAC 50/60Hz capable.
Maximum current draw of 3.3A (120V) / 1.7A (230V). Never connect pow-
er to a dimmer pack even if it is set to 100%. If unit does not power on
disconnect from the main power source and check fuse. Fuse rating must
be XXX.
2 Data
Data is daisy chained via the XLR 3-pin connectors. DMX512 low imped-
ance data cabling is recommended for optimal signal transmission.
3 Rigging
The xture comes with a quarter-turn omega bracket for mounting
clamps to base. Never mount a xture in a position that could easily be
knocked over and cause harm to anyone or the xture itself. Only expe-
rienced persons should be rigging xtures overhead. Always use a safety
cable to ensure security. Always verify that the safe working load of the
structure is greater than the total load of xtures on said structure.

M-PANEL
6
OPERATION
1 Control Panel
The M-Panel is equipped with a LED and 4 buttons for easy setup. From here
you can select run modes, manual control, setup, advanced settings, & system
info.
The menu breaks down like this:
Mode Sub Menu Option Description
Address 0-512 Addressing for control via
DMX512
Run Mode
DMX
121CH Full pixel control
38CH Pixel dimmer control
26CH Group control
20CH Macro control
Auto XY Auto01-Auto10 Automatic movement se-
quence
Auto LED LED 01-LED 10 Automatic color sequence
LED SP SP 01-SP 10 Adjusts color change speed
Sound So01-So10 Adjusts sensitivity of sound
mode
Manual
Red Red intensity (0-255)
Green Green intensity (0-255)
Blue Blue intensity (0-255)
White White intensity (0-255)

7
NETO
Mode Sub Menu Option Description
Setup
ProtocolMode DMX Set signal source to XLR
Art-Net Set signal source to ethernet
NetworkSettings
IP Mode Select between Auto, Manual,
or DHCP
Universe Set Universe oset (000-255)
Net Set IP address for Art-Net
Subnet Set subnet for Art-Net
Pan Reverse On Changes Pan orientation
O
Tilt Reverse On Changes Tilt orientation
O
Display On Display always on
O Display will shut o
Screen Rev On Changes screen orientation
O
LED Current
Red
Color oset calibration (10-
255)
Green
Blue
White
Motor Zero Pan Pan oset calibration (0-255)
Tilt Tilt oset calibration (0-255)
Reset Reset xture
Factory Set Restores xture to default
settings
Sys Info Ver Displays rmware version
DMX Address Displays current DMX addresss

M-PANEL
8
2 DMX Personalities
Users have a selection of 4 channel modes: 121, 38, 36, & 20 CH.
View the parameters map below.
20ch 26ch 121ch Function Value Description
Ch 1 Ch 1 Ch 1 Pan 0-255 0-540°
Ch 2 Ch 2 Ch 2 Pan Fine 0-255 Pan Fine
Ch 3 Ch 3 Ch 3 Tilt 0-255 0-270°
Ch 4 Ch 4 Ch 4 Tilt Fine 0-255 Tilt Fine
Ch 5 Ch 5 Ch 5 Pan / Tilt Speed 0-255 Fast to slow
Ch 6 Ch 6 Ch 6 Pan Spin 0-35 No function
36-162 Continuous Rotation CW
163-255 Continuous Rotation CCW
Ch 7 Ch 7 Ch 7 Tilt Spin 0-35 No function
36-162 Continuous Rotation CW
163-255 Continuous Rotation CCW
Ch 8 Ch 8 Ch 8 Built-in Program
(image)
0-47 No function
48-63 Single control
64-79 LED Chase
80-95 LED Run
96-111 LED Jump
112-127 LED Edacity
128-143 LED Grouping
144-159 Sequence 1
160-175 Sequence 2
176-191 Sequence 3
192-207 Sequence 4
208-223 Sequence 5
224-239 Sound Mode
240-245 Sound Mode with move-
ment
246-255 Auto Change sequence

9
NETO
20ch 26ch 121ch Function Value Description
Ch 9 Ch 9 Ch 9 Built-in Program
Speed
0-255 Slow to fast
Ch 10 Ch 10 Ch 10 Built-in Program
Color Macro 1
0-10 No function
11-20 RGBW @ Full
21-30 Red
31-40 Green
41-50 Blue
51-60 White
61-70 Cyan
71-80 Magenta
81-90 Yellow
91-100 Yellow-Green
101-110 Light Blue
111-120 Midnight Blue
121-130 Purple
131-140 Light Purple
141-150 Pink
151-160 Light Red
161-170 Orange
171-180 No Color / Black
181-255 RGBW Color chase (slow
to fast)
Ch 11 Ch 11 Ch 11 Built-in Program
Color Macro 2
0-10 No function
11-20 RGBW @ Full
21-30 Red
31-40 Green
41-50 Blue
51-60 White
61-70 Cyan
71-80 Magenta

M-PANEL
10
20ch 26ch 121ch Function Value Description
81-90 Yellow
91-100 Yellow-Green
101-110 Light Blue
111-120 Midnight Blue
121-130 Purple
131-140 Light Purple
141-150 Pink
151-160 Light Red
161-170 Orange
171-180 No Color / Black
181-255 RGBW Color chase
(slow to fast)
Ch 12 Ch 12 Ch 12 Built-in Program
(Numbers & Symbols)
0-6 No function
7-13 0
14-20 1
21-27 2
28-34 3
35-41 4
42-48 5
49-55 6
56-62 7
63-69 8
70-76 9
77-83 +
84-90 -
91-97 x
98-104 ÷
105-111 /
112-118 <
119-125 >

11
NETO
20ch 26ch 121ch Function Value Description
126-132 ?
133-139 !
140-146 *
147-153 Ó
154-160 #
161-167 Á
168-174 Ç
175-181 i
182-188 Ü
189-195 Ş
196-202 Ö
203-209 Ğ
210-216 (
217-223 )
224-255 Scroll
Ch 13 Ch 13 Ch 13 Built-in Program
(Letters)
0-8 No function
9-17 A
18-26 B
27-35 C
36-44 D
45-53 E
54-62 F
63-71 G
72-80 H
81-89 I
90-98 J
99-107 K
108-116 L
117-125 M
126-134 N

M-PANEL
12
20ch 26ch 121ch Function Value Description
135-143 O
144-152 P
153-161 Q
162-170 R
171-179 S
180-188 T
189-197 U
198-206 V
207-215 W
216-224 X
225-233 Y
234-242 Z
243-255 Scroll
Ch 14 Ch 14 Ch 14 Built-in Program
Rotation
0-31 Head Up
32-63 Head Right
64-95 Head Down
96-127 Head Left
128-191 Continuous Rotation CW
(slow to fast)
192-255 Continuous Rotation CCW
(slow to fast)
Ch 15 Ch 15 Ch 15 LED Strobe 0-255 Slow to fast & random
Ch 16 Ch 16 Ch 16 RGBW Dimmer 0-255 RGBW Intensity (can con-
trol built-in program)
Ch 17 Ch 17 Ch 17 Global Red 0-255 Red intensity (0-100%)
Ch 18 Ch 18 Ch 18 Global Green 0-255 Green intensity (0-100%)
Ch 19 Ch 19 Ch 19 Global Blue 0-255 Blue intensity (0-100%)
Ch 20 Ch 20 Ch 20 Global White 0-255 White intensity (0-100%)
Ch 21 LED Line 1 0-7 LED 1, 2, 3, 4, & 5 ON
Ch 22 LED Line 2 8-15 LED 1 ON
Ch 23 LED Line 3 16-23 LED 2 ON

13
NETO
20ch 26ch 121ch Function Value Description
Ch 24 LED Line 4 24-31 LED 1 & 2 ON
Ch 25 LED Line 5 32-39 LED 3 ON
40-47 LED 1 & 3 ON
48-55 LED 2 & 3 ON
56-63 LED 1, 2, & 3 ON
64-71 LED 4 ON
72-79 LED 1 & 4 ON
80-87 LED 2 & 4 ON
88-95 LED 1, 2, & 4 ON
96-103 LED 3 & 4 ON
104-111 LED 1, 3, & 4 ON
112-119 LED 2, 3, & 4 ON
120-127 LED 1, 2, 3, & 4 ON
128-135 LED 5 ON
136-143 LED 1 & 5 ON
144-151 LED 2 & 5 ON
152-159 LED 1, 2, & 5 ON
160-167 LED 3 & 5 ON
168-175 LED 1, 3, & 5 ON
176-183 LED 2, 3, & 5 ON
184-191 LED 1, 2, 3, & 5 ON
192-199 LED 4 & 5 ON
200-207 LED 1, 4, & 5 ON
208-215 LED 2, 4, & 5 ON
216-223 LED 1, 2, 4, & 5 ON
224-231 LED 3, 4, & 5 ON
232-239 LED 1, 3, 4, & 5 ON
240-247 LED 2, 3, 4, & 5 ON
248-255 No function

M-PANEL
14
20ch 26ch 121ch Function Value Description
Ch 21 Red Color of pixel 0-255 Red intensity (0-100%)
Ch 22 Green Color of pixel 0-255 Green intensity (0-100%)
Ch 23 Blue Color of pixel 0-255 Blue intensity (0-100%)
Ch 24 White Color of pixel 0-255 White intensity (0-100%)
Ch 25 Red Color of pixel 2 0-255 Red intensity (0-100%)
Ch 26 Green Color of pixel 2 0-255 Green intensity (0-100%)
Ch 27 Blue Color of pixel 2 0-255 Blue intensity (0-100%)
Ch 28 White Color of pixel 2 0-255 White intensity (0-100%)
↓ ↓ ↓ ↓
Ch 117 Red Color of pixel 25 0-255 Red intensity (0-100%)
Ch 118 Green Color of pixel 25 0-255 Green intensity (0-100%)
Ch 119 Blue Color of pixel 25 0-255 Blue intensity (0-100%)
Ch 120 White Color of pixel 25 0-255 White intensity (0-100%)
Ch 26 Ch 121 Reset 250-253 Reset xture

15
NETO
38ch Function Value Description
Ch 1 Pan 0-255 0-540°
Ch 2 Pan Fine 0-255 Pan Fine
Ch 3 Tilt 0-255 0-270°
Ch 4 Tilt Fine 0-255 Tilt Fine
Ch 5 Pan / Tilt Speed 0-255 Fast to slow
Ch 6 Pan Spin 0-35 No function
36-162 Continuous Rotation CW
163-255 Continuous Rotation CCW
Ch 7 Tilt Spin 0-35 No function
36-162 Continuous Rotation CW
163-255 Continuous Rotation CCW
Ch 8 LED Strobe 0-255 Slow to fast & random
Ch 9 RGBW Dimmer 0-255 Dark to bright (can control
built-in program)
Ch 10 Global Red 0-255 Red intensity (0-100%)
Ch 11 Global Green 0-255 Green intensity (0-100%)
Ch 12 Global Blue 0-255 Blue intensity (0-100%)
Ch 13 Global White 0-255 White intensity (0-100%)
Ch 14 Pixel 1 0-255 Pixel 1 intensity (0-100%)
Ch 15 Pixel 2 0-255 Pixel 2 intensity (0-100%)
Ch 16 Pixel 3 0-255 Pixel 3 intensity (0-100%)
Ch 17 Pixel 4 0-255 Pixel 4 intensity (0-100%)
Ch 18 Pixel 5 0-255 Pixel 5 intensity (0-100%)
Ch 19 Pixel 6 0-255 Pixel 6 intensity (0-100%)
Ch 20 Pixel 7 0-255 Pixel 7 intensity (0-100%)
Ch 21 Pixel 8 0-255 Pixel 8 intensity (0-100%)
Ch 22 Pixel 9 0-255 Pixel 9 intensity (0-100%)
Ch 23 Pixel 10 0-255 Pixel 10 intensity (0-100%)
Ch 24 Pixel 11 0-255 Pixel 11 intensity (0-100%)
Ch 25 Pixel 12 0-255 Pixel 12 intensity (0-100%)

M-PANEL
16
38ch Function Value Description
Ch 26 Pixel 13 0-255 Pixel 13 intensity (0-100%)
Ch 27 Pixel 14 0-255 Pixel 14 intensity (0-100%)
Ch 28 Pixel 15 0-255 Pixel 15 intensity (0-100%)
Ch 29 Pixel 16 0-256 Pixel 16 intensity (0-100%)
Ch 30 Pixel 17 0-257 Pixel 17 intensity (0-100%)
Ch 31 Pixel 18 0-258 Pixel 18 intensity (0-100%)
Ch 32 Pixel 19 0-259 Pixel 19 intensity (0-100%)
Ch 33 Pixel 20 0-260 Pixel 20 intensity (0-100%)
Ch 34 Pixel 21 0-261 Pixel 21 intensity (0-100%)
Ch 35 Pixel 22 0-262 Pixel 22 intensity (0-100%)
Ch 36 Pixel 23 0-263 Pixel 23 intensity (0-100%)
Ch 37 Pixel 24 0-264 Pixel 24 intensity (0-100%)
Ch 38 Pixel 25 0-265 Pixel 25 intensity (0-100%)

17
NETO
TECHNICAL SPECS
Light Source Lamp Type Cree Quad RGBW 15W LED
LED Qty 25
LED Lens 3-5°
Thermal Max. Ambient Temperature 40° C
Electrical Max. Power Consumption 400W
Max. Power Consumption
Per Color
95W
Operating Voltage AC 100-240V, 50/60Hz
Current Draw 3.3A (120V) / 1.7A (230V)
Power Supply Electric auto-ranging power
factor corrected switch-mode
Control Data Type USITT DMX-512 (1990) or
Art-Net
DMX Channels 121/38/26/20
Control Modes DMX/Auto Run/Master Slave
Pan 540°
Tilt 270°
Physical Dimensions 390 x 390 x 485 mm
Weight ????????????? kgs
Display LCD panel
Data In/Out Socket: XLR 3-pin
Construction Housing UV-resistant ber-reinforced
composite
Protection Factor IP 20 (protected against solid
objects greater than 12.5mm)
Features Fast 3-phase pan/tilt motor
Individual control of each LED in expanded mode
Built-in macros
Endless rotation on both pan & tilt
Art-Net in & out
Multiple unit Power & Data Linking
Quarter-turn omega bracket

M-PANEL
18
CONTACT US
NETO Lighting
1725 Basin
Montreal, Quebec, Canada
H3J 1S2
514-933-4476
[email protected]
www.netolighting.com

19
NETO

www.netolighting.com
