NV-700I Managed Industrial VDSL2 CO/CPE Modem USE ’S MANUAL Ver. A.5
1
Copyright
Copyright © 2019 by National Enhance Technology Corp. All rights reserved.
Trademarks
NETSYS is a trade ark of National Enhance Technology Corp.
Other brand and product na es are registered trade arks or trade arks of their respective holders.
Legal Disclaimer
The infor ation given in this docu ent shall in no event be regarded as a guarantee of conditions or characteristics. With respect
to any exa ples or hints given herein, any typical values stated herein and/or any infor ation regarding the application of the
device, National Enhance Technology Corp. hereby disclai s any and all warranties and liabilities of any kind, including without
li itation warranties of non-infringe ent of intellectual property rights of any third party.
Statement of Conditions
In the interest of i proving internal design, operational function, and/or reliability, NETSYS reserves the right to ake changes to
the products described in this docu ent without notice. NETSYS does not assu e any liability that ay occur due to the use or
application of the product(s) or circuit layout(s) described herein.
Maxi u signal rate derived fro IEEE Standard specifications. Actual data throughput will vary. Network conditions and
environ ental factors, including volu e of network traffic, building aterials and construction, and network overhead, lower actual
data throughput rate. Netsys does not warrant that the hardware will work properly in all environ ents and applications, and akes
no warranty and representation, either i plied or expressed, with respect to the quality, perfor ance, erchantability, or fitness for
a particular purpose. Make sure you follow in line with the environ ental conditions to use this product.

NV-700I Managed Industrial VDSL2 CO/CPE Modem USE ’S MANUAL Ver. A.5
2
Safety Warnings
For your safety, be sure to read and follow all warning notices and instructions before using the device.
 DO NOT open the device or unit. Opening or re oving the cover ay expose you to dangerous high voltage points or other
risks. ONLY qualified service personnel can service the device. Please contact your vendor for further infor ation.
 se ONLY the dedicated power supply for your device. Connect the power to the right supply voltage (110V AC used for
North A erica and 230V AC used for Europe. NV-700I supports 12 to 48 VDC dual power input (Redundant power)).
 Place connecting cables carefully so that no one will step on the or stu ble over the . DO NOT allow anything to rest on
the power cord and do NOT locate the product where anyone can work on the power cord.
 DO NOT install nor use your device during a thunderstor . There ay be a re ote risk of electric shock fro lightning.
 DO NOT expose your device to da pness, dust or corrosive liquids.
 DO NOT use this product near water, for exa ple, in a wet base ent or near a swi ing pool.
 Connect ONLY suitable accessories to the device.
 Make sure to connect the cables to the correct ports.
 DO NOT obstruct the device ventilation slots, as insufficient air flow ay har your device.
 DO NOT place ite s on the device.
 DO NOT use the device for outdoor applications directly, and ake sure all the connections are indoors or have waterproof
protection place.
 Be careful when unplugging the power, because it ay produce sparks.
 Keep the device and all its parts and accessories out of the reach of children.
 Clean the device using a soft and dry cloth rather than liquid or ato izers. Power off the equip ent before cleaning it.
 This product is recyclable. Dispose of it properly.

NV-700I Managed Industrial VDSL2 CO/CPE Modem USE ’S MANUAL Ver. A.5
3
Attention:
Be sure to read this manual carefully before using this product. Especially Legal Disclaimer, Statement
of Conditions and Safety Warnings.
NV-700I is a Managed Single CO/CPE LAN Extender that leverages the extraordinary bandwidth pro ise of VDSL2 technology
( ax. 100Mbps sy etric), the next step in the delivery of new high-speed Internet applications in Industrial-grade environ ents.
Quick, easy, econo ical to install and aintain, the NV-700I works over existing copper wire infrastructure. NV-700I is a Master(CO
side) device. And also can switch as Slave(CPE side) by web config enu.
NV-700I will allow operators worldwide to co pete with cable andsatellite operators by offering services such as HDTV, VOD,
videoconferencing, high speed Internet access and advanced voice services including VoIP, over a standard copper
telephone cable. NV-700I is seen by any operators as an ideal acco pani ent to a FTTP rollout, where for instance fiber optic is
supplied direct to an apart ent block and fro there copper cable is used to supply residents with high-speed VDSL2.
Caution:
The NV-700I is industrial-grade applications. This product does not have waterproof protection. Please note that do not use it over
the specifications or the warranty will be invalid.

NV-700I Managed Industrial VDSL2 CO/CPE Modem USE ’S MANUAL Ver. A.5
4
Table of Contents
COPYRIGHT ........................................................................................................................................................ 1
CHAPTER 1. NPACKING INFORMATION......................................................................................................... 7
1.1 Check List................................................................................................................................................... 7
CHAPTER 2. INSTALLING THE MODEM............................................................................................................ 8
2.1 Hardware Installation................................................................................................................................. 8
2.2 Pre-installation Requirements................................................................................................................... 8
2.3 General Rules............................................................................................................................................. 9
2.4 Terminal Block and DIN-Rail mount installation.................................................................................... 10
2.5 Connecting the RJ-11 / RJ-45 Ports........................................................................................................ 11
2.6 Point to Point Application ....................................................................................................................... 13
CHAPTER 3. HARDWARE DESCRIPTION ....................................................................................................... 17
3.1 Front Panel ............................................................................................................................................... 18
3.2 Front Indicators........................................................................................................................................ 18
3.3 Rear Panel ................................................................................................................................................ 21
3.4 Side Panel................................................................................................................................................. 21
CHAPTER 4. CONFIG RE THE NV-700I VIA WEB MANAGEMENT MEN .................................................... 26
4.1 BASIC Setup............................................................................................................................................. 27
4.1.1 Login Webpage ..................................................................................................................................................................27
4.1.2 Display status.....................................................................................................................................................................28
4.2 Select the Menu Level ............................................................................................................................. 29

NV-700I Managed Industrial VDSL2 CO/CPE Modem USE ’S MANUAL Ver. A.5
5
4.3 System...................................................................................................................................................... 30
4.3.1 Configuration Backup.........................................................................................................................................................31
4.3.2 Configuration Restore ........................................................................................................................................................32
4.3.3 pdate Software.................................................................................................................................................................33
4.3.4 Account Management ........................................................................................................................................................34
4.3.5 Log Level............................................................................................................................................................................35
4.3.6 Service Control...................................................................................................................................................................36
4.3.7 CWNP (TR-069 Settings) ...................................................................................................................................................39
4.3.8 Internet Time ......................................................................................................................................................................40
4.3.9 Restore Default ..................................................................................................................................................................41
4.4 Status Setup ............................................................................................................................................. 42
4.4.1 LAN Network ......................................................................................................................................................................43
4.4.2 Ethernet..............................................................................................................................................................................44
4.4.3 WAN(Line) Statistics...........................................................................................................................................................45
4.4.4 LAN Statistics .....................................................................................................................................................................46
4.4.5 ARP....................................................................................................................................................................................47
4.5 xDSL Setup............................................................................................................................................... 48
4.5.1 Dsl Status ...........................................................................................................................................................................49
4.5.2 Master/Slave mode & profile Config...................................................................................................................................50
4.5.2.1 VDSL Config Overview....................................................................................................................................................51
4.6 LAN Setup ................................................................................................................................................ 52
4.6.1 IPv4 Configuration..............................................................................................................................................................53
4.6.2 IPv6 Configuration..............................................................................................................................................................54
4.6.3 IPv6Static Route.................................................................................................................................................................55

NV-700I Managed Industrial VDSL2 CO/CPE Modem USE ’S MANUAL Ver. A.5
6
4.6.4 Ethernet Mode....................................................................................................................................................................57
4.7 Qos Setup................................................................................................................................................. 58
4.7.1 Qos Queue.........................................................................................................................................................................59
4.7.2 Qos Classification ..............................................................................................................................................................60
4.8 Applications ............................................................................................................................................. 63
4.8.1 Telnet Service Setup(for Security) .....................................................................................................................................64
4.8.2 SSH Service(Telnet Encryption).........................................................................................................................................65
4.8.3 Printer Sharing ...................................................................................................................................................................66
4.8.4 Multimedia Sharing ............................................................................................................................................................67
4.8.5 PnP..................................................................................................................................................................................68
4.8.6 Multicast IGMP...................................................................................................................................................................69
4.8.7 Multicast MLD (IPv6)..........................................................................................................................................................70
4.8.8 SNMP.................................................................................................................................................................................71
APPENDIX A: CABLE REQ IREMENTS .......................................................................................................... 74
APPENDIX B: PROD CT SPECIFICATION ...................................................................................................... 77
APPENDIX C: TRO BLESHOOTING................................................................................................................ 80
APPENDIX D: COMPLIANCE INFORMATION .................................................................................................. 88
WARRANTY ....................................................................................................................................................... 91
CHINESE SJ/T 11364-2014................................................................................................................................ 92

NV-700I Managed Industrial VDSL2 CO/CPE Modem USE ’S MANUAL Ver. A.5
7
Chapter 1. npacking Information
1.1 Check List
Thank you for choosing Netsys NV-700I Before installing the ode , please verify the contents inside package.
Package Contents:
1 x In
dustrial VDSL2
CPE ode
1 x QR code for user’s
anual hyperlink.
Accessory Kit : 1 x DIN-Rail ounting plate, 2 x screws, 4 x Feet,
Protective caps (RJ-11*1, RJ-45*3), 1 x 6pin Ter inal Block, 1 x 2pin
Ter inal Block
Notes:
1. Please infor your dealer i ediately for any issing or da aged parts. If possible, retain the carton including the
original packing aterials. Use the to repack the unit in case there is a need to return for repair.
2. If the product has any issue, please contact your local distributor.
3. Please use the provided protective caps for unused ports.
4. Please look for the QR code on the botto of the product, the user can launch the QR code scanning progra to
scan and download the user’s anual electronic for at file. Above QR code icon is for reference.
5. Power Input: This odel supports 12~48V DC dual power source(one for redundant power) with reco ended 17
Watts or above.

NV-700I Managed Industrial VDSL2 CO/CPE Modem USE ’S MANUAL Ver. A.5
8
Chapter 2. Installing the Modem
Caution:
Please equip the anti-static devices during INSTALLATION.
2.1 Hardware Installation
This chapter describes how to install the ode , and establish the network connections. The NV-700I ay be installed
on any level surface (e.g. a table or shelf). However, please take note of the following ini u site require ents
before you begin.
2.2 Pre-installation Requirements
Before you start the actual hardware installation, ake sure you can provide the right operating environ ent, including
power require ents, sufficient physical space, and proxi ity to other network devices that are to be connected.
Verify the following installation require ents:
• Power require ents: 12VDC ~ 48VDC / 17Watts or above power source.
• The ode should be located in a cool dry place, with at least 10cm/4in of space at the front and back for
ventilation.

NV-700I Managed Industrial VDSL2 CO/CPE Modem USE ’S MANUAL Ver. A.5
9
• Place the ode away fro direct sunlight, heat sources, or areas with a high a ount of electro agnetic
interference.
• Check if the network cables and connectors needed for installation are available.
• Do not install phone lines strapped together with AC power lines, or telephone office line with voice signal.
• Avoid installing this device with radio a plifying stations nearby or transfor er stations nearby.
2.3 General Rules
Before aking any connections to the ode , please note the following rules:
• Ethernet Port interface : RJ-45
All network connections to the ode Ethernet port ust be ade using Category 5 UTP/STP or above for
100 Mbps, Category 3, 4 UTP for 10Mbps.
No ore than 100 eters of cabling ay be use between the MUX or HUB and an end node.
• VDSL2 Port interface : RJ-11 & Terminal block combo
All network connections to the RJ-11/ ter inal block(sharing port) ust use 24~26 gauge with single
twisted pair phone wire.
We do not recommend the use of the 28 gauge phone wire or above.
The RJ-11 is an 6P2C connector, two of which are wired. The ode uses the center two pins. The pin out
assign ent for these connectors is presented below.
Please note that the line port is no polarity, therefore user can reverse the two wires of the phone cable
when installed.
RJ-11 Pin out Assign ents
Pin# MNEMONIC F NCTION
1 NC Unused

NV-700I Managed Industrial VDSL2 CO/CPE Modem USE ’S MANUAL Ver. A.5
10
2 NC Unused
3 DSL sed
4 DSL sed
5 NC Unused
6 NC Unused
2.4 Terminal Block and DIN-Rail mount installation
This section describes how to install the Ter inal Block and DIN-Rail to the ode , if you do not install the DIN-Rail, please
paste the 4 rubber feet at the botto of the hulled to avoid scratches of etal housing.
 Take out the “2pin / 6pin ter inal block” fro inside the accessory kit, and install to the ode properly. (Figure 2.4.1)
 Please refer to install the DIN-RAIL as following step:
1. Install the DIN-Rail ounting plate to the NV-700I. (Figure 2.4.2)
2. Please use the suitable DIN-Rail to install, please refer to the di ensions of the DIN-Rail.(Figure 2.4.3)
3. Insert the top of the DIN-Rail into the top slots on the DIN-Rail ounting plate and the DIN-Rail ounting plate will snap into
place. (Figure 2.4.4)

NV-700I Managed Industrial VDSL2 CO/CPE Modem USE ’S MANUAL Ver. A.5
11
Figure 2.4.1 Figure 2.4.2 Figure 2.4.3 Figure 2.4.4
2.5 Connecting the Line combo Ports
 The line port support 2 different connectors: RJ-11 and ter inal block. It is used to connect fro NV-700I(CO ode) using
single pair phone cable to NV-700I(CPE ode) bridge side (point to point solution). Take note that NV-700I line port cannot be
used at the sa e ti e. Either RJ-11 port is connected or ter inal block is connected using straight connection (Figure 2.4) or
cross-over connection(Figure 2.5)


NV-700I Managed Industrial VDSL2 CO/CPE Modem USE ’S MANUAL Ver. A.5
12
Figure 2.5.1 NV-700I line ports straight connection Figure 2.5.2 NV-700I line ports straight connection
 When inserting a RJ-11 plug, ake sure the tab on the plug clicks into position to ensure that it is properly seated.
 Do not plug a RJ-11 phone jack connector into the Ethernet port (RJ-45 port). This ay da age the bridge. Instead, use only
twisted-pair cables with RJ-45 connectors that confor to Ethernet standard
Notes:
1. Be sure each twisted-pair cable (RJ-45 Ethernet cable) does not exceed 100 eters (333 feet).
2. We advise using Category 5~7 UTP/STP cables for aking Bridge or Router connections to avoid any confusion or
inconvenience in the future when you attach high bandwidth devices.
3. Use 24 ~ 26 gauge twisted pair phone wiring, we do not reco end 28 gauge or above.
4. Be sure phone wire has been installed before the NV-700I boot.

NV-700I Managed Industrial VDSL2 CO/CPE Modem USE ’S MANUAL Ver. A.5
13
2.6 Point to Point Application
First a quick overview on a co plete setup of LAN extender CO(Master)/CPE(Slave) LAN extender.
NV-700I is a LAN extender leverages the extraordinary bandwidth pro ise of VDSL2 technology ( ax. 100Mbps Sy etric)
(Figure 2.6)

NV-700I Managed Industrial VDSL2 CO/CPE Modem USE ’S MANUAL Ver. A.5
14
Figure 2.6 NV-700I Point to Point application

NV-700I Managed Industrial VDSL2 CO/CPE Modem USE ’S MANUAL Ver. A.5
15
Figure 2.6 NV-700I industrial-grade application

NV-700I Managed Industrial VDSL2 CO/CPE Modem USE ’S MANUAL Ver. A.5
16
 2.6.1 Connect the NV-700I(CO) and the NV-700I(CPE) to the Line
The objective for LAN extender is to pass high speed data over a twisted pair cable. In the setup, connect NV-700I(Master) to
NV-700I (Slave) through phone wire(24~26 AWG) or line si ulator or any other hardware representation of a cable network, with
or without noise injection and crosstalk si ulations.
 2.6.2 Connect the NV-700I(CO) and the NV-700I(CPE) to LAN Devices
In the setup, usually an Ethernet tester serves as a representation of the LAN side as well as a representation of the WAN(Line)
side.
 2.6.3 Run Demos and Tests
The Ethernet tester ay send data downstrea as well as upstrea . It also receives the data in order to check the integrity of the
data trans ission. Different data rates can be tested under different line conditions

NV-700I Managed Industrial VDSL2 CO/CPE Modem USE ’S MANUAL Ver. A.5
17
Chapter 3. Hardware Description
This section describes the i portant parts of the NV-700I. It features the front panel and rear panel.
NV-700I Outward

NV-700I Managed Industrial VDSL2 CO/CPE Modem USE ’S MANUAL Ver. A.5
18
3.1 Front Panel
The figure shows the front panel. (Figure 3.1)
Figure 3.1 Front Panel(NV-700I)
3.2 Front Indicators
The Mode has Seven LED indicators. The following Table shows the description. (Table 3-1)
Table 3-1 LED Indicators Description and Operation
LED Color Status Descriptions
On(Steady) Lights to indicate that ode had power good
PWR
(Power LED) Green
Off The device is not ready or has alfunctioned.

NV-700I Managed Industrial VDSL2 CO/CPE Modem USE ’S MANUAL Ver. A.5
19
LED Color Status Descriptions
On(Steady) The device has a good Ethernet connection.
Blinking The device is sending or receiving data.
E1 ~ E4
(Ethernet LED)
Green
Off The LAN is not connected or has alfunctioned.
On(Steady) The Internet or network connection is up.
Fast Blinking 1. The Master device has detected a Slave device and ready to connect.
2. The device is sending or receiving data.
LINK
(Line LED) Green
Off The Internet or network connection is down.
CO(Master) Green On (Steady) NV-700I config on CO ode.
Off NV-700I config on CPE ode(band profile auto follow CO side)
Note:
1.It is nor al for the connection between two NV-700I to take up to 3 inutes, due to NV-700I(Master) connect NV-700I(Slave) to
establish a link echanis in auto-speed, with detects and calculates Master and Slave both PBO and PSD level, noise levels and
other argu ents for getting a better connection.
2. If select CPE(Slave) mode, which band profile will auto follow CO side
