netvox R718PA5 User manual

Model:R718PA9
Wireless NO
2
Sensor
Model: R718PA5
Wireless NO2 Sensor
R718PA5
User Manual
Copyright©Netvox Technology Co., Ltd.
This document contains proprietary technical information which is the property of NETVOX Technology. It
shall be maintained in strict confidence and shall not be disclosed to other parties, in whole or in part, without
written permission of NETVOX Technology. The specifications are subject to change without prior notice.

1
Table of Content
1. Introduction....................................................................................................................................... 2
2. Appearance........................................................................................................................................ 2
3. Main Feature..................................................................................................................................... 3
4. Set Up Instruction............................................................................................................................. 4
5. Data Report....................................................................................................................................... 5
6. Installation ........................................................................................................................................ 6
7. Important Maintenance Instruction................................................................................................... 7

2
1. Introduction
R718PA5 is a Class A device based on the LoRaWANTM protocol of Netvox and is compatible with
LoRaWAN protocol.
R718PA5 can be connected with an NO2sensor (RS485), and report the NO2concentration collected
by the device to the corresponding gateway. The device is compatible with LoRaWAN protocol.
LoRa Wireless Technology:
LoRa is a wireless communication technology dedicated to long distance and low power
consumption. Compared with other communication methods, LoRa spread spectrum modulation
method greatly increases to expand the communication distance. Widely used in long-distance,
low-data wireless communications. For example, automatic meter reading, building automation
equipment, wireless security systems, industrial monitoring. Main features include small size, low
power consumption, transmission distance, anti-interference ability and so on.
LoRaWAN:
LoRaWAN uses LoRa technology to define end-to-end standard specifications to ensure
interoperability between devices and gateways from different manufacturers.
2. Appearance

3
3. Main Feature
Adopt SX1276 wireless communication module
12V DC power supply
NO2sensor detection
The base is attached with a magnet that can be attached to a ferromagnetic material object
Protection level IP65 / 67
Compatible with LoRaWANTM Class A
Frequency hopping spread spectrum technology
Configuring parameters and reading data via the third-party software platforms, and set alarms
via SMS text and email (optional)
Applicable to the third-party platforms: Actility/ ThingPark/ TTN/ MyDevices/ Cayenn
Note:
Battery life is determined by the sensor reporting frequency and other variables, please refer to
http://www.netvox.com.tw/electric/electric_calc.html
On this website, users can find battery lifetime for varied models at different configurations.

4
4. Set Up Instruction
On/Off
Power On DC12V adapter
Turn On
DC12V power supply, the green indicator flashing once means
turn on successfully.
Turn Off
(Restore to factory setting)
Press and hold the function key for 5 seconds, and the green
indicator flashes 20 times
Power Off Remove DC12V adapter
Note
1. On/off interval is suggested to be about 10 seconds to avoid the
interference of capacitor inductance and other energy storage
components
2. The first five seconds after power on, the device will be in
engineering test mode
Network Joining
Never Join the Network
Turn on the device to search the network
The green indicator keeps on for 5 seconds: success
The green indicator remains off: fail
Had Joined the Network
(Not restore to the factory setting)
Turn on the device to search the previous network
The green indicator keeps on for 5 seconds: success
The green indicator remains off: fail
Fail to Join the Network
Suggest to check the device verification information on the
gateway or consult your platform server provider
Function Key
Press and Hold for 5 Seconds
Restore to the factory setting / turn off
The green indicator flashes 20 times: success
The green indicator remains off: fail
Press once
The device is in the network: the green indicator flashes once and
the
device sends a data report
The device is not in the network: the green indicator remains off+

5
5. Data Report
After power on, the device will immediately send a version packet report, and then send another
report with the data of NO2concentration after 20 seconds.
The device sends data according to the default configuration before any other configuring.
MaxTime: Max Interval=180s (3min)
MinTime: The MinTime configuration is not available.
*But the software has restriction, MinTime must be configured a number greater than 0.
Note: 1. Report interval is based on the factory default.
2. R718PA5 reports the NO2concentration value.
The device reported data parsing please refer to
Netvox LoraWAN Application Command document and Netvox Lora Command Resolver
http://loraresolver.netvoxcloud.com:8888/page/index
Report Configuration
(1) Configure R718PA5 device parameter MaxTime = 1min (The MinTime configuration is useless,
but it needs to be set greater than 0 because of the software limitation.)
Downlink: 0157000A003C0000000000
Device Return:
8157000000000000000000 (configuration success)
8157010000000000000000 (configuration failure)
(2) Read R718PA5 device parameter
Downlink: 0257000000000000000000
Device Return:
8257000A003C0000000000 (device current parameter)
Description Device Cmd
ID Device Type NetvoxPayLoadData
ConfigReportR
eq
R718PA5
0x01
0x57
MinTime
(2bytes Unit: s) MaxTime (2bytes Unit: s) Reserved
(5Bytes, Fixed 0x00)
ConfigReportR
sp 0x81 Status (0x00_success) Reserved (8Bytes, Fixed 0x00)
ReadConfigRe
portReq 0x02 Reserved (9Bytes, Fixed 0x00)
ReadConfigRe
portRsp 0x82 MinTime (2bytes Unit: s) MaxTime (2bytes Unit: s) Reserved
(5Bytes, Fixed 0x00)

6
6. Installation
2. R718PA5 regularly reports data that is
NO2 concentration according to MaxTime.
The default Max Time is 3 min.
Note:
MaxTime can be modified by the downlink
command, but it is recommended not to set
the interval too short.
R718PA5 can be applied to the scene of
detecting the NO2concentration.
Example:
Underground parking lot
Environmental protection monitoring
1. R718PA5 has the built-in magnet (as the figure
below) which can be attached to the surface of an
iron object during installation, which is convenient
and quick.
In order to make the installation firmer, please use
screws (purchased separately) to fix the device to
the wall or other surface (as Figure below).
NO2Sensor is fixed by screws that needs two
screws (purchased separately) in the middle.
Note: Do not install the device in a metal shielded
box or in an environment surrounded by other
electrical equipment to avoid affecting the wireless
transmission of the device.
NO2Sensor
Adapter 12V
Traditional socket
Screw
Fixation
Screw
Fixation
Screw
Fixation
Housing
Screw

7
7. Important Maintenance Instruction
Kindly pay attention to the following in order to achieve the best maintenance of the product:
•Keep the equipment dry. Rain, moisture and various liquids or water may contain minerals that
can corrode electronic circuits. In case the device is wet, please dry it completely.
•Do not use or store in dusty or dirty areas. This way can damage its detachable parts and
electronic components.
•Do not store in excessive heat place. High temperatures can shorten the life of electronic devices,
destroy batteries, and deform or melt some plastic parts.
•Do not store in excessive cold place. Otherwise, when the temperature rises to normal temperature,
moisture will form inside which will destroy the board.
•Do not throw, knock or shake the device. Treating equipment roughly can destroy internal circuit
boards and delicate structures.
•Do not wash with strong chemicals, detergents or strong detergents.
•Do not paint the device. Smudges can make debris block detachable parts up and affect normal
operation.
•Do not throw the battery into the fire to prevent the battery from exploding. Damaged batteries
may also explode.
All the above suggestions apply equally to your device, batteries and accessories.
If any device is not operating properly, please take it to the nearest authorized service facility for
repairing.
