Takex Pr-30be User manual

①

2PARTS DESCRIPTION

1PRODUCT DESCRIPTION

M4×20:6 M4×6:2

●Thissensorrequiresonlyone-sidewiring,socanbe

usedinplaceswhereitisdiﬃculttowireontwosides.

●Bothbeamreceptionlevelanddetectiondistanceare

monitoredtoformastableprotectionline.

●Theopticalunitinsidethesensorisadjustableby±90°horizontally,

and±5°verticallyforﬂexibilityinvariousapplications.

●Beamalignmentcanbeadjustedonlyonthesensorsidebyutilizingthe

viewﬁnder,monitoroutput,andsoundcheckfunction.

●Environmentaltroublesignalisoutputwhenthebeamreceptionlevelis

reducedbelowanacceptablelevel.

SENSOR

REFLECTOR

Terminals

Horizontal

adjustment

Vertical

adjustment

screw

Cover

Mountingplate

Grommet

Lensunit

Viewﬁnder

ACCESSORY

OPTIONALS

Instruction Manual

PR-30BE

PHOTOELECTRIC BEAM SENSOR

Transmitter

Sensor

Receiver

Reﬂector

Monitorjack

AlarmLED

Self-tapping

screws

φ4×30:5

Pushrivet

Polebracket

:2pcs.

Polemountingplate

:2pcs.

BL-11

Lﬁttings

Countersunk

oval-headscrew

Screw

※Sensitivityattenuation

/EnvironmentLED

※Sensitivityattenuation

/EnvironmentLED

Coveropen

:SensitivityattenuationLED

Coverclose

:EnvironmentLED

ThePR-30BE,adoptingTimeofFlighttechnology,consistofa

sensor(integratingbothatransmitterandareceiverinside)

andareﬂector.Asillustrated,aninfraredbeam,projectedby

thetransmitterisreﬂectedbacktothereceiver,forminga

protectionloopalongthepath.

Whentheprotectionloopisinterrupted,thereceiverinitiates

analarm.Thereceivernotonlymonitorsthechangeinthe

amountoflightthatisreﬂectedandreturned,butalsomeasures

andmonitorsthetime(distance)ofthereturn.Asaresult,stable

protectionlinecanbeconstructedbypreventingthesurrounding

environmentandmaterial/colorofanyshieldingobjectsfromaﬀectingthedetection.

Monitoroutput

changeoverswitch

Functionsetting

switch

Distancesetting

button

(Note)

: OUTDOOR 30m (100 ft.)

: INDOOR 40m (135 ft.)

Thank you for purchasing our photoelectric beam sensor.

This sensor will provide long and dependable service when properly installed.

Please read this Instruction Manual carefully for correct and eective use.

Please note : This sensor is designed to detect intrusion and to initiate an alarm ; it is not a burglary-preventing device.

TAKEX is not responsible for damage, injury or losses caused by accident, theft, Acts of God ( including inductive

surge by lightning ), abuse, misuse, abnormal usage, faulty installation or improper maintenance.

Thecoverincludesa

photocatalyticcoatingfor

weatherprotection.

Avoidclearningwitha

cloth.

②

Installationinlocations

wheresunlight(sunrise

/sunset)enterstheoptical

axis.

Warning

Caution

Warning

Caution

Description of the Display

Indicatesinformationthat,ifignoredandthedeviceishandledincorrectly,mayresultindeathorseriousinjury.

Indicatesinformationthat,ifignoredandthedeviceishandledincorrectly,mayresultininjuryordamagetopropertyalone.

Indicatesusefulinformation.

Example: Donotdisassemble

Donotinstallthedeviceasshownbelow.Itmaycauseafalsealarmoralostalarm.

Do not use the sensors powered with a voltage level other

thantheindicatedpowersupplyvoltagespeciﬁed(between

10.5to30VDC).Itmaycauseaﬁreorelectricalshock.

Do not connect a device that exceeds the capacity shown to

theoutputcontactofthisdevice.Itmaycauseﬁreorelectrical

shock.

Donottouchtheterminalsectionwithwethands.

Itmaycauseanelectricalshock.

Donotdisassembleormodifythisdevice.Itmaycauseaﬁre,

electricalshock,ormalfunctionofthedevice.

Donotinstallthisdeviceinalocationthatcannotsupportits

weight.Thedevicemayfallandcauseinjuryormalfunction

ofthedevice.

Considertheratedprotectiondistanceforeachdevice,and

usewithintherateddistance.

3PRECAUTIONS

Installationinareaswhere

objectsthatmove

(laundryonaline,etc)

canobstructtheopticalaxis

Thismanualdescribestheprecautionstobeobservedforsafeoperationofthisdevicebyclassifyingthemintothe

followingcategories.Astheseareimportant,besuretoreadandstrictlyobservethem.

Installationonuneven

ground

Installationinlocationswhere

thedevicemaybesplashedby

dirtywaterordirectseaspray

Installationdirectly

aboveawall

Installationinanunstable

location

1. Inareaswheretherearetreesorweeds,thephotoelectricbeamsmaygetobstructedbyovergrownbranchesorleaves.

 Asthismaycausefalsedetection,besuretotrimdownleavesandbranchesaccordingtothegrowthoftheplants.

 Furthermore,thephotoelectricbeamsmaygetobstructedbyswayingbranchesorleavesduetowind.Keepinmindtheswayingofleaves

andbrancheswhentrimmingthem.

2. Vineplantsmaywraparoundthephotoelectricbeamsensorcausingfalsedetections.Therefore,besuretoprunesuchplants

regularly.

3. Insects,birddroppings,orothernaturalphenomenamayalsosoilthesensorcausingfalsedetection.Besuretocleanthesensors

regularly.

Cautions when using the outdoor photoelectric beam sensor (Daily maintenance)

Installationinlocationswhere

stronglightsuchasvehicleheadlights,

LEDlights,orIRilluminationforcameras

entertheopticalaxis.

Thissymbolindicatesaprohibitedaction,withthespeciﬁcactionshownnearthesymbol.

Ifsmoke,anabnormalodororsoundisfound,leavingit

unattendedmaycauseaﬁreorelectricalshock.

Immediatelyturnoﬀthepowertothedeviceandconﬁrm

thattheabnormalstatehasbeencorrected,andthenask

theplaceofpurchaseforrepair.

Installationinlocations

shadedbytreesetc.

Slantedinstallation Overheadwiring Horizontalinstallation Installationclosetoawall

③

4BEFORE INSTALLATION

L=Within20m(66ʼ)

L=Over20m(66ʼ)butwithin30m(100ʼ)

L=Over30m(100ʼ)butwithin40m(135ʼ)

W=Morethan2m(6.6ʼ)

W=Morethan3m(10ʼ)

W=Morethan4m(13.5ʼ)

Inabovecase,keepthe

anglewithin±15° Correctinstallation

● Parallel installation

φA

L

Donotperformmulti-levelprotectionorstraightlineprotection

(3spansormore),toavoidmalfunctionorlostalarm.

● Multi-level / straight line installation

Installthereﬂectordirectly,facingthefrontoftheopticalunit

asmuchaspossible.

Reﬂectioneﬃciencyofthereﬂector,duetoitsnature,decreases

astheanglefromthedirectlyfacingpositionincreases.

Makesurethatangleremainswithin±15°evenifangled

installationisneeded.Whenexceedingthis,theamountof

reﬂectedlightwillbeinsuﬃcientanditwillnotoperatecorrectly.

※Alignthecenterofthesensorwiththecenter

ofthereﬂector(themiddleofthethreereﬂector

plates)andmountthembothkeepingthe

protectionlinehorizontal.Whenmountingon

apole,ﬁxeachpolemountingplateatthesame

heighttoalignthecenterofthesensor/reﬂector.

φA=0.2×L

L=10m(33ʼ):φA=φ2.0m(6.6ʼ)

L=30m(100ʼ):φA=φ6.0m(20ʼ)

MAX15°

OUTDOOR0.5to30m(1.7ʼto100ft.)

INDOOR0.5to40m(1.7ʼto135ft.)

POSITION OF INSTALLATION

INSTALLATION OF MULTIPLE SENSORS

CAUTIONS ON INSTALLATION

80to100cm

(31"to39")

PROTECTION DISTANCE

＊

HEIGHT OF INSTALLATION Centerof

thesensor Centerof

thereﬂector

Sensor

Reflector

Reﬂector

Example1

Example3

WhenBL-11(optional)isused

Example2

Rightangle

.......................

....

...

Inordertousethissensorcorrectly,thoroughlyreadthisinstructionmanualand

selectthemountingpositionandprotectiondistance.

Straightlineprotection

(bymountingsensors

back-to-back)

Multi-level

protection

Straightlineprotection(3spansormore)

Inordertoavoidmalfunctionorlostalarmcausedby

interference,keepthedistancebetweeneachsensor

wheninstallatedinparallelasbelow.

Installthesensorataheightof80to

100cm(31”to39”)tocatchahuman

target.(Installverticallysothatthe

centerofthesensorlensandmiddle

partofthereﬂectorassemblyare

placedatthesameheight.)

Theopticalunitcanbeadjustedhorizontally(±90degrees)and

vertically(±10degrees)forvariousinstallationtypes.

(example1to3)

Protectiondistance(betweensensor/reﬂector)

shouldnotexceedtheratedrange.

Outdoorprotectiondistancemaybereduceddueto

thepossibleeﬀectofmist,fog,frost,rain,or

condensationonthesensorunitcoverandreﬂector

unit,whichcancausefalsealarms.

④

5INSTALLATION

①

②

③

④

①

②

③

④

Grommet

※ ※

※Recommended

forcaulking

①

②

③

④

Cover

Mounting

plate

Heavyrain

NOTE: Wheninstallingthesensoronawallwithout

rooforeaves,orwhereitisatriskfrom

exposuretoheavyrainfallforprolonged

periods,werecommendcaulkingthetop

sideofthecoverasshownbelow.

①Removecoverfromunitandslidethemountingplate

upwardstodetachit.

②Pullthewirethroughtotheinstallationposition.

③Makeoneholeinthegrommetonthemountingplate

andpullthewirethroughit.Securetheplatewith2x

self-tappingscrews.(φ4x30mm)

④Forexposedwiring,breakknockouts(in2positions)on

therearoftheunit,pullthewirethroughasperthe

diagramandattachittotheterminalsonthesensor.

Wiringfrom

thebottom

Wiringfrom

thetop

Knockout

Thegrommetiscompatiblewithawireofφ3mm(φ0.12")to

φ6mm(φ0.24")outerdia.Whenawireofmorethanφ6mm(φ0.24")

outerdia.isused,cut

thedottedlineportionon

therightﬁgureusingpliers

orsimilar.

Thenusecaulkingtoprevent

insectsfromenteringtheunit.

●Sensor

WALL MOUNTING

⑤After wiring is completed, adjust alignment, attach

coverandcheckoperation.

83.5mm(3.29")

Holes

Self-tappingscrews

Pullthewirethroughthesensorbody(backtofront)and

attachittotheterminalsonthesensor.

Grommet

●Sensor

●Reflector

※Applicablepolesize:Outsidedia.42mm(1.65")to49mm(1.93").

※Fixthepolemountingplatesofthesensorandthereﬂectoratthesame

heighttoadjustthemtoeachcenter.

127mm(5”)

58mm(2.28”)

Hoodﬁxingscrew

Self-tappingscrews

（Note）Incaseofoutdoorinstallation,pleasedonotremovehood.

POLE MOUNTING

⑤

Followthesameprocedureaswallmounting(from③)forwiring.

Self-tappingscrews

196mm

(7.72”)

Hoodﬁxingscrews

Pushrivet

Hood

Upsidedown

Ovalcountersunk

headscrews

Screws

Polebracket

Polemountingplate

Sensormountingplate

(Removeitfromthesensorbody)

Reﬂector

Ovalcountersunk

headscrews

Ovalcountersunk

headscrews

Pushrivet

Polebracket

Polemounting

plate

※Incaseofindoorinstallation,thehoodcanberemovedifitisnotrequired.

Fixthereﬂectordirectlyfacingthesensorusing

3x(φ4x30mm)self-tappingscrews

①Loosen2xﬁxingscrewsonthetopofreﬂectorandremovethehood.

②Removethepushrivet.

③Invertthereﬂectorwiththehoodﬁxingholesfacingdownwardsand

ﬁxintopositionwith2x(φ4x30mm)self-tappingscrewsusingthe

upperandlowerholes.

④Insert2xpushrivetsintotheﬁxingscrewholestosealthem.

①Insert2xovalcountersunkheadscrews(M4x20)intothepole

bracketwithafewturns.

②Positionthepolebetweenthepolemountingplateandthepole

bracketandtightenthescrews.

③Insert2xscrews(M4x6)

intothepolemountingplate

withafewturns.

④Fixthesensor

mountingplate

tothepolemounting

plate.

①Insert2xovalcountersunkheadscrews(M4x20)intothepole

bracketwithafewturns.

②Holdapolebetweenthepolemountingplateandthepolebracket

andtightenthescrews.

③Fixthereﬂectorunittothe

polemountingplateby

2xovalcountersunkhead

screws(M4x20).

④Insertthepushrivet

intothelowerhole

inordertosealit.

For back-to-back and right angle mounting

（Note）Applicableonlytothesensor,nottothereﬂector.

（Note）

Applicableonlytothesensor,nottothereﬂector.

Self-tapping

screws

Screws

Pushrivet

②

③

①BL-11

Reﬂector

Installation with BL-11 (Sold separately)

①Fixtheﬁrstpolemountingplatewithﬁrstpolebracket.

②Passthesecondpolebracketundertheﬁrstpole

mountingplateandﬁxthesecondpolemountingplate

upsidedown.

※Followthesameprocedureaswall

mounting(from③)forwiring

①FixtheBL-11tothewallby2xself-tappingscrews.(φ4x20mm)

(usingkeyhole)

②FixthereﬂectortotheBL-11by2xovalcountersunkheadscrews

(M4x20).

③Insertthepushrivetintothelowerholeinordertosealit.

⑤

6WIRING

1 2 3 4 5 6 7 8

①②③④

｝

①②③④

｝

①②③④⑤⑥⑦⑧

7OPTICAL AXIS ADJUSTMENT

Byaligningtheopticalaxiscorrectly,aprotectionlinewithsuﬃcientmarginofsensitivitycanbecreated,reducingtheoccurrence

ofmalfunction.Applyboth“Distancecheck”and“Lightreceptionlevelcheck”properlyasshownbelow.

1 Before checking

③Supplypowertothesensor.

Whenmountingiscompleted,adjustthelensunit

horizontally(leftandrightdirection)tofacethereﬂector.

Mountthereﬂectorsothatitdirectlyfacesthefrontofthe

lensunitasmuchaspossible.

Thebeampathshouldbeas

closetoparallelaspossibleto

ensurereliableoperation.

Makesurethatangle

remainswithin±15°

evenifangledinstallation

isneeded.Whenexceeding

this,theamountofreﬂected

lightwillbeinsuﬃcientand

itwillnotoperatecorrectly.

Lensunit

②Adjusttheangleofthesensorwithverticaladjustmentscrew

bylookingthroughtheviewﬁnder.

Continueadjustuntilthecenterof

thereﬂectorcanbeseenin

themiddleof

theviewﬁnder

asshownon

theright.

Power

10.5Vto30VDC

(non-polarity)

Tamperoutput

1b(N.C.)

30V(AC/DC)0.25A

Tamper

Drycontactrelay

output1a/1b(N.O./N.C.)

30V(AC/DC)0.25A

Whencover

isdetached

●Example connection 1

●Example connection 2

●Example connection 3

Power

Alarm

Controlpanel

(12VDC)

Controlpanel

(12VDC)

Controlpanel

(12VDC)

Wiresize Voltage DC24VDC12V

500m(1,650')

750m(2,500')

1,200m(4,000')

1,400m(4,600')

50m(165')

100m(330')

150m(500')

AWG22(Dia0.65mm)

AWG20(Dia0.8mm)

AWG18(Dia1.0mm)

AWG17(Dia1.1mm)

TERMINAL CONFIGURATION

●Wiring distance

CONNECTION

Alarm

output Environmental

output

Environment

Currentconsumption(Max): 200mA(DC10.5V)

160mA(DC12V)

80mA(DC24V)

Vertically±5°

Horizontally±90°

Vertical

adjustmentscrew

Viewﬁnder

Insidethe

viewﬁnder

Therefore,makesuretocompleteboth

“2.Distancecheck”and“3.Lightreceptionlevelcheck”.

Adjustmentwiththeviewﬁndermaycause

somediﬀerencedependingontheviewpoint

asitisonlyaroughadjustment.

Maximumwiringdistance,whentwoormoresetsare

connected,isthevalueabovedividedbythenumberofsets.

（note）

①

⑥

1.0Vmostcorrespondtoapprox.10m.

Ex）1.25V ⇒ 12.5m

2.87V ⇒ 28.7m

4.00V ⇒ 40.0m

2 Distance check

3 Light reception level check

1.25V

12.5m

1.50V

15m

1.00V

10m

Ex）Whenthedistancefromthesensortothereﬂectoris15m

Beamonprotection

line

Beamreﬂected

onobjects

Tobereadjusted

IMPORTANT

10ｍ

15ｍ

⑤Replacethecoverandtightentheﬁxingscrew.

Oncethecoverisﬁxed,theunitautomatically

startsadjustingthetransmissionpower

withshortpipsound.

Becarefulnottoblocktheopticalunit

(protectionline)withyourbodyorhands

untilpipsoundstops.

(Itmaytakemax.10sec.)

Ifpipsoundstops,theopticalaxisadjustmentiscompleted.

Incasepipsoundcontinues,gobackto[2. Distance check]

anddothesettingagain.

①Ensurethatthemonitoroutputchangeoverswitchissetto

"Distance".Whenadjustingtheopticalaxisbychangingthe

installationdistance,longpressthedistancesettingbutton

(shortpipfor5secondsormore)

beforeproceeding

tothenextstep.

Especiallyatshortdistance,thehigh-powerbeamoutputfrom

thetransmittermayreﬂectonobjects

(walls,signboards,utilitypoles,etc.)

neartotheprotectionline.

Therefore,adjustcorrectly

wheninstalling.

②Insertatestmeterintothemonitorjackandcheckthevoltage.

Monitoroutputlevelcorrespondstothedistance.

Testmeter

Monitorjack

③Ifthedistancetothereﬂectorandtheconvertedvalueofthe

testmeterdonotmatch,ﬁneadjusttheopticalaxisofthelensunit

orremoveanyobjectsneartotheprotectionline.

④Pressthedistancesettingbutton.

Thedistancebetweenthesensorandthe

reﬂectorissetwhilepipissounding.

Becarefulnottoblocktheopticalunit

(protectionline)withyourbodyorhands.

①Forthelightreceptionlevelcheck,setthemonitoroutput

changeoverswitchto"Reception".

②Settoneindicatorsettingto“ON”.

Ifthetoneindicatorisundesirable(atnight),proceeddirectlyto④.

③Fine-tunetheopticalunitthetonebecomescontinuousandas

high-pitchedaspossible.



④Formoreaccurateadjustment,insertatestmeterintothemonitorjack

andcheckthevoltage.

Asaguide,themonitorvoltageisshownintheabovetable.

However,adjustthesensitivitytoashighlevelaspossibleinorder

toimproveenvironmentalresistance.

Themonitorvoltageofthelightreceptionlevelmaychangedue

totheambienttemperatureorjustafterturningonthepower.

Distance Reception

Monitoroutput

changeoverswitch

Utilitypoles,etc.

Beamreﬂected

onobjects

Beamon

protectionline

Distancesetting

button

push

Bythisoperation,thedistancebetweenthesensorandthereﬂectoris

memorizedsothattheadjustmentandalarmjudgmentare

properlyperformed.Sobesuretopressthedistancesettingbutton.

Beforepushingthisbutton,thepitchoftoneindicatorand

monitoroutputvoltagearekeptbasedontheprevioussetting.

Sobesuretomakeadjustmentafterpressingthebutton.

※Oncememorized,thesettingwillnotberesetwithoutpressingthe

buttonagain,evenifthepoweristurnedonagain.Whenincorrect

distanceisset,gobackto[2. Distance check]anddothesetting

again.

Distance Reception

Monitoroutput

changeoverswitch

Toneindicator

Functionsettingswitch

ONOFF

Verticalangle

Horizontalangle

Lensunit

Whenthelightreceptionlevelis

"Good",Sensitivityattenuation

/EnvironmentLEDturnsoﬀ.

Vertical

adjustment

screw

Lightreceptionlevel Much

Intermittenttone (Best)(Good) Continuoustone

(Low) Tone (High)

Pip(tone:long⇔short) Bleep

LED:ON LED:OFF

Little

Monitoroutput

voltage Reception

sensitivity

Morethan2.5V Best

2.0to2.5V Good

Lessthan2.0V Re-adjustment

Incasetoneindicatoris“ON”,walktestmodefollowsfor5

minutesandmakespipsoundwhendetecting.

→Referto“9. OPERATION CHECK”

※Oncewalktestmodeiscompleted,nopipsoundisheardevenwith

thetoneindicator"ON".

(Note)

Ifnosoundcomesout,thesensorunitmaynotfacethedirectionofthe

reﬂector.Inthiscase,gobackto[1. Before checking]anddothesetting

again.AlsocheckthatthetoneindicatorswitchisON.

Whenthedirectionoftheopticalaxisroughlymatchesthereﬂector,

a beep sound begins which changes according to the light reception

levelasbelow.

Aftermoutingthesensor

andthereﬂector,wiring

andmakingthealignment

adjustment,checkthe

operationofthesensorwith

itscoverattachedbylooking

atthealarmLED.

※Whensettingtoneindicatorto“ON”,

walktestmodestarts5minutesafterclosing

thecover,andpipsoundcomesoutforalarm.

⑦

8FUNCTIONS

Environmentaloutputsetting:

Whenthelightreceptionlevelreachestheprescribedlevelorlessforthe

followingreasons,theenvironmentalcontactoutputandLEDwillactivate.

・Protectionlineobstructedduetogrowingtreesandweeds

・Dirtonthesurfaceofsensorcoverandreﬂector

・

Environmentaldeteriorationcausedbythickfog,blizzard,snowcover

・Incorrectalignmentofopticalaxisofsensorandreﬂector,etc.

Besuretowashthesensorcoveronlywithwaterwithoutwipingit

withacloth.

Insuchcases,takeappropriatemeasureslikecuttingtrees,

cleaningthedevice,adjustingopticalaxesandsoon,

sothatthelightreceptionisrestoredtotheprescribed

levelormore.

(Signaloutputcontinuesmin.5sec.until

thelightreceptionisrestoredtothe

prescribedlevelormore)

Sensitivityattenuation

/EnvironmentLED:ON

Itmaytakesometime(max.afewminutes)fortheenvironmental

outputtorecovereveniftheenvironmentisrestored.Pressthe

distancesettingbuttonforimmediaterecovery.

123456

（factoryset：0.05sec）

3 4 3 4 3 4 3 4

0.05sec.0.1sec.0.25sec.0.5sec.

Wall,signboard,etc.

123456

①Alarmoutputchangeover

(Functionsettingswitch:DIP1)

N.C.orN.O.canbeselected

foralarmoutputlogic. N.C.(Factoryset)

N.C. N.O.

②Environmentaloutputchangeover

(Functionsettingswitch:DIP2)

N.C.orN.O.canbeselected

forenvironmentaloutputlogic.

③Responsetimeadjustment(Functionsettingswitch:DIP3/4)

Thedetectableinterruptiontimecanbeselected.

(Refertothediagrambelowtoadjusttheresponsetime.)

・Iftheinterruptiontimeisshorterthantheresponsetime,thereisno

detectionofobstructingobject.

・Ifthereisapossibilitythatlargeﬂyingobjects(birds,fallingleaves,etc.)

shieldtheopticalaxis,settheresponsetimelonger,consideringthe

installationconditions.

Detection mode changeover

Select"Normal"mode(factoryset)asregularsetting.

Thisdeviceisdesignedtoemitaninfraredbeamfromthe

sensorbody,monitorthechangeintheamountoflight

returningfromthereﬂectingobjectandthechangeinthe

distancetothereﬂectingobject

andoutputanalarmsignalwhen

theyexceedtheprescribedvalue.

In"Normal"mode,lostalarm

causedbylightwraparound

canbepreventedbymonitoring

thesetwochanges.

However,whentheenvironmentsuddenlychangesinashortperiod

oftime(suchasconcentratedtorrentialrain,rapidthickfogorsnowstorm),

theamountoflightreﬂectedandreturnedmaychangesosuddenly

thatanalarmsignalisoutput.

④ToneIndicator(Functionsettingswitch:DIP5)

WhentoneindicatorswitchisON,receptionlevelisnotiﬁedwithsound.

(OnlywhenMonitoroutputswitchissetto“Reception”)

・Asthelightreceptionlevelincreases,thesoundchangesfrom

intermittenttonetocontinuoustone,andthepitchincreasesafterthat.

・Thisfunctionoperatesonlywhenthesensorcoverisremoved.

ToneIndicator

:ON

Also,whenselecting"ON",walktestmodestartsafterclosingofthecover.

※Walk test mode

For5minutesafterclosingthecover,apipsoundisemittedwhen

crossingtheprotectionline,foreasyoperationcheck.

(Itautomaticallystopsafter5minutes)

Toextendthetimeforanother5minutes,openthecoverandcloseit

again.Repeatthisactiontoextendthetimefurther.

⑤Detectionmodechangeover

(Functionsettingswitch:DIP6)

Dependingontheenvironment

oftheinstallationlocation,

"Normal"or"Harsh"canbe

selected.

Select"Normal"mode(factoryset)asregularsetting.Whensettingto

"Harsh",readthesectionof【Detectionmodechangeover】below

carefullyandfullyunderstandthecontentbeforeuse.

HarshNormal

⑥Monitoroutput

"Distance"or"Reception"canbeselectedwhenadjustingtheopticalaxis

usingatestmeter.Whensetto"Distance",youcancheckthedistanceto

thereﬂector.Useitwhentherearereﬂectiveobjectsneartheprotection

line.

Distance Reception

※Referto“7 OPTICAL AXIS ADJUSTMENT”forfurtherdetail.

9OPERATION CHECK

AlarmLEDisON

Functionsettingswitch

N.C.(Factoryset)

Functionsettingswitch

Runatfullspeed Walkingnormally Walkingslowly

Response:0.05sec. Response:0.25sec. Response:0.5sec.

OFF(factoryset)

Normal(factoryset)

OFF ON

Monitoroutputswitch:

“Reception”

Ifthishappensoccasionally,setthedetectionmodeto"Harsh"mode."Harsh"

modemonitorsonlythechangeinthedistancetothereﬂectingobject,which

makesitdiﬃcultforafalsealarmsignaltobeoutputevenifthereisasudden

changeintheenvironment.

※”Environmentaloutput”isoutputregardlessofdetectionmode.

Ontheotherhand,inthe"Harsh"mode,wraparoundofthelightmaynotbe

prevented.Rechecktheoperation,suchaswhetherthealarmsignalisalways

outputwhencrossingtheprotectionline,andstartoperatingthedevice.

Beamonprotectionline

Beamreﬂected

onobjects

pip

①MakesurethatthealarmLEDisoﬀ(inalarmcondition)

andconﬁrmthatthereisnothingtoblocktheinfraredlight.

②Crosstheinfraredlightinvariousplacesonthe

protectionlineandchecktheoperation.Conﬁrmthat

thealarmLEDisON(alarmcondition).

③ThedeviceisoperatingnormallyifthealarmLED

changesfromON(alarm)toOFF(protection)when

youcrosstheinfraredlight.

④Checkalsotheoperationoftheconnectedsystem.

Alarmisoutputduringthelightinterruptiontimeorfor

2secondswhenlightisblockedforlessthan2seconds.

11 SPECIFICATIONS

10 TROUBLESHOOTING

12 EXTERNAL DIMENSIONS

196mm(7.72”)

4)Protectiondistanceexceeds40m.(30moutdoor) 4)Keepprotectiondistancewithin40m.(30moutdoor)

Symptom Possiblecause Remedy

1)Nopowersupply.

2)Badwiringconnectionorbrokenwire,short.

3)Beamisreﬂectedonanotherobjectandsentintothereceiver.

1)Turnonthepowersupply.

2)Checkwiring.

3)Removethereﬂectingobjectorchangebeamdirection

AlarmLEDdoesnotlight

whenthebeamisbroken.

AlarmLEDcontinuesto

light.

1)Beamalignmentisincorrect.

2)Shadingobjectbetweensensorandreﬂector.

3)Sensorcoverorrefrectoraresoiled.

1)Checkandadjustagain.

2)Removetheshadingobject.

3)

Cleanthereﬂectorwithasoftcloth,orwashthecoverwater.

1)Badwiringconnection.

2)Unstablesupplyvoltage.

3)Shadingobjectbetweensensorandreﬂector.

4)Alargeelectricnoisesourcesuchaspowermachineislocated

nearbysensor.

5)Unstableinstallationofsensorandreﬂector.

6)Sensorcoverorrefrectoraresoiled.

7)Improperalignment.

8)Bigbirdsmaypassthroughthebeams.

1)Checkagain.

2)Stabilizesupplyvoltage.

3)Removetheshadingobject.

4)Changetheplaceforinstallation.

5)Stabilizetheinstallation.

6)

Cleanthereﬂectorwithasoftcloth,orwashthecoverwater.

7)Checkandadjustagain.

8)Settheresponsetimelonger.(Donotusethissetting



whereanintrudercanrunatfullspeedthroughthebeam.)

Intermittentalarm

Knockout

□12mm×7mm

(□0.47"×0.28")

□12mm×7mm

2-φ0.16"(φ4)

Wiringlead

20mm(0.79")

83.5mm

(3.29")

14.5mm

(0.57")

44mm

(1.73")

12mm

(

0.47"

)

73mm(2.87") 71.5mm(2.81")

25mm

(0.98")

170mm(6.69")

Model

Detectionsystem

Protectiondistance

Supplyvoltage

Currentconsumption

Alarmoutput

Tamperoutput

Responsetime

AlarmLED

Functions

Ambienttemperaturerange

Mountingpositions

Wiring

Weight

Appearance

PR-30BE

Outdoor1.7to100'(0.5to30m)

Indoor  1.7to135'(0.5to40m)

10.5Vto30VDC(Non-polarity)

(Class2powereddevice)

200mAorless

160mAorless(12VDC)

80mAorless(24VDC)

Drycontactrelay

Contactcapacity:30V(AC/DC)0.25Aorless

Relayoperation:Interruptiontime(minimum2secs)

Drycontactrelay

Contactcapacity:30V(AC/DC)0.25Aorless

Drycontactrelay1b(N/C)

Action:Activatedwhencoverisdetached.

Contactcapacity:30V(AC/DC)0.25Aorless

0.05/0.1/0.25/0.5sec.

RedLEDON:whenanalarmisinitiated

RedLED

・Monitoroutput

-13°Fto+140°F(-25 ℃to+60℃)

Outdoor/Indoor

Terminals

Sensor:Resin(winered)

Reﬂector:Resin(clear/black)

REFLECTOR

SENSOR

＊Donotcleanthecoverwithacloth.

〈Dailycheck〉

〜〜〜〜〜〜〜〜〜〜〜〜〜〜〜〜〜〜〜〜〜〜〜〜

＊Donotcleanthecoverwithacloth.

〜〜〜〜〜〜〜〜〜〜〜〜〜〜〜〜〜〜〜〜〜〜〜〜

Checktheoperationoftheunitonceaweek.Ifthecoverbecomessoiled,washitwithwater.

Nevercleanitwithaclothotherwiseitcoulddamagethephotocatalyticcoatingappliedtothesensorcover.

Thecoatingisdesignedtopreventattenuationoftheinfraredcausedbywaterdropsfromtorrentialrain.

〜〜〜〜〜〜〜〜〜〜〜〜〜〜〜〜〜〜

3-0.16”(φ4)

19.5mm(0.77”)

100mm(3.94”)

93mm(3.66”)

226mm(8.90”)

126.8mm(4.99”)

58mm

(2.28”)

101mm(3.98”)

6mm

(0.24”)

Centerofthereﬂector

Environmentaloutput

Sensor:13oz(370g)Reﬂector:6.7oz(190g)

DrycontactrelayN.O./N.C.

Sensitivityattenuation

/EnvironmentLED

Whenfrontcoverdetached(whenalignment):

Beamisattenuated.

Whenfrontcoverattached:Weathercondition

getsworse.(SynchronizewithEnv.output)

・Responsetimeadjustment

⑧

Limited Warranty :

TAKEX products are warranted to be free from defects in material and workmanship for

12 months from original date of shipment. Our warranty does not cover damage or

failure caused by natural disasters, abuse, misuse, abnormal usage, faulty installation,

improper maintenance or any repairs other than those provided by TAKEX. All implied

warranties with respect to TAKEX, including implied warranties for merchantability and implied warranties for tness, are limited in duration to 12 months from original date of

shipment. During the Warranty Period, TAKEX will repair or replace, at its sole option,free of charge, any defective parts returned prepaid. Please provide the model number of the

products, original date of shipment and nature of diculty being experienced. There will be charges rendered for product repairs made after our Warranty Period has expired.

InJapan

TakexAmerica Inc.TakenakaEngineeringCo.,Ltd.

https://www.takex-eng.co.jp/

TakexAmericaInc.

https://www.takex.com

TakexEuropeLtd.

https://www.takex.com

IntheU.S. IntheU.K.

InAustralia

AviaryCourt,WadeRoad,

Basingstoke,Hampshire.RG248PE,U.K.

Tel:(+44)01256-475555
