New Age HOME BAR SERIES User manual

STOP ATTENTION: Is your cabinet damaged?
Need help or spare parts? For fastest service,
contact NewAge Products at 1-877-306-8930;
or [e-mail].
Do not return to the retailer.
Use two or more people to move, assemble, or
install cabinets and locker to avoid back injury.
Do not leave children unattended near cabinets.
High risk of tipping if cabinets are installed
incorrectly: securely attach cabinets to the
wall to avoid serious injury. For assistance, call
1.877.306.8930; for U.K 0800.031.4069: e-mail at
[e-mail].
Warning: Excessive weight
hazard!
HOME BAR SERIES
3 DRAWER BASE

48”Countertop. Fits over 2 Cabinets
72”Countertop. Fits over 3 Cabinet
96”Countertop. Covers over 4 Cabinet
CountertopsWeight
Capacity
55lbs.
55lbs.
55lbs.
55lbs.
220 lbs.
3 Drawer
Base Cabinet
Max 440 lbs.

Unpacking
• Begin by placing the package on a covered at surface.
• Remove all cardboard, foam packaging material and clear plastic bags.
• Dispose / recycle all packaging materials.
• Verify all the contents in the box and gather the required tools. See“Parts”and“Tools Needed” in the list below.
Handles
Handle Bolts (M4 x30mm)
3
6
3 Drawer
Cabinet
6
#8 x 25mm Screws
Parts Supplied
Handle Handle Bolt
M4 x 30mm
Tools Needed
1 x Tape Measure
1 x #2 Phillips Bit
(opitional)
1 x Pencil
1 x Cordless Power Drill
(optional)
1 x #2 Phillips head
screwdriver
1 x Flashlight
(optional)
1 x Drill Bit
2.5mm or 3/32”
Screws
#8 x 25mm

Installing the Handles
Parts Needed. Align handle to holes
on doors or drawers.
Screw in bolts.
12
3
3 x Handle 6 x Handle Bolt
(M4x 30mm)
Note:
Cabinets come with handles installed on
inside of drawers/doors.

Extend drawer fully.
Removing Drawer
Press plastic triggers on underside of
drawer according to arrows in image.
Tilt and remove shelf rack.
45
6
Partially extend drawer slides. Put drawer on slides and slide each drawer
slide forward until you hear a click sound.
3
Inserting Drawer
10 11

Fastening Cabinets Note:
All drawers must be removed prior
to fastening cabinets together.
Using pilot hole as guides, screw into second cabinet.
Do not over-tighten screws and punch through other side!
X4
Drill 3/32” pilot holes on interior wall of cabinet being fastened.
Parts Needed.
910
11
4 - #8 x 25mm
screws

Mounting the Worktop
Drill 3/32” pilot holes on
interior roof of cabinet. Tighten screws to secure cabinets.
3
Place worktop over cabinets and lower onto cabinets.
Parts
Needed.
12 13
14 15
4 - #8 x 25mm
screws
X4

SÉRIE VIN ET BAR
ARMOIRE À 3 TIROIRS
ARRÊT ATTENTION: Est votre armoire
endommagée? Avez vous besoin d’aide ou de
pièces de rechange? Contactez NewAge Products
a 1-877-306-8930; ou support@newageproducts.
com. Ne pas retourner au détaillant.
Déplacer, assembler ou installer les armoires et
armoires-vestiaires avec l’aide de deux personnes
ou plus. Dans le cas contraire, il pourrait en
découler des blessures au dos ou autre. Ne pas
laisser les enfants sans surveillance près des
armoires. Risque élevé de basculement si les
armoires ne sont pas installées correctement :
Fixer solidement les armoires au mur pour éviter
des blessures graves.Pour obtenir de l’aide,
composer le 1.877.306.8930; au R.-U., composer
le 0800.031.4069; ou envoyer un courriel à
l’adresse [e-mail].
AVERTISSEMENT: RISQUE DE
POIDS EXCESSIF!

Plan de travail de 122 cm (48 po).
Peut se poser sur deux armoires.
Plan de travail de 183 cm (72 po).
Peut se poser sur trois armoires.
Plan de travail de 244 cm (96 po).
Peut se poser sur quatre armoires
Plans de travailCapacité
pondérale
25 kg (55 lb)
25 kg (55 lb)
25 kg (55 lb).
25 kg (55 lb).
100 (220) lbs.
Capacité pondérale maximale
de l’armoirede plancher
à trois tiroirs : 200 kg (440 lb).

Déballage
• Commencer par placer le paquet sur une surface plane couverte.
• Enlever les cartons, le matériel d’emballage en mousse et les sacs en plastique transparents.
• Jeter/recycler tous les matériaux d’emballage.
• Vérier le contenu de la boîte et rassembler les outils requis. Voir la liste des « Pièces » et des « Outils nécessaires » ci-après.
Poignées
Boulons de poignée (M4 x 30 mm)
3
6
Armoire à
trois tiroirs
6
Vis n˚ 8 x 25mm
Pièces fournies
Poignée Boulon de
poignée
M4 x 30 mm
Les outils nécessaires
1 x Tape Measure
1 x Tête Phillips n 2
(facultative)
1 x Crayon
1 x Perceuse sans ls
(facultative)
1 x Tournevis à tête Phillips n 2
1 x Lampe de poche
(facultative)
1 x Foret de 2,5 mm
ou 3/32 pooo
Vis no8 x 25 mm

Installation des poignées
Pièces nécessaires. Aligner la poignée sur les trous
des portes ou des tiroirs.
Visser les boulons.
12
3
3 x Poignées 6 x Boulons
de poignée
(M4 x 30 mm)
Remarque :
Les armoires sont fournies avec des
poignées montées à l’intérieur des
tiroirs/portes.

Ouvrir le tiroir complètement.
Extraction du tiroir Appuyer sur les gâchettes en plastique
qui se trouvent sous le tiroir aux endroits
indiqués par les èches sur l’image.
Basculer l’étagère et l’enlever.
Extraire partiellement les glissières
du tiroir.
Poser le tiroir sur les glissières et faire
coulisser chacune des glissières vers
l’avant jusqu’à entendre un déclic.
3
Insertion du tiroir
45
6
78

Fixation des armoires Remarque :
Il importe d’enlever tous les
tiroirs avant de xer ensemble les
armoires.
Visser la deuxième armoire en se servant des avant-trous comme guides.
Ne pas trop serrer les vis, elles risqueraient de ressortir de l’autre côté!
X4
Percer des avant-trous de 3/32 po dans la paroi intérieure
de l’armoire en train d’être xée.
Pièces
nécessaires.
910
11
4 – Vis no
8 x 25 mm

Montage du plan de travail
Percer des avant-trous de 3/32 po dans le
plafond de l’armoire, à l’intérieur de
celle-ci.
Serrer les vis pour immobiliser les
armoires.
3
Placer le plan de travail au-dessus des armoires et l’abaisser
pour le mettre en place.
Pièces
nécessaires.
12 13
14 15
4 – Vis no
8 x 25 mm
X4

HOME BAR SERIES
WALL WINE RACK
Warning: Excessive weight hazard!
Use two or more people to move, assemble or install cabinets to avoid back injury.
Do not leave children unattended near cabinets. High risk of tipping if cabinets are installed
incorrectly: securely attach cabinets to the wall to avoid serious injury.
For assistance, call 1.877.306.8930; for UK 0800.031.4069; e-mail at [e-mail]
STOP ATTENTION: Is your cabinet damaged?
Need help or spare parts? For fastest service,
contact NewAge Products at 1-877-306-8930;
or suppor[email protected].
Do not return to the retailer.
Use two or more people to move, assemble, or
install cabinets and locker to avoid back injury.
Do not leave children unattended near cabinets.
High risk of tipping if cabinets are installed
incorrectly: securely attach cabinets to the
wall to avoid serious injury. For assistance, call
1.877.306.8930; for U.K 0800.031.4069: e-mail at
[e-mail].
Warning: Excessive weight
hazard!

48”Countertop. Fits over 2 Cabinets
72”Countertop. Fits over 3 Cabinet
96”Countertop. Covers over 4 Cabinet
CountertopsWeight
Capacity
50 lbs.
50lbs.
50lbs.
Wall
Wine Rack
Max 150 lbs.
(for Base cabinets only.)

Handles
Threaded Washer
Threaded Caps
Handle Bolts ( M4 x 22mm)
#8 x 25mm Screws
Lag Screw ( 6 mm x 55 mm)
2
4
4
4
4
4
Wall Rack Cabinet
Parts Supplied
Handles Handle Bolts
M4 x 22 mm
Tools Needed
1 x Tape Measure
1 x #2 Phillips Bit
(opitional)
1 x Pencil
1 x Cordless Power Drill
(optional)
1 x #2 Phillips head
screwdriver
1 x Flashlight
(optional)
1 x
2.5mm or 3/32”
drill bit
1 x
6.5 mm or 1/4”
drill bit
1 x Stud Finder
Lag Screw
6 mm x 55 mm
#8 x 25 mm
Screws Threaded
Washer Threaded Cap
Unpacking
• Begin by placing the package on a covered at surface.
• Remove all cardboard, foam packaging material and clear plastic bags.
• Dispose / recycle all packaging materials.
• Verify all the contents in the box and gather the required tools. See“Parts”and“Tools Needed” in the list below.

Installing the Handles
Parts Needed. Align handle to holes
on doors or drawers.
Screw in M4 x 22mm bolts.
12
3
Note:
Cabinets come with handles installed on
inside of drawers/doors.
2 x Handle 4 x Handle Bolt
M4 x 22mm

Mounting Cabinets
Gather parts.
Use stud nder to locate the studs
and mark the wall with a pencil.
4 x Lag Screw
6mm x 55mm
Near the top of the cabinet, drill 1/4”holes through the back of the cabinet that are in line with
marked studs. Repeat for drilling two holes near the bottom of the cabinet.
Use threaded caps to cover screws.
4 x Threaded
Washer 4 x Threaded Caps
7 8
9
11
Wall Studs Wall Studs
Pilot Holes
Place cabinet ush against wall and
attach using screws and washers.
10

Fastening Cabinets Note:
Remove wine rack to make
attaching cabinets easier.
Using pilot hole as guides, screw into second cabinet.
Do Not Over-tighten screws and Punch through other side!
X4X4
Drill 3/32” pilot holes
on interior wall of cabinet being fastened.
Parts Needed.
4 5
6
4 - #8 x 25mm
screws
