New Age BIOSONYC User manual

BIOSONYC
USER MANUAL
Instructions for use
New Age Italia srl
Via De Brozzi, 3 - 48022 Lugo (RA)
Tel:[phone] –Telefax: +39-0545.369028
Website: www.newageitalia.it e-mail: [e-mail]
This document is the property of New Age Italia srl. All rights reserved. It is forbidden to copy or reproduce it in
any way, including photocopying its contents in whole or in part, without written permission by New Age Italia
srl.

Rev. 02 of 10/12/04
2/24
TABLE OF CONTENTS:
Chap. 1 –PRESENTATION.....................................................................4
1.1 –What is BIOSONYC ?....................................................................4
1.2 –Why use the BIOSONYC ?............................................................4
1.3 –Whom is BIOSONYC addressed to ?...........................................4
Chap. 2 –INDICATIONS / CONTRAINDICATIONS..........................5
2.1 –Indications.......................................................................................5
2.2 –Contraindications ...........................................................................5
Chap. 3 –OPERATION.............................................................................7
3.1 –The BIOSONYC keys.....................................................................7
3.2 –Connecting the head.......................................................................7
3.3 –Turn on the device..........................................................................8
3.4 –Choose the program .......................................................................8
3.5 –Start of therapy...............................................................................8
3.6 –Setting the power of emission ........................................................8
3.6.1 –Contact control .....................................................................................8
3.7 –Program interruption.....................................................................8
3.8 –Turn off the device..........................................................................9
Chap. 4 –APPLICATION TECHNIQUES.............................................9
4.1 –Direct contact method ....................................................................9
4.2 –Indirect contact method.................................................................9
Chap. 5 –PRESET PROGRAMS...........................................................10
5.1 –Therapy programs........................................................................10
5.1.1 –List of therapy programs.....................................................................10
5.1.2 –Description of therapy programs........................................................11
5.1.3 –Areas of application of the head.........................................................13
5.1.4 –Adjusting the power of emission........................................................13
5.1.5 –Position to be kept during the sessions...............................................14
5.2 –Aesthetic treatments.....................................................................14

Rev. 02 of 10/12/04
3/24
5.2.1 –Preset aesthetic programs ...................................................................14
5.2.2 –List of aesthetic programs...................................................................15
5.3 –Description of the preset programs.............................................15
5.4 –Head application areas.................................................................17
5.5 –Adjusting the power of emission .................................................17
5.6 –Position to be kept during the sessions .......................................18
5.7 –Integrated thinning program.......................................................18
Chap. 6 –POWER SUPPLY...................................................................19
Chap. 7 –MAINTENANCE....................................................................19
7.1 –Head and cables............................................................................19
7.2 –Device.............................................................................................19
7.3 –Replacing the power supply cable...............................................19
Chap. 8 –SYMBOLS...............................................................................20
Chap. 9 –WARNINGS ............................................................................21
Chap. 10 –TECHNICAL SPECIFICATIONS......................................22
10.1 –Power supply...............................................................................22
10.2 –Output specifications..................................................................22
10.3 –Other specifications....................................................................22
Chap. 11 –BASIC EQUIPMENT AND ACCESSORIES....................23
11.1 –Basic BIOSONYC equipment....................................................23
11.2 –Accessories and expendable materials......................................23
Chap. 12 –BIBLIOGRAPHY.................................................................24
WARNING: READ CAREFULLY THE
INSTRUCTIONS BEFORE USE

Rev. 02 of 10/12/04
4/24
Chap. 1 –PRESENTATION
BIOSONYC belongs to the new line of electromedical equipment for physiotherapy and
beauty care. It is small, easy to use and versatile –these are the main features of this
innovative line of products.
1 . 1 –What is B IO SONY C ?
Unceasing research in the field of medical devices has led to the creation of this new
system for ultra-sound therapy, consisting of the Biosonyc generator. Biosonyc can ensure
the user the utmost reliability and safety in compliance with the current Safety Rules of
Medical Devices. The technological innovation and the ease of use make it an extremely
versatile and innovative product in the electromedical appliance business.
1 . 2 –Why use the B IO SONY C ?
BIOSONYC houses inside itself all the technology needed to generate ultrasounds,
through the use of pre-set programs contained in its memory. The generator carries out
control tasks, while the memory –small electronic inside microchips - make it possible to
generate Ultra-sounds for therapy and beauty treatment and for treating pathologies
(wounds, accidents, illness) and aesthetic problems (cellulitis, skin affections).
1 . 3 –Whom i s BIO SO NY C addr ess ed t o ?
The most suitable fields for BIOSONYC to express its full potential are medicine
(especially physiotherapy) and beauty treatment. However, thanks to its ease of use, it can
be used by physicians, by rehabilitation therapists and professional beauticians, but also
by anybody who wants to take care of his or her own physical well being at home, thanks
to the ease of use and the versatility of the product.

Rev. 02 of 10/12/04
5/24
Chap. 2 –INDICATIONS / CONTRAINDICATIONS
This Chapter lists the main situations where the use of ultrasounds is advisable, and the
restrictions on the use of this therapy.
2 . 1 –Indi c a ti ons
The most common pathologies treated by ultrasounds are those involving the bone,
muscle and tendon system, fats. They are especially indicated for:
Therapy:
periostitis;
tendinitis;
arthrosis;
muscular contractures;
scarring;
organized oedemas.
Aesthetics:
Celulitis;
Lymphatic draining;
Local thinning;
Skin pathologies.
Ultrasounds today also have proven validity in the treatment of such extra-articular
rheumatological alterations as scapulohumeral periarthritis, elbow epicondylitis and
other pathologies, thanks to their anti-pain, fibrolytic and decontracturing effect.
The structures involved suffer their main traumas especially during physical activity;
however, in many cases, they may also be due to aging (rheumatisms, muscular
hypotrophy, lack of balance due to little movement); these cases are increasing steeply
due to the progressive rising of the average age, not accompanied by a suitable
improvement of the quality of life.
In sports, the most frequent traumas affect the articulations of the knee and the ankle and
can be cured by ultrasounds through daily applications, repeated in several sessions. The
treatments are especially performed for anti-pain purposes and are preparatory for
kinesitherapy sessions.
2 . 2 –Co nt raindi c ation s
Ultrasounds have the same contraindications as any physical media which act through
endogenous production of heat:
degenerative osteoporosis;
presence of metal fragments;
varicose veins
acute thrombosis and thrombophlebitis;
obliterative arteriopathies haemorrhages;
menstruations;
neoplasms;
tuberculosis;
acute inflammatory processes;
skin injuries;
altered sensitivity.
During applications with ultrasound techniques, use on the following is not advisable:

Rev. 02 of 10/12/04
6/24
specialized tissues (fertile metaphysis, testicles, ovaries), since they could suffer
damage;
avoid use in the neighbourhood of the heart, especially if there are any electro-
mechanical appliances (pace-maker), since this could damage them permanently.
Special precautions should be taken when carrying out applications on the rachis of
patients with a diagnosis of laminectomy, for possible damage to the spinal medulla.
No applications must be made in the immediate neighbourhood of the eyes or the uterus
(abdomen/lumbar area) in case of pregnancy, due to the risk of provoking cavitation, even
with a proper dosage.
The presence of articular prostheses and metal synthesis media may cause problems, since
they can absorb a higher amount of ultrasounds and thus deteriorate or damage the
adjacent tissues.
Use of such physical therapy is not advisable when treating pathologies of young people,
especially children (e.g. fertile conjugation cartilage).
The staff performing the operations must not be exposed for too long a time to the action
of ultrasounds, since this could cause lesions (the so-called “ultrasound illness”).

Rev. 02 of 10/12/04
7/24
Chap. 3 –OPERATION
BIOSONYC is very easy to use; at the same time, however, all the operations must be
carried out properly and in the right sequence.
3 . 1 –The BIOSO NY C k e ys
POWER SUPPLY OUTPUT ON/OFF
DISPLAY
START UP
DOWN
PAUSE
STOP
+ INTENSITY
- INTENSITY
OUTPUT
3 . 2 –Co n nectin g the h e a d
Before turning the device on, connect the head to the output socket of the device via the
connector. To introduce the connector, turn it so that the connections coincide with the
output socket; once you have introduced it, screw it all the way down in order to fasten the
cable firmly to the device.

Rev. 02 of 10/12/04
8/24
3 . 3 –Tur n on t he devi c e
In order to turn BIOSONYC on, press the button 1/0 –ON/OFF. The display will show a
welcome message, with the name and the software version, and the Selection Menu screen
will appear.
3 . 4 –Cho ose t h e progr am
On the Menu, choose the program with UP/DOWN keys.
3 . 5 –St a rt of t herapy
To start the therapy press start; the power of the stimulation is already preset but can be
set by pressing (+)(-) keys. The minimum increase of power is 0.1 W/cm2 and the
maximum is 3.0 W/cm2.
NOTE: if no head has been fitted into the device at the start, you can hear an acoustic
warning and the display will show an error message until it is inserted, then it will start up
again automatically.
3 . 6 –Se tt ing the pow er of emiss i o n
Use the (+) and (–) keys to set the intensity of emission. Generally speaking, it stays
constant throughout the duration of the program; however, in case of pain or overheating
of the area being treated, you must decrease the power using the (–) key or else break off
the therapy by pressing pause stop.
NOTE: during the program it is possible to increase or decrease the Timer by pressing
UP/DOWN keys (one minute each touch).
3.6.1 –Contact control
To detect the contact between head and skin, fasten the bracelet in the patient's wrist and
in the back output of the device. If the head does not adhere perfectly to the treating area
or to the mean of transmission (gel, water in immersion) the device will let out an acoustic
signal and interrupt the program; adjust the contact to continue.
3 . 7 –Prog r am i n terrup tion
The stimulation will stop automatically as soon as the Timer reaches 0 and you hear the
end program acoustic signal; if you want to interrupt the program before the end, press the
pause stop key: once to make a pause (to continue press start), twice to stop the program.
3 . 8 –Fre e pr o g ram s et u p
Biosonyc allows to create and save up to 5 free programs listed from prog. no 41 to no.
45.
To save a free program go to the program list and select one of the mentioned programs.
Press STOP. You enter the parameter configuration menu PARIMP. From here with the
keys + and –adjust the value of the parameter shown, while with the up/down arrow key
select another parameter.

Rev. 02 of 10/12/04
9/24
Parameters are:
Freq: frequency from 1MHzHz to 3MHz
Modul: modulation CONTINUOUS, 50%, 20%, or 10%
Power: power from 1 to 30 that is from 0,1W/cm2 to 3W/cm2
Time: duration of the program from 1 to 60 minutes.
Once you have set the parameters press START to enter the window of program name
configuration.
Thanks to the arrows you can change the position of the flashing pointer while with + and
–key it’s possible to change the selected letter. Once the name is set up press START.
3 . 9 –Tur n o ff the de vi c e
To turn the device off, press the 1/0 - ON/OFF button on the back of the device.
Chap. 4 –APPLICATION TECHNIQUES
There are different techniques of application for ultrasound therapy; they are usually
performed in one of two ways: direct or indirect contact.
4 . 1 –Di r ect c ontact m e t h od
With this technique, the head comes directly into contact with the skin through a medium
allowing both surfaces to adhere perfectly to each other (e.g. gel for ultrasounds, provided
together with the device); during direct contact the head may be:
fixed –in order to treat a very limited surface, holding the handpiece firmly down on
the area affected by hand or by the mechanical arm (not provided together with the
device) which allows the operator to devote himself to other patients until the end of
the program;
mobile –in order to treat a large surface, making small movements, backward and
forward or else circular, throughout the area to be treated. This technique is used to
treat large flat and regular surfaces.
Note: if the surface to be treated is very small and/or hard to reach, we suggest you use a
smaller head (see Accessories).
4 . 2 –Indi r e ct cont ac t method
The indirect method consists of applying a medium between the head and the skin for
transmitting the ultrasound waves (usually water). This way the number of vibrations
which reaches the skin becomes uniform. This is used to treat body areas with an
irregular surface (hands, feet), which are hard to reach and do not permit perfect adhesion
between the two surfaces (head of the handpiece and skin). To perform the application,
use a rather deep basin, full of water, and immerse the body part you want to treat entirely
in the water together with the head; direct the flat surface of the head towards the area you
want to work on, from a distance of about 10 to 15 cm, and then start the therapy.

Rev. 02 of 10/12/04
10/24
NOTE: full colour pictures with examples of the applications (therapy / beauty)
appear in the attachment to the centre of the manual; in any case, before applying
ultrasound therapy, check the contraindications and refer to a physician or a
professional beautician.
Chap. 5 –PRESET PROGRAMS
Ultrasound therapy has long been used to treat certain pathologies which can benefit from
the effects of mechanical vibrations: chronic pathologies, phlogosis, oedemas, etc.
Actually it is used also for aesthetic treatments (cellulitis, fats, etc.). This chapter lists the
techniques of application and certain examples on how to carry out ultrasound therapy
sessions in order to cure these pathologies through use of the preset programs.
5 . 1 –Ther apy p ro grams
BIOSONYC has a large number of preset therapy programs, i.e. with all the parameters
memorized and ready to use. The various available programs are subdivided according to
the kind of tissue being treated:
1) Bone tissue: programs which deliver ultrasounds with the most common parameters
for the treatment of pathologies affecting the bone structure and related structures.
2) Articulations: preset programs for the therapy of the main problems affecting
articulations and cartilages.
3) Muscles: specific programs for the therapy of pathological or traumatic situations
affecting the muscles, due to physical activity or to daily life;
4) Tendons: programs of various kinds for carrying out therapy sessions applied to the
tendon structures, to muscle-tendon insertions and to bursae containing synovial
fluid.
The following sections list the preset THERAPY programs and then explain how to use
them.
5.1.1 –List of therapy programs
BIOSONYC has 18 different preset therapy programs subdivided according to the areas to
be treated as developed in the previous section, plus 7 new therapy programs for
superficial pathologies with 3 MHz frequency. The Programs are listed on the following
table.
1 MHz Therapy Programs
Kind of Program
No.
Name of the program
Bone tissue pathologies
1
Bone atrophy
2
Callus
3
Osteitis and Periostitis
4
Ossification lag

Rev. 02 of 10/12/04
11/24
Kind of Program
No.
Name of the program
Articulation
pathologies
5
Arthritis-Arthrosis
6
Articulation stiffness
7
Sprains
8
Lumbago
Muscle pathologies
9
Myalgia
10
Pangs
11
Strains
12
Contractures
13
Bruises
Tendon pathologies
14
Tenosynovitis
15
Tenovaginitis
16
Epicondylitis
17
Periarthritis
18
Bursitis
3 MHz Therapy Programs (new*)
Programme Type
Name on display
Timer
Power
Freq. Mod.
Superficial
pathologies
Sprains
10
1,5 W
Continue
Strains
10
1,5 W
Continue
Contractures
8
1 W
Continue
Oedemas
10
1 W
Continue
Tenonitis
10
1 W
1/2
Epicondylitis
10
1 W
1/2
Cicatrization
10
1 W
Continue
NOTE (*): some 1 MHz therapy programs are available also with 3 MHz frequency for
superficial pathologies (see table) except Cicatrization program, wich is completely new
and specific for skin scars, cuts, wounds, etc. For the use see 1 MHz Programs.
5.1.2 –Description of therapy programs
The following tables describe the various preset programs, subdividing them according to
the anatomic parts involved in the pathologies they were designed for. On each of the
following tables, the first column shows the program on the display –so it can be
identified immediately –together with its duration, while the second column contains
explanations regarding the program and its applications.
NOTE: during the program it is possible to increase or decrease the Timer by pressing
UP/DOWN keys.

Rev. 02 of 10/12/04
12/24
Program Description Tables
PROGRAMS FOR BONE TISSUE
These programs feature specific parameters for treating pathologies involving the bone structure
and related structure. They must be used every day until the problem disappears.
NAME ON THE DISPLAY
USE OF THE PROGRAM
Bone atrophy
This helps regenerate the bone through stimulation of the metabolism
of calcium and local al circulation.
10 minutes
Callus
This prevents the development of callus after fractures; it helps the
physiological regeneration of the bone.
8 minutes
Osteitis and Periostitis
Treatment of phlogosis affecting the bone structures and the
periostium covering it.
8 minutes
Ossification lag
This stimulates local metabolism and helps the regeneration of the
bone, delayed by problems of circulation or other situations.
10 minutes
PROGRAMS FOR THE ARTICULATIONS
Programs for treating pathologies affecting the articulations and cartilages. They must be used
every day until the problem disappears.
NAME ON THE
DISPLAY
USE OF THE PROGRAM
Arthritis-Arthrosis
Treatment of phlogosis affecting the articular cartilages; it stabilizes the
local metabolism and favours the afflux of the blood.
10 minutes
Articular stiffness
Treatment of stiffness affecting the articular cartilages; it restores the
trophism of the cartilage facilitating its articular mobility.
15 minutes
Sprains
Treatment of sprains; it diminishes pain and functional limitation.
10 Minutes
Lumbago
Treatment of pain affecting the lumbar spinal chord; it diminishes pain
and functional limitation.
10 minutes
PROGRAMS FOR MUSCLES
Programs for treating muscle problems of various kinds. They must be used every day until the
problem disappears.
NAME ON THE
DISPLAY
USE OF THE PROGRAM
Myalgia
Treatment of muscle pain; it warms the area being treated and favours the
afflux of blood.
10 minutes
Pangs
Treatment of phlogosis affecting the articular muscles; it stabilizes the
local metabolism and favours the afflux of the blood.
6 minutes
Strains
Treatment of phlogosis affecting the articular muscles; it stabilizes the
local metabolism and favours the afflux of the blood.
10 minutes
Contractures
Treatment of muscle contractures; it warms up the affected area and
favours the afflux of the blood which eliminates the metabolites.
8 minutes
Bruises
Treatment of muscular oedemas after bruises; it warms the affected area
and helps to reabsorb the oedema.
10 minutes

Rev. 02 of 10/12/04
13/24
PROGRAMS FOR TENDONS
Programs for the treatment of phlogosis to tendon structures, including bursae. They must be used
every day until the problem disappears.
NAME ON THE
DISPLAY
USE OF THE PROGRAM
Tenosynovitis
Treatment of phlogosis of the synovial sheath of the long tendons (e.g.
fingers).
10 minutes
Tenovaginitis
Treatment of phlogosis of the wide and flat tendons (e.g. Achilles tendon).
10 minutes
Epicondylitis
Treatment of phlogosis of the insertion of the outside forearm muscles on
the elbow (tennis elbow)
10 minutes
Periarthritis
Treatment of phlogosis of the tendons of the articulation of the shoulder
(rotator cuff); this removes pain and allows you to get back the mobility
of the arm.
10 minutes
Bursitis
Treatment of the phlogosis affecting the synovial bursae located between
the tendons and the bones.
10 minutes
5.1.3 –Areas of application of the head
The following table shows some examples of application of the head on the main areas of
the body affected by the most common kinds of pathology, to be carried out using the
direct technique (mobile and fixed) and the indirect technique (by immersion).
DIRECT METHOD: MOBILE TECHNIQUE
Area to be stimulated
Notes about the position of the head
Muscle
Move the head all over the surface of the muscle
Knee, ankle
Move the head over the hurting side of the articulation (if the
pain is widespread, on the other side as well)
Back
Move the head over the hurting side of the back
Neck
Move the head over the back of the neck
Tendon (large)
Move the head backward and forward along the tendon
Shoulder
Move the head over the back of the shoulder
DIRECT METHOD: FIXED TECHNIQUE
Area to be stimulated
Notes about the position of the head
Spinal chord
Place the head on the affected part of the back
Tendon (small)
Place the head on the inflamed tendon
INDIRECT METHOD: UNDERWATER
Area to be stimulated
Notes about the position of the head
Hand
Immerse the head directed towards the hurting area
Foot
Immerse the head directed towards the hurting area
5.1.4 –Adjusting the power of emission
Adjusting the intensity of the vibrations is fundamental for the success of the ultrasound
therapy program. The adjustment must differ depending on the kind of program being
used, the technique of application and the features of the patient. The following table
shows the initial adjustment of intensity, i.e. right after the START of the program, which

Rev. 02 of 10/12/04
14/24
can be increased during the program, in order to increase the effects, or else diminished in
case of skin overheating or pain.
Initial intensity
Modulation
The power of emission must be
set by the user and will change
depending on the kind of
application (see following table).
The power of emission may be modified: increasing by a
few tenths (+ 0,1) to increase the effects of the therapy;
diminishing the value in case of overheating of the
treated area. (*)
Should the power of emission which has been set, or its adjustment, lead to excessive heating
or pain in the area being treated, you must immediately reduce the intensity of stimulation or else
turn the application off.
This table shows the intensities suggested for the most common applications:
Application
Suggested intensity
Ossification lag, articular stiffness, myalgia, epicondylitis,
periarthritis
0.5 –1 W/cm²
Bruises, tenosinovitis, bursitis
1 –1.5 W/cm²
Arthritis - arthrosis, callus, lumbago, pangs, tenovaginitis
1.5 –2 W/cm²
Bone atrophy, osteitis –periostitis, sprains
2 –2.5 W/cm²
5.1.5 –Position to be kept during the sessions
During the therapy programs, the ideal position is a relaxed one, with the body either
supine or prone, depending on the area of application. This position must be kept
throughout the duration of the session, in order to facilitate the effects produced by the
vibrations, especially the flow of blood increased due to vascular expansion, as a
consequence of the heating induced in the affected area.
5 . 2 –Ae s t heti c tre atments
Ultrasounds can also be used on the surface or below the skin to heal and treat certain
pathologies of the skin and the derma. Also, steady application of such treatments can
help local thinning and lead to a regression of cellulitis tissue.
5.2.1 –Preset aesthetic programs
BIOSONYC has preset aesthetic programs, i.e. programs with all the parameters
memorized and ready for use. The various available programs are subdivided according to
the kind of treatment to be performed:
1. Cellulitis: programs which deliver high frequency ultrasounds to treat cellulitis in
the area where it tends to collect most (thighs, glutei, hips, abdomen…).
2. Lymphatic draining: preset programs for warming and stimulation of the
circulation in areas with marked water retention and swelling.
3. Local thinning: specific programs to reduce fat accumulation in men (or in women
without cellulitis) due to a sedentary lifestyle or to disorderly diets.
4. Skin pathologies: programs to be applied to the skin in order to cure various surface
pathologies.

Rev. 02 of 10/12/04
15/24
The following paragraphs list the preset BIOSONYC aesthetic programs and then explain
how to use them.
5.2.2 –List of aesthetic programs
BIOSONYC has 15 different preset aesthetic programs, subdivided according to the
differentiations described in the previous section. The programs are listed in the following
table and can be selected as described in the Chapter on Operation.
Aesthetic Programs
Kind of Program
No.
Name of the program
Cellulitis
1
Localized oedematous cellulitis
2
Localized flaccid cellulitis
3
Localized compact cellulitis
4
Diffuse oedematous cellulitis
5
Diffuse flaccid cellulitis
6
Diffuse compact cellulitis
Lymphatic draining
7
Localized lymphatic draining
8
Diffuse lymphatic draining
Thinning
9
Local thinning
10
Diffuse thinning
Skin pathologies
11
Boils
12
Granulomas
13
Local dermatosclerosis
14
Paravertebral dermatosclerosis
15
Warts
5 . 3 –De sc ri pt io n of th e pr es et prog ra ms
The following tables describe the various preset programs, subdivided according to the
kind of treatment they were designed for. Each of the following tables is set up as follows:
the first column shows the program on the display, in order to facilitate identification,
together with its length in minutes, whereas the second column contains the explanations
about the program and the relevant kind of application.
NOTE: during the program it is possible to increase or decrease the Timer by pressing
UP/DOWN keys.

Rev. 02 of 10/12/04
16/24
CELLULITIS
Programs for treating every kind of cellulitis. They can be used every day until the problem
disappears.
NAME ON DISPLAY
USE OF THE PROGRAM
Localised oedematous
cellulitis
Treatment of localized and clearly limited cellulitis: it breaks down
the fat, frees the fluids which are being withheld and facilitates local
circulation and lymphatic draining.
10 minutes
Localised flaccid
cellulitis
Treatment of localized and clearly limited cellulitis: it breaks down
the fat, frees the fluids which are being withheld and facilitates local
circulation and lymphatic draining.
12 minutes
Localised compact
cellulitis
Treatment of localized and clearly limited cellulitis: it breaks down
the fat, frees the fluids which are being withheld and facilitates local
circulation and lymphatic draining.
15 minutes
Diffuse oedematous
cellulitis
Treatment of diffuse cellulitis; it breaks down the fat, frees the fluids
which are being withheld and facilitates local circulation and
lymphatic draining.
20 minutes
Diffuse flaccid
cellulitis
Treatment of diffuse cellulitis; it breaks down the fat, frees the fluids
which are being withheld and facilitates local circulation and
lymphatic draining.
25 minutes
Diffuse compact
cellulitis
Treatment of diffuse cellulitis; it breaks down the fat, frees the fluids
which are being withheld and facilitates local circulation and
lymphatic draining.
30 minutes
LYMPHATIC DRAINING
Programs for treating water retention and widespread swelling. They can be used every day
until all the excess fluids have been drained away.
NAME ON DISPLAY
USE OF THE PROGRAM
Localized lymphatic
draining
Treatment of water retention localized in certain clearly limited
surface areas; it helps reabsorption of the lymphatic vessels and local
circulation.
15 minutes
Diffuse lymphatic
draining
Treatment of diffuse water retention in certain body areas; it helps
reabsorption of the lymphatic vessels and local circulation.
20 minutes
THINNING
Programs for treating the accumulation of fat in men and in women without cellulitis. They
can be used every day until the desired goals have been achieved.
NAME ON DISPLAY
USE OF THE PROGRAM
Local thinning
Treatment of deposits of fat localized in certain well defined body areas;
it helps to dissolve the adipose cells and reabsorb the fats through local
circulation.
20 minutes
Diffuse thinning
Treatment of deposits of fat spread through various body parts (e.g.
men’s waists); it helps to dissolve the adipose cells and reabsorb the fats
through local circulation.
30 minutes

Rev. 02 of 10/12/04
17/24
SKIN PATHOLOGIES
Programs for superficial beauty treatments and skin pathologies. They can be used every day until
the problem disappears.
NAME ON THE DISPLAY
USE OF THE PROGRAM
Boils - 8 minutes
Programs for the treatment of boils.
Granulomas - 4 minutes
Programs for the treatment of granulomas.
Local dermatosclerosis
Programs for the treatment of local dermatosclerosis.
6 minutes
Paravertebral dermatosclerosis
Programs for the treatment of paravertebral
dermatosclerosis.
6 minutes
Warts - 8 minutes
Programs for the treatment of warts.
5 . 4 –Head appl i cation areas
The following table shows some examples of application of the head on the main areas of
the body affected by the most common aesthetic problems, to be carried out using the
direct technique (mobile and fixed).
DIRECT METHOD: MOBILE TECHNIQUE
Area to be stimulated
Notes about the position of the head
Arms
Move the head over the back of the arm and repeat the program on
the other arm
Abdomen
Move the head over the whole surface of the abdomen
Hips
Move the head over one hip and then repeat the program on the
other
Glutei
Move the head over the whole area affected by cellulitis
Thighs (inside/outside)
Move the head over the side affected by cellulitis
DIRECT METHOD: FIXED TECHNIQUE
Area to be stimulated
Notes about the position of the head
Skin
Rest the head against the affected skin part
5 . 5 –Adjusting the p ow er of emissio n
Adjustment of the intensity of vibration is a basic component for the success of the
ultrasound therapy program and differs according to the type of program being used, the
technique of application and the features of the patient. The following table shows the
initial adjustment of intensity, i.e. right after the START of the program, which can be
increased during the program, in order to increase the effects, or else diminished in case of
skin overheating or pain.
Initial intensity
Modulation
The power of emission must be
set by the user and will change
depending on the kind of
application (see following table).
The power of emission may be modified: increasing by a
few tenths (+ 0,1) to increase the effects of the therapy;
diminishing the value in case of overheating of the
treated area. (*)
Should the power of emission which has been se, or its adjustment, lead to excessive heating or
pain in the treated area, immediately reduce the intensity of stimulation or else turn the application
off.

Rev. 02 of 10/12/04
18/24
This table shows the intensities suggested for the most common applications:
Application
Suggested intensity
Boils, granulomas, dermatosclerosis (loc./paravert.)
1 –1.5 W/cm²
Loc. oedem./flacc. cell., Loc. lymph. draining
1.5 –2 W/cm²
Comp. loc. cell., Comp. oedem./flacc. cell.,
Diff. lymph. draining, Loc. thinning
2 –2.5 W/cm²
Comp. diff. cell., Diff. thinning, Warts
2.5 –3 W/cm²
5 . 6 –Posi t i o n t o be ke pt d uring the se ssions
During the aesthetic programs, the ideal position is a relaxed one, with the body either
supine or prone, depending on the area of application. This position must be kept
throughout the duration of the session, in order to facilitate the effects produced by the
vibrations, especially the flow of blood increased due to the vascular expansions, as a
consequence of the heating induced in the affected area, thus facilitating the draining of
the freed substances (fats, excess fluids).
5 . 7 –Int eg r at ed t hinni n g pr o gram
To achieve the best results from the body thinning and modelling program, we suggest
you integrate different methods: along with ultrasounds, which produce localized effects,
it is good practice to carry out aerobic exercise (fast walking, cyclette/cycle, slow running
or Aerobics or spinning in a gym) plus a controlled and regular diet, restricting
hydrocarbons and drastically cutting down fat (sweets, fried foods, soft cheese). A very
effective thing to do during local thinning sessions is to combine ultrasounds with
electrostimulation, using specific beauty programs, CAPILLARIZATION and programs
for firming and toning the more relaxed muscles.

Rev. 02 of 10/12/04
19/24
Chap. 6 –POWER SUPPLY
BIOSONYC is supplied by mains voltage at 230V50Hz by the supply cable.
To identify the power supply cable provided with the appliance, refer to the chapter
on “Technical specifications”.
Chap. 7 –MAINTENANCE
The following routine maintenance must be performed so the appliance can work
regularly and in a safe condition, even long after the date of purchase.
7 . 1 –Head and cabl es
The head and the connecting cable must be checked regularly in order to make sure there
are no cracks which the conductor fluid (water, gel) can leak into; also, the head must be
cleaned after each application using a damp cloth and dried before storing.
7 . 2 –De vice
In order to clean the appliance, we suggest you use a damp cloth. Never use any liquid,
since it's not protected against their penetration (IP20).
7 . 3 –Re pl acing t he pow er s u p ply ca ble
It is good practice to constantly check the state of wear of the insulation cable before
connecting it to the power mains. If it has been damaged, even in part, replace the cable at
once.
Immediate maintenance: New Age Italia or staff authorized by New Age Italia must
perform immediate maintenance if:
the device has been submitted to outside mechanical stress, such as serious falls;
the device has been subject to strong overheating, for example if it is left near intense
heat sources;
one suspects that fluids may have leaked into the device;
the power supply cable, the cover or any other part of the device is damaged, broken
or missing;
the operation of the device appears to be altered.
For safety purposes, do not work with any other accessories (for example head or
power supply cable) different from those provided together with the device.
Maintenance, functional control and monitoring the compliance with the safety
regulations EN60601-1 on medical devices –carried out using a secur-tester –must be
performed once a year. The working life of the instrument is guaranteed by the company
only if such maintenance is performed regularly.

Rev. 02 of 10/12/04
20/24
IMPORTANT NOTICE: Service should be performed only by New Age Italia or by the
specialized personnel appointed by New Age Italia. For maintenance purposes, the device
may be sent directly to the company service laboratories or else delivered to the dealer it
was purchased from.
Service Centre:
New Age Italia srl
Via Keplero, 7 - 48022 Lugo (RA)
Tel:[phone] –Telefax: +39-0545.369028
Website: www.newageitalia.it e-mail: [email protected]
Chap. 8 –SYMBOLS
CLASS II APPLIANCE
BF TYPE APPLIANCE
WARNING, REFER TO ENCLOSED DOCUMENTATION
THIS DEVICE HAS CE MARKING ACCORDING TO THE EEC
DIRECTIVE 93/42.
O476
