CAE Apollo User manual

User Guide
Your worldwide
training partner
of choice
CAEApollo

©2020 CAE 905K351052 v1.1 i
Contents
CONTENTS
Contents....................................................................................................................... 1
Cautions and Warnings .............................................................................................. 1
Electrical Safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Product Use Warnings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Manikin. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Fluids System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Important Canister Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
CO2 Canister . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
CO2 Regulator Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Use of Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Simulator Batteries. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Battery Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Precautions for Handling. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Potential Health Effects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Safety Measures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Transport Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Specifications .............................................................................................................. 9
Size and Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Ambient Temperature Range. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Maximum Altitude . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Communications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Electrotherapy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Air Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
CO2 Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
System Requirements .............................................................................................. 13
Software and Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Windows® Operating System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Mac® Operating System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Approved Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Equipment Overview................................................................................................ 15
Standard Equipment and Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

Contents
ii ©2020 CAE 905K351052 v1.1
CAEApollo
Full-Body Wireless Manikin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Instructor Laptop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
CO2 Canisters (Prehospital Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Power Adapter and Cord. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Inventory Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Trauma Fill Tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Optional Equipment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Patient Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Microsoft Surface Go Tablet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Apollo Replacement Lithium Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
External Compressed Air Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
External CO2 Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Air Compressor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Hands-Free Training Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Tool Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
FX™ Simulated Wound Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Moulage Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Meet Apollo ............................................................................................................... 21
Setup .......................................................................................................................... 23
Unpacking the Manikin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Setup Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Setup Procedure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Step 1: Place the Manikin in the Work Area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Step 2: Attach Lower Legs to the Manikin. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Step 3: Power on the Manikin. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Step 4: Power on the Instructor Laptop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Step 5: Connect to the Simulator’s Network. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Step 6: Launch Maestro . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Optional Step: Setup the TouchPro Computer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Optional Step: Connect to the SpO2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Optional Step: Connect External Air. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Optional Step: Insert CO2 Canister (Prehospital Only) . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Optional Step: Detach the Arms. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Optional Step: Prepare the Bleeding System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Using Apollo............................................................................................................... 37
Neurologic System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37

©2020 CAE 905K351052 v1.1 iii
Contents
Neurologic System Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Head Secretions (Prehospital Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
Respiratory System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
Respiratory System Controls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
Chest Excursion. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
Cricothyrotomy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
Tracheostomy Tube Placement and Suctioning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
Cardiovascular System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
Cardiovascular System Controls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
Pulses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
IV Cannulation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
IV Administration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
Intramuscular (IM) Subcutaneous (SQ) Injection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
Intraosseous (IO) Cannulation and Administration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
Subclavian Catheter (Nursing Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
Hemorrhage Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
Chest Compressions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57
ECG . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57
Defibrillation, Cardioversion, and Pacing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
Blood Pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61
Gastrointestinal System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
Gastric Gavage and Lavage (Nursing Only). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
Genitourinary System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64
Changing the Simulator’s Genitalia . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64
Urinary Catheterization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64
Medication Administration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66
Simulated Medication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66
Intravenous, Intramuscular/Subcutaneous, and Intraosseous Medication. . . . . . . . . .66
Wound Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66
Tourniquet Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66
Sounds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67
Speech . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67
Microphones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .68
Care and Maintenance ............................................................................................. 69
General Simulator Care. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69
Breakdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69

Contents
iv ©2020 CAE 905K351052 v1.1
CAEApollo
Step 1: Clean the Manikin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .70
Step 2: Remove Excess Fluids . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .70
Step 3: Power off the Instructor Laptop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .75
Step 4: Power Off the Manikin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .76
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .76
Airway Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .76
Replacing the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .76
Recharging the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .78
Storage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .79
Short-Term Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .79
Long-Term Storage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .80
Appendix A - Recommended Clinical Supplies ...................................................... 81
Appendix B - Wireless Voice Link ............................................................................ 83
Cautions and Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .83
Recommendations for Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .83
Wireless Voice Link Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .83
Physical Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .84
Preparing the Base Station in the Simulator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .85
Preparing the Handset for Use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .86
Selecting the Radio Frequency Channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .87
Powering Up the WVL Pair. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .88
Using the iPhone/Standalone Microphone. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .88
Special Handset Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .89
Battery Capacity Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .89
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .89
Power Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .90
Audio Problems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .90
RF Channel Initial Operating Frequencies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .91

©2020 CAE 905K351052 v1.1 1
Cautions and Warnings
CAUTIONS AND WARNINGS
Please read and understand these cautions and warnings before you begin using the Product.
Important: Do not use the product in any manner other than specified, as safety features designed
for protection may be impaired.
Electrical Safety
• This product must be connected to an electrical outlet that is properly grounded. Take
precaution to ground or polarize correctly.
• Always use the supplied power cords. Do not substitute.
• Always use the supplied power adapter to run the simulator from AC.
• Operate the system from a power source with the following ratings.
• Do not allow excess fluids to flow on or into electronic parts.
• Do not attempt to disassemble the simulator or service any of the electrical components
without receiving instructions from Customer Service.
• Do not operate the manikin in rain. Apply water to the manikin only in accordance with the
supported clinical procedures explained in this guide.
Power Frequency
(cycles per second)
Location
120 VAC 50/60 hertz North America, Japan
220 VAC 50/60 hertz Europe

Cautions and Warnings
2 ©2020 CAE 905K351052 v1.1
CAEApollo
Product Use Warnings
Manikin
• Make sure the manikin is set up on a stable, sturdy work surface that will not collapse and
cause injury to users.
• Operate the manikin in ambient temperatures below 104°F (40°C).
Note: This only applies when using the manikin without the tablet where CAEMaestro
software is installed. For information about temperature ranges for the tablet, see
Ambient Temperature Range in the Specifications section of this User Guide.
• Do not disassemble factory-assembled parts of the manikin without receiving instructions
from Customer Service.
• Clean the manikin with water and a light soap solution only. Do not use chemical solvents.
Do not immerse the manikin in liquid or use abundant liquid to wash the manikin. For
more information, see the Care and Maintenance section.
• Do not place foreign substances into the airway, with the exception of small amounts of
approved lubricant. Only perform invasive procedures supported by the Product as
described in the applicable sections of the User Guide.
• Do not insert any materials into the manikin except the equipment or probes supplied.
• Do not lift the manikin by its limbs. Support the head and lift it from the torso. If necessary,
have another person help you lift and move the manikin using a patient transfer device
such as a patient transfer board, when available.
Fluids System
For manikins such as Apollo that are equipped with fluid systems:
• Do not modify the reservoirs or any assembly component.
• Always protect your eyes, skin, and clothing against accidental exposure.

©2020 CAE 905K351052 v1.1 3
Cautions and Warnings
Important Canister Information
The 16 Gram CO2 Canister with threaded neck is available at most sports equipment retailers - most
often used for bicycle tire inflators. We recommend purchasing Leland brand canisters (P/N 82122Z),
which are also available from CAE.
Punctured canisters are considered to be empty. No residue remains in the canister after use. The
steel used is a low carbon type, which rusts if disposed in a landfill. If your community requires
recycling, then place with normal household recycling.
CO2 Canisters are considered by the U.S. Department of Transportation to be “Other Regulated
Materials - Domestic” (ORM-D). Ground shipping containers must be clearly marked with this label.
CO2 Canisters are considered hazardous material when offered for air transportation, so different
rules apply. Contact carrier for details and instructions.
CO2 Canister
• Store the CO2 canisters in a dry location between 32° and 104° F (0 to 40°C).
• Do not expose the CO2 canister to heat above 140° F, as rupture may occur.
• Never point the CO2 canister towards your face or someone nearby.
• Use only CAE specified CO2 canisters.
CO2 Regulator Assembly
• Care must always be taken when using high-pressure equipment.
• Do not disassemble or alter regulator.
• Dry completely if the regulator becomes wet.
• Discontinue use of this equipment if leakage or visible damage is evident.

Cautions and Warnings
4 ©2020 CAE 905K351052 v1.1
CAEApollo
Use of Equipment
• Canister end becomes punctured when screwed into regulator base and therefore should
not be removed until empty.
• Unscrewing canister before it is empty will result in sudden release of all high-pressure
gas with a possibility of liquid CO2 spray. Unprotected skin could receive freezing burns.
• Wear protective gloves and eye protection when removing canister from regulator
assembly.
• Remove CO2 canister from regulator assembly when shipping simulator.
Battery
Manikins and tablets use lithium batteries that all have special handling requirements to avoid
hazardous situations.
For more information about battery specifications, see the Specifications section. For more
information about battery safety, see the Battery Safety Information section.
Simulator Batteries
• Always store the polymer lithium-ion battery pack indoors.
• Always keep the battery away from objects or materials with static electric charges.
• Batteries can be charged and used between 32°F (0°C) and 113°F (45°C)Do not charge the
battery while it is inside the simulator.
• Do not use or charge the battery inside of a car where temperatures may exceed 176˚F
(80˚C).
Manufacturer BatterySpace.com/ AA Portable Power Corp.
825 South 19th street, Richmond, CA 94804
Website: http://www.batteryspace.com
Email: [email protected]
Phone number 510-525-2328
Or contact your national poison information center in the event of an
emergency.

©2020 CAE 905K351052 v1.1 5
Cautions and Warnings
Battery Replacement
• If a simulator battery needs to be replaced, immediately remove the old battery from the
equipment to ensure no damage occurs.
• Before disposing of a simulator battery, apply vinyl tape to its positive (+) and negative (-)
terminals to avoid short circuits.
• If the simulator battery power diminishes significantly, contact Customer Service to
replace the battery. For safety, only replace the battery with an approved make and
model.
Battery Safety Information
For information about battery specifications, see the Specifications section of this user guide.
Important: Refer to the battery manufacturer’s Safety Data Sheet (SDS) for complete safety
instructions and handling information.
Precautions for Handling
Hazards are associated with the contents of the cell or battery. Under recommended use conditions,
the electrode materials and liquid electrolyte are non-reactive, as long as the cell or battery integrity
remains, and the seals remain intact.
Potential exposure should not exist unless the cell or battery:
• leaks,
• is exposed to high temperatures,
• is mechanically, electrically or physically abused/damaged.
If the cell or battery is compromised and starts to leak, based upon the battery ingredients, the
contents are classified as hazardous. In general, if liquid leaks from the battery or foul odor is
detected, DO NOT use the battery and keep it away from heat or flame.
• Avoid short circuiting the battery. Do not store with coins, screws or other similar objects.
• Do not immerse in water.
• Do not disassemble or deform the battery.
• Do not expose to, or dispose of the battery in fire.
• Avoid excessive physical shock or vibration.
• Keep out of the reach of children.
• For rechargeable batteries, the battery must be charged in an approved charger.
• Never use a modified or damaged charger.

Cautions and Warnings
6 ©2020 CAE 905K351052 v1.1
CAEApollo
• Store in a cool, dry, and well-ventilated area.
• Never use a battery that has been damaged or deformed.
• Do not short-circuit the positive (+) and negative (-) terminals.
• Do not place the battery in a device with the positive (+) and negative (-) terminals in the
wrong positions.
• Do not solder a battery directly.
Potential Health Effects
• Acute (short term): In the event that the cell or pack ruptures, the electrolyte solution
contained within the cell will corrode and can cause burns to skin and eyes.
• Inhalation: Inhaling materials from a sealed cell is not an expected route of exposure.
Vapors or mists from a ruptured cell can cause respiratory irritation.
• Ingestion: Swallowing materials from a sealed cell is not an expected route of exposure.
Swallowing the contents of an open cell can cause serious chemical burns to mouth,
esophagus, and gastrointestinal tract.
• Skin: Contact between the cell and skin will not cause any harm. Skin contact with the
contents of an open cell can cause severe irritation or burns to the skin.
• Eye: Contact between the cell and the eye will not cause any harm. Eye contact with the
contents of an open cell can cause severe irritation or burns to the eye.
• Interactions with other chemicals: Immersion in high conductivity liquids can corrode
or breach the cell or battery enclosure. The electrolyte solution inside of the cells can react
with alkaline (basic) materials and present a flammability hazard.
Safety Measures
Only trained personnel familiar with the battery safety information should handle the simulator
batteries.
Should exposure to hazardous battery components occur, or in the event of a fire, follow all local first
aid measures and safety protocols.
Transport Information
CAE complies with the most current International Air Transport Association (IATA) Dangerous Goods
Regulations when transporting and shipping Li-ion batteries. The following terms are defined as
follows:
Consignment - Equivalent to the term "shipment,” meaning one or more packages of
hazardous materials accepted from one shipper at one time and at one address, receipted
in one lot, and moving to one consignee at one destination address.

©2020 CAE 905K351052 v1.1 7
Cautions and Warnings
Equipment - The device or apparatus for which the lithium cells or batteries will provide
electrical power for its operation.
It is the shipper’s responsibility to ensure that the consignment is packed in compliance to the latest
edition of the applicable regulations. Regulations require appropriate training for shipping dangerous
goods. Shipping regulations and requirements may vary depending upon:
• Wattage of the battery.
• Whether the battery is shipped independent of, contained within, or packed with the
equipment.
When transporting batteries CAE follows these documentation and labeling requirements:
Item Description
Batteries Shipped Independent of
the Tablet and/or Laptop
Batteries contained in or packed
with the Tablet and/or Laptop
UN No. 3480N No. 33480480 3481
UN Shipping
Name:
Lithium-ion Batteries Lithium-ion Batteries
Transport Hazard
Class:
9 9
Labeling:

Cautions and Warnings
8 ©2020 CAE 905K351052 v1.1
CAEApollo
Batteries contained in or packed with the MSI TouchPro
UN No. 3091
UN Shipping Name: Lithium Metal Batteries
U
Transport Hazard Class: 9
Labeling:

©2020 CAE 905K351052 v1.1 9
Specifications
SPECIFICATIONS
All hardware and software needed for operating the simulator are provided with the shipment.
Size and Weight
Ambient Temperature Range
Maximum Altitude
Equipment Size Weight
Manikin/Simulator 74” H x 26” W x 11” D
(188 cm x 66 cm x 28 cm)
100lbs (45.4kg)
Instructor Tablet/
Laptop
Surface Pro 7
11.5” x 7.9” x 0.33”
(29.2 cm x 20.1 cm x 0.85 cm)
Surface Pro 7
1.7 lb (775 g)
Item Operation Storage Relative Humidity
Manikin/Simulator 40°F to 104°F
(4°C to 40°C)
40°F to 122°F
(4°C to 50°C)
0% to 90%
non-condensing
Laptop 50°F to 95°F
(10°C to 35°C)
-13°F to 113°F
(-24°C to 45°C)
0% to 90%
non-condensing
Item Operation Storage Shipping
Laptop 10,000 ft (3,048 m) 15,000 ft (4,572 m) 35,000 ft (10,668 m)

Specifications
10 ©2020 CAE 905K351052 v1.1
CAEApollo
Battery
Power
Communications
Electrotherapy
Item Description
Commercial product name Powerizer Custom Li-ion
Use of the substance/
preparation
Lithium-ion (Li-ion) battery
Additional Information Battery-System: Lithium-ion
Wh rating: 233.1 Wh
Item Description
StethoSym • Run Time: 2 hr 45 min while constantly reading a RFID tag and playing
audio; 4 hours when ON and receiving signal (Sleep Mode)
• Recharge time: 50 minutes
SymDefib • Run Time: 17 hours (with Pads not on Manikin)
• 2-3 hours (with Pads on Manikin)
Item Description
Simulator Network • Wired: 10/100 Ethernet
• Wireless: IEEE 802.11 g
•
Wireless Voice • 537 MHz to 819MHz (Country Specific)
Item Description
Defibrillation • 20 to 360 Joules (Monophasic, Biphasic)
Pacing • 20 mA to 180 mA

©2020 CAE 905K351052 v1.1 11
Specifications
Air Supply
To properly regulate psi, the optional wall air kit must be used in conjunction with the facility supply
source and facility wall adapter. The wall air kit is an additional optional accessory. When using a CAE
External Air kit in conjunction with a supply source at a facility, it is recommended that the facility air
supply be 30-psi to 60-psi (2-bar to 4-bar). The source should be clean, dry air.
CO2 Supply
Apollo pre-hospital simulator will have four CO2cartridges included in the shipment. When using
the optional CAE External CO2 Kit in conjunction with the facility CO2source and adapter, the
recommended pressure is 30-psi to 60-psi (2-bar to 4-bar).

Specifications
12 ©2020 CAE 905K351052 v1.1
CAEApollo
THIS PAGE INTENTIONALLY LEFT BLANK

©2020 CAE 905K351052 v1.1 13
System Requirements
SYSTEM REQUIREMENTS
This section describes the minimum and optimal requirements to run the simulator.
Software and Hardware
Any computer (or tablet) used to operate the Maestro or Patient Monitor software must meet
minimum hardware and software requirements. However, optimal requirements should be met to
enhance performance. These requirements also apply to devices running Maestro Standalone.
Windows® Operating System
Mac® Operating System
Mac is a registered trademark of Apple Inc. Windows and Internet Explorer are registered trademarks
of the Microsoft Corporation in the United States and/or other countries. Chrome is a registered
trademark of Google Inc.
Minimum Requirements
Software • Win 10 Pro
Hardware • Surface Pro
• Intel Pentium Gold Processor 4425Y
• 4 GB DDR3 RAM
• 32 GB Hard Drive space available
• 1920x1280 screen resolution
• USB-C
• Wireless 802.11 a/b/g/n/ac/ax
Minimum Optimal
Software • Mac OS X 10.12 (Sierra) • Mac OS X 10.13 (High Sierra)
Hardware • Intel Core 2 Duo, 2.0 GHz
• 4 GB DDR3 RAM
• 32 GB Hard Drive space available
• 1024x768 screen resolution
• USB 2.0
• Wireless 802.11b/g/n Ethernet card
100BASE-T Ethernet Adapter
• Intel Core i5 CPU
• 8 GB DDR3 RAM
• 32 GB Hard Drive space available
• 1920x1080 screen resolution
• USB Port
• Wireless 802.11b/g/n Ethernet card
100BASE-T Ethernet Adapter

System Requirements
14 ©2020 CAE 905K351052 v1.1
CAEApollo
Approved Devices
Note: Upon installation, the software takes up 1.2 GB of hard drive. For standalone versions of
Maestro, the software can store approximately 30.8 GB of patient record files. In the event this
storage capacity is expected to be maximized, plan for additional hard drive space.
Make/Model • MacBook Pro (Mid-2012 or newer), MacBook Air, or iMac
Software • macOS 10.14
• Google Chrome
Hardware • Intel Core i5 1.6 GHz
• 4GB RAM (8 GB RAM recommended)
• 32 GB Hard Drive free space available
• 1440x900 screen resolution
Make/Model • Microsoft Surface Pro 7
Software • Windows 10
• Google Chrome
Hardware • Intel Core i5 1.6 GHz
• 4 GB RAM (8GB RAM recommended)
• 32 GB Hard Drive free space available
• 1366x768 screen resolution

©2020 CAE 905K351052 v1.1 15
Equipment Overview
EQUIPMENT OVERVIEW
Apollo has been designed to be used in any learning environment. Apollo’s standard features are
easily integrated into a laboratory setting or remote locations. Apollo comes with standard
equipment as well as optional equipment.
Optional equipment refers to items which are available for purchase to enhance the simulation
experience and additional accessories refers to consumable items which are available for purchase
as they may need to be replaced.
Standard Equipment and Accessories
Apollo comes with standard equipment and accessories.
Full-Body Wireless Manikin
All patient assessments and clinical interventions are played out on the Apollo manikin, which
represents a human patient. At six feet, two inches (188 cm) in height and weighing 100 pounds
(45.36 kg), Apollo is fully operational in the supine, lateral, prone and seated positions. The simulator
offers features like arm pronation and supination; breath, heart and bowel sounds; palpable pulses;
patient voice; and genitourinary features.
Instructor Laptop
The laptop Instructor Workstation is a computer that utilizes Müse or Maestro software to operate as
the main simulation control center. Instructors control the simulation session from the workstation
by running Simulated Clinical Experiences (SCEs) that meet their learning objectives or on the fly.
IMPORTANT: All CAE computer components are preconfigured for use with the simulator. There are
no software installation steps required. Only approved CAE applications should be installed or run
with the simulator.
Standard Equipment and Accessories
Full-Body Wireless Manikin
Instructor Laptop
CO2 Canisters (Prehospital Only)
Power Adapter and Cord
Inventory Kit
Trauma Fill Tank
