New-Flow T-1000 User manual

Instruction Manual
MANUFACTURE OF FIELD MOUNTED
TEMPERATURE TRANSMITTER WITH DISPLAY
T-1000

New-Flow Field Mounted Temperature Transmitter With Display Instruction Manual
page 1
Technical Data
Parts Location
Cover with Lens
Inner Figure
Power Input
Terminal
Sensor Converter
NT-IB
Sensor Input Terminal
RTD wire
A-Red
B-Black
B-Black
Sensor
(NT-IB Output)
R+ W-
Sensor
Indicator
Enclosure
Housing
Dimensions

New-Flow Field Mounted Temperature Transmitter With Display Instruction Manual
page 2
1. Factory mode (ZERO, SPAN, UNIT, DOT DEFAULT), JP1 with Short Pin.
− Zero setting (ZERO mA): Supply “4mA” on the line (or the represented current value for “ZERO”).
Depress “A/B”, LCD display “ZERO mA” , and “004.00”
Depress “B+A” LCDdisplay “004.0U
0
U”（Digit with under line__ be flashed, depress button
“B” to increase the value),
Depress “B” once for 1 increment “004.0U
1
U”, depress “B” once again 2, 3,
4, . ..9, 0 ...until the number you want.
Depress “A” shift the flashed digit to next left digit. “004. U
0
U3”.
Depress “B” to adjust the number as requested,
Depress “A” and “B” until get the represented value of “ZERO”.
Depress “B+A”, LCD display “ZERO mA” on lower line and the final number (or 004.00)
on upper line.
Front
DC supply input
Rear
LCD display
Parameter and Default Value
Zero Setting (ZERO mA): 4mA
Full Span Setting (SPAN mA): 20mA
Unit Adjust (UNIT mA): mA
Decimal Point (DOT): 2 digits (4.00mA~20.00mA)
DEFAULT recover (DEFAULT):
Control Knob and Input Terminals’ Location
Button “B” Button “A” Meter Input Sensor Input
Mold Select
(JP1)
All segments of LCD light on for about 2.0 seconds, then LCD display “NEW-FLOW” and “88888”, scale indicator
“ for 2.0 seconds”. (88888, light on 1 and
Stat Turn On
st 2 digit...till 5 digit sequentially, scale indicator light on from 1 nd th st
till full scale.)
1. JP1: Short
Factory mode (there is 5 parameters. ZERO, SPAN, UNIT, DOT, and DEFAULT).
2. JP1: Open
User mode (there is only 4 parameters. ZERO, SPAN, UNIT, and DOT)
Parameter Adjustment
“A”: Depress button “A”
“B”: Depress button “B”
“A/B”: Depress button “A” firstly, then depress button “B” (Hold button “A” same time).
“B+A”: Depress button “B” firstly, then button “A” (Hold button “B” same time).
Steps

New-Flow Field Mounted Temperature Transmitter With Display Instruction Manual
page 3
“mA, A, mV, V, PH, °F, °C, PSI, Pa, Kpa, Mpa, mbar, bar, %, M, cm, BLANK, mA, A, ..... )
Depress “A” and/or “B” until get the right “UNIT” you want.
Depress “A” for next parameter adjustment ”Decimal point”).
If you want to finish parameter setting, depress “B+A” and then “A/B” to return to
operation mode, the LCD display “ mA” on lower and “015.00” (according to the
Sensor input current) on upper line.
Depress “A/B”, LCD display “ZERO mA”on lower line, and “004.00” on upper line.
Depress “A”, LCD display “SPAN mA” on lower line and “020.00” on upper line.
− Decimal Point (DOT): 2 digits (4.00mA~20.00mA)
Depress A”, LCD display “UNIT mA” on lower and , “---.--” on upper.
(or continuously set the parameter from last parameter setting “UNIT setting”)
Depress “A” for next parameter set (SPAN mA).
If you want to finish parameter set, depress “A/B” return to operation mode. the LCD
display “ mA” on lower line and “final set number or 004.00” on upper line.
Note:
Represented “SENSOR ZERO value” (4.0mA) must be supplied into the power line.
− Full Span setting (SPAN mA): Supply “20mA” on the line (or the represented current value for “full span”).
Depress “A/B”, LCD display “ZERO mA” on lower line, and
“004.00” on upper line.
(or continuously set the parameter from Zero setting “ZERO mA”).
Depress “A”, LCD display “SPAN mA” on lower line and “020.00”
on upper line.
Depress either one of button “A” or/and “B” with Referring the adjusting procedure of
“Zero setting (ZERO mA)” to get the represented number of full span.
Depress “B+A”, LCD display “SPAN mA” on lower line and the final number (or 020.00)
on upper line.
Depress “A” for next parameter set (Unit Setting).
If you want to finish parameter setting, depress “A/B” return to operation mode. The LCD
display “ mA” on lower line and “final set number or 020.00” on upper line.
Note:
Represented “SENSOR full span value” (20mA) must be supplied in to the power line.
Unit Setting (UNIT) : mA
Depress “A/B”, LCD display “ZERO mA” on lower line, and “004.00” on upper line.
Depress “A”, LCD display “SPAN mA” on lower line and “020.00” on upper line.
(or continuously set the parameter from last parameter setting “Full span setting”).
Depress A”, LCD display “UNIT mA” on lower and , “---.--” on upper.
Depress “B+A”, LCD display “UNIT
U
mA
U” (“mA” flashing)
Depress “B”, LCD display “UNIT
U
A
U”, depress “B” once again the “Unit”
will be changed as the following sequence

New-Flow Field Mounted Temperature Transmitter With Display Instruction Manual
page 4
− Zero setting (ZERO mA):
2. JP1: open
USER mode (ZERO, SPAN, UNIT, DOT).
The parameter (ZERO, SPAN, UNIT, DOT) adjustment is same as above steps of
factory mode, except no need input represented value of zero or full span (just pass
some current between 4 ~ 20mA into the power line).
No need input represented current value for ZERO and SPAN setting..
All 4 parameters adjustment is independent, which is set as per different requirement.
On USER mode, can not recover the PARAMETER to default value, it is to keeping the
meter assurance.
Depress “A/B”, LCD display “ZERO mA” on lower line, and “004.00” on upper line.
Depress “B+A”, LCD display “004.0U
0
U”（Digit with under line ˍbe flashed,
depress button “B” to increase the value),
Depress “B” once for 1 increment “004.0U
1
U”, depress “B” once again 2, 3,
4, ...9, 0, 1....until the number you want.
Depress “A”, LCD display “DOT ” on lower and , “---.--” on upper.
Depress “B+A”, LCD upper line “---.--”.flashing display
Depress “B”, the decimal point will be shifted forward to the next left digit“--.---”.
Depress “B” once again, the decimal point shift toward to left. “-.----”.
Depress “B” until what number of decimal point you want.
Depress “B+A” to complete decimal point set. LCD display “DOT ” on lower line and
“-.----” (decimal point at the last setting).
To complete parameter setting, depress “A/B” for returning to operation mode, the LCD
display “ mA” on lower line and “0.0510” (according to the Sensor input current) on
upper line..
Depress “A/B” to parameter adjust mode. , LCD (below) “ZERO mA” and ,
(above) “004.00”
Depress “B”, LCD display “DEFAULT” on lower line and “888.88”on upper line.
(If you do not want to recover to DEFAULT value, you just depress “A” and A/B to return
to operation mode).
Depress “B+A”, LCD display “DEFAULT” on lower line and “U
888.88
U” (flash) on upper line.
Depress “B”, all parameter recover to original default value. And the meter returns to
operation mode. LCD display “ mA” on lower and “005.10” (according to the Sensor
input current) on upper line.
Remarks :
“Default recovery” can be done at either one of parameter set (ZERO, SPAN, UNIT,
DOT).Just depress “B” with above procedures for recovering to DEFAULT value.
− Default Value Recovery (DEFAULT):

New-Flow Field Mounted Temperature Transmitter With Display Instruction Manual
page 5
Unit Setting (UNIT) : mA
Depress “A/B”, LCD display “ZERO mA” on lower line, and “004.00” on upper line.
Depress “A”, LCD display “SPAN mA” on lower line and “020.00” on upper line.
(or continuously set the parameter from last parameter setting “Full span setting”).
Depress A”, LCD display “UNIT mA” on lower and , “---.--” on upper.
Depress “B+A”, the LCD display “UNIT
U
mA
U” (“mA” flashing)
Depress “B”, LCD display “UNIT
U
A
U”, depress “B” once again the “Unit”
will be changed as the following sequence
“mA, A, mV, V, PH, °F, °C, PSI, Pa, Kpa, Mpa, mbar, bar, %, M, cm, BLANK, mA, A, ..... )
Depress “A” and/or “B” until get the right “UNIT” you want.
Depress “A” for next parameter adjustment ”DECIMAL point”).
If you want to finish parameter setting, depress “B+A” and then “A/B” to return to
operation mode, the LCD display “last setting % (or mA)” on lower and
“035.92” (according to the Sensor input current) on upper line.
Depress “A” shift the flashed digit to next left digit. “004. U
0
U
3”.
Depress “B” to adjust the number of 2nd digit as requested,
Depress “A” and/or “B” until getting the represented value of “ZERO”.
Depress “B+A”, LCD display “ZERO mA” on lower line and the final number (or 004.00)
on upper line.
Depress “A” for next parameter set (SPAN mA).
If you want to finish parameter set, depress “A/B” return to operation mode. the LCD
display “ mA” on lower line and “real input current (or relative number)” on upper line.
Depress “A/B”, LCD display “ZERO mA” on lower line, and
“004.00” on upper line.
(or continuously set the parameter from last setting “ Zero setting”).
Depress “A”, LCD display “SPAN mA” on lower line and “020.00”
on upper line.
Depress either one of button “A” or/and “B” with referring to the adjusting procedure of
“Zero setting (ZERO mA)” until getting the represented number of full span.
Depress “B+A”, LCD display “SPAN mA” on lower line and the final number (or 020.00)
on upper line.
− Full Span setting (SPAN mA):
Depress “A” for next parameter set (Unit Setting).
If you want to finish parameter setting, depress “A/B” return to operation mode. The LCD
display “ mA” on lower line and “real input current (or relative number)” on upper line.

New-Flow Field Mounted Temperature Transmitter With Display Instruction Manual
page 6
Blocking Diagram
NOTE.
DC 24V
DC power supply
SENSOR
Sensor Input
1. DC24V Power Supply, Transducer sensor 2. 4~20mA Power Supply
Meter Input
+
–
4~20mA
− Decimal Point (DOT): 2 digits (4.00mA~20.00mA)
Depress “A/B”, LCD display “ZERO mA”on lower line, and “004.00” on upper line.
Depress “A”, LCD display “SPAN mA” on lower line and “020.00” on upper line.
Depress A”, LCD display “UNIT mA” on lower and , “---.--” on upper.
(or continuously set the parameter from last parameter setting “UNIT setting”)
Depress “A”, LCD display “DOT ” on lower and , “---.--” on upper.
Depress “B+A”, LCD upper line “---.--”.flashing display
Depress “B”, the decimal point will be shifted toward to the next left
digit“--.---”.
Depress “B” once again, the decimal point shift toward to more left. “-.----”.
Depress “B” until what number of decimal point you want.
Depress “B+A” to complete decimal point set. LCD display “DOT ” on lower line and
“-.----” (decimal point at the last setting).
To complete parameter setting, depress “A/B” for returning to operation mode, the LCD
display “ %” on lower line and “0025.0” (according to the Sensor input current) on
upper line..
Error Message:
3.75 mA
Over range: 3.75mA、Element fail: 3.75mA.
