New Holla d
Mid-mou t Fi ishi g Mower Specificatio s
54CMS 60CMS 230GM
Pa e 1 of 3
MODEL 54CMS 60CMS 230GM
SIZE 54-inch 60-inch 60-inch
Cutting width, in. (mm) 54 (1371.6) 60 (1524.0) 60 (1524.0)
Number of blades ........................................................................................................................................3..............................................................................................................
Blade length, in. (mm) 18.7 (475) 20.6 (523.2) 20.6 (523.2)
Blade width, in. (mm) 2.4 (61) 2.8 (71.1) 2.8 (71.1)
Blade tip speed (fpm) 14,970 15,452 15,452
Blade type .............................................................................................................................................. tandard .......................................................................................................
PTO drive ...................................................................................................................................................Mid............................................................................................................
Cutting height - min. setting, in. (mm) ..................................................................................................1 (25.4)........................................................................................................
Cutting height - max. setting, in. (mm).................................................................................................4 (101.6) .......................................................................................................
Transport height, in. (mm) ....................................................................................................................6 (152.4) .......................................................................................................
Gauge wheels, in. (mm) ...............................................................................................................5 x 2.8 (127 x 71.1) ..............................................................................................
Overall width, in. (mm) 67.9 (1724.7) 73.8 (1874.5) 73.8 (1874.5)
Compatibiity with loader ............................................................................................................................Yes............................................................................................................
Tire compatibility:
Agricultural (R1) ....................................................................................................................................Yes............................................................................................................
Industrial (R4)........................................................................................................................................Yes............................................................................................................
Turf (R3).................................................................................................................................................Yes............................................................................................................
Weight, lbs. (kg) 220 (99.8) 254 (115.2) 254 (115.2)

New Holla d
Mid-mou t Fi ishi g Mower Specificatio s
914A Side-discharge 914A Rear-discharge
Pa e 2 of 3
MODEL 914A Side-dischar e
SIZE 54-inch 60-inch 60-inch 72-inch
Cutting width, in. (mm) 54 (1371.6) 60 (1524.0) 60 (1524.0) 72 (1828.8)
Cutting height - min., in. (mm) 1.5 (38.1) 1 (25.4) 1.5 (38.1) 1.5 (38.1)
Cutting height - max., in. (mm) 4 (101.6) 3.5 (88.9) 4 (101.6) 4 (101.6)
Overall width, in. (mm) 67 (1701.8) 73.3 (1860.6) 76.5 (1943.1) 85.5 (2171.7)
Number of blades .......................................................................................................................................3...............................................................................................................
Blade type tandard High lift High lift tandard
Blade length, in. (mm) 18.3 (463.6) 20.4 (518.2) 20.4 (518.2) 24.5 (622.3)
Blade width, in. (mm) 2.5 (63.5) 2.5 (63.5) 2.5 (63.5) 3 (76.2)
Blade tip speed (fpm) 16,026 15,306 15,306 15,616
PTO drive ..................................................................................................................................................Mid.............................................................................................................
Gauge wheels, in. (mm).............................................................................................................6 x 2.5 (152.4 x 63.5)..............................................................................................
Deck spring suspension ....................................................................................................................... tandard ........................................................................................................
Compatibiity with loader ...........................................................................................................................Yes.............................................................................................................
Tire compatibility:
Agricultural (R1) ...................................................................................................................................Yes.............................................................................................................
Industrial (R4).......................................................................................................................................Yes.............................................................................................................
Turf (R3)................................................................................................................................................Yes.............................................................................................................
Galaxy®Turf NA NA Yes* Yes*
Weight, lbs. (kg) 440 (199.6) 475 (215.5) 515 (233.6) 530 (240.4)
* Requires accessory
MODEL 914A Rear-dischar e
SIZE 60-inch 72-inch 84-inch
Mulching design.........................................................................................................................................Yes............................................................................................................
Cutting width, in. (mm) 60 (1524.0) 72 (1828.8) 84 (2133.6)
Cutting height - min., in. (mm) 1.5 (38.1) 1.5 (38.1) 2 (50.8)
Cutting height - max., in. (mm).............................................................................................................4 (101.6).......................................................................................................
Overall width, in. (mm) 62.4 (1585.0) 74.4 (1889.8) 87.4 (2220.0)
Number of blades 334
Blade type tandard High lift Gator Mulcher®blades
Blade length, in. (mm) 20.4 (518.2) 24.5 (622.3) 22.8 (579.4)
Blade width, in. (mm) 2.5 (63.5) 3 (76.2) 3 (76.2)
Blade tip speed (fpm) 15,306 15,616 15,616
PTO Drive...................................................................................................................................................Mid............................................................................................................
Gauge wheels, in. (mm)..............................................................................................................6 x 2.5 (152.4 x 63.5).............................................................................................
Deck spring suspension ........................................................................................................................ tandard .......................................................................................................
Compatible with loader ..............................................................................................................................Yes............................................................................................................
Tire compatibility:
Agricultural (R1) ....................................................................................................................................Yes............................................................................................................
Industrial (R4)........................................................................................................................................Yes............................................................................................................
Turf (R3).................................................................................................................................................Yes............................................................................................................
Galaxy®Turf NA Yes* Yes*
Weight, lbs. (kg) 424 (192.3) 520 (235.9) 775 (351.5)
* Requires accessory

New Holla d
Mid-mou t Fi ishi g Mower Specificatio s
Grass Catcher Specificatio s
9CG, U it for 914A
Pa e 3 of 3
MODEL 9CG Unit for 914A
Number of bags.........................................................................................................................3 ................................................................................................................................
Bag capacity (less lid) - bu. 9.75 NA
Bag capacity (with lid) - bu. 12 10
Dump system .......................................................................................................................Manual ...........................................................................................................................
Impeller blade #.........................................................................................................................4 ................................................................................................................................
Impeller and blower assembly type High density polyethylene Welded steel
Width with 54-inch mower deck, in. (mm) 68 (1727) NA
Width with 60-inch mower deck, in. (mm) 73 (1854) NA
torage stands tandard NA
Drive type PTO shaft drive Belt drive to 90-degree gearbox
Mount type....................................................................................................................Three-point hitch ...................................................................................................................
Weight, lbs. (kg)..................................................................................................................180 (82) ..........................................................................................................................
Safety begins with a th r ugh understanding f
the equipment. Always make sure y u and
y ur perat rs read the Operat r’s Manual
bef re using the equipment. Pay cl se
attenti n t all safety and perating
decals and never perate machinery
with ut all shields, pr tective devices
and structures in place.
Design, materials and/ r specificati ns are subject t
change with ut n tice and with ut liability theref r.
Specificati ns are applicable t units s ld in Canada, the
United States, its territ ries and p ssessi ns, and may
var y utside these areas.
© 2008 CNH America LLC
New H lland is a registered trademark f CNH America LLC.
Visit ur Web site at www.newholland.com/na. Or, call t ll-free 866-NEW-HLND (866-639-4563).
