New Holland H6700 Series Heavy-d ty

Disc Mower Specifications

H6730 H6740 H6750

Page 1of 3

MODEL H6730 H6740 H6750

CU ER BAR

Cutting width, ft. in. (mm) 6' 8" (2040) 7' 10" (2400) 9' 2" (2800)

Cutting height, in. (mm) .................................................................................................................95-3.25 (24-82.5)...............................................................................................

Cutter bar tilt angle, degrees ..................................................................................................................0 to -10........................................................................................................

Cutter bar operating range, degrees +18 to -32 +18 to -30 +18 to -28

Breakaway angle, degrees ..........................................................................................................................19............................................................................................................

Type cutterbar .............................................................................................................. odular with individual sealed reservoirs.............................................................................

Cutterbar drivetrain protection.......................................................................................Std.-frangible splines in disc drive hub...............................................................................

Number of discs 567

Knives per disc.............................................................................................................................................2.............................................................................................................

Disc cutting diameter, in. (mm) ...........................................................................................................19.7 (500) .....................................................................................................

Disc drive..............................................................................................................................Bevel gears in sealed modules......................................................................................

Disc speed, RP ......................................................................................................................................3,000 .........................................................................................................

DRIVELINE

inimum PTO horsepower required, hp (kW)145 (33.5) 55 (40.9) 60 (44.7)

Input speed, RP ......................................................................................................................................540...........................................................................................................

Driveline protection.....................................................................................................................Belt drive to cutter bar............................................................................................

Overrunning clutch.............................................................................................................................On PTO shaft ...................................................................................................

Belt tension .............................................................................................................Spring-loaded tensioner with adjustment gauge........................................................................

HYDRAULICS AND HI CH

Hydraulic circuits required...................................................................................................................One remote.....................................................................................................

inimum relief pressure required, psi (bar).......................................................................................1,500 (104) ....................................................................................................

Hitch Category I or II Category II Category II

DIMENSIONS AND WEIGH

Overall width, in. (mm) 138.75 (3524) 160.25 (4070) 181.75 (4616)

Overall length, in. (mm) 42.5 (1080) 50.5 (1283) 50.5 (1283)

Height - transport position, in. (mm) 98 (2489)2119.5 (3035)3141 (3581)3

Weight, lb. (kg) 1,200 (546) 1,460 (662) 1,590 (698)

1Recommended for use with tractors having a fully enclosed cab.

2Transport height is based on 24-inch (609-mm) hitch-pin height above ground on H6730 model.

3Transport height is based on 18-inch (457-mm) hitch-pin height above ground on H6740 and H6750 models.

New Holland H6830 Heavy-d ty P ll-type

Disc Mower Specifications

H6830

Page 2of 3

MODEL H6830

CU ER BAR

Cutting width, ft. in. (m) 10’ 4” (3160)

Cutting height, in. (m) 0.95-3.2 (24-81)

Cutter bar tilt angle, degrees -2 to -10

Type cutterbar odular, w/individual sealed reservoirs

Number of discs/knives per disc 8/2

Disc speed @ rated PTO speed, rpm 2,835

Cutterbar drivetrain protection Std.-frangible splines in disc drive hub

Cutter bar floatation Vertical and lateral, adjustable springs

Swath width, less shields, in. (m) 95 (2.4)

DRIVELINE

Input speed, RP 540

Driveline protection Slip clutch and overrunning clutch assembly

@ rear of PTO shaft

RAC OR REQUIREMEN S

inimum PTO horsepower required, hp (kW) 60 (45)

Hydraulic circuits required 2

inimum relief pressure required, psi (bar) 1,500 (103)

Drawbar/3 pt. hitch requirements ASAE category II drawbar

IRES

Tubeless ag rib implement tires 27x9.5-15 6PR

RANSPOR SPEED, MAXIMUM, mph (k/h) 20 (32.19)

DIMENSIONS AND WEIGH

Width, transport, ft. in. (m) 10’ 10” (3.3)

Width, operating, ft. in. (m) 16’ 4” (4.9)

Length, transport, ft. in. (m) 15’ 8” (4.8)

Length, operating, ft. in. (m) 15’ 3” (4.6)

Height, transport, in. (m) 62 (1.6)

Height, operating, in. (m) 62 (1.6)

Ground clearance w/head fully raised, in. (mm) 11 (279)

Weight, operating, lb. (kg) 2,610 (1186)

New Holland HM200 Series Economy

Disc Mower Specifications

HM234 HM235 HM236

Page 3of 3

Safety begins with a th r ugh understanding f

the equipment. Always make sure y u and

y ur perat rs read the Operat r’s Manual

bef re using the equipment. Pay cl se

attenti n t all safety and perating

decals and never perate machinery

with ut all shields, pr tective devices

and structures in place.

Design, materials and/ r specificati ns are subject t

change with ut n tice and with ut liability theref r.

Specificati ns are applicable t units s ld in Canada, the

United States, its territ ries and p ssessi ns, and may

var y utside these areas.

New H lland is a registered trademark f CNH America LLC.

Visit ur Web site at www.newholland.com/na. Or, call t ll-free 866-NEW-HLND (866-639-4563).

MODEL HM234 HM235 HM236

CU ER BAR

Cutting width, ft. in. (mm) 5' 6" (1.7) 6' 9" (2.1) 7' 11" (2.4)

Cutting height, in. (mm) ................................................................................................................0.63"-2.36 (16-60)...............................................................................................

Cutter bar tilt angle, degrees 0 to -8 1 to -8 2 to -8

Cutter bar operating range, degrees.....................................................................................................+18 to -30 .....................................................................................................

Breakaway angle, degrees ..........................................................................................................................21............................................................................................................

Type cutterbar ...............................................................................................................................Enclosed gear drive ..............................................................................................

Number of discs 456

Disc cutting diameter, in. (mm) ..........................................................................................................20.47 (520) ....................................................................................................

Disc drive...........................................................................................................................Spur gear drive in common sump...................................................................................

Disc speed, RP ......................................................................................................................................3154..........................................................................................................

DRIVELINE

inimum PTO horsepower required, hp (kW)135 PTO (26.1) 40 PTO (29.8) 50 PTO (37.3)

Belt tension.......................................................................................................................Adjustable drawbolt-3/4" Deflection..................................................................................

HYDRAULICS AND HI CH

inimum relief pressure required, psi (bar).......................................................................................2,320 (160) ....................................................................................................

Hitch Category I or II Category I or II Category II

DIMENSIONS AND WEIGH

Overall width, in. (mm) 134.25 (3410) 149.21 (3790) 178.35 (4530)

Overall length, in. (mm) .....................................................................................................................54.33 (1380) ...................................................................................................
