MZ-H Zero-Turn-Radius Mower Specifications
MZ16H MZ17H MZ18H MZ19H
Page 1of 2
MODEL MZ16H MZ17H MZ18H MZ19H
ENGINE
Horsepower, hp (kW) 16 (11.9) 18 (13.4) 18 (13.4) 19 (14.2)
Make Briggs & Stratton Kohler Command Briggs & Stratton Kawasaki
No. of cylinders 1112
Cooling system .....................................................................................................................................Air.................................................................................................................
Fuel capacity, gal. (L) 2 (7.6) 5 (18.9) 2 (7.6) 5 (18.9)
Full pressure lubrication ..................................................................................................................Standard............................................................................................................
Starter key w/safety interlock ...........................................................................................................Standard............................................................................................................
Air cleaner, dual element ..................................................................................................................Standard............................................................................................................
DRIVE SYSTEM
Type...............................................................................................Dual Hydrostatic: Two pumps each drive a separate motor at each wheel ........................................................
Max speed, forward, mph (kph) 6.0 (9.6) 7.0 (11.3) 6.0 (9.6) 7.0 (11.3)
Max speed, reverse, mph (kph) 3.0 (4.8) 3.4 (5.5) 3.0 (4.8) 3.4 (5.5)
Implement clutch ..............................................................................................................................Electric .............................................................................................................
BRAKES
Service Brake....................................................................................................................Hydrostatic Dynamic Braking............................................................................................
Parking Brake Lock .....................................................................................Automatic Engagement with steering levers in neutral................................Manual, LH lever
ELECTRICAL
Voltage ..................................................................................................................................................12 ................................................................................................................
Charging System (amps) 9 15 16 13
Battery ...............................................................................................................................................260 cca.............................................................................................................
Headlights N/A ptional ptional ptional
OPERATOR STATION AND CONTROLS
Steering ......................................................................................................Dual padded lever hydrostatic with hydraulic dampening......................................................................
Front Casters..................................................................................................................................Double yoke .........................................................................................................
Armrests ..........................................................................................................................................Standard............................................................................................................
Cup Holder .......................................................................................................................................Standard............................................................................................................
Storage Bin ......................................................................................................................................Standard............................................................................................................
Seat Type .............................................................................................................Contoured, high back, adjustable fore and aft...............................................................................
Footrest Adjustable N/A Adjustable N/A
HEELS AND TIRES
Front Casters ................................................................................................................................10 x 4, 4-ply.........................................................................................................
Rear 18 x 7.5-8, 4-ply 18 x 7.5-8, 4-ply 18 x 8.5-8, 4-ply 18 x 10.5-10, 4-ply
DIMENSIONS, in. (cm)
Length, overall 72.6 (184.4) 77.5 (196.9) 72.6 (184.4) 77.5 (196.9)
Width, overall
with deck deflector down 50.7 (128.8) 60 (152.4) 55 (139.7) 65 (165.1)
with deck deflector up 46.0 (116.8) 49 (124.4) 46.6 (118.4) 58 (147.3)
Height, overall 39 (99.1) 40 (101.6) 39 (99.1) 41 (104.1)
Wheelbase 47.6 (120.9) 52.1 (132.3) 47 (119.4) 52.1 (132.3)
Turning Radius, inside rear wheel.................................................................................................Zero degrees.........................................................................................................
Net weight, estimated, lb. (kg) 516 (234) 641 (290) 535 (243) 680 (309)
MO ER DECKS (optional mulching kits available)
42 in. side discharge Standard —— —
44 in. side discharge — Standard ——
48 in. side discharge ——Standard —
52 in. side discharge ———Standard
Spindles 2 3 33
Anti-scalp gauge wheels ..................................................................................................................Standard............................................................................................................

New Holland
MZ-H Zero-Turn-Radius Mower Specifications
MZ16H MZ17H MZ18H MZ19H
Page 2of 2
MODEL MZ16H MZ17H MZ18H MZ19H
ATTACHMENTS & ACCESSORIES
2-bag grass catcher (6 cu. ft.) ptional —— —
2-bag vacuum grass catcher — ptional ptional —
48-inch front blade ptional — ptional —
56-inch front blade — ptional — ptional
Front lights — ptional ptional ptional
Smooth-tread front tires ................................................................................................................... ptional ............................................................................................................
Safety begins with a th r ugh understanding f
the equipment. Always make sure y u and
y ur perat rs read the Operat r’s Manual
bef re using the equipment. Pay cl se
attenti n t all safety and perating
decals and never perate machinery
with ut all shields, pr tective devices
and structures in place.
Design, materials and/ r specificati ns are subject t
change with ut n tice and with ut liability theref r.
Specificati ns are applicable t units s ld in Canada, the
United States, its territ ries and p ssessi ns, and may
var y utside these areas.
