New Holland G Series
Zero-Turn-Radius Mower Specifications
G4010 G4020 G4030 G4035 G4050
Page 1of 2
MODELS G4010 G4020 G4030 G4035 G4050
ENGINE
Horsepower, hp (kW) 19 (14.2) 21 (15.7) 23 (17.2) 25 (18.6) 25 (18.6)
Make Kohler Courage SV590 Kohler Courage SV610 Kohler Courage SV720 Kohler Courage SV730 Kohler Courage RO
No. of cylinders 11222
Cooling system...........................................................................................................................................Air............................................................................................................
Fuel capacity, gal. (L) ......................................................................................................3 (11.4)................................................................................... 4 (15.1)
Full pressure lubrication ........................................................................................................................Standard.......................................................................................................
Starter key w/safety interlock ................................................................................................................Standard.......................................................................................................
Air cleaner..............................................................................................................................................Standard.......................................................................................................
DRIVE SYSTEM
Type .........................................................................Dual hydrostatic: transaxle with integral pump and motor; one at each wheel ............................ Twin hydro-gear
ZT2800 hydrostatic
transaxle with
charge pumps
Max speed, forward, mph (kph) ...........................................................................................................7.0 (11.3)......................................................................................................
Max speed, reverse, mph (kph) 3.4 (5.5) 3.4 (5.5) 3.4 (5.5) 5 (8.0) 5 (8.0)
Implement clutch ....................................................................................................................................Electric........................................................................................................
BRAKES
Service brake .........................................................................................................................Hydrostatic dynamic braking.......................................................................................
arking brake lock ......................................................................Automatic engagement with steering levers in neutral............................................... Manual LH lever
ELECTRICAL
Voltage....................................................................................................................................................12 volts .......................................................................................................
Charging system (amps) ............................................................................................................................15............................................................................................................
OPERATOR STATION AND CONTROLS
Steering............................................................................................................Dual padded lever hydrostatic with hydraulic dampening.................................................................
Seat type, adjustable fore and aft..................................................Contoured, high back.................................................... 18” high back 18” high back
Armrests Optional Optional Standard Standard Standard
Cup holder .............................................................................................................................................Standard.......................................................................................................
Storage bin ............................................................................................................................................Standard.......................................................................................................
Front casters .......................................................................................................................................Double yoke....................................................................................................
HEELS AND TIRES
Front Casters 10 x 4 ribbed 10 x 4 smooth 10 x 4 smooth 10 x 4 smooth 10 x 4 smooth
Rear 18 x 7.5-8, 2-ply 18 x 9.5-8, 2-ply 18 x 9.5-8, 2-ply 18 x 9.5-8, 2-ply 20 x 10, 4-ply
DIMENSIONS, in. (cm)
Length, overall
with grass catcher ...................................................................................................90.0 (228.6) ............................................................................... NA
less grass catcher...........................................................................................................................73.1 (185.7)....................................................................................................
Width, overall
with deck deflector down 53.8 (136.7) 63.0 (160.0) 63.0 (160.0) 63.0 (160.0) 65.5 (166.4}
with deck deflector up 46.0 (116.8) 53.5 (135.9) 53.5 (135.9) 53.5 (135.9) 53.0 (134.6)
with grass catcher 52.8 (134.1) 56.8 (144.3) 56.8 (144.3) 56.8 (144.3) NA
Height, overall, to top of seat 37.2 (94.5) 40.2 (102.1) 40.2 (102.1) 40.2 (102.1) 42.2 (107.2)
Wheelbase....................................................................................................................48.1 (122.2) ............................................................................... 46.4 (117.9)
Turning radius, inside rear wheel ..........................................................................................................Zero turn ......................................................................................................
Net weight, estimated, lb. (kg) 500 (226.8) 552 (250.4) 565 (256.3) 565 (256.3) 649 (294.4)

New Holland G Series
Zero-Turn-Radius Mower Specifications
G4010 G4020 G4030 G4035 G4050
Page 2of 2
MODELS G4010 G4020 G4030 G4035 G4050
MO ER DECKS
(optional mulching kits available)
42 in. (107 cm) side discharge Standard NA NA NA NA
50 in. (127 cm) side discharge NA Standard Standard Standard NA
52 in. (132 cm) side discharge NA NA NA NA Standard
Spindles 23333
Anti-scalp gauge wheels........................................................................................................................Standard.......................................................................................................
ATTACHMENTS & ACCESSORIES
2-bag grass catcher (8 cu. ft./.23 m3) Optional Optional Optional NA Optional
Rear engine guard Optional Standard Standard Standard Standard
Engine top cover ....................................................................................................................................Optional .......................................................................................................
Foot assist height of cut kit Optional Optional Standard Standard Standard
Smooth-tread front tires Optional Standard Standard Standard Standard
Sunshade kit........................................................................................................................NA ....................................................................................... Optional
Hitch kit ..................................................................................................................................................Optional .......................................................................................................
Front light kit .......................................................................................................................NA ....................................................................................... Optional
Rubber floor mat Optional Optional Optional Optional NA
Multch kit ...............................................................................................................................................Optional .......................................................................................................
ARRANTY .......................................................................................................................................3 year limited...................................................................................................
Safety begins with a th r ugh understanding f
the equipment. Always make sure y u and
y ur perat rs read the Operat r’s Manual
bef re using the equipment. Pay cl se
attenti n t all safety and perating
decals and never perate machinery
with ut all shields, pr tective devices
and structures in place.
Design, materials and/ r specificati ns are subject t
change with ut n tice and with ut liability theref r.
Specificati ns are applicable t units s ld in Canada, the
United States, its territ ries and p ssessi ns, and may
var y utside these areas.
© 2009 CNH America LLC
New H lland is a registered trademark f CNH America LLC.
Visit ur Web site at www.newholland.com/na. Or, call t ll-free 866-NEW-HLND (866-639-4563).
