Shark V3800UK User manual

OWNER’S GUIDE
V3800UK
www.sharkclean.eu

2FREEPHONE 0800 862 0453
IMPORTANT SAFETY INSTRUCTIONS
For Household Use Only
WARNING:
TO REDUCE THE RISK OF FIRE, ELECTRIC
SHOCK OR INJURY:
1. DO NOT charge this unit outdoors.
2. DO NOT use outdoors or on wet surfaces.
3. Use ONLY as described in this manual. Use only
manufacturer’s recommended attachments.
4. Unplug from electrical outlet when not in use and
before servicing.
5. DO NOT use with damaged cord or plug.
6. DO NOT use if the appliance is not working, has
been dropped, dropped into water, damaged or left
outdoors.
7. NO SERVICEABLE PARTS. Incorrect re-assembly
or repair can cause a risk of electrical shock or injury
to persons when the appliance is used. Contact
Customer Service.
8. DO NOT abuse the charger cord. Never carry the
charger or base by the cord or yank to disconnect
from an outlet; instead grasp the charger and pull to
disconnect.
9. Keep charger cord away from heated surfaces.
10. This product includes Lithium Ion batteries. Batteries
must be recycled or disposed of properly. Do not
incinerate batteries or expose to high temperatures,
as they may explode.
11. DO NOT handle plug or appliance with wet hands.
12. DO NOT put any object into openings. Do not use
with brush roll blocked; keep free of fibre, lint,
hair and anything that may prevent brush roll from
working.
13. Keep hair, loose clothing, fingers, and all parts of
body away from openings and moving parts.
14. DO NOT pick up anything that is burning or smoking,
such as cigarettes, matches, or hot ashes.
WHEN USING YOUR SHARK®CORDLESS
SWEEPER, BASIC SAFETY PRECAUTIONS
SHOULD ALWAYS BE FOLLOWED, INCLUDING
THE FOLLOWING:
READ ALL INSTRUCTIONS BEFORE USING
YOUR SHARK®CORDLESS SWEEPER.
IMPORTANT: This appliance is not intended for use
by persons with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person
responsible for their safety.
Children shall not use or play with this appliance.
Close supervision is necessary to keep appliance out
of reach of children during use.

3
www.sharkclean.eu
15. Use extra care when cleaning on stairs.
16. DO NOT use to pick up flammable or combustible
liquids such as gasoline or use in areas where they
may be present.
17. Read and follow all labels, operational and marking
instructions.
18. DO NOT use charger with an extension cord. Plug
charger directly into an electrical outlet. Use charger
only in a standard (100-240V~, 50/60Hz) electrical
outlet.
19. DO NOT use the Cordless Sweeper without dust cup
in place.
20 Store the Cordless Sweeper indoors. Store the
appliance after use to prevent accidents.
21. Discontinue use if the battery runtime changes
abruptly or battery has white residual (venting) near
positive terminal or the cell is deformed or leaked.
22. Use only on dry, indoor surfaces.
23. DO NOT use for any purpose other than described in
this user’s guide.
24. DO NOT attempt to use the charger with any other
product or attempt to charge this product with
another charger. Use only charger CHV3900BS
supplied with this Cordless Sweeper.
25. The charger converts the 100-240V AC voltage to
safety extra-low voltage.
26. The Cordless Sweeper must be disconnected from
the power supply when removing the battery.
TO MAXIMISE THE LIFE OF YOUR LITHIUM ION
BATTERIES:
1. Charge for 3.5 hours before initial use.
2. DO NOT store unit with the charging adapter
attached and plugged in.
3. DO NOT store in areas of high temperature or
humidity.
4. Use only the charger supplied with the product.
If other chargers are used, the batteries can fail
causing damage to the battery, product, or personal
property.
5. Do not attempt to replace the battery with another
manufacturer or different battery chemistry
(alkaline). The battery is designed specifically for this
product. The battery part number for this product is
XBTV3900.
NOTE: Li-Ion batteries have a long useful life but at
some time they will need to be replaced. To purchase
replacement batteries, visit www.sharkclean.eu.
To remove and replace the batteries, refer to
“Removing and Replacing the Battery” section on
page 11.
NOTE: The Power Switch must be switched in the
“Off” position in order to charge the unit. If the
charging indicator does not light, press the On/Off
button once.
IMPORTANT: This appliance contains Li-Ion
batteries. The batteries must be recycled or disposed
of in accordance with local regulations. The batteries
must be removed from the appliance before it is
scrapped. Please consult your local recycling centre
for more information.
SAVE THESE INSTRUCTIONS

4FREEPHONE 0800 862 0453
IMPORTANT: Before you can start using your new Cordless
Sweeper, charge it for 3.5 hours.
NOTE: The charging adapter will be shipped inside the
packaging.
Fig. 1
a
b
Fig. 2 Fig. 3
QUICK START
ASSEMBLE
1Insert the lower extension tube
into the head connector (a).
Then insert the upper extension
tube into the lower extension
tube (b). Now attach the upper
handle to the upper extension
tube. (Fig. 1)
CLEAN
2Pull back on the handle and
press lightly on the body of the
unit with your foot to engage the
steering. (Fig. 2)
3Using your foot, press the power
button and push the unit forward
over the surface you wish to
clean. (Fig. 3)

5
www.sharkclean.eu
EMPTY
4When you’re finished cleaning,
empty the No Touch Dust Cup.
Simply press the dust cup
release pedal and lift out the
dust cup. (Fig. 4)
NOTE: Be careful not to
accidentally turn the unit on.
Fig. 5
Fig. 4
5Over a rubbish bin, empty the
dust cup by pressing the bottom-
empty button on the lower portion
of the handle. When it’s empty,
gently snap the No Touch Dust
Cup back into place. (Fig. 5)

6FREEPHONE 0800 862 0453
THIS MANUAL COVERS MODEL NUMBER:
V3800UK 32
TECHNICAL SPECIFICATIONS
Voltage: 7.2V
Power: 22 Watts
Charger Output: 10V 1000mA
Euro-Pro and Shark are trademarks of Euro-Pro Operating LLC. All
other brand names may be trademarks of their respective owners.
This appliance complies with the WEEE-Directive 2012/19/EU on the disposal of electrical and electronic
equipment (WEEE).
This marking indicates that this product should not be disposed with other household wastes throughout
the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal
(especially the battery), recycle it responsibly to promote the sustainable reuse of material sources. To
return your used device, please use the return and collection systems or contact the retailer where this
product was purchased. They can take this product for environmental safe recycling.
This appliance complies with the European directives for electromagnetic compatibility (EMC) 2004/108/EC and its
revisions, as well as Low Voltage Directive (LVD) 2006/95/EC and its revisions.
Li-Ion
Guarantee: This product is unconditionally guaranteed for one year against all defects of workmanship and
materials. This guarantee does not affect your statutory rights. If this product proves unsatisfactory please contact
our customer service department on freephone 0800 862 0453 or by e-mail [e-mail].

7
www.sharkclean.eu
Contents
Assembly ....................................................................................................8
Charging Your Shark®Cordless Sweeper .......................................................9
Using Your Shark®Cordless Sweeper ............................................................9
Emptying the No Touch Dust Cup ................................................................10
Storing Your Shark®Cordless Sweeper........................................................10
Maintenance..............................................................................................11
Troubleshooting Guide................................................................................12
Ordering Replacement Parts .......................................................................12
Thank you for
purchasing the Shark®
Cordless Sweeper.

8FREEPHONE 0800 862 0453
ASSEMBLY OF YOUR
CORDLESS SWEEPER:
NOTE: The charging adapter will
be shipped inside the packaging.
IMPORTANT: Charge the
batteries for 3.5 hours before
using the unit for the first time.
See page 9 for instructions on
charging your unit.
ASSEMBLY
1Insert the lower extension tube
into the head connector (a). Then
insert the upper extension tube
into the lower extension tube (b).
Now attach the upper handle to
the upper extension tube. (Fig. 1)
Fig. 1
COMPONENTS:
AMain Unit
BPower Button
CNo Touch Dust Cup
DUpper Handle
EUpper Handle Extension Tube
FLower Handle Extension Tube
GNo Touch Dust Cup Empty Button
H Charging Adapter
E
D
H
F
G
B
A
C
a
b

9
www.sharkclean.eu
1Always make sure that the unit
is turned off. (Fig. 2)
2Insert the charger plug into the
back of the unit then plug it into a
wall outlet. The 4 blue LED lights
will light up sequentially from 1
(Low) to 4 (high) while charging.
When all 4 lights turn solid blue,
the unit is fully charged and
ready for use. If the lights do not
illuminate when the unit’s plugged
in, press the power button
once. The lights should start the
illuminating sequence, signifying
the unit is charging. (Fig. 3)
Fig. 4
CHARGING YOUR SHARK®CORDLESS SWEEPER
NOTE: When the power switch is
on the sweeper will not charge.
3Charge the battery for 3.5 hours
before initial use and 3.5 hours
for each recharge. Our Cordless
Sweeper is powered by Li-Ion
batteries that need this time to build
up their charge. All 4 will turn blue
when the unit is fully changed.
4For best battery performance,
remove the charging adapter
from the unit after the charging
period has completed. Storing
the unit with the adapter
attached and plugged in will
reduce the battery life.
5 The LED lights indicate battery
capacity. As the unit loses
battery strength, the LED
lights will begin to turn off in a
descending order, from 4 (High)
to 1 (Low). When all four lights
begin flashing, the motor on the
unit will stop working. Please
recharge the batteries according
to step 2.
IMPORTANT: Although
many adapters look similar,
it’s important to use only the
adapter that came with the unit
CHV3900BS.
Fig. 2 Fig. 3
If the brush roll stops
moving, it’s probably due
to the anti-jam feature.
This feature protects the
motor from becoming
USING YOUR SHARK®CORDLESS SWEEPER
OFF
overheated. If the brush
becomes overloaded, it will
stop turning and both speed
indicator and the first LED
light will flash. Turn off your
unit by pressing the power
button once. See page 12
for further instructions
on removing or cleaning
the brush roll. Wait for 10
seconds to let your unit cool
down. Now press the power
button again and you’re
ready to resume cleaning!
1Press the power button to start
the unit. When finished cleaning,
press the power button again to
turn the unit off. (Fig. 4)
2Do not use the unit to pick up
liquids or clean wet floors.
3Do not use the unit on concrete,
tar or other rough surfaces.
4Do not use the unit to pick
up pieces of string or fabrics.
Do not use the unit to clean
tasselled or frayed carpets.

10 FREEPHONE 0800 862 0453
EMPTYING THE NO TOUCH DUST CUP
1To achieve the best
performance, empty the No
Touch Dust Cup after each use.
Press the No Touch Dust Cup
release pedal on back of the unit
to remove the No Touch Dust
Cup. (Fig. 5)
2Hold the No Touch Dust Cup
over a rubbish bin and push
the No Touch Dust Cup empty
button located on the lower
portion of the handle. The trap
door will spring open and release
the debris into the rubbish bin.
(Fig. 6)
3To re-insert the No Touch Dust
Cup, position it over the unit and
press down gently until it snaps
into place. (Fig. 7)
For easy insertion into the base,
tip the No Touch Dust Cup
slightly forward.
Fig. 5 Fig. 6 Fig. 7
STORING YOUR SHARK®CORDLESS SWEEPER
CAUTION: Any electronic
appliance should not be stored in
or exposed to areas of high heat
or humidity. Do not store the
unit close to stoves, radiators,
furnaces or in a bathroom or
bathing area.
1Properly storing your unit will
keep it ready to go the next time
you want to use it. Store the unit
in a dry area where it won’t be
exposed to the elements.
2When storing your cordless
sweeper, hang the handle from
ahook.
3Always empty the No Touch
Dust Cup before storing.
Fig. 8
4Pull back on the handle and
press lightly on the body of the
unit with your foot. (Fig. 8)
5Lift the unit and rotate the base
one quarter turn so that you can
lay it flat against the wall. Hang
the unit using the handle from a
hook secured to a wall or other
vertical surface. (Fig. 9)
Fig. 9

11
www.sharkclean.eu
CAUTION: Do not clean the unit
while it is charging.
1Once a month, wipe down the
unit with a dry cloth, including
the area under the No Touch
Dust Cup. Wipe away any hair,
fibre or other dirt that may have
built up in the chamber and on
the rotating brush. Do not use
any harsh cleaner or chemicals.
2Do not immerse the unit in
water.
CLEANING THE ROTATING
BRUSH
1Press the No Touch Dust Cup
release pedal with your foot and
remove the No Touch Dust Cup
from the unit.
2Turn the unit upside down. Be
careful not to accidentally turn
the unit on!
3Remove all hair, string or fibres
wrapped around the brush bar.
Using a pair of scissors, carefully
cut along the raised guide to
remove anything wound around
the brush bar. Avoid damaging
or cutting the bristles. (Fig. 8)
Fig. 8
Fig. 11
Fig. 12
MAINTENANCE
4Use a coin to remove the trap
door if you need to remove the
brushroll to either clean it or
replace it. (Fig. 9)
REMOVING AND REPLACING
THE BATTERY
NOTE: Make sure the charging
adaptor is not connected to
the sweeper when removing or
replacing the batteries.
NOTE: If uncertain as to how
to remove your battery pack,
we suggest you take the unit
to a reputable small appliance
service technician to have this
service performed.
1Make sure the unit is off. If not,
press the power button once to
turn the unit “OFF”. (Fig. 10)
2Turn the unit upside down.
3Push in the locking tab and lift
off the battery compartment
cover. (Fig. 11)
4Carefully lift out the battery
pack and disconnect the wire
terminals by pressing on the
latch and pulling apart the wire
terminal connectors. (Fig. 12)
5Remove the battery pack.
(Fig. 12)
6Connect the wire terminal from the
unit to the wire terminal connector
of the new Shark®battery pack
(XBT V3900) and replace the
battery pack into the unit.
7Replace the battery
compartment cover.
8Please call customer service at
0800 862 0453 if you have any
problems removing the battery
pack.
IMPORTANT: This appliance
contains Li-Ion batteries. The
batteries must be recycled or
disposed of in accordance with
local regulations. Please consult
your local recycling centre for
more information.
WARNING: Never use ordinary
batteries for replacement as
these may leak and cause
damage. Use only battery pack
XBTV3900 for replacement.
LI-ION BATTERY
MUST BE RECYCLED
OR DISPOSED OF
PROPERLY
Fig. 9
Fig. 10
OFF

12 FREEPHONE 0800 862 0453
TROUBLESHOOTING GUIDE
REPLACEMENT PARTS
AXBTV3900 Battery Pack
BCHV3900BS AC Adapter
To order any of the above replacement parts, go to www.sharkclean.eu or call 0800 862 0453.
ORDERING REPLACEMENT PARTS
PROBLEM POSSIBLE REASONS AND SUGGESTED SOLUTION
The unit will not operate or the
charging light is flashing
Batteries need to be recharged.
Batteries are dead and need to be replaced.
There is no power in the electrical outlet supplying the charging adapter.
Try to charge using a different outlet.
Ensure the wire terminal connectors on the battery pack are securely
attached.
If the unit still doesn’t work, call Customer Service at 0800 862 0453.
The unit will not pick up Empty the No Touch Dust Cup.
Recharge the battery.
Dust is escaping from the unit Empty the No Touch Dust Cup.
Ensure that the No Touch Dust Cup is properly in place.
The rotating brush will not pick up Check for and remove any excessive material on the brush roll or in the
bottom of the unit.
Empty the No Touch Dust Cup.
The unit will not charge Press the power button once to turn the unit “OFF”.
There is no power in the electrical outlet supplying the charging adapter.
Try to charge using a different outlet.
Ensure the wire terminal connectors on the battery pack are securely
attached.
Charging adapter may not be working. Call Customer Service at
0800 862 0453.
Batteries are dead and need to be replaced.

13
www.sharkclean.eu
NOTES

14 FREEPHONE 0800 862 0453
NOTES

15
www.sharkclean.eu
NOTES

Li-Ion
Euro-Pro Europe Limited
1 Mariner Court
Calder Park
Wakefield
WF4 3FL
Freephone 0800 862 0453
www.sharkclean.eu
Technical Details
Model number: V3800UK 32
Voltage: 7.2V
Power: 22 Watts
Charger Output: 10V 1000mA
COPYRIGHT © EURO-PRO OPERATING LLC 2014
Euro-Pro and Shark are trademarks of Euro-Pro Operating LLC. All
other brand names may be trademarks of their respective owners.
PRINTED IN CHINA
V3800UK_32_140804_2
Illustrations may differ from actual product.
