Newland EM3000 User manual

SCANNING MADE SIMPLE
EM3000
OEM scan engine
quick start

Page 1
Quick Start
Disclaimer
Newland Auto-ID Tech Inc.(“Newland Auto-ID”) reserves the right to make
changes in specifications and other information contained in this document
without prior notice, and the reader should in all cases consult Newland Auto-ID
to determine whether any such changes have been made. The information in this
publication does not represent a commitment on the part of Newland Auto-ID.
This document contains proprietary information that is protected by copyright. All
rights are reserved. No part of this document may be photocopied, reproduced,
or translated into another language without the prior written consent of Newland
Auto-ID.
© 2009 Newland Auto-ID Tech. Inc. All rights reserved.
Trademark
, , are trademarks or registered trademarks of Newland Auto-ID
Tech Inc.
Other product names mentioned in this manual may be trademarks or registered
trademarks of their respective companies and are hereby acknowledged.

Page 2
Quick Start
Introduction
EM3000 is an embedded barcode reading engine. Its gray scale CMOS image
capturer and the Newland patented , a Computerized Image Recognition
System, ensure the fast scanning and decoding accuracy on different barcode
media such as paper, plastic card, and metal surface. It can be easily integrated
into OEM equipments or systems (hand-held, portable, and mounted) to provide
solutions for image capture, bar code reading, and barcode message processing.
Box Content
NLS-EM3000 Embedded Barcode
Scanning Engine
24-12 Pin Flexible Cable

Page 3
Quick Start
Hardware Overview
Aiming LED
24 Pins Cable Socket
Camera
CMOS Circuit
L-Bracket
LED
NLS-EM3000
24-12 Pin Flexible Cable

Page 4
Quick Start
How to read 1D/2D barcode with EM3000 Embedded Barcode Reading Engine
When the trigger line (Pin 12 on the flexible cable) is pull low for 10ms, the
engine starts a read. For the optimum reading stance, aiming pattern width should
be 1mm or 2mm less than barcode width.
Focus the green aiming bar on the central of a barcode. The distance of scan
window & barcode between 2cm and 50cm,15mm~25mm is the best distance
between scan window and barcode. Yaw (αas below) between 0°and 45°(0 is
the best); Pitch (γas below) between 0°and 45°(5-20 is the best); Roll (βas
below)360°.
For more information about EM3000 reading engine, please visit Newland Auto-
ID website. www.nlscan.com

Page 5
Quick Start
Supports & Service
If you have a problem with your equipment, contact the Newland Support Center
for your region. Before calling, have the model number, serial number, and several
of your barcodes at hand.
Call the support Center from a phone near the scanning equipment so that the
service person can try to talk you through your problem. If the equipment is found
to be working properly and the problem is barcode readability, the Support Center
will request samples of your bar codes for analysis at our plant.
If your problem cannot be solved over the phone, you may need to return your
equipment for servicing. If that is necessary, you will be given specific directions.
Note: Newland Auto-ID Tech. is not responsible for any damages incurred during
shipment.
For service information, warranty information or technical assistance contact or
call the Support Center listed below.
If you purchased your Newland product from a Newland Business Partner,
contact that Business Partner for Service.
Newland EMEA
[phone]
[email protected]
Newland D-A-CH
[phone]
[email protected]
Newland UK
[phone]
[e-mail]
Newland Nordic
[phone]
[email protected]
Newland Ibérica
[phone]
[email protected]
Newland France
[phone]
[email protected]
Newland Middle East
[phone]
[email protected]
Newland South Africa
[phone]
[email protected]
Newland Italy
[phone]
[email protected]
Newland Russia
[phone]
[email protected]

Page 6
Quick Start
Revisions
Version Data Source Description Date Approved
V1.0 20090826
