Nex Dryft A90 BLDC User manual

Have more questions? Talk to us at [e-mail]
FEEL THE FUTURE
This handy guide will help you
put your Nex fan together.
INSTRUCTION
MANUAL

Classification | Internal
CONNECTION
WIRES
BOTTOM CANOPY
Figure 1 Figure 2
MOTOR
BLADE
THERMO BUFFER BLADE FIXING SCREW
Figure 5Figure 4Figure 3
CONNECTION
WIRES
CANOPY STOPPER
DOWN ROD
6
7
9
11
10
8
MOTOR
CONNECTION
WIRES
CANOPY STOPPER
DOWN ROD
ASSEMBLY & INSTALLATION: FAN
INSTALLATION & ASSEMBLY OF BLADE
Note :- Kindly use same serial number blade as these are precisely balanced for same weight.
1. Place the motor on thermo buffer to avoid any scratches as shown in (Figure 1).
2. Unscrew the blade screw from Motor and align the blade with the motor as shown in
(Figure 1).
3. Screw the Blade to the Motor and ensure a tight fit.

CONNECTION
WIRES
CANOPY
STOPPER
Figure 6A
Figure 6B
Classification | Internal
INSTALLATION OF HANGING
ASSEMBLY & CANOPIES TO MOTOR
1. Hold the down-rod vertically with Slit side downward.
2. Slide canopy stopper (4a) from top end of down rod & Ensure
stopper should be below down rod(3)slit hole. Now Pass the
connection wires through slit hole at the Bottom end of down
rod (3) and remove them from the top end of down rod (Figure
2).
3. Insert the bottom end of down rod (3) (with slit) on spindle (6)
and insert bolt (7) Place the plain washer (8), spring washer (9),
and fully tighten nut (10), insert the split pin (11) in the small
hole on the bolt end and open the ends, so that it does not fall
off. The assembly of bolt (7), plain washer (8), spring washer
(9), nut (10), split pin (11) is separately packed with hanger
assembly (18).
4. Align hole in downrod (3) and slot in canopy stopper (4a) and
push canopy stopper (4a) from top to rest it on bolt (3).Now
pass connection wire through canopy stopper slot & connect to
the terminal block. (Figure 6a).
5. Slide the bottom canopy (4) from top end of down rod (3) and
rest it on canopy stopper (4a) (Figure 4).
6. Slide the top Canopy(5) in Bottom canopy (4) and push it
downward. (Figure 5)
7. Slide the false ceiling cover (5b) from top end of down rod (3)
and rest it on top canopy (5) (Figure 5).
8. Remove the split pin (17), nut (16), spring washer (15), plain
washer (14), bolt (13), at the bottom end of hanger assembly
(12).(Figure 6)
9. Place hanger assembly (12) in ceiling hook in such a way that
rubber reel (18) rests on the ceiling hook.
10.Insert the top end of down rod (3) between the steel clamps of
hanger assembly (12). Match the holes with holes in down rod
(3). Insert bolt (13), place plain washer (14), spring washer (15),
and fully tighten nut (16), insert the split pin (17) in the small
hole on bolt end and open the ends, so that it does not fall off.
11. Assemble top canopy (5) and false ceiling cover (5b) together
and lift the Top canopy (5) and false ceiling cover (5b) to cover
hanger assembly and fix with screw (5a) (Figure 6).
12. Regulator not recommended with BLDC remote Fan
CONNECTION
WIRES
TERMINAL
BLOCK
16
14
17
15
12
13
TOP END OF
DOWN ROD
6
7
9
11
10
8
2
7a
BOTTOM END OF
DOWN ROD
WITH SLIT
MOTOR
BODY
18
4
3
Canopy stopper
4a
5b
CANOPY CUT
1

Figure 7
Figure 8
Classification | Internal
IN CASE OF FALSE CEILING WHERE DOWN
ROD IS ALREADY INSTALLED IN CEILING
1. Assemble top canopy (5) and false ceiling cover (5b) together (figure 7) and slide it up from
bottom end of down rod (already mounted).
2. Slide the bottom canopy(4) from down side of top canopy(5).
3. Slide canopy stopper (4a) from bottom end of down rod (already mounted) (Figure 7).
4. Insert the bottom end of down rod (already mounted) (with slit) on spindle (6) and insert bolt (7)
Place the plain washer (8), spring washer (9), and fully tighten nut (10), insert the split pin (11)
in the small hole on the bolt end and open the ends, so that it does not fall off. The assembly of
bolt (7), plain washer (8), spring washer (9), nut(10) split pin (11) is separately packed with
hanger assembly (12). & connect connection wire with terminal block.
5. Push canopy stopper (4a) from top to rest it on bolt (7) (Figure 7). Slide down bottom canopy and
rest it on canopy stopper.
6. Lift the Top Canopy (5) and false ceiling cover (5b) assembly as per requirement to cover false
ceiling hole and Tighten the screw (5a) to fix it (Figure 6).
NOTE
If there, is not sufficient space to accommodate top canopy (5), kindly cut top canopy (5) from bottom
side below screw hole and assemble false ceiling cover (5b) in top canopy (4) and assemble as per
instruction (Figure 8).
TERMINAL
BLOCK
6
7
9
11
10
8
2
7a
BOTTOM END OF
DOWN ROD
MOTOR
BODY
Down Rod (already mounted)
Top canopy
False Ceiling cover
Bottom Canopy
Canopy Stopper
4a
4
5
5b
1
CONNECTION
WIRES
TERMINAL
BLOCK
16
14
17
15
12
13
TOP END OF
DOWN ROD
6
7
9
11
10
8
2
7a
BOTTOM END OF
DOWN ROD
WITH SLIT
MOTOR
BODY
18
4
3
Canopy stopper
4a
5b
CANOPY CUT
1

Classification | Internal
1. To optimize the air delivery and avoid turbulence ceiling fan should be approx. 7 ~ 8 feet from the
ground level and 1 feet below the ceiling/false ceiling (if Applicable).
2. Minimum distance between blade tip and wall & between 2 Fans blade tip should be almost equal
or more than the fan sweep size.
3. Don’t mix the blade of one set with another set as these blades are balanced and packed as a set for
efficient performance and safety.
4. In case of false ceiling, the hole in false ceiling must be in line with ceiling hook and minimum 1
inch gap should be available all around the down rod.
5. Ensure that the down rod &fan blade are placed away from any ceiling beam for proper assembly,
follow the down rod instruction given in the diagram
IMPORTANT
The diagram of fan are just the general representation of ceiling fan and not the actual fan. Read the
instructions carefully. Open the packing and arrange the fan parts as per the numers marked on
diagram. Assemble & install fan as per the assembly, wiring diagram and written instruction. Check the
assembled fan, ensure proper installation before switching ON the fan.
PRECAUTIONS
REMOTE CONTROL
DIAGRAM
Power ON/OFF
To increase or decrease speed
in small steps while running.
Speed 1 to 5
2 Hrs. timer
6 Hrs. timer
To stimulate natural breeze
by varying the speed
periodically.
BREEZE
2
5
4
2H
6H
1 3
FINE SPEEDTIMER

REMOTE PAIRING
INSTRUCTIONS
IF PAIRING FAILS REPEAT ABOVE STEPS
PERFORM WITHIN 10 SECONDS
STEP 1 Initially Switch OFF the fan from mains supply
STEP 2 Switch ON the fan from mains supply.
STEP 3 Press the "POWER" button on the remote. Then Press "Speed 1" button on the remote within 10secs.
Successful pairing will be confirmed by two beeps from the Controller
PAIRING ACKN-
OWLEDGEMENT
Classification | Internal
TURN "OFF" FAN
FROM MAINS
2 BEEPS
INDICATES
SUCCESSFUL
PAIRING
HOLD THE
REMOTE IN
HAND
1.TURN "ON" FAN FROM MAINS SUPPLY
2.PRESS "POWER" BUTTON ON REMOTE
3.THEN PRESS "SPEED 1" ON REMOTE
WITHIN 10 SECONDS
Note: If pairing fails, repeat the steps after switching OFF and powering ON the fan from the mains supply
Note: Multiple fans can be paired with single remote
REMOTE UN-PAIRING INSTRUCTIONS (FAN OPERATES WITH TWO REMOTES)
INSTRUCTION 1: PCB Controller have 2 memories for remote.
INSTRUCTION 2: Remote 1 & Remote 2 both can be paired with the ceiling fan
INSTRUCTION 3: Firstly Remote 1 gets paired with PCB. Then Remote 2 gets paired. Pairing should happen within 10 secs.
Both memories of the controller are filled with Remote 1 & Remote 2. Now the fan will operate as per Remote
1 & Remote 2 command.
INSTRUCTION 4: You can remove Remote 1 from pairing list and pair the PCB with Remote 3
INSTRUCTION 5: Once you remove Remote 1 from pairing list, memory of the controller is filled with Remote 2 & Remote 3.
Now you can operate the fan with Remote 2 & Remote 3. After that, PCB won't respond to the commands of Remote 1.
SINGLE REMOTE PAIRING INSTRUCTIONS (FAN OPERATES ONLY WITH SINGLE REMOTE)
INSTRUCTION 1: If you want to operate with single remote means you want to pair the PCB with single remote you can pair, it
for 2 times within 10 seconds.
That means both the memories are filled with single remote. Now you can operate the fan with single remote
only (Remote 1).

TROUBLE-SHOOTING
INSTRUCTION
Problem Causes Solutions
Excessive gap between
Bottom canopy and Top Cover
A. Opposite Placement of Canopy
Stopper
A. Ensure the slotted bush of canopy
stopper must be on upper side
Power is ON but fan is
not working
Noisy operation
A. Circuit breaker tripped A. Reset the breaker
B. Loose connection of wire B. Tighten the wire connections
C. Fan turned OFF with the remote C. Press the power button to turn
ON the fan
D. Remote not paired with the fan D. Follow the remote pairing
instructions to pair the remote
A. Place the canopy stopper
in down rod
A. Bottom canopy touching the
top cover of Fan
B. Tight the mounting screw of the bladeB. Fan blade does not tighten properly
C. Input wire coming out from the
down rod and touching the top cover
C. Reduce the length of the wire
to avoid touching the top cover
Excessive Shaking Down rod not fitted tightly Tighten the bolt and nut as per
Instruction Manual
Fan speed increasing
& Decreasing
Fan is operating in breeze Mode Press the breeze/all 5 speed/fine
speed button to exit the breeze mode
Fan speed not changing when
using speed buttons of remote
Frequent commands received
by remote
Give 1-2 sec delay between
remote commands
B. Remote batteries drained B. Replace the old remote batteries
with the new batteries
Initial Jerk & Starting Problem Shackle kit is loose Tighten the shackle kit properly
Remote does not work A. Remote not paired with the fan A. Follow the remote pairing
instructions to pair the remote
Fan restart Fault detected Fan will restart once fault condition
no longer exists
Fan not working Fan turned off after timer completed
pre-set time
Restart the fan by using any of 1-5
speed button or power button
B. Bottom Canopy does not rest on
Canopy stopper
B. Pull Bottom Canopy downward
up to canopy stopper
All 2 canopies not fitting
in false ceiling
Down rod length is short because
of false ceiling
Remove the top canopy of the Fan
and fix the Ceiling cap above Bottom
Canopy at wider diameter groove side.
Classification | Internal

WARNING
THE INSTALLATION OF THE FANS SHOULD BE AS PER INSTRUCTION MANUAL TO AVOID ANY
DAMAGE TO FANS AND OTHER MOVING PARTS. DAMAGE OF ANY MOVING PARTS DUE TO
IMPROPER INSTALLATION MAY LEAD TO INJURY.
Room Size Fan Sweep
Less than 8 X 8 ft 600mm (24 ”)
8-10 ft X 8-10 ft 900mm (36 ”)
11-13 ft X 11-13 ft 1200mm (48 ”)
14-16 ft X 14 -16 ft 1300mm (52 ”) 1400mm (56 ”)
SELECTION GUIDE
Ceiling Fan
recommend Sweep
for different room sizes.
WIRING DIAGRAM
Figure 9
DOWN ROD DIAGRAM
Figure 10
RED
P
SUPPLY
FAN MOTOR BODY
N N
P
BLACK
Classification | Internal
ALL DIMENSIONS ARE IN mm
OD of Downrod
must be Ø 18.5 mm
minimum
Ø 18.5
Ø 8
Down Rod
SLIT MUST
BE STRAIT
2.5 MINIMUM
1.6
Ø 7.5
Thickness of Down rod
must be 1.6 mm minimum
This Dimension Must be
8mm From Down Rod end to
ø7.5mm Hole End
8

INSTALLATION OF SUPPORT
CABLE WITH FAN
Fig- 1
CAUTION
Installation of Secondary Support Cable
The purpose of Secondary support Cable is to temporarily hold the fan with ceiling hook, in case
of failuse of primary suspension system, which may happen due to faulty installation, inadequate
tightening of fasteners like nut & bolts etc. The fan should be switched off immediately & faulty
system should be corrected before using again.
Fig- 3
Un wind the support cable (2) and remove the
metal clamp (3).
Pass the cable through the shaft hole/ support
clip 1 (Hole below Down rod assembly hole)
so that it stops at the beaded end.
Thread the Cable (2) thro' the two holes on
cable clamp (3) & then thro" the ceiling hook
(4). Loop it & thread the free and thro another
set of hole in the clamp. Ensure that the Cable
is slack & approximately about an inch losse
and in no case supporting the fan directly as
shown in Fig - 3 & Fig - 4. Then fully tighten
the clamp by tightening nut & screw to ensure
that the secondary support is rigidly held.
2
2
34
5
13
Fig- 2 Fig- 4
Push the free end of cable (2) thro' the hole in
the down rod (thro' which supply
wires are not run) till it comes out of the
shackle end.
Fold the free and of the Cable (2). Raise the
canopy to appropriate position. Likewise place
the condensor cover in it's desire position.
2
1
