Thank you for choosing the XiPTM Wash+Cure station. If you need support with this Product
Please visit: Support.Nexa3D.com/Wash+Cure or call 800-797-0633.
The XiPTM Wash+Cure is suitable for washing and post-curing the printed objects of
XiPTM 3D printers. The Wash+Cure is an all-in-one automated post processing system for
washing and curing. Magnetic stirrers provide consistent cleans and a rotating base
platform provides an evenly cured nish.
Please read this manual carefully. The installation instructions and safety guidelines in
this manual can help you avoid any unnecessary damage or frustration.
Always follow the safety instructions during usage of the XiPTM Wash+Cure
to avoid any unnecessary damage to the machine or individual injury.
1. UV-blocking cover – Blocks 99.995% of UV light
2. Mode button – Press to switch between wash mode or cure mode
3. Time display – Shows washing or curing time
4. Time knob – Turn to set the washing time or curing time, from 1 to 60 minutes
5. UV LED Tower – LED lights on a movable use UV light to cure resin
6. Turnable & UV Reector – Removable rotational platform and reective surface
7. Wash Bucket – holds 8.5 Liters of solvent for wash Mode
Welcome to your XiPTM Wash+Cure User Guide
Safety Instruction
Product Overview
Technical Specications
TM
TM
Wash+Cure User Guide Wash+Cure User Guide
1
2
3
4
5
DANGER
Use appropriate protective equipment when handling resin and solvents, including
chemical-resistant nitrile gloves gloves, safety goggles, smock, and vapor respirator
if recommended by SDS for the resin or solvent you are using.
Seal and store washing solvent in a cool and dry place after use. If the solvent is
Isopropyl Alcohol, please comply with local regulations for use of alcohol.
This product is covered under
a 1-Year Manufacurer’s Limited
Hardware Warranty
While using Curing Mode, do not remove the cover of the machine to prevent
potential hazards from UV light.
CAUTION
CAUTION
CAUTION
Control Method
Digital Display + LED Dual
Light, Knob
40W
Rated Power
Power Requirements
UV LED Wavelength
Time Selection
Product Dimensions
270 mm Wide x 290 mm Deep x 479 mm High
Maximum Wash
Volume
120 mm Wide x 192 mm Deep x 245 mm High
Indicator Light
Red: Idle
Green: Working
1 ~ 60 min
100-240Vac, 50/60Hz
405nm
Maximum Cure
Volume
190 mm Deep x 245 mm High
Net Weight
~6.5 kg
1
YEAR
Customer Name:
Scan for the Full 1-Year
Manufacturer’s Limited
Hardware Warranty, or visit
https://nexa3d.com/3d-printers/ xip-warranty
Serial Number:
Purchase Date:
Online User Manual
& Recommended
Wash+Cure Times
