Nexcom nTUF 600 User manual

NEXCOM International Co., Ltd.
NEXCOM International Co., Ltd.
Published January 2013 www.nexcom.com
Industrial Computing Solutions
Fan-less Computer
nTUF 600
User Manual

Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. ii nTUF 600 User Manual
Content
Contents
Preface
Copyright ............................................................................................. iv
Disclaimer.............................................................................................. iv
Acknowledgements ............................................................................... iv
Regulatory Compliance Statements........................................................ iv
Declaration of Conformity...................................................................... iv
RoHS Compliance ................................................................................... v
Warranty and RMA ................................................................................ vi
Safety Information ................................................................................viii
Installation Recommendations...............................................................viii
Safety Precautions.................................................................................. ix
Technical Support and Assistance............................................................ x
Conventions Used in this Manual............................................................ x
Global Service Contact Information........................................................ xi
Package Contents.................................................................................xiii
Ordering Information ............................................................................xiv
Chapter 1: Product Introduction
Overview ................................................................................................1
Key Features........................................................................................1
Hardware Specifications..........................................................................2
Knowing Your nTUF 600.........................................................................4
Front Panel ..........................................................................................4
Rear Panel ...........................................................................................6
Mechanical Dimensions...........................................................................7
Chapter 2: Jumpers and Connectors
Before You Begin ....................................................................................8
Precautions ............................................................................................8
Jumper Settings ......................................................................................9
Locations of the Jumpers and Connectors for nROM600.......................10
nROB600...........................................................................................10
Jumpers................................................................................................11
RTC Clear..........................................................................................11
Pineview-D LVDS Backlight Power Select ............................................11
Connector Pin Definitions .....................................................................12
External I/O Interfaces - Front Panel ...................................................12
24V DC Input.................................................................................12
Keyboard and Mouse.....................................................................12
COM 5 and COM 6 Ports...............................................................13
HDMI.............................................................................................13
DVI & VGA Connector....................................................................14
DVI ................................................................................................14
VGA...............................................................................................14
Max. Resolution .............................................................................14
LAN 1 Connector ...........................................................................15
LAN 2 Connector ...........................................................................15
Quadruple USB Port .......................................................................16
LAN1/LAN2 Link/Active LEDs ..........................................................16
Power LEDs....................................................................................17
External I/O Interfaces - Rear Panel.....................................................18

Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. iii nTUF 600 User Manual
Content
Digital Input Connector..................................................................18
Digital Output Connector...............................................................18
NMEA Port 1..................................................................................19
NMEA Port 2..................................................................................19
NMEA Port 3..................................................................................20
NMEA Port 4..................................................................................20
Internal Connectors...........................................................................21
CPU Fan Connector........................................................................21
System Fan Connector ...................................................................21
System Fan Connector ...................................................................22
LVDS Panel Backlight Connector.....................................................22
LVDS Connector.............................................................................23
LVDS Connector.............................................................................23
USB Connector ..............................................................................24
Line-out Pin Header........................................................................24
Mic-in Pin Header...........................................................................25
Line-in Pin Header..........................................................................25
Power Connector...........................................................................26
SATA1 Connector...........................................................................26
SATA2 Connector...........................................................................27
SATA Power Connector ..................................................................27
SATA Power Connector ..................................................................28
CFast Connector ............................................................................28
Mini-PCIe Connector......................................................................29
SIM Card Connector ......................................................................30
GPS Connector ..............................................................................30
Box Header Connector...................................................................31
PWR_BT/RET_BT/LED/SM BUS Pin Header .......................................32
Locations of the Jumpers and Connectors for ICES253-600...................33
ICES253-600 - Top.............................................................................33
ICES253-600 - Bottom.......................................................................34
Connector Pin Definitions .....................................................................35
Internal Connectors...........................................................................35
High Speed Board-to-Board Connector: Row A and B.....................35
High Speed Board-to-Board Connector: Row C and D ....................38
CPU FAN Connector.......................................................................40
Chapter 3: System Setup
Removing the Chassis Cover ................................................................41
Installing the SIM Card..........................................................................43
Installing a Wireless LAN Module ..........................................................45
Installing a Wireless LAN Module (Bracket) ............................................47
Installing a Hard Drive...........................................................................48
Installing a CFast Card ..........................................................................50
Chapter 4: BIOS Setup
About BIOS Setup.................................................................................51
When to Configure the BIOS.................................................................51
Default Configuration...........................................................................52
Entering Setup......................................................................................52
Legends................................................................................................52
BIOS Setup Utility..................................................................................54
Main .................................................................................................54
Advanced .........................................................................................55
Boot..................................................................................................75
Chipset..............................................................................................77
PCIPnP...............................................................................................79
Security .............................................................................................80
Exit....................................................................................................81
Appendix A: Power Consumption.........................82
Appendix B: GPI/O Programming Guide...............84
Appendix C: Watchdog Timer Setting...................86

Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. iv nTUF 600 User Manual
Preface
Preface
Copyright
This publication, including all photographs, illustrations and software, is
protected under international copyright laws, with all rights reserved. No
part of this manual may be reproduced, copied, translated or transmitted in
any form or by any means without the prior written consent from NEXCOM
International Co., Ltd.
Disclaimer
The information in this document is subject to change without prior notice and
does not represent commitment from NEXCOM International Co., Ltd. However,
users may update their knowledge of any product in use by constantly checking
its manual posted on our website: http://www.nexcom.com. NEXCOM shall
not be liable for direct, indirect, special, incidental, or consequential damages
arising out of the use of any product, nor for any infringements upon the rights
of third parties, which may result from such use. Any implied warranties of
merchantability or fitness for any particular purpose is also disclaimed.
Acknowledgements
nTUF 600 is a trademark of NEXCOM International Co., Ltd. All other
product names mentioned herein are registered trademarks of their
respective owners.
Regulatory Compliance Statements
This section provides the FCC compliance statement for Class B devices and
describes how to keep the system CE compliant.
Declaration of Conformity
FCC
This equipment has been tested and verified to comply with the limits for
a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference
to radio communications. Operation of this equipment in a residential area
(domestic environment) is likely to cause harmful interference, in which
case the user will be required to correct the interference (take adequate
measures) at their own expense.
CE
The product(s) described in this manual complies with all applicable
European Union (CE) directives if it has a CE marking. For computer systems
to remain CE compliant, only CE-compliant parts may be used. Maintaining
CE compliance also requires proper cable and cabling techniques.

Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. vnTUF 600 User Manual
Preface
RoHS Compliance
NEXCOM RoHS Environmental Policy and Status
Update
This publication, including all photographs, illustrations
and software, is protected under international copyright
laws, with all rights reserved. No part of this manual
may be reproduced, copied, translated or transmitted in any form or by any
means without the prior written consent from NEXCOM International Co.,
Ltd.
RoHS restricts the use of Lead (Pb) < 0.1% or 1,000ppm, Mercury (Hg) < 0.1%
or 1,000ppm, Cadmium (Cd) < 0.01% or 100ppm, Hexavalent Chromium
(Cr6+) < 0.1% or 1,000ppm, Polybrominated biphenyls (PBB) < 0.1% or
1,000ppm, and Polybrominated diphenyl Ethers (PBDE) < 0.1% or 1,000ppm.
In order to meet the RoHS compliant directives, NEXCOM has established
an engineering and manufacturing task force to implement the introduction
of green products. The task force will ensure that we follow the standard
NEXCOM development procedure and that all the new RoHS components
and new manufacturing processes maintain the highest industry quality
levels for which NEXCOM are renowned.
The model selection criteria will be based on market demand. Vendors and
suppliers will ensure that all designed components will be RoHS compliant.
How to recognize NEXCOM RoHS Products?
For existing products where there are non-RoHS and RoHS versions, the
suffix “(LF)” will be added to the compliant product name.
All new product models launched after January 2006 will be RoHS compliant.
They will use the usual NEXCOM naming convention.

Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. vi nTUF 600 User Manual
Preface
Warranty and RMA
NEXCOM Warranty Period
NEXCOM manufactures products that are new or equivalent to new in
accordance with industry standard. NEXCOM warrants that products will
be free from defect in material and workmanship for 2 years, beginning on
the date of invoice by NEXCOM. HCP series products (Blade Server) which
are manufactured by NEXCOM are covered by a three year warranty period.
NEXCOM Return Merchandise Authorization (RMA)
▪Customers shall enclose the “NEXCOM RMA Service Form” with the
returned packages.
▪Customers must collect all the information about the problems
encountered and note anything abnormal or, print out any on-screen
messages, and describe the problems on the “NEXCOM RMA Service
Form” for the RMA number apply process.
▪Customers can send back the faulty products with or without accessories
(manuals, cable, etc.) and any components from the card, such as CPU
and RAM. If the components were suspected as part of the problems,
please note clearly which components are included. Otherwise, NEXCOM
is not responsible for the devices/parts.
▪Customers are responsible for the safe packaging of defective products,
making sure it is durable enough to be resistant against further damage
and deterioration during transportation. In case of damages occurred
during transportation, the repair is treated as “Out of Warranty.”
▪Any products returned by NEXCOM to other locations besides the
customers’ site will bear an extra charge and will be billed to the customer.
Repair Service Charges for Out-of-Warranty Products
NEXCOM will charge for out-of-warranty products in two categories, one is
basic diagnostic fee and another is component (product) fee.
Repair Service Charges for Out-of-Warranty Products
NEXCOM will charge for out-of-warranty products in two categories, one is
basic diagnostic fee and another is component (product) fee.
System Level
▪Component fee: NEXCOM will only charge for main components such as
SMD chip, BGA chip, etc. Passive components will be repaired for free,
ex: resistor, capacitor.
▪Items will be replaced with NEXCOM products if the original one cannot
be repaired. Ex: motherboard, power supply, etc.
▪Replace with 3rd party products if needed.
▪If RMA goods can not be repaired, NEXCOM will return it to the customer
without any charge.
Board Level
▪Component fee: NEXCOM will only charge for main components, such
as SMD chip, BGA chip, etc. Passive components will be repaired for free,
ex: resistors, capacitors.
▪If RMA goods can not be repaired, NEXCOM will return it to the customer
without any charge.

Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. vii nTUF 600 User Manual
Preface
Warnings
Read and adhere to all warnings, cautions, and notices in this guide and
the documentation supplied with the chassis, power supply, and accessory
modules. If the instructions for the chassis and power supply are inconsistent
with these instructions or the instructions for accessory modules, contact
the supplier to find out how you can ensure that your computer meets
safety and regulatory requirements.
Cautions
Electrostatic discharge (ESD) can damage system components. Do the
described procedures only at an ESD workstation. If no such station is
available, you can provide some ESD protection by wearing an antistatic
wrist strap and attaching it to a metal part of the computer chassis.

Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. viii nTUF 600 User Manual
Preface
Installation Recommendations
Ensure you have a stable, clean working environment. Dust and dirt can get
into components and cause a malfunction. Use containers to keep small
components separated.
Adequate lighting and proper tools can prevent you from accidentally
damaging the internal components. Most of the procedures that follow
require only a few simple tools, including the following:
▪A Philips screwdriver
▪A flat-tipped screwdriver
▪A grounding strap
▪An anti-static pad
Using your fingers can disconnect most of the connections. It is recommended
that you do not use needle-nose pliers to disconnect connections as these
can damage the soft metal or plastic parts of the connectors.
Safety Information
Before installing and using the device, note the following precautions:
▪Read all instructions carefully.
▪Do not place the unit on an unstable surface, cart, or stand.
▪Follow all warnings and cautions in this manual.
▪When replacing parts, ensure that your service technician uses parts
specified by the manufacturer.
▪Avoid using the system near water, in direct sunlight, or near a heating
device.
▪The load of the system unit does not solely rely for support from the
rackmounts located on the sides. Firm support from the bottom is highly
necessary in order to provide balance stability.
▪The computer is provided with a battery-powered real-time clock circuit.
There is a danger of explosion if battery is incorrectly replaced. Replace
only with the same or equivalent type recommended by the manufacturer.
Discard used batteries according to the manufacturer’s instructions.

Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. ix nTUF 600 User Manual
Preface
Safety Precautions
1. Read these safety instructions carefully.
2. Keep this User Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a
damp cloth. Do not use liquid or spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near the
equipment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a stable surface during installation. Dropping it or
letting it fall may cause damage.
7. The openings on the enclosure are for air convection to protect the
equipment from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before connecting
the equipment to the power outlet.
9. Place the power cord in a way so that people will not step on it. Do not
place anything on top of the power cord. Use a power cord that has been
approved for use with the product and that it matches the voltage and
current marked on the product’s electrical range label. The voltage and
current rating of the cord must be greater than the voltage and current
rating marked on the product.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the
power source to avoid damage by transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or electrical
shock.
13. Never open the equipment. For safety reasons, the equipment should be
opened only by qualified service personnel.
14. If one of the following situations arises, get the equipment checked by
service personnel:
a. The power cord or plug is damaged.
b.Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
d.The equipment does not work well, or you cannot get it to work
according to the user’s manual.
e. The equipment has been dropped and damaged.
f. The equipment has obvious signs of breakage.
15. Do not place heavy objects on the equipment.
16. The unit uses a three-wire ground cable which is equipped with a third
pin to ground the unit and prevent electric shock. Do not defeat the
purpose of this pin. If your outlet does not support this kind of plug,
contact your electrician to replace your obsolete outlet.
17. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY
REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE
RECOMMENDED BY THE MANUFACTURER. DISCARD USED BATTERIES
ACCORDING TO THE MANUFACTURER’S INSTRUCTIONS.

Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. xnTUF 600 User Manual
Preface
Technical Support and Assistance
1. For the most updated information of NEXCOM products, visit NEXCOM’s
website at www.nexcom.com.
2. For technical issues that require contacting our technical support team or
sales representative, please have the following information ready before
calling:
– Product name and serial number
– Detailed information of the peripheral devices
– Detailed information of the installed software (operating system,
version, application software, etc.)
– A complete description of the problem
– The exact wordings of the error messages
Warning!
1. Handling the unit: carry the unit with both hands and handle it with care.
2. Maintenance: to keep the unit clean, use only approved cleaning products
or clean with a dry cloth.
3. CompactFlash: Turn off the unit’s power before inserting or removing a
CompactFlash storage card.
Conventions Used in this Manual
Warning:
Information about certain situations, which if not observed,
can cause personal injury. This will prevent injury to yourself
when performing a task.
CAUTION!
CAUTION!CAUTION! Caution:
Information to avoid damaging components or losing data.
Note:
Provides additional information to complete a task easily.

Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. xi nTUF 600 User Manual
Preface
Global Service Contact Information
Headquarters
NEXCOM International Co., Ltd.
15F, No. 920, Chung-Cheng Rd., ZhongHe
District, New Taipei City, 23586, Taiwan,
R.O.C.
Tel: [phone]
Fax: [phone]
www.nexcom.com.tw
America
USA
NEXCOM USA
2883 Bayview Drive,
Fremont CA 94538, USA
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.com
Asia
Taiwan
Taichung Office
16F, No.250, Sec. 2,
Chongde Rd., Beitun Dist.,
Taichung City 406, R.O.C.
Tel: [phone]
Fax: [phone]
www.nexcom.com.tw
NEXCOM Japan
9F, Tamachi Hara Bldg.,4-11-5, Shiba
Minato-ku,
Tokyo, 108-0014, Japan
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom-jp.com
China
NEXCOM China
2F, Block 4, Venus Plaza, Building 21,
ZhongGuanCun Software Park, No.8,
Dongbeiwang West Road, Haidian District,
Beijing, 100193, China
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.cn
Shanghai Office
Room 1505, Greenland He Chuang Bldg.,
No. 450 Caoyang Rd.,
Shanghai, 200062, China
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.cn
Nanjing Office
Hall C, Block 17, Tian Xing Cui Lang Bldg.,
No. 49 Yunnan North Rd.,
Nanjing, 210018, China
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.cn
Shenzhen Office
Western Room 708, Block 210,
Tairan Industry & Trading Place, Futian Area,
Shenzhen, 518040, China
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.cn
Wuhan Office
1-C1804/1805,Mingze Liwan, No.519
South Luoshi Rd,Hongshan District,
Wuhan,430070,China
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.cn

Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. xii nTUF 600 User Manual
Preface
Chengdu Office
9F, Shuxiangxie, Xuefu Garden,
No.12 Section 1, South Yihuan Rd.,
Chengdu, 610061, China
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.cn
Europe
France
NEXCOM France
La Grande Arche-Paroi Nord
92044 Paris La Défense
France
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.eu
Germany
NEXCOM GmbH
Leopoldstraße Business Centre,
Leopoldstraße 244,
80807 Munich, Germany
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.eu
Italy
NEXCOM ITALIA S.r.l
Via Gaudenzio Ferrari 29,
21047 Saronno (VA), Italia
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcomitalia.it
United Kingdom
NEXCOM EUROPE
10 Vincent Avenue,
Crownhill Business Centre,
Milton Keynes, Buckinghamshire
MK8 0AB, United Kingdom
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.eu

Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. xiii nTUF 600 User Manual
Preface
Package Contents
Before continuing, verify that the nTUF 600 package that you received is complete. Your package should have all the items listed in the following table.
Item Part Number Description Qty
1 602DCD0477X00 (N)nTUF600 DVD DRIVER VER:1.0 1
2 60177A0263X00 (N)nROB600 QUICK REFERENCE GUIDE VER:A 1
3 5060900226X00 MINI PCIe BRACKET CHYUAN-JYH 1
4 50311F0295X00 FLAT HEAD SCREW LONG FEI:F2x4 NYLOK NIGP 2
5 50311F0294X00 I HEAD SCREW LONG FEI:I2x4 NYLOK NIGP 2
6 50311F0110X00 (H)FLAT HEAD SCREW LONG FEI:F3x5ISO+NYLOK NIGP 8
7 4NCPM00302X00 (T)TERMINAL BLOCKS 3P PHOENIX CONTACT:1777992 1
8 4NCPF00806X00 TERMINAL BLOCKS 8P PHOENIX CONTACT:1803633 1
9 4NCPF00611X00 TERMINAL BLOCKS 6P PHOENIX CONTACT:1803617 1
10 4NCPF00512X00 TERMINAL BLOCKS 5P PHOENIX CONTACT:1803604 4

Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. xiv nTUF 600 User Manual
Preface
Ordering Information
The following information below provides ordering information for nTUF 600 series.
• Barebone
nTUF 600 (P/N: 10M00060000X2)
- Intel® Atom™ Dual Core D525 1.8GHz Fanless Marine Computer
nTUF 605 (P/N: 10M00060500X0)
- Intel® Atom™ Dual Core D525 1.8GHz Marine Computer with DVD Combo

Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. 1nTUF 600 User Manual
Chapter 1: Product Introduction
Chapter 1: Product Introduction
Key Features
▪On-board Intel® Atom™ Dual Core D525 processor, 1.8 GHz
▪4x USB ports
▪Dual M12 connector for Intel® 82574L GbE LAN ports
▪1x VGA display output
▪2x RS232
▪2x PS/2 for keyboard and mouse
Overview
▪1x external CFast socket
▪1x mini-PCIe with two Antenna Holes
▪Support +24V DC power input
▪Dual cold swappable 2.5” SSD tray
▪Supports ATX Power Mode, WoL, LAN Teaming and PXE function

Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. 2nTUF 600 User Manual
Chapter 1: Product Introduction
Hardware Specifications
CPU Support
▪On-board Intel® Atom™ Dual Core processor D525, 1.8 GHz, 1M cache
▪Intel® ICH8M PCHs chipset
Main Memory
▪1x DDR2 SO-DIMM sockets, support up to 2 GB DDR2 667/ 800 SDRAM,
un-buffered and non-ECC
I/O Interface-Front
▪ATX power on/off switch
▪HDD access/ power status LEDs
▪LAN1 & LAN2 status LEDs
▪4x USB2.0 ports
▪2x M12 GbE LAN ports
Intel® 82574L GbE LAN controller on board with1.5KV surge protection
▪1x VGA output
▪1x DVI-D & 1x HDMI (only work when optional MXM 3.0 graphic module
is installed)
▪Audio jack (speaker-out & Mic-in & Line-in)
▪2x antenna holes
▪2x DB9, RS232
▪2x PS/2 for keyboard & mouse
▪2x cold swappable 2.5” HDD tray
▪1x external screwed type CFast socket
▪3-pin +24V DC input
▪1x external fuse;10A
I/O Interface-Rear
▪4x Digital Input: 6-pin screw terminals
Voltage level: 5V, TTL-level
▪4x Digital Output: 8-pin screw terminals
36V DC with 100mA relay
▪4x NMEA 0183 Interfaces
Signal: TX / RX signals
2KV optical isolation protection
Device
▪2x 2.5” SSD driver bay
▪1x external CFast socket
▪1 x mini-PCIe socket
Default: support optional Wi-Fi module
Option: support optional 3.5G module
Power Requirements
▪DC input range: 16V~30V DC input
▪Nominal DC input: +24V DC input with 1.5KV isolation protection
▪Pin definition: Positive, Negative and Chassis Ground
Dimensions
▪294mm (W) x 200mm (D) x 100mm (H) (11.6”x 7.9”x 3.94”)
Construction
▪Aluminum chassis with fanless design

Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. 3nTUF 600 User Manual
Chapter 1: Product Introduction
Environment
▪Operating temperature:
Ambient with air flow: -25°C~55°C
(Based on IEC60945 4th edition, IACS E10 and DNV 2.4)
▪Storage temperature: -30°C ~ 80°C
▪Relative humidity: 10% to 93% (non-condensing)
Certifications
▪IEC60945
▪IACS E10
▪DNV 2.4

Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. 4nTUF 600 User Manual
Chapter 1: Product Introduction
Knowing Your nTUF 600
Front Panel
DC Input
Fuse
HDD Tray
CFast socket
Power/HDD/LAN LED
USB
VGA
Mic-in
Line-out
Line-in
Antenna hole
Mouse & Keyboard COM5&6: RS232
M12 LAN port
HDMI DVI-D
Power
switch
DC Input
Used to plug a DC power cord.
Mouse & Keyboard
PS/2 connector for mouse and keyboard.
COM 5 & 6 Ports
Used to connect RS232 compatible devices.
Antenna Hole
Used to install external antennas.
VGA
Used to connect an analog VGA monitor.
Mic-in
Mic-in jack to connect microphones.
Line-out
Line-out jack to connect speakers or headphones.
Line-in
Line-in jack for audio input.
USB
4 USB2.0 ports to connect the system with USB2.0/1.1 device.

Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. 5nTUF 600 User Manual
Chapter 1: Product Introduction
Fuse
A 10A fuse used to protect the system from overcurrent.
HDD Tray
Hard drive trays to install hard drives on.
HDMI
Used to connect a high-definition display. HDMI display output is active only
when MXM Graphic card is installed. In addition, the air ventilation holes are
necessary if MXM graphic card is installed.
DVI-D
Used to connect a digital LCD panel. DVI-D display output is active only
when MXM Graphic card is installed. In addition, the air ventilation holes are
necessary if MXM graphic card is installed.
M12 LAN Port
Dual M12 LAN ports used to connect the system to a local area network.
CFast Socket
Used to insert a CFast card.
Power/HDD/LAN LED
Indicates the power status, hard drive and LAN activity of the system.
Power Switch
Press to power-on or power-off the system.

Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. 6nTUF 600 User Manual
Chapter 1: Product Introduction
Rear Panel
Digital input Digital output
NMEA 0183 interface
Digital Input and Output
Four channels of digital input and output used to connect to switches,
detectors, lights or alarm triggers.
NMEA 0183 Interface
Four NMEA interfaces used to connect NMEA 0183 RS422 serial devices.
(Please set the mode to RS485 in the BIOS menu if RS485 connection is
used.)
