Nexcom NISE 50 User manual

NEXCOM International Co., Ltd.
NEXCOM International Co., Ltd.
Published August 2021 www.nexcom.com
IoT Automation Solutions Business Group
Fan-less Computer
NISE 50 and NISE 50W
User Manual

Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. ii NISE 50 and NISE 50W User Manual
Contents
Contents
Preface
Copyright ............................................................................................. iv
Disclaimer.............................................................................................. iv
Acknowledgements ............................................................................... iv
Regulatory Compliance Statements........................................................ iv
Declaration of Conformity...................................................................... iv
RoHS Compliance ................................................................................... v
Warranty and RMA ................................................................................ vi
Installation Recommendations................................................................vii
Safety Information ................................................................................viii
Safety Precautions.................................................................................. ix
Technical Support and Assistance............................................................ x
Conventions Used in this Manual............................................................ x
Global Service Contact Information........................................................ xi
Package Contents.................................................................................xiii
Ordering Information ............................................................................xiv
Chapter 1: Product Introduction
Overview ................................................................................................1
Key Features........................................................................................1
NISE 50 ...............................................................................................1
NISE 50W............................................................................................1
Hardware Specifications..........................................................................2
Knowing Your NISE 50 and NISE 50W.....................................................4
Front Panel..........................................................................................4
Rear Panel ...........................................................................................5
Mechanical Dimensions...........................................................................6
NISE 50 ...............................................................................................6
NISE 50W............................................................................................7
Chapter 2: Jumpers and Connectors
Before You Begin ....................................................................................8
Precautions ............................................................................................8
Jumper Settings ......................................................................................9
Locations of the Jumpers and Connectors for NISB 50...........................10
NISB 50 .............................................................................................10
Jumpers................................................................................................11
AT/ATX Power Select .........................................................................11
CMOS Clear Select ............................................................................11
ME Clear Select .................................................................................12
COM3 RS422/485 Select ...................................................................12
SIM Card Power Select ......................................................................13
COM1 5V/12V/RI Select.....................................................................13
COM3 TX Terminal Pin header...........................................................14
COM3 RX Terminal Pin header...........................................................14
Connector Pin Definitions .....................................................................15
External I/O Interfaces - Front Panel ...................................................15
Power Button.................................................................................15
SIM Card Slot.................................................................................15
HDMI.............................................................................................16
USB1/2 Ports (USB 2.0)...................................................................16

Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. iii NISE 50 and NISE 50W User Manual
Contents
USB3/4 Ports (USB 2.0)...................................................................17
LAN 1 Port .....................................................................................17
LAN 2 Port .....................................................................................18
External I/O Interfaces - Rear Panel.....................................................19
24V DC Power Input ......................................................................19
COM 1 Port (RS232).......................................................................19
COM 2 Port (RS232).......................................................................20
COM 3 Port (RS422/485 Only)........................................................20
Line-out Connector........................................................................21
Internal Connectors...........................................................................22
LAN1 LED Signal Pin Header...........................................................22
LAN2 LED Signal Pin Header...........................................................22
SATA Connector.............................................................................23
SATA Power Connector..................................................................23
GPIO Pin Header ............................................................................24
Mic-in Pin Header...........................................................................24
COM 4 Pin Header (RS232) ............................................................25
Power & HDD LEDs/Power & Reset Switches...................................25
RTC Connector ..............................................................................26
SMBUS Pin Header.........................................................................26
SPI and I2C Pin Header...................................................................27
GPIO Pin Header ............................................................................27
UART Pin Header (Signal from CPU) ...............................................28
Mini-PCIe Connector (3G/4G/mSATA).............................................29
Mini-PCIe Connector (3G/4G/Wi-Fi)................................................30
Half-size Mini-PCIe Connector (Wi-Fi).............................................31
Chapter 3: System Setup
Removing the Chassis Cover ................................................................32
Installing a Wi-Fi/BT Mini-PCIe Module (Half-size)..................................33
Installing a Mini-PCIe Module (Full-size).................................................34
Installing a 3G Mini-PCIe Module (Half-size)..........................................35
Installing a SIM Card.............................................................................36
Installing an Antenna............................................................................38
Installing a 2.5” SSD/HDD Storage (For NISE 50W Only) ........................40
Wallmount Installation ..........................................................................43
DIN Rail Clip Installation........................................................................45
Aluminum DIN Rail Clip Installation.......................................................46
Packing (NISE 50)..................................................................................47
Packing (NISE 50W)...............................................................................49
Chapter 4: BIOS Setup
About BIOS Setup.................................................................................51
When to Configure the BIOS.................................................................51
Default Configuration...........................................................................52
Entering Setup......................................................................................52
Legends................................................................................................52
BIOS Setup Utility..................................................................................54
Main .................................................................................................54
Advanced .........................................................................................55
Chipset..............................................................................................65
Security .............................................................................................67
Boot..................................................................................................68
Save & Exit ........................................................................................69
Appendix A: Power Consumption ........................70
Appendix B: GPIO Control Commands
Command List................................................................................71
GPIO Default Table.........................................................................71
Read GPIO Status Sequence ...........................................................72
Write GPIO Status Sequence ..........................................................72
Read GPIO Direction Sequence.......................................................73
Write GPIO Direction Sequence ......................................................73

Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. iv NISE 50 and NISE 50W User Manual
Preface
PrefaCe
Copyright
This publication, including all photographs, illustrations and software, is
protected under international copyright laws, with all rights reserved. No
part of this manual may be reproduced, copied, translated or transmitted in
any form or by any means without the prior written consent from NEXCOM
International Co., Ltd.
Disclaimer
The information in this document is subject to change without prior notice and
does not represent commitment from NEXCOM International Co., Ltd. However,
users may update their knowledge of any product in use by constantly checking
its manual posted on our website: http://www.nexcom.com. NEXCOM shall
not be liable for direct, indirect, special, incidental, or consequential damages
arising out of the use of any product, nor for any infringements upon the rights
of third parties, which may result from such use. Any implied warranties of
merchantability or fitness for any particular purpose is also disclaimed.
Acknowledgements
NISE 50 and NISE 50W are trademarks of NEXCOM International Co., Ltd.
All other product names mentioned herein are registered trademarks of
their respective owners.
Regulatory Compliance Statements
This section provides the FCC compliance statement for Class A devices and
describes how to keep the system CE compliant.
Declaration of Conformity
FCC
This equipment has been tested and verified to comply with the limits for
a Class A digital device, pursuant to Part 15 of FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference
to radio communications. Operation of this equipment in a residential area
(domestic environment) is likely to cause harmful interference, in which
case the user will be required to correct the interference (take adequate
measures) at their own expense.
CE
The product(s) described in this manual complies with all applicable
European Union (CE) directives if it has a CE marking. For computer systems
to remain CE compliant, only CE-compliant parts may be used. Maintaining
CE compliance also requires proper cable and cabling techniques.

Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. vNISE 50 and NISE 50W User Manual
Preface
RoHS Compliance
NEXCOM RoHS Environmental Policy and Status
Update
NEXCOM is a global citizen for building the digital
infrastructure. We are committed to providing green
products and services, which are compliant with
European Union RoHS (Restriction on Use of Hazardous Substance in
Electronic Equipment) directive 2011/65/EU, to be your trusted green
partner and to protect our environment.
RoHS restricts the use of Lead (Pb) < 0.1% or 1,000ppm, Mercury (Hg) < 0.1%
or 1,000ppm, Cadmium (Cd) < 0.01% or 100ppm, Hexavalent Chromium
(Cr6+) < 0.1% or 1,000ppm, Polybrominated biphenyls (PBB) < 0.1% or
1,000ppm, and Polybrominated diphenyl Ethers (PBDE) < 0.1% or 1,000ppm.
In order to meet the RoHS compliant directives, NEXCOM has established
an engineering and manufacturing task force to implement the introduction
of green products. The task force will ensure that we follow the standard
NEXCOM development procedure and that all the new RoHS components
and new manufacturing processes maintain the highest industry quality
levels for which NEXCOM are renowned.
The model selection criteria will be based on market demand. Vendors and
suppliers will ensure that all designed components will be RoHS compliant.
How to recognize NEXCOM RoHS Products?
For existing products where there are non-RoHS and RoHS versions, the
suffix “(LF)” will be added to the compliant product name.
All new product models launched after January 2013 will be RoHS compliant.
They will use the usual NEXCOM naming convention.

Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. vi NISE 50 and NISE 50W User Manual
Preface
Warranty and RMA
NEXCOM Warranty Period
NEXCOM manufactures products that are new or equivalent to new in
accordance with industry standard. NEXCOM warrants that products will be
free from defect in material and workmanship for 2 years, beginning on the
date of invoice by NEXCOM.
NEXCOM Return Merchandise Authorization (RMA)
▪Customers shall enclose the “NEXCOM RMA Service Form” with the
returned packages.
▪Customers must collect all the information about the problems
encountered and note anything abnormal or, print out any on-screen
messages, and describe the problems on the “NEXCOM RMA Service
Form” for the RMA number apply process.
▪Customers can send back the faulty products with or without accessories
(manuals, cable, etc.) and any components from the card, such as CPU
and RAM. If the components were suspected as part of the problems,
please note clearly which components are included. Otherwise, NEXCOM
is not responsible for the devices/parts.
▪Customers are responsible for the safe packaging of defective products,
making sure it is durable enough to be resistant against further damage
and deterioration during transportation. In case of damages occurred
during transportation, the repair is treated as “Out of Warranty.”
▪Any products returned by NEXCOM to other locations besides the
customers’ site will bear an extra charge and will be billed to the customer.
Repair Service Charges for Out-of-Warranty Products
NEXCOM will charge for out-of-warranty products in two categories, one is
basic diagnostic fee and another is component (product) fee.
System Level
▪Component fee: NEXCOM will only charge for main components such as
SMD chip, BGA chip, etc. Passive components will be repaired for free,
ex: resistor, capacitor.
▪Items will be replaced with NEXCOM products if the original one cannot
be repaired. Ex: motherboard, power supply, etc.
▪Replace with 3rd party products if needed.
▪If RMA goods can not be repaired, NEXCOM will return it to the customer
without any charge.
Board Level
▪Component fee: NEXCOM will only charge for main components, such
as SMD chip, BGA chip, etc. Passive components will be repaired for free,
ex: resistors, capacitors.
▪If RMA goods can not be repaired, NEXCOM will return it to the customer
without any charge.

Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. vii NISE 50 and NISE 50W User Manual
Preface
Warnings
Read and adhere to all warnings, cautions, and notices in this guide and
the documentation supplied with the chassis, power supply, and accessory
modules. If the instructions for the chassis and power supply are inconsistent
with these instructions or the instructions for accessory modules, contact
the supplier to find out how you can ensure that your computer meets
safety and regulatory requirements.
Cautions
Electrostatic discharge (ESD) can damage system components. Do the
described procedures only at an ESD workstation. If no such station is
available, you can provide some ESD protection by wearing an antistatic
wrist strap and attaching it to a metal part of the computer chassis.
Installation Recommendations
Ensure you have a stable, clean working environment. Dust and dirt can get
into components and cause a malfunction. Use containers to keep small
components separated.
Adequate lighting and proper tools can prevent you from accidentally
damaging the internal components. Most of the procedures that follow
require only a few simple tools, including the following:
▪A Philips screwdriver
▪A flat-tipped screwdriver
▪A grounding strap
▪An anti-static pad
Using your fingers can disconnect most of the connections. It is recommended
that you do not use needle-nose pliers to disconnect connections as these
can damage the soft metal or plastic parts of the connectors.

Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. viii NISE 50 and NISE 50W User Manual
Preface
Safety Information
Before installing and using the device, note the following precautions:
▪Read all instructions carefully.
▪Do not place the unit on an unstable surface, cart, or stand.
▪Follow all warnings and cautions in this manual.
▪When replacing parts, ensure that your service technician uses parts
specified by the manufacturer.
▪Avoid using the system near water, in direct sunlight, or near a heating
device.
▪The load of the system unit does not solely rely for support from the
rackmounts located on the sides. Firm support from the bottom is highly
necessary in order to provide balance stability.
▪The computer is provided with a battery-powered real-time clock circuit.
There is a danger of explosion if battery is incorrectly replaced. Replace
only with the same or equivalent type recommended by the manufacturer.
Discard used batteries according to the manufacturer’s instructions.
CAUTION!
CAUTION!CAUTION!
Danger of explosion if battery is incorrectly replaced.
Replace with the same or equivalent type recommended by
the manufacturer. Discard used batteries according to the
manufacturer’s instructions.
CAUTION!
CAUTION!CAUTION!
ATTENTION
IL Y A RISQUE D’EXPLOSION SI LA BATTERIE EST REMPLACÉE
PAR UNE BATTERIE DE TYPE INCORRECT.
METTRE AU REBUT LES BATTERIES USAGÉES
CONFORMÉMENT AUX INSTRUCTIONS.
CAUTION!
CAUTION!CAUTION!
This product is intended to be supplied by a Listed Power
Adapter, rated 24Vdc, 2.5A minimum, Tma = 55 degrees C,
and the altitude of operation = 2000m.
(2000m for general requirement, 5000m for collocation with
Adapter: FSP Group Inc. / FSP060-DAAN3.)
If need further assistance with purchasing the power source,
please contact to NEXCOM (mfr.) for further information.

Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. ix NISE 50 and NISE 50W User Manual
Preface
Safety Precautions
1. Read these safety instructions carefully.
2. Keep this User Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a
damp cloth. Do not use liquid or spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near the
equipment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a stable surface during installation. Dropping it or
letting it fall may cause damage.
7. The openings on the enclosure are for air convection to protect the
equipment from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before connecting
the equipment to the power outlet.
9. Place the power cord in a way so that people will not step on it. Do not
place anything on top of the power cord. Use a power cord that has been
approved for use with the product and that it matches the voltage and
current marked on the product’s electrical range label. The voltage and
current rating of the cord must be greater than the voltage and current
rating marked on the product.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the
power source to avoid damage by transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or electrical
shock.
13. Never open the equipment. For safety reasons, the equipment should be
opened only by qualified service personnel.
14. If one of the following situations arises, get the equipment checked by
service personnel:
a. The power cord or plug is damaged.
b.Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
d.The equipment does not work well, or you cannot get it to work
according to the user’s manual.
e. The equipment has been dropped and damaged.
f. The equipment has obvious signs of breakage.
15. Do not place heavy objects on the equipment.
16. The unit uses a three-wire ground cable which is equipped with a third
pin to ground the unit and prevent electric shock. Do not defeat the
purpose of this pin. If your outlet does not support this kind of plug,
contact your electrician to replace your obsolete outlet.
17. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY
REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE
RECOMMENDED BY THE MANUFACTURER. DISCARD USED BATTERIES
ACCORDING TO THE MANUFACTURER’S INSTRUCTIONS.

Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. xNISE 50 and NISE 50W User Manual
Preface
Technical Support and Assistance
1. For the most updated information of NEXCOM products, visit NEXCOM’s
website at www.nexcom.com.
2. For technical issues that require contacting our technical support team or
sales representative, please have the following information ready before
calling:
– Product name and serial number
– Detailed information of the peripheral devices
– Detailed information of the installed software (operating system,
version, application software, etc.)
– A complete description of the problem
– The exact wordings of the error messages
Warning!
1. Handling the unit: carry the unit with both hands and handle it with care.
2. Maintenance: to keep the unit clean, use only approved cleaning products
or clean with a dry cloth.
Conventions Used in this Manual
Warning:
Information about certain situations, which if not observed,
can cause personal injury. This will prevent injury to yourself
when performing a task.
CAUTION!
CAUTION!CAUTION! Caution:
Information to avoid damaging components or losing data.
Note:
Provides additional information to complete a task easily.

Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. xi NISE 50 and NISE 50W User Manual
Preface
Global Service Contact Information
Headquarters
NEXCOM International Co., Ltd.
9F, No. 920, Chung-Cheng Rd.,
Zhonghe District, New Taipei City, 23586,
Taiwan, R.O.C.
Tel: [phone]
Fax: [phone]
www.nexcom.com
Asia
Taiwan
NexAIoT Headquarters
Industry 4.0 and Cloud Services
13F, No.916, Zhongzheng Rd.,
Zhonghe District, New Taipei City,
23586, Taiwan, R.O.C.
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexaiot.com
NexAIoT Co., Ltd.
Taichung Office
16F, No.250, Sec. 2, Chongde Rd.,
Beitun District,
Taichung City, 406, Taiwan, R.O.C.
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexaiot.com
NexCOBOT Taiwan Co., Ltd.
13F, No.916, Chung-Cheng Rd.,
Zhonghe District,
New Taipei City, 23586, Taiwan, R.O.C.
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcobot.com
GreenBase Technology Corp.
13F, No.922, Chung-Cheng Rd.,
Zhonghe District,
New Taipei City, 23586, Taiwan, R.O.C.
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.com.tw
EMBUX Technology Co., Ltd.
13F, No.916, Chung-Cheng Rd.,
Zhonghe District,
New Taipei City, 23586, Taiwan, R.O.C.
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.com.tw
TMR Technology Corp.
13F, No.916, Chung-Cheng Rd.,
Zhonghe District,
New Taipei City, 23586, Taiwan, R.O.C.
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.com.tw
China
NEXSEC Incorporated
5F, No.4, No.7 Fengxian Middle Rd.,
(Beike Industrial Park), Haidian District,
Beijing, 100094, China
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexsec.cn
NEXCOM Shanghai
No.4, 16 Building,
Shanghai OMNI Tech & Science Park
No. 1699, Douhui Rd.,
Shanghai, 201108, China
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.cn

Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. xii NISE 50 and NISE 50W User Manual
Preface
NexCOBOT China
Room 501, Building 1, Haichuang Building,
No.7 Qingyi Road, Guicheng Street,
Nanhai District, Foshan City,
Guangdong Province, 528314, China
Tel: [phone]
Email: [email protected]
www.nexcobot.com.cn
Beijing NexGemo Technology Co.,Ltd.
5F, Gemotech Building, No.1, Development Rd.,
Changping International Information Industry Base,
Changping District,
Beijing, 102206, China
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexgemo.cn
Japan
NEXCOM Japan
9F, Tamachi Hara Bldg.,
4-11-5, Shiba Minato-ku,
Tokyo, 108-0014, Japan
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom-jp.com
NEXCOM Surveillance Technology Corp.
5F, Building C, ZhenHan Industrial Zone,
GanKeng Community, Buji Street,
LongGang District,
ShenZhen, 518112, China
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.cn
NEXCOM United System Service
Room 603/604, Huiyinmingzun Plaza Bldg. 1,
No. 609, Yunlin East Rd.,
Shanghai, 200062, China
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.cn
NEXGOL Chongqing
1F, Building B4, Electronic 2nd Area,
(Phoenix Lake Industrial Park), Yongchuan Dist.,
Chongqing City, 402160, China
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcobot.com/NexGOL
America
USA
NEXCOM USA
46665 Fremont Blvd.,
Fremont CA 94538, USA
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcomusa.com
Europe
United Kingdom
NEXCOM EUROPE
10 Vincent Avenue,
Crownhill Business Centre,
Milton Keynes, Buckinghamshire
MK8 0AB, United Kingdom
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.co.uk

Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. xiii NISE 50 and NISE 50W User Manual
Preface
Package Contents
Before continuing, verify that the package that you received is complete. Your
NISE 50/NISE 50W package should have all the items listed in the following tables.
NISE 50
Item Part Number Description Qty
1 6012200052X00 PE Zipper Bag #8 170x240mm 1
2 60177A0433X00 NISE 50 Quick Reference Guide VER: A Size: A4 1
3 6012200053X00 PE Zipper Bag #3 100x70mm 2
4 50311F0330X00 Round Head Screw P2x3 NI Nylok 6
5 4NCPM00302X00 Terminal Blocks 3P Male DIP Green 1
6 5060900226X00 Mini PCIe Bracket 29x30x2.1mm SPCC t= 1.0mm NI 1
7 50311F0295X00 Flat Head Screw F2x4 NIGP Nylok 2
8 602DCD1143X00 NISE 50 DVD Driver VER: 1.0 1
NISE 50W
Item Part Number Description Qty
1 6012200052X00 PE Zipper Bag #8 170x240mm 1
2 60177A0433X00 Quick Reference Guide VER:A SIZE:A4 1
3 6012200053X00 PE Zipper Bag #3 100x70mm 2
4 50311F0330X00 Round Head Screw P2x3 NI NYLOK 6
5 4NCPM00302X00 Terminal Blocks 3P Male DIP Green 1
6 5060900226X00 Mini PCIe Bracket 29x30x2.1mm SPCC t=1.0mm NI 1
7 50311F0295X00 Flat Head Screw F2x4 NIGP Nylok 2
8 602DCD1143X00 DVD Driver VER: 1.0 1
9 6012200126X00 Chain Bag #6 170x120mm 1
10 4BJK0100A1X10 PCB For HDD Tray 100x94mm Thickness:1.6mm 1
11 50311F0144X00 I Head Screw: M3x4mm 8

Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. xiv NISE 50 and NISE 50W User Manual
Preface
Ordering Information
The following information below provides ordering information for NISE 50
and NISE 50W.
• Barebone
NISE 50 (P/N: 10J00005000X0)
- Intel®Atom™ processor E3826 dual core fanless system, with onboard
16GB EMMC and 2GB DDR3L RAM
NISE 50W (P/N:10J00005011X0)
- Intel®Atom™ processor E3826 dual core fanless system, with onboard
16GB EMMC and 2G DDR3L RAM
• 24V, 60W AC/DC power adapter w/o power cord
(P/N: 7400060054X00)

Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. 1NISE 50 and NISE 50W User Manual
Chapter 1: Product Introduction
ChaPter 1: ProduCt IntroduCtIon
Key Features
▪Onboard Intel®Atom™ processor E3826 dual core, 1.46GHz
▪1 x HDMI display
▪2 x Intel®I120AT GbE LAN ports; support WoL, Teaming and PXE
▪4 x USB 2.0
▪3 x mini-PCIe sockets for optional Wi-Fi/3.5G/LTE modules
Overview
NISE 50 NISE 50W
▪1 x RS232, 1 x RS232 (only Tx/Rx/GND), 1 x RS422/485 with auto flow
control
▪Support -5 ~ 55 degree C operating temperature
▪Support 24V DC input
▪1 x 2.5” Front Accessible HDD Tray (NISE 50W only)

Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. 2NISE 50 and NISE 50W User Manual
Chapter 1: Product Introduction
Hardware Specifications
CPU Support
▪Default: Onboard Intel®Atom™ processor E3826 Dual Core, 1.46GHz
▪Optional: Support Intel®Atom™ processor E3845 Quad Core, 1.91GHz
(by request)
Main Memory
▪On-board DDR3L 2GB
Display Option
▪1 x HDMI display
I/O Interface - Front
▪ATX power on/off switch
▪1 x Storage/2 x GPO programmable LED
▪1 x SIM card holder
▪2 x Intel®I210AT GbE LAN ports; support WoL, Teaming and PXE
▪1 x HDMI Display Output
▪4 x USB 2.0 (500mA per each)
▪2 x Antenna holes for optional Wi-Fi/3.5G antenna
I/O Interface - Rear
▪3 x DB9 for COM1 & COM2 & COM3
– COM1: Full RS232 signal
– COM2: RS232, only supports Tx/Rx/GND
– COM3: RS422/485 auto flow control
▪1 x Line-out
▪Support 24V DC INPUT
I/O Interface - Internal
▪4 x GPI and 4 x GPO (Programmable to GPI or GPO)
▪1 x DB9, only supports RS232, Tx/Rx/GND single
Storage Device
▪On-board 16GB EMMC
▪Optional mSATA module
▪Optional 2.5” HDD/SSD in 7mm thickness (NISE 50W only)
Expansion Slot
▪3 x Mini-PCIe sockets for optional Wi-Fi/3.5G modules
Mini-PCIe Size USB PCIe mSATA 3.5G/4G
CN5 Full N/A Support Support
CN6 Full   N/A Support
CN7 Half   N/A N/A

Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. 3NISE 50 and NISE 50W User Manual
Chapter 1: Product Introduction
Power Requirements
▪Power input: 24V DC +/-20%
▪1 x optional 24V, 60W power adapter
Support OS
Model Name NISE 50 NISE 50-4G-32G NISE 50W
Storage eMMC
16GB mSATA eMMC 32GB mSATA SSD
Memory 2GB 4GB 2GB
OS
Android 4.4 64-bit 64-bit
Windows 10
IoT Enterprise 64-bit 64-bit
WES8 32-bit 32-bit 64-bit 64-bit 32-bit
Windows 7
Professional 32-bit 64-bit 32-bit
WES7E 32-bit 64-bit 32-bit
WEC7 32-bit 32-bit 32-bit
* Note: Only one LAN can be active under Android 4.4.
Dimensions
▪NISE 50: 162mm(W) x 26mm(H) x 150mm(D) without wall-mount
bracket
▪NISE 50W: 261mm(W) x 26mm(H) x 150mm(D) without wall-mount
bracket
Construction
▪Metal chassis with fanless design
Environment
▪Operating Temperature:
Ambient with air flow: -5°C to 55°C
(According to IEC60068-2-1, IEC60068-2-2, IEC60068-2-14)
▪Storage Temperature: -20°C to 75°C
▪Relative Humidity: 10% to 95% (non-condensing)
NISE 50:
▪Shock Protection:
– mSATA / EMMC: 50G, half sine, 11ms, IEC60068-27
▪Vibration protection w/mSATA or EMMC condition:
– Random: 2Grms @ 5~500 Hz, IEC60068-2-64
– Sinusoidal: 2Grms @ 5~500 Hz, IEC60068-2-6
NISE 50W:
▪Shock Protection:
– HDD: 20G, half sine, 11ms, IEC60068-27
– SSD / mSATA: 50G, half sine, 11ms, IEC60068-27
▪Vibration protection w/HDD condition:
– Random: 0.5Grms @ 5~500 Hz, IEC60068-2-64
– Sinusoidal: 0.5Grms @ 5~500 Hz, IEC60068-2-6
▪Vibration protection w/SSD or mSATA condition:
– Random: 2Grms @ 5~500 Hz, IEC60068-2-64
– Sinusoidal: 2Grms @ 5~500 Hz, IEC60068-2-6
Certifications
▪CE
▪FCC Class A
▪UL/cUL

Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. 4NISE 50 and NISE 50W User Manual
Chapter 1: Product Introduction
Knowing Your NISE 50 and NISE 50W
Front Panel
HDD/SSD Drive Bay
Used to install a 2.5” HDD/SSD.
Antenna Hole
Used to install external antennas.
Power Switch
Press to power-on or power-off the system.
SIM
Used to insert a SIM card.
LED Indicators
Indicates the hard drive and GPIO (programmable) activity of the system.
HDMI
Used to connect a high-definition display.
USB 2.0
USB 2.0 ports to connect the system with USB 2.0/1.1 devices.
LAN
Used to connect the system to a local area network.
USB 2.0SIM HDMI LAN
Antenna Hole LEDs Antenna Hole
Power
Switch
NISE 50
USB 2.0SIM HDMI LAN
Antenna Hole Antenna HoleLEDs
Power
Switch
HDD/SSD
Drive Bay
NISE 50W

Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. 5NISE 50 and NISE 50W User Manual
Chapter 1: Product Introduction
Rear Panel
COM1/2/3 Line-outDC Input
COM1/2/3 Line-outDC Input
DC Input
Used to plug a DC power cord.
COM1 to COM3
Three DB9 ports used to connect serial devices.
– COM1: Full RS232 signal
– COM2: RS232, only supports Tx/Rx/GND
– COM3: RS422/485 auto flow control
Line-out
Used to connect a headphone or a speaker.
NISE 50
NISE 50W

Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. 6NISE 50 and NISE 50W User Manual
Chapter 1: Product Introduction
Mechanical Dimensions
NISE 50
4.00
Ø 8.00
25.00
26.00
70.00
150.00
174.00
186.00
162.00
Ø 3.70
