Nexcom EBC340 User manual

www.nexcom.com
Single Board Computer
EBC340
User’s Manual
Apr.-01-2009 Build
User’s Manual is subject to change without prior notice.
For any update, please visit our website: www.nexcom.comk

EBC340 User’s Manual 2 Table of Content
Preface
Copyright
This publication, including all photographs, illustrations and software, is protected under international
copyright laws, with all rights reserved. No part of this manual maybe reproduced, copied, translated or
transmitted in any form or by any means without the prior written consent from NEXCOM International
Co., Ltd.
Version 1.3
Copyright 2006
Disclaimer
The information in this document is subject to change without prior notice and does not represent
commitment from NEXCOM International Co., LTD. However, users may update their knowledge of any
product in use by constantly checking its manual posted on our website: http://www.nexcom.com.
NEXCOM shall not be liable for direct, indirect, special, incidental, or consequential damages arising out
of the use of any product, nor for any infringements upon the rights of third parties, which may result from
such use. Any implied warranties of merchantability of fitness for any particular purpose is also
disclaimed.
Acknowledgements
The EBC 340 series is a trademark of NEXCOM international CO., LTD. All other product names
mentioned herein are registered trademarks of their respective owners.
Regulatory Compliance Statements
This section provides the FCC compliance statement for Class A devices and describes how to keep the
system CE compliant.
Federal Communications Commission (FCC) For ClassA Device
This equipment has been tested and verified to comply with the limits for a Class A digital device, pursuant
to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates, uses,

EBC340 User’s Manual 3 Table of Content
and can radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. Operation of this equipment in a residential area
(domestic environment) is likely to cause harmful interference, in which case the user will be required to
correct the interference (take adequate measures) at their own expense.
CE Certification
The product(s) described in this manual complies with all applicable European Union (CE) directives if it
has a CE marking. For computer systems to remain CE compliant, only CE-compliant parts may be used.
Maintaining CE compliance also requires proper cable and cabling techniques.
Safety Information
Before installing and using the EBC340, note the following precautions:
Read all instructions carefully.
Do not place the unit on an unstable surface, cart, or stand.
Follow all warnings and cautions in this manual.
When replacing parts, ensure that your service technician uses parts specified by the manufacturer.
Avoid using the system near water, in direct sunlight, or near a hearing device.
WARNINGS
Read and adhere to all warnings, cautions, and notices in this guide and
the documentation supplied with the chassis, power supply, and accessory
modules. If the instructions for the chassis and power supply are inconsistent
with these instructions or the instructions for accessory modules, contact
the supplier to find out how you can ensure that your computer meets
safety and regulatory requirements.
CAUTION
Electrostatic discharge (ESD) can damage NSA components. Do the
described procedures only at an ESD workstation. If no such station is
available, you can provide some ESD protection by wearing an antistatic
wrist strap and attaching it to a metal part of the computer chassis.

EBC340 User’s Manual 4 Table of Content
Table of Content
Preface……………...……………..……………………………………….………….……..……………..2
Copyright………………..……………………………………….……………………………………….... 2
Disclaimer………………………..………………………………..……………………………………….. 2
Acknowledgements……………………………………………..………………………..………..…..……2
Regulatory Compliance Statements……………………..…………………………………….……………2
Federal Communications Commission (FCC) For Class A Device……………..……….…………..…..…2
CE Certification………………………………………………………………………….……….………...3
Safety Information……………………………………………………………………….………..………..3
Table of Content……………………………………………………………………………………....…….4
Chapter 1 General Information
1.1 Specification…………………………………………………….…………………………………….. 6
1.2 Power Consumption Measurement……………………………………………………………………..8
1.3 Board Layout…………………………………………………………………….… …………………. 9
1.4 Board Dimensions……………………………………………………….………… …….…………… 9
Chapter 2Jumper Setting
2.1 Before You Begin……………………………………………..….……………………………………11
2.2 Precautions………………………………………………………………………………………...…..11
2.3 Setting Jumpers………………………………………………………………………………………..12
2.4 Location of Jumpers……………………………………………………………………………….…..13
2.5 Function of Jumpers and Connectors…………….………………………………………………........14
GPIO Programming Guide………………………………………………………………………………28
Chapter 3 Expansion
3.1 System Memory…………………………………………………………………………………..…….31
3.2 Installing Compact Flash……………….……...………………………………………..…………….. 32
Chapter 4 BIOS Setting
4.1 Entering Setup………………………………………………………………………………………….34
4.2 Getting Help……………………………………………………………………………………………34
4.3 The Main Menu………………………………………………………………………………………...36

EBC340 User’s Manual 5 Chapter 1
Chapter 1
General Information

EBC340 User’s Manual 6 Chapter 1
1.1 Specification
CPU Support
Intel® Atom™ Processor N270 1.6GHZ
Main Memory
1 x DDR2 SO-DIMM Socket (up to 1GB)
Chipset
Intel 945GSE Express chipset
Intel® 82801GBM (ICH7-M)
Graphic
Intel® 945GSE integrated graphics
Support Dual Independent Display:CRT+LVDS
CRT: 1 x DB15 VGA CON
LVDS: 1x DF13 20-pin connector
Storage
Support 1x Type I/II Compact Flash socket

EBC340 User’s Manual 7 Chapter 1
uDOC mechanical dimension to support USB interface SSD
1x 7-pin SATA connector
Expansion
1x PCI-104
Audio
Realtek ALC888 CODEC
Mic-In x1 / Line out x1 Phone Jack
Network
LAN Chip: Realtek RTL8111C-GR
Support Boot From LAN (PXE)
I/O
1 x Parallel Port 26-pin Box header
COM1 by DB9 Male CON
COM2 support RS232/422/485 w/10pin Box header
2 x 10pin Box Header for COM3~COM4
1 x USB 2.0 Port
1 x 2.0mm Jst Connector for USB
1 x 10Pin Header for USB
1 x 10pin header for GPIO
1 x Power LED pin header
1 x HDD Active LED Pin header
1 x LAN Link-Active LED Pin header
1 x 3pin fan connector(Reserved)
Power Supply
+12V/+5V AT/ATX mode
6pin Power CON
System Management
Derived from Super I/O to support system monitor
Monitoring of 5 voltages For +5V, Vcore,+12V, +3.3V, +1.5V5 voltage
2 Temperatures (CPU, System)
RTC
On chip RTC with battery back up / External Li-ion Battery
RTC Torrance less than 2sec (24 hours) under 25˚C
BIOS
Award system BIOS
8M bits SPI ROM
Operating Systems
Windows XP,XP Embedded, CE
Certification
CE

EBC340 User’s Manual 8 Chapter 1
FCC Class A
100% RoHS competed
Environment
Operating temperatures: 0°C to 60°C
Storage temperatures:-20˚C to 85˚C
Relative Humidity:
Operating 10%~90%, non-condensing
1.2 Power Consumption Measurement
EBC340 Power Consumption
Power Type +12V +5v +12v-to-Vcore
DC/DC
+12v-to-1.8v
DC/DC
+12v-to-0.9v
DC/DC
5v-to-1.5v
DC/DC
5v-to-1.05v
DC/DC
+12v-to-3.3v
DC/DC
Consumed watts 18W 34.75W 4.4W 5.544W 0.9W 5.79W 7.581W 19W
Consumed
currents
(Item A )
1.5A 6.95A 0.367A 0.462A 0.075A 1.158A 1.5162A 1.584A
Actually
required
currents
(Item A/0.80 )
0.46A 0.578A 0.01A 1.448A 1.896A 1.98A
12v needed 4.528A
5v needed 10.294A

EBC340 User’s Manual 9 Chapter 1
1.3 Board Layout
Figure 1.2: Overview of EBC 340
1.4Board Dimensions
Figure 1.3: Mechanical Drawing of the EBC 340

EBC 340 User’s Manual 10
Chapter 2
Jumper Setting

EBC 340 User’s Manual 11
This chapter of the User’s Manual describes how to set jumpers.
Note: The procedures that follow are generic for all EBC340.
2.1 Before You Begin
Ensure you have a stable, clean working environment. Dust and dirt can get into components and cause a
malfunction. Use containers to keep small components separated.
Adequate lighting and proper tools can prevent you from accidentally damaging the internal components.
Most of the procedures that follow require only a few simple tools, including the following:
♦A Philips screwdriver
♦A flat-tipped screwdriver
♦A set of jewelers Screwdrivers
♦A grounding strap
♦An anti-static pad
Using your fingers can disconnect most of the connections. It is recommended that you do not use
needle-nosed pliers to disconnect connections as these can damage the soft metal or plastic parts of the
connectors.
Before working on internal components, make sure that the power is off. Ground yourself before touching
any internal components, by touching a metal object. Static electricity can damage many of the electronic
components. Humid environment tend to have less static electricity than dry environments. A grounding
strap is warranted whenever danger of static electricity exists.
2.2 Precautions
Computer components and electronic circuit boards can be damaged by discharges of static electricity.
Working on the computers that are still connected to a power supply can be extremely dangerous. Follow
the guidelines below to avoid damage to your computer or yourself:
♦Always disconnect the unit from the power outlet whenever you are working inside the case.
♦If possible, wear a grounded wrist strap when you are working inside the computer case. Alternatively,
discharge any static electricity by touching the bare metal chassis of the unit case, or the bare metal
body of any other grounded appliance.
♦Hold electronic circuit boards by the edges only. Do not touch the components on the board unless it
is necessary to do so. Don’t flex or stress the circuit board.
♦Leave all components inside the static-proof packaging that they shipped with until they are ready for
installation.
♦Use correct screws and do not over tighten screws.

EBC 340 User’s Manual 12
2.3 Setting Jumpers
A jumper is the simplest kind of electric switch. It consists of two metal pins and a cap. When setting the
jumpers, ensure that the jumper caps are placed on the correct pins. When the jumper cap is placed on
both pins, the jumper is SHORT. If you remove the jumper cap, or place the jumper cap on just one pin,
the jumper is OPEN. Please see the following illustrations
The illustrations on the right show
a 2-pin jumper. When the jumper
cap is placed on both pins, the
jumper is SHORT. If you remove
the jumper cap, or place the
jumper cap on just one pin, the
jumper is OPEN.
Open (Off) Short (On)
These illustrations show a 3-pin
jumper. Pins 1 and 2 are SHORT.
Table 2-1: Setting Jumpers

EBC 340 User’s Manual 13
2.4 Location of Jumpers
Figure 2-1: Jumper Location

EBC 340 User’s Manual 14
2.5 Functions of Jumpers and Connectors
◎ VGA Port
VGA1 (D-Sub 15 pins)
Pin Definition: VGA1
Pin NO. Description Pin NO. Description
1 RED_VGA 9 VGA_VCC
2 GREEN_VGA 10 GND
3 BLUE_VGA 11 NC
4 NC 12 VGA_DDC_DATA
5 GND 13 G_HSYNC
6 GND 14 G_VSYNC
7 GND 15 VGA_DDC_CLK
8 GND
◎ LVDS CON
CN6 ( 2 X10 2.0 Pitch)
Pin Definition: CN6
Pin NO. Description Pin NO. Description
1 DDCCLK 11 LB_CLK_P
2 DDC_DATA 12 LB_DATAN1
3 VDD 13 LB_CLK_N
4 LB_DATAP0 14 GND
5 PULL LOW 15 GND
6 LB_DATAN0 16 VCC12_INV
7 PULL LOW 17 LB_DATAP2
8 VDD 18 VCC12_INV
9 GND 19 LB_DATAN2
10 LB_DATAP1 20 GND

EBC 340 User’s Manual 15
◎ CCFL CON
J4 (JST 7 Pins 2.54 Pitch)
Pin Definition: J4
Pin NO. Description Pin NO. Description
1 +5V 2 +12V
3 +12V 4 Brightness Ctrl
5 GND 6 GND
7 Backlight Enable
◎Panel Power selection:
Pin header 1x3 2.54 Pitch.
Pin Definition: JP8
Pin NO. Description
1 VCC5
2 Panel power
3 VCC3
◎ RTC Clear:
Pin header 1x3 2.54 Pitch.
Pin Definition: JP2
Pin NO. Description
1 Battery 3.3V
2 RTCRST#
3 GND
◎ Reset Button:
Pin header 1x2 2.0 Pitch.
Pin Definition: JP1

EBC 340 User’s Manual 16
Pin NO. Description
1 RESET#
2 GND
◎ HDD Active LED:
Pin header 1x2 2.0 Pitch.
Pin Definition: JP3
Pin NO. Description
1 VCC5
2 HD_LED#
◎Power LED:
Pin header 1x2 2.0 Pitch.
Pin Definition: JP4
Pin NO. Description
1 VCC5
2 GND
◎ SMBus:
Pin header 1x2 2.0 Pitch.
Pin Definition: JP5
Pin NO. Description
1 SMB_DATA
2 SMB_CLK
◎ LAN Active LED
Pin header 1x2 2.0 Pitch.

EBC 340 User’s Manual 17
Pin Definition: JP6
Pin NO. Description
1 VCC3
2 LAN1_ACTLED#
◎ LAN Link LED
Pin header 1x2 2.0 Pitch.
Pin Definition: JP7
Pin NO. Description
1 VCC3
2 LAN1_LINKLED#
◎P/S 2 Keyboard / Mouse
Pin header 2x4 2.54 Pitch.
Pin Definition: JP9
KM1 FOR KEYBOARD/ MOUSE:
Pin NO. Description Pin NO. Description
1 VCC5 2 VCC5
3 KB_DATA 4 LM_DATA
5 KB_CLK 6 LM_CLK
7 GND 8 GND

EBC 340 User’s Manual 18
◎ PCI104 Connector
A. Connector size: 4X30 pin
B. Connector location: CN1
C. Connector pin definition：
Pin Signal Pin Signal
PA1 GND PC1 VCC5
PA2 VIO PC2 PCI_AD1
PA3 PCI_AD5 PC3 PCI_AD4
PA4 PCI_CBE#0 PC4 GND
PA5 GND PC5 PCI_AD8
PA6 PCI_AD11 PC6 PCI_AD10
PA7 PCI_AD14 PC7 GND
PA8 VCC3 PC8 PCI_AD15
PA9 PCI_SERR# PC9 NC
PA10 GND PC10 VCC3
PA11 PCI_STOP# PC11 PCI_LOCK#
PA12 VCC3 PC12 GND
PA13 PCI_FRAME# PC13 PCI_IRDY#
PA14 GND PC14 VCC3
PA15 PCI_AD18 PC15 PCI_AD17
PA16 PCI_AD21 PC16 GND
PA17 VCC3 PC17 PCI_AD22
PA18 PCI_104_IDSEL0 PC18 PCI_104_IDSEL
1
PA19 PCI_AD24 PC19 VIO
PA20 GND PC20 PCI_AD25
PA21 PCI_AD29 PC21 PCI_AD26
PA22 VCC5 PC22 GND
PA23 PCI_REQ#2 PC23 PCI_REQ#3
PA24 GND PC24 VCC5
PA25 PCI_GNT#3 PC25 PCI_GNT#4
PA26 VCC5 PC26 GND
PA27 PCI_CLK2 PC27 PCI_CLK3

EBC 340 User’s Manual 19
PA28 GND PC28 VCC5
PA29 VCC12 PC29 PCI_IRQ#F
PA30 VCC12N PC30 PCI_GNT#5
PB1 NC PD1 PCI_AD0
PB2 PCI_AD2 PD2 VCC5
PB3 GND PD3 PCI_AD3
PB4 PCI_AD7 PD4 PCI_AD6
PB5 PCI_AD9 PD5 GND
PB6 VIO PD6 GND
PB7 PCI_AD13 PD7 PCI_AD12
PB8 PCI_CBE#1 PD8 VCC3
PB9 GND PD9 PCI_PAR
PB10 PCI_PERR# PD10 NC
PB11 VCC3 PD11 GND
PB12 PCI_TRDY# PD12 PCI_DEVSEL#
PB13 GND PD13 VCC3
PB14 PCI_AD16 PD14 PCI_CBE#2
PB15 VCC3 PD15 GND
PB16 PCI_AD20 PD16 PCI_AD19
PB17 PCI_AD23 PD17 VCC3
PB18 GND PD18 PCI_104_IDSEL
2
PB19 PCI_CBE#3 PD19 PCI_104_IDSEL
3
PB20 PCI_AD26 PD20 GND
PB21 VCC5 PD21 PCI_AD27
PB22 PCI_AD30 PD22 PCI_AD31
PB23 GND PD23 VIO
PB24 PCI_REQ#4 PD24 PCI_GNT#2
PB25 VIO PD25 GND
PB26 PCI_CLK0 PD26 PCI_CLK1
PB27 VCC5 PD27 GND
PB28 PCI_IRQ#H PD28 PCI_RST#
PB29 PCI_IRQ#E PD29 PCI_IRQ#G
PB30 PCI_REQ#5 PD30 GND
D. PCI routing :
AD20 : E F G H
AD21 : H E F G
AD22 : G H E F

EBC 340 User’s Manual 20
AD23 : F G H E
