Nexcom NPT-1500 User manual

1

Copyright 2011
All Rights Reserved
Manual Version 1.1
Part Number: NPT-1500
The information contained in this document is subject to changewithout notice.
We make no warranty of any kind with regard to this material, including, but not limited to, the
implied warranties of merchantability and fitness for a particular purpose. We shall not be liable
for errors contained herein or for incidental or consequential damages in connection with the
furnishing, performance, or use of this material.
This document contains proprietary information that is protected by copyright. All rights are
reserved. No part of this document may be photocopied, reproduced or translated to another
language without the prior written consent of the manufacturer.
TRADEMARK
Intel®, Atom™ brand are registered trademarks of Intel® Corporation.
Microsoft® and Windows® are registered trademarks of Microsoft
Corporation.
Other names and brands may be claimed as the property of others.

2

Safety
IMPORTANT SAFETY INSTRUCTIONS
1. To disconnect the machine from the electrical power supply, turn off the power
switch and remove the power cord plug from the wall socket.
The wall socket must be easily accessible and in close proximity to the machine.
2. Read these instructions carefully. Save these instructions for future reference.
3. Follow all warnings and instructions marked on the product.
4. Do not use this product near water.
5. Do not place this product on an unstable cart, stand, or table.
The product may fall, causing serious damage to the product.
6. Slots and openings in the cabinet and the back or bottom are provided for ventilation
to ensure reliable operation of the product and to protect it from overheating. These
openings must not be blocked or covered.
The openings should never be blocked by placing the product on a bed, sofa, rug, or
other similar surface. This product should never be placed near or over a radiator or
heat register or in a built-in installation unlessproper ventilation is provided.
7. This product should be operated from the type of power indicated on the marking
label. If you are not sure of the type of power available, consult your dealer or local
power company.
8. Do not allow anything to rest on the power cord. Do not locate this product where
persons will walk on the cord.
9. Never push objects of any kind into this product through cabinet slots as they may
touch dangerous voltage points or short out parts that could result in a fire or electric
shock.
Never spill liquid of any kind on the product.

3

CE MARK.
This device complies with the requirements of the EEC directive
2004/108/EC with regard to “Electromagnetic compatibility” and
2006/95/EC “Low Voltage Directive”
This device complies with part 15 of the FCC rules. Operation is subject
to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including
interference that may cause undesired operation.
CAUTION ON LITHIUM BATTERIES
There is a danger of explosion if the battery is replaced incorrectly.
Replace only with the same or equivalent type recommended by the manufacturer.
Discard used batteries according to the manufacturer’s instructions.
LEGISLATION AND WEEE SYMBOL
2002/96/EC Waste Electrical and Electronic Equipment Directive on the treatment,
collection, recycling and disposal of electric and electronic devices and their
components.
The crossed dustbin symbol on the device means that it should not be disposed of
with other household wastes at the end of its working life. Instead, the device should
be taken to the waste collection centers for activation of the treatment, collection,
recycling and disposal procedure.
To prevent possible harm to the environment or human health from
uncontrolled waste disposal, please separate this from other types
of wastes and recycle it responsibly to promote the sustainable
reuse of material resources.
Household users should contact either the retailer where they
purchased this product, or their local government office, for details
of where and how they can take this item for environmentally safe
recycling.
Business users should contact their supplier and check the terms
and conditions of the purchase contract.
This product should not be mixed with other commercial wastes for disposal.

4

Revision History
Changes to the original user manual are listed below:
VersionDateDescription
1.0Mar. 2011Initial release
1.1 Jul. 2011 Change power adapter and COM5, COM6



5

Table of Contents
1. Package Checklist……………................................................................. 1
1-1 Standard items…………………………………………………………………… 1
1-2 Optional items……………………………………………………………………. 1
2. System View…………………………………………………………………... 2
3. System Assembly & Disassembly………………………………………… 4
3-1 Replace the HDD…………………………………………………………………... 4
3-2 Replace the Motherboard…………………………………………………………. 5
3-3 Replace the Inverter Board & Touch Board…………………………………... 6
4. Specification………………………………………………………………….. 7
5. Jumper Settings……………………………………………………………… 9
5-1 NP-D5250 Motherboard Layout………………………………………………….. 9
5-2 Connectors Description…………………………………………………………… 10
5-3 Jumper Settings……………………………………………………………………. 11
5-4 Install a Cash Drawer……………………………………………………………… 12
6. BIOS Settings…………………………………………………………………. 13
6-1 Entering Setup …………………………………………………………………….. 13
6-2 The Main Menu…………………………………………………………………….. 13
6-3 Main Features……………………………………………………………………… 14
6-4 Advanced Features………………………………………………………………... 15
6-5 Boot Settings……………………………………………………………………….. 22
6-6 Chipset……………………………………………………………………………… 26
6-7 PCIPnP………………………………………………………………………………… 29
6-8 Security Settings…………………………………………………………………… 30
6-9 Exit Options………………………………………………………………………… 31
Appendix…………………………………………………………………………. 33

1

1. Package Checklist
1-1 Standard items
1-2 Optional items
a. Systemb. power adapter
b. MSRa. Second Display c. VFD
d. driver bank /
e-User Manual
e. power cord

2

2. System View
No.Description
8SystemBox(InsidewithMothboard)
9Power Button
10Power LED
11Hinge Cover
No.Description
1Touch Screen
2MSR/2-in-1 MSR (Option)
3Stand
4Cables outlet
5Avoid cover the vents
6Model No. Label
7OS License Label
Top View
Front View Rear View
Side View

3

No.Description
1DC 12V IN
2Cash Drawer Port
3USB (x4)
4LAN (10/100/1000)
5COM(x4)
62nd VGA
7DC 12V OUT
82.5 HDD
9Parallel port
10Line OUT
Rear I/O View

4

3. System Assembly & Disassembly
3-1 Replace the HDD
a. Unfasten the screws (x2) to remove the HDD cover.
b. Disconnect the HDD Cable and take out the HDD with HDD metal bracket.
c. Unfasten
c. Unfasten the screws (x4) at both sides of HDD metal bracket.
d. Slide out the HDD from the HDD metal bracket and replace the HDD.


5

3-2 Replace the Motherboard
To replace the motherboard, please follow the below steps:
(1) Disconnect the HDD cable from the motherboard (Chapter 3-1, step a,b)
(2) Open the system box to access the motherboard (See below)

a. Unfasten the screws(x8) on the back of system box.
b. Press the Front bezel then separate top and bottom chassis(L1、L2、L3).
c. Remove the LCD rear cover.

d. Unfasten the screw(x8) fixing the motherboard and heatsink.
e. Unfasten the screw(x4) fixing the motherboard.
f. cable unplug out the motherboard with metal I/O bracket.







6

3-3 Replace the Inverter Board & Touch Board:
3-3-1 Replace the Inverter Board
a. The location of Inverter board on the LCD sheet metal bracket.
b. Unfasten the screws (x2).
c. Disconnect the cables (x3).
3-3-2 Replace the Touch Board:
a. The location of touch board on the LCD sheet metal bracket.
b. Unfasten the screws (x2).
c. Disconnect the cables (x2).

7

4. Specification
Model Name NPT-1500
Motherboard NP-D5250 / NP-D4250
Processor Default: Intel® Atom D525 Dual-Core Processor, 1.8GHz, 1M L2 Cache;
Optional: Intel® Atom D425 Single-Core Processor, 1.8GHz, 512KB L2 Cache
Chipset Intel® ICH8M, NH82801HBM I/O Control Hub
System Memory Default: 1 x SO-DIMM DDR3 1GB; Optional: 1 x SO-DIMM DDR3 2GB
Graphic Memory Integrated Intel® Graphics Media Accelerator 3150, share system memory
maximum from 256MB to 384MB
LCD / Touch Panel
LCD Size 15” TFT XGA (1024x768) 250cd/m² LCD panel
Touch Screen 15" 5-wire Resistive Touch panel
Tilt Angle 0° ~ 70°
Storage Device
Hard Drive 1 x 2.5" SATA HDD 160GB 5,400rpm, Removable type
Expansion
mini-PCIe 1 x mini-Card slot (mini-PCIe / USB)
Rear I/O
Serial port 4 x RS-232
USB port 4 x USB 2.0
Parallel port 1 x Parallel
LAN Port 1 x RJ-45 (10/100/1000Mbps Ethernet)
VGA 1 x VGA
Cash Drawer Port 1 x RJ-11, support 2 cash drawers (24V, Max 1.1A)
DC Jack 1 x 12V-IN
DC-OUT Jack 1 x 12V-OUT for 2nd Display Power
Line-OUT 1 x Line-OUT for Audio
Audio
System Buzzer 1 x System Buzzer
Internal Speaker 1 x 3W Speaker
System Control/ Indicator
Power Switch 1 x Power ON/OFF switch
Power LED 1 x Power ON LED (Green)
Power
Power Supply External AC-DC 12V/96W or 100W Power Brick

8

Peripheral (Optional)
MSR ISO 3 Tracks MSR (USB or PS/2)
Customer Display 2 x 20 VFD customer display
2nd Display 15" LCD monitor
Certificate
EMC & Safety FCC Class A / CE / LVD
Environment
Operating Temperature 0°C ~ 40°C (32°F ~ 104°F)
Storage Temperature -20°C ~ 60°C (-4°F ~ 140°F)
Operating Humidity 20% - 80% RH non-condensing
Storage Humidity 20% - 85% RH non-condensing
Dimension
70° tilt angle 355(W) x 290(H) x 230(D) mm
0° tilt angle 355(W) x 210(H) x 300(D) mm
Display Head 355(W) x 290(H) x 78(D) mm
Footprint 270(W) x 215(D) mm
Package Size 490 x 350 x 400mm
Weight
Net Weight 7.0kg (15.4lbs)
Gross Weight 8.5kg (17.8lbs)
OS Support
Windows POSReady 2009, Win 7 Pro, XP Pro, Win CE 6.0.
Linux 2.6 / 2.4 (Ubuntu, SuSE, CENTOS, Fedora)

9

5. Jumper Settings
5-1 NP-D5250 Motherboard Layout

10

5-2 Connectors Description
Connector Purpose Connector Purpose
CN1 COM5 CN2 LVDS CON 24bit
CN3 COM6 CN4 LVDS CON 18bit
CN5 MINI PCI-E CN6 AUDIO (Line out and MIC IN)
CN7 Parallel Interface CN8 COM4
CN9A COM3 Connector CN9B VGA Connector
CN10 DC-Power Input Connector
COM1A COM1 Connector COM1B COM2 Connector
CON1 MSR CONN CON3 DC-Power Output Connector
CON4 LAN+USBx2 Connector CON5 RJ11 Connector
J1 INV18 1x5 JST Connector J4 SATA Power Connector
J5 JST USB Connector J7 JST USB Connector.
J9 HW RESET SW J10 KB Connector
J11 SPEAK OUT J12 POWER SW
J14 TOUCH Connector
JP5 LED Connector

11

5-3 Jumper Settings
Panel Power selection:JP1
Function JP1 (1-2) (2-3)
◎3V
5V
◎Default setting 1-2 short.
CMOS CLEAR SIGNAL: JP2
Function JP1 (1-2) (2-3)
◎NORMAL
CLEAR CMOS
◎Default setting 1-2 short.
Note:

12

5-4 Install a Cash Drawer
You can install a cash drawer through the cash drawer port. Please verify the pin
assignment before installation.
Pin Signal
1 CASEOPEN2#
2 CASH1_P
3 CASEOPEN#
4 24V
5 CASH2_P
6 GND
Cash Drawer Controller Register
The Cash Drawer Controller use one I/O addresses to control the Cash Drawer.
Cash Drawer Pin Assignment

13

6. BIOS Settings
This chapter explains how to use the BIOS Setup program for the NPT-1500. The current
BIOS setup pictures in the chapter are for reference only, which may change by the BIOS
modification in the future. User can download any major updated items or reversion from
NEXCOM web site http://www.nexcom.com.tw. If any unclear message occurs, please
contact NEXCOM customer service representative for help.
When the BIOS Main Menu is displayed, the following items can be selected.
Use the arrow keys to select items and the Enter key to accept and enter the sub-menu.
6-1 Entering Setup
Power on the computer and press <Del> immediately will allow you to enter Setup.The other
way to enter Setup is to power on the computer, when the below message appears briefly at
the bottom of the screen during the POST (Power On Self Test), press <Del> key.
6-2 The Main Menu
Once you enter Award BIOS CMOS Setup Utility, the Main Menu will appear on the screen.
The Main Menu allows you to select from ten setup functions and two exit choices. Use
arrow keys to select among the items and press <Enter> to accept or enter the sub-menu.
※Note: The BIOS setup menus shown in this section are for reference only and may

14

not exactly match the items of your BIOS version.
6-3 Main Features
Use this menu for basic system configuration.
