Next Century LS4 Quick start guide

[email protected]
www.nextcenturymeters.com
V. 051222
LS4 Leak Sensor
Wireless Leak Sensor
Operation and Installation Guide
1| Product Overview
The LS4 Leak Sensor introduces advanced water
detection and alerting to the NextCentury platform.
Featuring LeakSense+™ technology, the LS4
protects against costly water damage claims and
repairs.
2| Technical Specifications
2.1 – Certifications
FCC: 2AB8I-LS4 IC: 20949-LS4
2.2 – Wireless Communication
• Two-way NextCentury RF Connect™
• 902-928 MHz Unlicensed Band
2.3 – Sense Cable Options
• Connect additional Sense Cables on to each other
to extend detection area (additional Sense Cables
sold separately)
• Up to 12’ of Sense Cable length
2.4 – In-Field Setup
• Simple programming and verification using mobile
app
2.5 – Battery
• Preinstalled, field-replaceable CR18505
• Estimated 10-year battery life*
*Note: 10-year battery estimated with operating temperatures
between 60ºF-90ºF, and 6-hr device check-in. Achieved battery
life can be greater or less than 10 years depending on the meter
type, system configuration, and lifetime operating temperature.
2.6 – Dimensions
• 3.3in x 1.8in x 1.3in (84mm x 46mm x 33mm)
2.7 – Operation Environment:
• -20°C to 60°C (-4°F to 140°F )
• Indoor installation
4| Package Contents
A – LS4 Leak Sensor
B – Sense Cable
C - Mounting Plate
D – Mounting screws & anchors
4| In-Field Installation
4.1 – Mounting Plate Installation
• Peel off backing on the included adhesive pad and mount
onto the wall
• (Optional) For additional holding strength, the included
screws and plastic anchors can be used. Pre-drill using a
7/32” (5.5mm) drill bit

[email protected]
www.nextcenturymeters.com
V. 051222
4.2 – Cable Connection
• Connect the Sense Cable into the LS4
• An audible chime will confirm the connection
4.3 – Leak Sense Zone
• Lay out the Sense Cable under the appliance or water
system and secure
5| LED Indicators
The LS4 features two separate LED indicators with simple color-
coded feedback.
9| Programming & Wireless Check-In
9.1 – Property Setup
The NextCentury website or NCSS mobile app can be used to set
up and configure the property, units, and meters. Visit
support.nextcenturymeters.com for additional property setup
details.
9.2 – Programming
Property programming is the process of associating Leak Sensor
serial numbers to the meters they are reading. Scan the barcode
to ensure the serial number is entered accurately.
9.3 – Gateway Device Management
After programming, the connected Gateway will automatically
sync and communicate with the LS4.
9.4 – Wireless Connection LED Indicators
The RF LED indicator provides feedback to easily check that the
LS4 is within range of the property’s Gateway (either directly, or
through Repeaters)
• Tap the Test Connect button
• The LS4 RF LED will rapidly blink red, indicating it is
transmitting
• The RF LED will then blink 2x green if a response is
received from the Gateway
9.5 – Wireless Troubleshooting
If the RF LED does not blink green after tapping the Test Connect
button, then the LS4 is not receiving a response from the
Gateway. The following steps can help identify the issue:
• If the LS4 does not blink green, even when close to the
Gateway, make sure it has been programmed to the
property and the Gateway is online
• Try multiple times—if eventually a response is received,
then an additional Repeater may be needed to improve
the wireless network
• Move the LS4 closer to the Gateway or nearest
Repeater. If a response is received, then an additional
Repeater may be needed
10| Advanced Features &
Troubleshooting
Visit support.nextcenturymeters.com for additional guides and
troubleshooting information.

[email protected]
www.nextcenturymeters.com
V. 051222
11| Television and Radio Interference
NOTE: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more ofthe following
measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for
help.
The FCC requires the user to be notified that any changes or
modifications made to this device that are not expressly
approved by Company Name may void the user’s authority to
operate the equipment.
Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set
forth for an uncontrolled environment. This equipment should
be installed and operated with minimum distance 20cm between
the radiator & your body.
As per 47 CFR §15.19
(All other devices shall bear the following statement in a
conspicuous location on the device:
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
As per 47 CFR §15.21
The user’s manual or instruction manual for an intentional or
unintentional radiator shall caution the user that changes or
modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the
equipment. In cases where the manual is provided only in a form
other than paper, such as on a computer disk or over the
Internet, the information required by this section may be
included in the manual in that alternative form, provided the
user can reasonably be expected to have the capability to access
information in that form.
ISED Statement
This radio transmitter (identify the device by certification
number)
has been approved by Industry Canada to operate with the
antenna
types listed below with the maximum permissible gain indicated.
Antenna types not included in this list, having a gain greater than
the
maximum gain indicated for that type, are strictly prohibited for
use
with this device.
Immediately following the above notice, the manufacturer shall
provide a list of all antenna types approved for use with the
transmitter, indicating the maximum permissible antenna gain
(in dBi).
8.4 User Manual Notice for Licence-Exempt Radio Apparatus
User manuals for license-exempt radio apparatus shall contain
the following text, or an equivalent notice that shall be displayed
in a conspicuous location, either in the user manual or on the
device, or both:
This device complies with Innovation, Science and Economic
Development Canada’s licence-exempt RSSs. Operation is
subject to
the following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including
interference
that may cause undesired operation of the device.
Cet appareil est conforme aux flux RSS exemptés de licence
d'Innovation, Science et Développement économique Canada.
L'opération est soumise aux deux conditions suivantes:
(1) Cet appareil ne doit pas provoquer d'interférence; et
(2) Cet appareil doit accepter toute interférence, y compris les
interférences susceptibles de provoquer un fonctionnement
indésirable de l'appareil.
--------------------------
ISEDC Radiation Exposure Statement
[English] Radiation Exposure Statement: This equipment
complies with the IC RSS-102 radiation exposure limits set forth
for an uncontrolled environment. This equipment should be
installed and operated with a minimum distance of 20 cm
between the radiator and your body.
[French] Énoncé d'exposition aux rayonnements: Cet
équipement est conforme aux limites d'exposition aux
rayonnements ioniques RSS-102 Pour un environnement
incontrôlé. Cet équipement doit être installé et utilisé avec un
Distance minimale de 20 cm entre le radiateur et votre corps.

[email protected]
www.nextcenturymeters.com
V. 051222
13| Warranty/Disclaimer Scope of
Warranty
NextCentury warrants that all communication equipment manufactured
by NextCentury will be free from defects in materials and workmanship
under normal use and in accordance with NextCentury’s documented
installation and operating procedures for a period of three (3) years from
the date of manufacture.
Products not manufactured by NextCentury, including without
limitation, accessories, attachments, meters, or batteries used in
conjunction with NextCentury equipment are warranted, if at all, only
by the original manufacturer. NextCentury’s warranties do not include
replacement of batteries used to power NextCentury products.
Limits of Liability
This warranty only applies to Read Management System components
produced by NextCentury, and does not cover any products which have
been damaged by misconduct, negligence, vandalism, acts of God,
excessive operating conditions, or unauthorized attachments or
modifications. This warranty will be null and void if products are placed in
non-recommended installation application/fashion, or are converted,
altered, or treated by other than NextCentury recommended procedures
and instructions, or are read by equipment not approved by NextCentury.
NextCentury’s liability and customer’s exclusive remedy under this
warranty is expressly limited to repair or replacement of the product at
NextCentury’s option, and is conditioned upon the customer returning
the product(s) to the location designated by NextCentury within the
warranty periods or limits stated herein, and pre-paying the freight costs
both to and from the specified location. In no event shall NextCentury be
liable for costs or expenses associated with the removal or installation of
products under this warranty.
NextCentury shall have no liability or responsibility to the purchaser or
any third party for any loss, cost, expense, damage, or liability, whether
direct or indirect, or for special, incidental, indirect, or consequential
damages of any kind, regardless of whether such liability is based on
breach of contract, tort, strict liability, breach of warranties, or otherwise,
and even if advised of the likelihood of such damages. Incidental and
consequential damages include, but are not limited to, lost revenue, loss
of profits, data, business, or goodwill. In addition, damages resulting from
negligence on the part of the customer, including, but not limited to, the
care and maintenance of NextCentury products or damages resulting
from negligence regarding periodic testing of the product’s performance,
are not covered under this guarantee.
CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY
NEXTCENTURY MAY VOID THIS WARRANTY AND THE USER’S
AUTHORITY TO OPERATE THE EQUIPMENT.
THE FOREGOING WARRANTY IS THE SOLE AND EXCLUSIVE REMEDY
AVAILABLE TO THE PURCHASER AND IS IN LIEU OF ALL OTHER
WARRANTIES, GUARANTEES, OR REMEDIES, WHETHER WRITTEN
OR ORAL, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION,
THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE, ALL OF WHICH NEXTCENTURY
HEREBY EXPRESSLY DISCLAIMS.
Due to updated regulations and product improvements, NextCentury
Submetering Systems, LLC reserves the right to change the product
specifications without notice.
14| Contact Information
For any questions or concerns, please contact NextCentury
Submetering Solutions Product Support:
• Phone: [phone]
• Email: [email protected]
