CAILIN CONSOLE
378891
Assembly instructions
Actual product size
H81 x W94 x D34.5cm 
Need Help ?
With: Assembly instruction 
Missing or damaged parts 
IMPORTANT - RETAIN FOR FUTURE REFERENCE
CALL: 0333 777 8999
Produced in China for Next Retail Ltd.
378891-2022-V2.

CAILIN CONSOLE
378891
Assembly instructions
BEFORE YOU START
Produced in China for Next Retail Ltd.
378891-2022-V2.
1
30
● If broken, it is designed to break safely and shatter into many small pieces rather than large shards. However, please note that the
● Safety glass is stronger than regular glass to better withstand the wear and tear of everyday use, but some basic precautions need to
●
●Unwrap all packaging materials and place the components on a clean surface to protect it from damage,we recommend that the
●Carefully check that you have all the parts before begining assembly.
●Due to the size of this product we recomement that it is assembled in the room intended for use.
●Ensure the product is fully assembled as illustrated and all fixings fully tightened before use.
●
●
●Strike the glass with hard or pointed objects.
●Sunlight reflecting from the glass surface can reflect onto other surfaces in your home, so if you have items likely to be affected by
Do's
●
Always use a coaster or table mat to protect the glass from very hot or cold cups, glasses or plates etc.
Take care when placing items on the glass surface so as not to damage it.
Take particular care not to damage the edge of the glass surface - this type of damage can cause the whole panel to shatter. If you
notice damage on the edge of the glass, contact a local glazier for advice.
●
●
Don'ts
●
●
●
Do not drag or pull your furniture.
Place heavy items on the glass surface
Position the unit near direct heat (e.g. in front of a radiator or other strong heat source) as this can cause internal stress in the glass
and cause it to shatter.
Use it as a chopping board.
If the glass will be in direct sunlight, ensure that drops of liquid etc are removed as they can focus the sun’s light and cause damage
to your furnishings.
this, please ensure you position them accordingly, or shade the sunlight as required.
This product contains Safety glass (also known as Toughened glass).
IMPORTANT INFORMATION
●
edges of these pieces can still be sharp, so care is needed when handling them.
be taken to prolong its life.
We suggest you sepend a short time reading through this leaflet before you start.
When you are ready to start, make sure that you have the right tools and plenty of space.
packaging is used to protect the surfaces during assembly.
To clean the glass, use a proprietary glass cleaner and a soft cloth. Do not use abrasive cleaners as they can damage the finish of the
glass.
CARE INSTRUCTIONS
●
●

CAILIN CONSOLE
378891
Assembly instructions
GETTING TO KNOW YOUR PRODUCT
Produced in China for Next Retail Ltd.
378891-2022-V2.
2
10
2
3
4
1
9
8
7
6
5

CAILIN CONSOLE
378891
Assembly instructions
Components supplied. Please use this guide if you require replacement parts.
RefDimensionsVisualQty tnC
1 80 x34.1cm 1 1
2 80 x 34.1cm 1 1
3 89.6 x 4cm 1 1
4 89.6 x 4cm 1 1
5 89.6 x 4cm 1 1
6 40.4 x 2cm 1 1
7 40.4 x 2cm 1 1
8 82 x 2cm 1 1
9 82 x 2cm 1 1
10 94 x 34.5cm 1 1
Produced in China for Next Retail Ltd.
378891-2022-V2.
3

CAILIN CONSOLE
378891
Assembly instructions
Fixtures and fittings
supplied (actual size)

RefDimensionsQty
Spare Qty
A Ø6 x10mm 26 2
B Ø16 x 2mm 4 1
Fixtures and fittings supplied ( not to scale) 
Ref Dimensions Qty
Spare Qty
Visual
C 4mm 1 N/A
D 50 x 25 x 17mm 2 N/A
Produced in China for Next Retail Ltd.
378891-2022-V2.
4

CAILIN CONSOLE
378891
Assembly instructions
1
A Ø6 x10mm 6
2
A Ø6 x10mm 6
Produced in China for Next Retail Ltd.
378891-2022-V2.
5
Bolts should be slightly loose,
fully tighten them at step five.
Bolts should be slightly loose,
fully tighten them at step five.
A
34C
5
1
Screw hole is facing outward.
2A
C
4
3
5

CAILIN CONSOLE
378891
Assembly instructions
3
A Ø6 x10mm 8
4
A  Ø6 x10mm  4 Bolts should be slightly loose,
fully tighten them at step five.
B Ø16 x 2mm 4
Produced in China for Next Retail Ltd.
378891-2022-V2.
6
Bolts should be slightly loose,
fully tighten them at step five.
8
C
6
1
A
5
9
27
C
A
B
4
3
10

CAILIN CONSOLE
378891
Assembly instructions
5
C
6
A  Ø6 x10mm  2 
D 50 x25 x17mm 2
Produced in China for Next Retail Ltd.
378891-2022-V2.
7
Fully tighten all bolts from
step one to step four.
C
C
4
A
D

CAILIN CONSOLE
378891
Assembly instructions
7
8
Produced in China for Next Retail Ltd.
378891-2022-V2.
8
