Next NEWHAVEN ROBE 729440 User manual

Assembly instructions
IMPORTANT- RETAIN FOR FUTURE REFERENCE CALL: 0333 777 8999
Produced in Poland for Next Retail Ltd.
With: Assembly instructions
Missing or damaged parts
Need Help?
NEWHAVEN ROBE
729440
P9IWNH82
729440-2014-V1
Actual product size
H192 x W93 x D62 cm

PH2
1
BEFORE YOU START
Warnings
Do’s
Don’ts
We suggest you retain these instructions for future reference.
Keep fittings out of children’s reach and keep children well
away from the construction area.
This product should only be used on firm, level ground.
Please periodically check all fittings and re-tighten as
necessary.
Please do not sit or stand on your furniture.
Avoid exposing the furniture to excessive heat or direct
sunlight as this can cause deterioration of the colour.
Unwrap all packaging materials and place the components
on top of the carton box or on a clean floor to protect it from
damage.
We suggest you spend a short time reading through this leaflet
before you start.
When you are ready to start, make sure that you have the
right tools and plenty of space.
Unwrap all packaging materials and place the components
on a clean surface to protect it from damage.
We recommend that the packaging is used to protect the
surfaces during assembly.
Carefully check that you have all the parts before beginning
assembly.
Due to the size of the product we recommend that it is
assembled in the room intended for use.
Ensure the product is fully assembled as illustrated and all
fixings are fully tightened before use.
Wipe occasionally with a soft cloth slightly dampened with
water. Then buff with a dry clean soft cloth.
Wood will mellow and change colour over time, we recommend
that ornaments and items placed on the surface are moved
regularly for the first few months to prevent uneven mellowing.
Do not drag or pull your furniture.
Do not use silicone based furniture polish. Silicone in furniture
polishes can break down the finish.
Never allow any kind of liquid to remain on your furniture.
Absorption can cause wood to warp or finishes to de-laminate.
Number of people required to assemble
Time to assemble
Two persons are required to assemble this item.
2.0 hours
Tools required
not supplied not supplied
Missing parts
Home service technicians
You can write to us at
If you are missing any fixtures and fittings for your product
please contact our customer service team on 0333 777 8999
and they will be happy to arrange for a replacement to be sent
to you free of charge.
If you have a fault with your product please contact our
customer service team on 0333 777 8999. If you have had the
product for 28 days or less you may be offered a replacement,
refund or for a fully trained home service technician to visit your
home to assess the fault and repair the product where possible.
If you have had the product for more than 28 days we will send
an independant home service technician to review and repair
the product where possible and recommend further action.
Home Customer Services
Next Retail Ltd,
Desford Road,
Leicester,
LE19 4AT
To View our full furniture range please visit www.next.co.uk
Produced in Poland for Next Retail Ltd.
2 person assembly
Assembly instructions
NEWHAVEN ROBE
729440
729440-2014-V1

GETTING TO KNOW YOUR PRODUCT
2
Produced in Poland for Next Retail Ltd.
Assembly instructions
11
13L
13R
12
14
10
1L
9L
2R
9R
3
5
4
6
7
8
NEWHAVEN ROBE
729440
729440-2014-V1

Components supplied. Please use this guide if you require replacement parts.
Ref Dimensions Visual Qty Ctn
1L 189,2x58 cm
189,2x58 cm
1 1
2R 1
1
2
2
377x56,2 cm
77x55,4 cm
171,5x39,2 cm
77x55,2 cm
77x6 cm
93x8 cm
62x8 cm
62x8 cm
147,1x38,1 cm
76,4x21,6 cm
72,1x17 cm
50,2x17 cm
50,2x17 cm
73,2x50 cm
1
1
1
1
2
1
1
1
1
1
1
1
2
2
2
2
2
1
2
1
1
1
1
2
4
5
6
7
8
9L
9R
10
11
12
13L
13R
14
1
1
GETTING TO KNOW YOUR PRODUCT
3
Produced in Poland for Next Retail Ltd.
Assembly instructions
NEWHAVEN ROBE
729440
729440-2014-V1

Fixtures and fittings
supplied (actual size)
4
Qty
Ref Dimensions
B1 8x28 mm 12
mm 10 20 30 40 50 60 70 80 90 100 110 120 130
Produced in Poland for Next Retail Ltd.
Assembly instructions
T1 12
M1 15x12 mm 12
+
5x39mm
R25 N/A 1
ATTACH TO DRAWER
ATTACH TO CARCASS
Qty
Ref Dimensions Visual
Y0
Y5
N/A
N/A
1
6
6
Fixtures and fittings supplied (not to scale)
J1N N/A
L1 N/A 1
U2N 4
N/A
F7
J20
N/A
N/A
N/A
2
1
P10 13
3,0x13mm
16
J23
P2 4
3,0x20mm
P7 7
4x40mm
W1
2
5x16mm
E24 6
6,0x11mm
S3 4
3,5x13mm
E3 12
6,3x13mm
S8 12
4x13mm
A18
A4
2
2
4,0x23mm
4,0x12mm
T21 2
5x32mm
M10 2
+
12x10mm
P5 2
4x30mm
G22 2
Ø15mm
NEWHAVEN ROBE
729440
729440-2014-V1
F33 N/A 3

5Produced in Poland for Next Retail Ltd.
1
2
Assembly instructions
SCREW IN CAM SCREWS
ONLY D O W N TO FIRST R I N G.
FLUSH
WITH
PANEL
+
M10
WHEN FITTING CAMS
ENSURE STARTING POSITION IS CORRECT
BEFORE YOU INSERT CONNECTING CAM-PILLAR
TURN CLOCKWISE UNTIL SECURE
WRONGCORRECT
+
12x10 mm
M10 x 2
+
T21 x 2
5x32mm
+
+
T21
11 12
13L
13R
11
13R
14
13L
12
12
13L
13R
NEWHAVEN ROBE
729440
729440-2014-V1
P5
14
L1
L1
GLUE
P5 x 2
4x30mm
+
+
L1 x 1

6Produced in Poland for Next Retail Ltd.
Assembly instructions
4
3
P10 x 6
A4x2
3,0x13mm
4,0x12mm
R25x1 Left / 1 Right
11
11
14
R25
P10
P10
U2N
A4
FRONT
BACK
S3
E24
R25
front
F7
S3
front
Y5
E3
1L
T1
T1 x 6
5x39mm
Y5 x 3
R25 x1 Left
6,3x13mm
S3 x 2
E24 x 3
F7 x 1
3,5x13mm
6,0x11mm
E3 x 6
NEWHAVEN ROBE
729440
729440-2014-V1
P10
F23
U2N x 2
F23 x 1

7Produced in Poland for Next Retail Ltd.
Assembly instructions
6
5
15x12 mm
M1 x 8
+
8x28 mm
B1 x 8
FRONT
FRONT FRONT
FRONT
BACK
F7
S3
front
Y5
E3
T1
S3
E24
R25
front
T1 x 6
5x39mm
Y5 x 3
R25 x1 Right
6,3x13mm
S3 x 2
E24 x 3
3,5x13mm
6,0x11mm
E3 x 6
2R
+
+
+
+
+
+
+
+
M1
B1
+
3
carefullylift the unit upright
W1
W1 x 2
5x16mm
4
4
F7 x 1
NEWHAVEN ROBE
729440
729440-2014-V1

8Produced in Poland for Next Retail Ltd.
Assembly instructions
7
8
15x12 mm
M1 x 4
+
8x28 mm
B1 x 4
FRONT
+
+
+
+
M1
B1
+
5
Produced in Poland for Next Retail Ltd.
7
NEWHAVEN ROBE
729440
729440-2014-V1
P10 x 3
F33 x 3
3,0x13mm
F33
P10
60mm
60mm

Assembly instructions
9
Produced in Poland for Next Retail Ltd.
9
10
S8
Y0
S8
U2N
A18
10
S8 x 12
Y0 x 6
A18 x 2
4x13mm
4x23mm
U2N x 2
+
+
NEWHAVEN ROBE
729440
729440-2014-V1
DO THIS STEP TWICE (2x)
FRONT
BACK
2R
5
4
3
+
+
+
+
+
+
+
