Next OXFORD 381155 User manual

Carefully check that you have all the parts before beginning assembly.
Helpline
Tools Needed
•We recommend that the packaging is used to protect the surfaces during assembly. We suggest you retain these instructions for future reference.
• Keep fittings out of children’s reach and keep children well away from construction area.
•
All you need to assemble this piece of
furniture is a flat and crosshead screwdriver
as well as a hammer
If you have any problems with this product or
require any replacement fittings please contact
Customer Services Tel: [phone]
(Not supplied)
•
•
Assembly Instructions
Please keep these instructions for future reference
Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the items
• A minimum of 2 persons is required to assemble this product.
are found to be faulty. Should you need to return the unassembled product, please repack in its original
packaging.
We suggest you spend a short time reading through this leaflet and then follow the simple step-by-step•
instructions.
Made with solid oak and oak veneer with a clear lacquer finish.•Natural features ensure that each piece is individual. Every effort is made to ensure colour continuity between•
pieces, however this is a natural product, slight colour variations and natural grain markings may occur.
Oak wood and veneers often have random pale markings in the grain, these are medullary rays which are a•
natural unique feature of this wood
Made in China.
1 of 9
381155 OXFORD KINGSIZE BED
Important
Product Information

A x 8
M8x65 B x 10 C x 8 D x 8 E x 1
F x 8 G x 2
4x30 4x20
10x40 35 M8
H x 28 J x 14 K x 2
15x12
L x 2
6x44
Avoid exposing the furniture to excessive heat or direct sunlight as this can cause cracking•
of the wood and deterioration of the colour.
Periodically dust lightly with a soft cloth.•Any spills should be removed immediately with a damp cloth.•Do not use silicone based furniture polish.•Ensure that the product is protected with mats & coasters when items are placed on to its surface.•
Never put hot dishes directly onto wooden or glass surfaces as this may mark the furniture.
Wood will mellow and change colour over time, we recommend that ornaments and items placed on•
the surface are moved regularly for the first few months to prevent uneven mellowing.
Take care when moving the furniture and never drag the pieces across the floor, as this will cause•
damage to the joints.
Periodically check fittings are secure and re-tighten as necessary.•
2 of 9
Care Instructions
Fittings

3 of 9
1
2
3
3
4
5
5
5
6
6
7
7
8
8
PACK PANELS LIST
1 - 2 1x 1
2
3
4
6
7x 1
x 2
x 1
x 2
x 2
PACK PANELS LIST
2 - 2
5x 3 8 x 2
Parts

A
46mm
(Assemble on a flat and even surface)
Insert bolts (A) into panel (1) by hand.•
Attach block (6) to panel (1) and tighten with screws (F).•
Insert bolts (A) into panel (2) by hand.•
Attach block (6) to panel (2) and tighten with screws (F).•
Ax4
Fx4
Ax4
Fx4
1
6
4 of 9
2
6
A
46mm
Step One
Step Two

5 of 9
1
2
3
3
Insert dowels (B) into panels (3) with a hammer.•
Attach panels (3) to panels (1) and (2), insert half moon washers (C) and nuts (D)•
into panels (3) and tighten with spanner (E).
Bx8
Dx8
Cx8
Ex1
3x2
Step Three
Step Four

Gx2
Attach feet (5) to panel (4), rotate clockwise to tighten.•
Attach panel (4) to the bed and tighten with screws (G).•
4
5
4
6 of 9
4
5
5
5
Step Five
Step Six

5mm
7 of 9
Attach plastic ends (H) and (J) to slats (7).•
IMPORTANT
Once the feet have been assembled and attached, they should be adjusted to ensure
they do not touch the floor, (5mm above the floor) to allow for movement once the
mattress is placed on the bed frame.
It is important to note that when moving the bed that it is not dragged into its new
position to prevent the possibility of these feet being twisted or angled to one side,
which could lead to the collapse of the centre of the bed.
To move the bed, remove the mattress and lift the bed into its new position to avoid
damage.
Ensure the feet are at 90 to the floor before replacing the mattress.
5
7
Hx28
7
Jx14 H
Step Seven
Step Eight

Attach slats (7) to the body of bed. Ensure each cap is pushed firmly in place and•
ensure the curve of the slat is facing upwards.
Insert cam bolts (L) into parts (8), tighten with a screwdriver.•
Insert dowels (B) into parts (8) with a hammer.•
Lx2
Bx2
8x2
7
7
8 of 9
Step Nine
Step Ten

9 of 9
8
8
1
Attach parts (8) to panel (1), insert cam locks (K) and tighten with a screwdriver.•
PLEASE KEEP THIS CARE GUIDE FOR FUTURE REFERENCE
Next Retail Ltd, Desford Road, Enderby, Leicester, LE19 4AT.
Kx2
Step Eleven
