Nextel iR1200 GPS User manual
iR1200 Data Modem
Installation Guide
Draft Version 1.1
April 17, 2003
Table of Contents
2
Table of Contents
Table of Contents...............................................................................................................2
Safety Notice.......................................................................................................................5
Safe and Efficient Operation Guidelines .........................................................................5
Exposure to Radio Frequency Energy .............................................................................5
Medical and Personal Electronic Devices .......................................................................5
Pacemakers......................................................................................................................5
Hearing Aids....................................................................................................................5
Other Medical Devices ....................................................................................................6
Interference to Other Electronic Devices ........................................................................6
FCC Regulation.................................................................................................................7
Introduction........................................................................................................................8
Welcome to NexteliR1200 Data Modem......................................................................8
Using This Guide.........................................................................................................8
NextelCoverage........................................................................................................8
NextelCustomer Care...............................................................................................8
Overview...........................................................................................................................10
General Overview..........................................................................................................10
Modem Operating Modes..............................................................................................12
Installation Procedures...................................................................................................13
Before You Start Installing............................................................................................13
Installation Tools .......................................................................................................13
Vehicle Installation..........................................................................................................14
iR1200
3
Mounting the Modem....................................................................................................14
AntennaMounting.........................................................................................................15
Antenna Installation Considerations.........................................................................15
Mounting Modem Antenna ........................................................................................16
Mounting GPS Antenna (optional)............................................................................17
Power Cable Installation................................................................................................17
Wiring Diagram.........................................................................................................18
Ignition Cable Installation .............................................................................................19
Modem Data Cable Installation.....................................................................................20
GPS (optional) Data Cable Installation .........................................................................20
Stationary Installation.....................................................................................................21
Mounting the Modem....................................................................................................21
AntennaMounting.........................................................................................................22
Antenna Installation Considerations.........................................................................22
Mounting Modem Antenna ........................................................................................23
Mounting GPS Antenna (optional)............................................................................24
Power Cable Installation................................................................................................24
Modem Data Cable Installation.....................................................................................25
GPS (optional) Data Cable Installation .........................................................................25
Verifying Installation.......................................................................................................26
Powering Up the Modem...............................................................................................26
Powering Up –Vehicle Installation ..........................................................................26
Powering Up –Building Installation.........................................................................26
Communication Indicators.............................................................................................27
LED Status Indicators....................................................................................................28
Troubleshooting...............................................................................................................29
Common Problems ........................................................................................................29
Table of Contents
4
HyperTerminal...............................................................................................................30
Setting up HyperTerminal..........................................................................................30
Diagnostic Menu........................................................................................................32
TechnicalSupport............................................................................................................36
Customer Care Support Line.........................................................................................36
Nextel Online (nextel.com) ...........................................................................................36
Appendix A: Accessories.................................................................................................37
Appendix B: Glossary......................................................................................................38
Safety Notice
5
Safety Notice
The following is important information for safe and efficient operation of
the iR1200 modem. We recommend that all users read this information
before using the modem.
Safe and Efficient Operation Guidelines
Your modem contains a transmitter and receiver. When it is ON, it receives and transmits
radio frequency (RF) energy. The modem operates in the frequency range of 806 MHz to
870 MHz and utilizes the digital modulation techniques. This product is authorized by
FCC Rule Part 47CFR2.1091 (b) which states that it should be used in such a way that it
maintains a distance of at least 8 inches (20 cms) between the radio’s antenna and the
human body. When you use your modem, the system handling your call, controls the
power level at which your modem transmits. The output power level typically may vary
over a range from 600 mW .
Exposure to Radio Frequency Energy
Your modem is designed to comply with the United States Federal Communications
Commission, Code of Federal Regulations; 47 CFR part 2 sub-part J. The modem is in
compliance with FCC’s national standards and guidelines regarding exposure of human
beings to radio frequency electromagnetic energy:
Medical and Personal Electronic Devices
Most electronic equipment are protected from RF energy. However, certain equipment
may not be shielded against the RF signals being emitted from your modem.
Pacemakers
Operators should not use the modem if individuals with pacemakers are within 6 inches
(0.15 meters) of the antenna.
Hearing Aids
The modem may cause interference with hearing aid devices. Individuals who experience
such interference should consult the hearing aid manufacturer to discuss alternative
solutions.
iR1200Modem
6
Other Medical Devices
Individuals who have other medical devices not specifically mentioned in this chapter
may want to consult their physician or the manufacturer of the device to determine if it is
adequately protected from external RF energy.
Interference to Other Electronic Devices
RF energy may affect improperly installed or inadequately protected electronic operating
and entertainment systems in motor vehicles. Check with the manufacturer or
representative to determine if these systems are adequately shielded from external RF
energy. It is recommended that you also check with the manufacturer of any equipment
that has been added to the vehicle.
Safety Notice
7
FCC Regulation
Introduction
8
Introduction
Welcome to NexteliR1200 Data Modem
Thank you for purchasing the Nextel iR1200 Data modem. This modem was designed to
work specifically within the iDENnetwork. Once installed and configured, it provides
you with wireless data communications.
NOTE: Nextel does not warrant or guarantee that data transmitted is accurate,
complete, or free from errors, mistakes, omissions, any delays or
interruptions of the data or information stream from any cause.
This chapter includes:
Using This Guide Page 5
NextelCoverage Page 5
NextelCustomer Care Information Page 5
Using This Guide
This guide provides instructions for the installation of the iR1200 Rugged Modem and
the iR1200 GPS Enabled Modem.
NextelCoverage
For details on Nextel digital cellular and data coverage, visitnextel.com.
NOTE: Transmission and reception speed may vary, based on your relative
position within the coverage area. If you are in a marginal location (close to
the border of the coverage area), the throughput of your modem during
data transmission may be affected.
NextelCustomer Care
For domestic customer care issues, including billing issues, general service needs, or to
order additional services, contact Nextel Customer Care.
iR1200Modem
9
Visit nextel.com for a variety of Customer Care services:
•Browse for information on phones, coverage, rates and other Nextel services. View
and download user’s guides, try out our interactive virtual products and service
demos, find answers to frequently asked questions, order accessories, locate service
and repair centers, upgrade phone software, send a message and more.
•For self-service on your Nextel account, click on My Account to view your account,
payyour bill (not available in all areas), add phones to your account; reset your
Voice Mail password, and more.
•For online assistance, click on Contact Us to send us an email request. Our
representatives are committed to assisting you. Every effort will be made to address
your questions or concerns within 24 hours. Contact us to add Wireless Web and
other services, change rate plans, inquire on your bill and more.
Or, call us at 1-800-639-6111 or dial 611 from your Nextel phone.
Overview
10
Overview
In this chapter, we will provide you with a general overview of the iR1200 Rugged and
GPS Enabled modems.
This chapter includes:
General Overview Page 10
Modem Dimensions Page 11
Modem Operating Modes Page 12
General Overview
The iR1200 Rugged Modem an is iDENdata modem that consists of a radio card and
an optional GPS (iR12000 GPS Enabled Modem) receiver, contained in a ruggedized
enclosure, to provide wireless data communications. The iR1200 modem is primarily
intended for vehicle-mounted applications but can also be mounted to stationary
environments.
Figure 1. iR1200 Modem
iR1200Modem
11
The following diagrams outlines the dimensions of the iR1200 modem.
NOTE: This diagram depicts the dimensions of the iR1200 modem and should not
be used as a template for mounting the modem. Please see the insert in the
back of this installation guide for a copy of the mounting template.
Figure 2 –Dimensions of the iR1200 Modem
Overview
12
Modem Operating Modes
The iR1200 provides the following data connection modes:
•Packet Data: A wireless modem connection used for accessing the Internet, sending
and receiving e-mail, and transferring small files over the packet data network using
standard IP protocols.
Data is sent in packets (blocks) of data at high speed, with the user being charged on
a per byte basis. After the transmission is completed, the user can remain connected
indefinitely without being charged for the idle time.
•Circuit data: A wireless modem connection for sending and receiving data (faxes,
files, etc.) over the circuit-switched cellular channel, providing a direct point to
point connection with the destination device. The user is charged for the connection
time in minutes regardless of the amount of data transmitted.
InstallationProcedures
13
Installation Procedures
In this chapter, you will learn everything you need to know to begin installing your
iR1200 modem.
This chapter includes:
Before You Start Installing
•Installation Tools
Page 13
Page 13
Before You Start Installing
Experienced technicians familiar with installing similar types of hardware equipment
should perform installation of the modem.
Planning is the key to a quick and simple installation. Before drilling holes or running
wires, you should inspect the vehicle or area of the building to determine how and where
you intend to mount the modem, antenna and accessories.
NOTE: The following instructions are intended to provide you with quick reference
to installing your iR1200 modem.
•Mount Modem – Mount the modem in the desired location.
•Mount Antenna –Mount the antenna using the instructions included with your
selected antenna’s installation guide.
•Connect Cables – Connect the antenna cables to the mounted modem.
•Connect Power – Connect the AC power cables and ignition sensor cables to the
mounted modem.
•Power Up – Power up the modem to check for successful installation.
Installation Tools
The following are the recommended tools you will need to install the iR1200 modem:
•Portable Drill •Hammer
•Center Punch •Crimp tool
•Four #10 self-tapping sheet metal screws •Phillips Screwdriver
Vehicle Installation
14
Vehicle Installation
In this chapter, you will learn everything you need to know to install your iR1200 modem
in a vehicle.
This chapter includes:
Mounting the iR1200 Modem Page 14
Modem Antenna Mounting
•Installation Considerations
•Approved Parts
•Mounting Antenna
•Mounting GPS Antenna (optional)
•Approved Parts
Page 15
Page 15
Page 16
Page 16
Page 17
Page 17
Power Cable Installation
•Wiring Diagram
Page 17
Page 18
Ignition Cable Installation Page 19
Modem Cable Installation Page 20
GPS Data Cable Installation (optional) Page 20
Mounting the Modem
The standard mounting of the iR1200 modem can be mounted on different types of
surfaces. You should determine if the surface is able to support the weight of the iR1200
modem. The area should allow sufficient space around the modem for cool air to
circulate.
For vehicle mounting, the unit should be close enough to the vehicle’s operator to permit
easy access to modem’s indicators. Although the modem can be mounted on a plastic
dashboard, it is recommended that the mounting screws be positioned so they penetrate
the supporting metal frame of the dashboard.
iR1200Modem
15
Figure 3 –iR1200 Rear Panel Layout
The following table contains the steps for mounting your iR1200 data modem in a
vehicle.
1Determine a convenient location in the vehicle –either onthe
transmission bump or under the dashboard. If mounting the iR1200
modem on the transmission bump, ensure that the transmission
housing is not affected.
2Use the mounting template or the iR1200 mounting bracket to mark
the positions of the holes on the mounting surface.
3Mark the holes on the location for the mounting.
4Drill the holes in the marked location.
5Mount the unit using the #10 sheet metal screws.
Antenna Mounting
Regardless of whether the modem is installed inside a vehicle or building, the best
location for mounting the antenna is in the center of a large, flat surface.
Antenna Installation Considerations
•All equipment must be properly installed in accordance with Nextel’s installation
instructions.
Vehicle Installation
16
•To assure compliance with United States FCC regulations on RF exposure, the user
of the equipment must position the antenna in such a way to maintain a separation of
at least 8 inches (20 cms) between the antenna and the human body.
•Ensure that the antenna is properly installed external to the vehicle and in
accordance with the requirements of the antenna manufacturer/supplier.
•Use only the supplied or an approved antenna. Unauthorized antennas, modifications
or attachments could impair call quality, damage the modem, or result in violation of
the FCC.
Mounting Modem Antenna
The following table outlines the approved antennas that can be used with the iR1200
modem.
1RAF4136AMM –Magnetic Antenna
2FAD5524A –Mobile Window Antenna
3HAF9067A –Mobile Roof Mount Antenna
4CLR-877MU –Antenna World Magnetic Mount
5CLR-853MU –Antenna World Portable antenna
NOTE: Antennas with gain exceeding 3db do not comply with FCC RF exposure
and are not allowed for use with this product.
The following table outlines the steps for mounting an antenna.
1Use an antenna suitable for the cellular band of frequencies (806-
870 MHz) with Mini UHF jack and matched for 50-ohm impedance.
2Position the antenna to allow as free a radiation pattern as practical.
3Screw the male connector of the antenna cable to the MODEM ANT
jack (refer to Figure 3 –Rear Panel Layout).
NOTE: Each antenna has specific installation instructions. Please refer to the
antenna installation instructions for specific requirements and details.
iR1200Modem
17
Mounting GPS Antenna (optional)
The iR1200 GPS Enabled modem comes equipped with a connector for a GPS antenna.
The following GPS antenna can be used with the iR1200 Modem:
139265-50 -Trimble Magnetic Mount Antenna
The following table contains the steps for mounting a GPS antenna.
1Use an antenna suitable for the GPS of frequency (1575 MHz) with
an MCX connector and matched for 50-ohm impedance.
2Locate the antenna to allow as free a radiation pattern as practical.
3Insert the male connector of the GPS antenna cable to the GPS ANT
jack (refer to Figure 3 –Rear Panel Layout).
NOTE: Because of the operating frequencies involved with GPS signal, splicing or
using adapters to extend the length of the antenna coaxial cable is not
recommended and will likely prevent the system from operating properly.
We recommend that a single length of coax without splices or adapters be
used.
Power Cable Installation
The iR1200 must be operated only in a negative ground electrical system, however
reverse polarity will not damage the modem. Check the vehicle power polarity before you
begin installation.
Vehicle Installation
18
Wiring Diagram
Figure 4 –Power Cable Assembly
The following DC power cable can be used:
15100-C5-RFM –eLutions’ Vehicle Power Harness
The following table contains the steps for installing the power cable:
1Determine a cable routing plan which will allow you to connect the
plug end of the DC power cable to the jack labeled POWER located
on the front panel of the iR1200 modem (refer to Figure 7).
2Locate the nearest available chassis ground mounting point and
shorten the black lead to remove any excess cable length.
3Position the fuse holder as close to the battery as possible and away
from any potentially hot components.
4Mount the fuse holder by tie wrapping it to the other cabling wires
and dress wires as necessary.
iR1200Modem
19
and dress wires as necessary.
5Shorten the white lead to remove any excess length and crimp the
fuse holder’s red lead to the white lead using the in-line splice.
6Crimp on the ring tongue terminal and connect the power cable
black lead directly to the chassis ground.
7Connect the ring tongue terminal from the fuse holder to the positive
(+) battery terminal. Make sure the adapter cable is connected to the
main power cable red lead.
Ignition Cable Installation
To turn on the iR1200 modem, an ignition signal is required at the ignition connector.
When installed in a vehicle, the modem receives the ignition signal from the vehicle’s
ignition switch.
Figure 5 –Switched Power Configuration
The following table contains the steps for installing your modem for switched power
connection:
1Once the modem has been mounted, prepare a routing plan for the
ignition.
+12VDC
VEHICLE BATTERY
+12VDC
ENGINE IGNITION
SWITCH
FUSE
GPS ANTENNA
(OPTIONAL) MODEM
ANTENNA
iR1200
POWER
IGNITION
Vehicle Installation
20
2Connect the free end of the ignition cable to a fused vehicle circuit
which provides +12V DC when the engine is running and no voltage
when the vehicle is off.
3Connect the other end (with the plug) to the iR1200 jack labeled
IGNITION (refer to Figure 7 –Front Panel Layout).
Modem Data Cable Installation
The iR1200 Rugged Modem can be connected to the host DTE equipment using a
standard “straight through” 9-pin to a 9-pin serial cable.
The following part can be used:
45200-C5-RFM –eLutions Power Cable
The following table contains the steps for connecting the data cable:
Connect one side of the 9-pin cable to the iR1200 communication
connector and the other side of the DTE.
GPS (optional) Data Cable Installation
The iR1200 GPS Enabled Modem can be connected to the host DTE equipment using a
standard “straight through” 9-pin to a 9-pin serial cable.
The following part can be used:
15200-C5-RFM –eLutions Power Cable
The following table contains the steps for connecting the data cable:
Connect one side of the 9-pin cable to the iR1200 communication
connector and the other side of the DTE.
Other manuals for iR1200 GPS
4
Table of contents
Other Nextel Modem manuals
