Nextel iDEN i60c User manual
Nextel®
iDEN®
Digital Multi-Service Data-Capable Phone
i60c Phone User’s Guide
@NNTN4296A@
NNTN4296-A
nextel.com
i
Table of Contents
IMPORTANT!
Read “Nextel Terms and Conditions of Service” on
page 166 and “Safety and General Information” on
page 171 before using your i60cphone.
Introduction ..........................................................................................1
Welcome to Nextel®.......................................................................................1
Customer Care.................................................................................................2
Ordering Information ......................................................................................2
Driving Safety Tips.........................................................................................3
Getting Started......................................................................................5
i60cPhone Features .......................................................................................6
i60cPhone Menu Tree....................................................................................7
i60cIcon Glossary...........................................................................................8
Battery .............................................................................................................9
Turning Your i60cPhone On/Off ................................................................12
Enabling Over-the-Air-Radio-Service Software (OARSS) Security............14
Receiving OARSS Programming..................................................................14
SIM Card.......................................................................................................15
Status of Your i60cPhone ............................................................................23
My Information .............................................................................................23
Using T9® Text Input...................................................................................24
Display Essentials ...............................................................................31
Display Screen...............................................................................................31
Status Icons....................................................................................................32
Text Display Area .........................................................................................34
Call Information Icons...................................................................................34
Menu Icon......................................................................................................35
ii
Table of Contents
IMPORTANT!
Read “Nextel Terms and Conditions of Service” on
page 166 and “Safety and General Information” on
page 171 before using your i60cphone.
Display Options.............................................................................................35
Navigating Menus and Lists..........................................................................35
Main Menu Options.......................................................................................36
Phonebook...........................................................................................39
Phonebook Entries and Speed Dial Numbers................................................40
Phonebook Icons ...........................................................................................40
Accessing Your Phonebook ..........................................................................41
About Phonebook Entries..............................................................................41
Pause Digit Entry...........................................................................................50
Plus Dialing...................................................................................................51
Address Book ................................................................................................52
Digital Cellular....................................................................................53
Making Phone Calls ......................................................................................54
Emergency Calling........................................................................................58
Special Dialing Codes...................................................................................59
Receiving a Phone Call .................................................................................59
Ending a Phone Call......................................................................................60
Recent Calls...................................................................................................61
Missed Calls..................................................................................................64
Call Timers....................................................................................................64
Hands-Free Speakerphone (Optional)...........................................................65
Mute...............................................................................................................66
Call Waiting ..................................................................................................66
iii
Table of Contents
IMPORTANT!
Read “Nextel Terms and Conditions of Service” on
page 166 and “Safety and General Information” on
page 171 before using your i60cphone.
Call Hold .......................................................................................................69
Three-Way Calling........................................................................................70
Call Forwarding.............................................................................................71
Caller ID........................................................................................................75
Alternate Line Service...................................................................................76
Call Restrictions ............................................................................................77
Nextel 411 .....................................................................................................77
Nextel Voice Mail................................................................................81
Setting Up Your Voice Mail Box..................................................................81
Logging Into Voice Mail...............................................................................82
Using Voice Mail ..........................................................................................83
Advanced Voice Mail Features.....................................................................87
Nextel Voice Mail Tree.................................................................................95
Messaging Services.............................................................................97
Receiving Messages ......................................................................................97
Message Center .............................................................................................99
Voice Mail Messages ..................................................................................100
Text and Numeric Messaging......................................................................101
Nextel Two-Way Messaging.......................................................................104
Direct Connect..................................................................................105
Nextel Direct Connect®..............................................................................105
Private Call..................................................................................................105
iv
Table of Contents
IMPORTANT!
Read “Nextel Terms and Conditions of Service” on
page 166 and “Safety and General Information” on
page 171 before using your i60cphone.
Call Alerts....................................................................................................108
Group Call...................................................................................................112
Memo.................................................................................................117
Adding a New Memo ..................................................................................117
Viewing a Memo.........................................................................................117
Editing a Memo...........................................................................................118
Deleting a Memo.........................................................................................118
Nextel Wireless Web.........................................................................119
Wireless Web Navigation Keys ..................................................................119
Starting the Microbrowser...........................................................................120
Using Your Phone as a Modem...................................................................121
Customizing the i60cPhone ............................................................123
Settings........................................................................................................123
Accessories.........................................................................................139
Batteries.......................................................................................................139
Chargers.......................................................................................................140
Universal Serial Bus (USB) ........................................................................142
Other Important Information.........................................................143
Nextel Customer Care.................................................................................143
Understanding Status Messages..................................................................144
v
Nextel Terms and Conditions of Service ....................................................146
Safety and General Information .....................................................151
RF Operational Characteristics ...................................................................151
PORTABLE RADIO PRODUCT OPERATION AND EME EXPOSURE.....
151
Electro Magnetic Interference/Compatibility..............................................154
Medical Devices..........................................................................................154
Operational Warnings..................................................................................156
Operational Cautions...................................................................................157
Limited Warranty Motorola Communication Products...............................161
Patent and Trademark Information..............................................................167
vi nextel.com
1
Introduction
Welcome to Nextel®
Thank you for choosing Nextel as your wireless communications provider. Your
i60cphone enables you to enjoy clear connections through Nextel’s All-Digital
National Network. In addition, with Nextel iTravelerSM Service, you can use
your i60c phone to roam internationally in select countries using other iDEN®
networks. Countries in which iTraveler service can be used are Argentina,
Brazil, Canada, Philippines, Israel, Mexico, and Peru.
NOTE: Contact Nextel Customer Care to obtain iTraveler service.
Nextel gives you more ways than anyone to communicate with everyone.SM
Your i60cphone offers many innovative features:
•Phonebook – Your consolidated Phonebook holds up to 250 entries and
allows you to store multiple contact numbers for each person, offering you
various ways to communicate with your business and personal contacts.
•Subscriber Identity Module (SIM) Card – Your phone’s SIM card holds
all entries stored in your Phonebook. In addition, you have a PIN (Personal
Identification Number) to keep your information safe and secure.
•Messages – The Message Center allows you to manage and access your
Voice Mail, Text Messages, and Two-Way Messages all from the same
inbox.
•Nextel Direct Connect®– With Nextel Direct Connect, you can use your
phone as a digital two-way radio to communicate directly with business
and personal contacts at a fraction of the cost of cellular calls.
•Nextel Wireless Web – Using the Net feature with the built-in
microbrowser, you can access Nextel’s wireless Internet. It offers a suite of
Nextel wireless data products and Internet applications to quickly access
the information you need to get business done.
•Closed Cover Features – The external control buttons enable you to
access several functions of your i60cphone without opening the cover.
•Customization – Use the Settings feature to customize your i60cphone to
meet your individual needs.
•Speakerphone – With this optional feature, you can enjoy hands-free
communication at the touch of a button. And Speakerphone is especially
great for conference calls.
For more information on these and other features of the i60cphone, review this
User’s Guide.
Enjoy using your i60cphone!
2nextel.com
Customer Care
For domestic customer care issues, including billing issues, general service
needs, or to order additional services, contact Nextel Customer Care.
Visit nextel.com for a variety of Customer Care services:
•Browse for information on phones, coverage, rates, and other Nextel
services. View and download user’s guides, try out our interactive virtual
products and service demos, find answers to frequently asked questions,
order accessories, locate service and repair centers, upgrade phone
software, send a message, and more.
• For self-service on your Nextel account, click on My Account to view
your account, pay your bill, add phones to your account, reset your Voice
Mail password, and more.
• For online assistance, click on Contact Us to send us an email request. Our
representatives are committed to assisting you. Every effort will be made to
address your questions or concerns within 24 hours. Contact us to add
Wireless Web and other services, change rate plans, inquire on your bill,
and more.
Or, call us at 1-800-639-6111 or dial 611 from your Nextel phone.
To complement the i60cphone and Nextel Worldwide Service, Nextel has also
launched International Roaming Customer Care support. When traveling
outside of the U.S. and Canada, call +1 (360) 662-5202 for your Customer Care
Service needs. This Customer Care number will be toll-free from your Nextel
handset both domestically and internationally.
For more information about Nextel or to view this guide on our Web site, visit
us on nextel.com.
International and domestic coverage, rates, and other information are also
available on nextel.com.
Ordering Information
Nextel Business Networks®allows you to communicate with individuals outside
as well as inside your company. These Networks link Nextel customers in
similar industries or geographies. So, if you need to reach a client, vendor, or
contractor instantly, work smarter by joining the Nextel Business Networks.
Call 1-888-NEXTEL2 (1-888-639-8352).
3
Driving Safety Tips
Various accessories are available for use with your i60cphone, including a
Leather Carry Case, Vehicle Battery Charger, extra batteries, a variety of
Hands-Free accessories, and more. To order accessories or an accessories
catalog, go to nextel.com or call Nextel NextdaySM Accessories at
1-800-914-3240. You can also contact your Nextel Authorized Sales
Representative or stop by any Nextel Store. For information on retail store
locations, go to nextel.com.
Contact Nextel Customer Care to order any of the services discussed in this
guide, including Nextel Wireless Web, additional phone services, Voice Mail,
Nextel Mobile Messaging and much more!
For information on Direct ProtectSM insurance protection for your i60cphone,
call 1-888-352-9182 or contact your Nextel Authorized Representative.
Visit us at nextel.com to learn more about Nextel products and services!
Driving Safety Tips
NOTE: For safety and legal reasons (in many countries), do not use your phone while
driving.
Check and follow the local laws regarding the use of mobile phones while
driving.
Your wireless phone is a great safety tool. You can instantly call for help in
emergencies or alert your next appointment that you’re running late. Please
follow these tips for using your wireless phone when you’re behind the wheel.
1. Give driving your full attention. Don’t let anything interfere with your
concentration.
2. Assess road conditions before making or taking a call.
3. Let voice mail pick up when its inconvenient or unsafe to answer the
phone.
4. Program your most frequently dialed numbers into your phone for
speed dialing. When dialing manually without the Turbo Dial ® one-touch
dialing feature, dial only when your vehicle is stopped — or have a
passenger dial for you.
5. Position your phone where it is easy to see and reach.
6. Keep your eyes on the road. Never take notes while driving.
7. Consider using a hands-free speakerphone or hands-free accessory
which allows you to keep both hands on the wheel when speaking.
8. Use your phone’s Internet capabilities before you drive. Wireless Web
Services are not designed to be used while driving.
4nextel.com
9.Be a Good Samaritan. Dial 9-1-1 in emergencies to
report accidents, impaired or aggressive drivers, crimes
or fires. It’s a free call. Know your phone number so
emergency services personnel can call you back if
necessary.
5
Getting Started
This section will help you get started using your phone. It contains details about
some of the features and functions described in the Getting Started Guide.
This section includes:
i60cPhone Features Page 6
i60cMenu Tree Page 7
i60cIcon Glossary Page 8
Battery Page 9
Turning Your i60cPhone On/Off Page 12
Enabling Over-the-Air-Radio-Service Software
(OARSS) Security Page 14
Receiving OARSS Programming Page 14
SIM Card Page 15
Status of Your i60cPhone Page 23
My Information Page 23
Using T9® Text Input Page 24
6nextel.com
i
60
c
Phone Features
Antenna
Earpiece
Display Screen
Menu Key
Option Key
Photosensor
Send Key
AlphaNumeric
Keypad
Microphone
Option Key
4-Way
Navigation
Key
Punctuation
Key
Headset Jack
Back/Pause
Dialing Key Next Word/
International
Plus Dialing Key
Accessory and Data
Cable Connector
Speaker Key
Nextel Direct
Connect®
Push-To-Talk
(PTT) Button
Status Light
End/Home
Key
Power On/Off
Cover
Cover
Volume
Control
Buttons
SmartKey
COVER CLOSED
COVER OPEN
TOP VIEW
Antenna
Audio Jack
Speaker Key
SmartKey Accessory and Data
Cable Connector
BOTTOM VIEW
Status Light
7
i60c Phone Menu Tree
i
60
c
Phone Menu Tree
You can access the main menu options by pressing qfrom the idle screen. Use to
navigate through the menus and submenus. Press Cunder the display options to perform
the desired phone function.
8nextel.com
i
60
c
Icon Glossary
You may see these icons while using your i60cphone:
Fax
A
Navigation
d
g
Menu
P
2
Line and CallInfo Info
0
1
G
E
X
Mobile
T
Main
N
h
Work
+
Home
C
%
Other
W
Status
s
Z
Y
%
c
i
Locked
M
On Hold
V
Main Menu
Net
j
7
Phonebook
b
Settings
m
;
z
My Info
U
Memo
O
Miscellaneous
:
S
T9
#
$
T9 Alpha
w
Q
{
*
-
[
\
y
K
End Call
?
]
<
Phonebook
Pager
a
Connected
6
D
u
R
Messages
RR
T9 Numeric
,
T9 Symbols
!
x
e
f
TalkgroupID
Private ID
Line1Active
Line2 Active
Line1 Forward
Line2 Forward
Incoming Call
Outgoing Call
Missed Call
PickerUp
Picker Down
Picker Left
Picker Right
Up Down Arrows
Signal Strength
Mobile IP
Battery Strength
Packet Data
Packet Activity
Phone In Use
Private In Use
Talkgroup In Use
VibrateAll
Speaker Off
VibrateThenRing
Silent On
Vibrate On
Call Forward
Call Timers
RecentCalls
CallAlert
Text Message
Net Alert
MessageRead
T9Uppercase
T9CapsLock
SecureData
CheckMark
Voice Mail
IP
Word
|
9
Battery
The icon of the main menu feature in use displays in the top left of the status
icon rows. For a list of the main menu options, see “Main Menu Options” on
page 36.
Battery
Your i60cphone comes with a Lithium Ion battery and charger. After attaching
the battery, you must charge it before you use it for the first time. See
“Batteries” on page 139 for the charging times for your phone’s battery. The
first time you charge your phone’s battery, charge for 30 minutes more than the
time shown on page 139. After the initial charging, the battery can be charged in
the time shown on page 139.
Remove the battery from the protective plastic safety tray provided in the
original packaging. When the battery is not attached to the phone, store it in the
original tray.
NOTE: Use only the batteries approved for this product.
10 nextel.com
Attaching the Battery
Detaching the Battery
1
Slide the battery cover release button, located on the bottom of the
phone, away from the battery cover and remove the battery cover from
the back of the phone.
TIP: Holding the battery cover downward allows it to fall
easily from the back of the phone without being pulled.
2
Insert the top of the battery into the battery area. Press the bottom of the
battery to secure it.
3
Replace the battery cover and press it gently until you hear a click.
1
Ensure the phone is powered off before attempting to detach the battery.
Battery cover
release button
11
Battery
Charging the Battery
NOTE: The battery can be charged with the phone either turned on or
off. For best results, charge it with the phone turned off.
2
Slide the battery cover release button, located on the bottom of the
phone, away from the battery cover and remove the battery cover from
the back of the phone.
3
Remove the battery by pushing the battery toward the antenna and
lifting it out of the phone.
1
With your phone’s display screen facing up, plug
the charger’s accessory connector into the left side
of the accessory connector on the bottom of the
phone.
NOTE: To reduce damage to the phone’s bottom
connector, the cable or accessory button
should always be used to remove the
charger.
2
If the charger has folding electrical prongs, flip open the prongs.
3
Plug the charger into an electrical outlet.
Accessory Button
12 nextel.com
Battery Charging Status
The battery strength indicator icon found on your phone’s display screen shows
the amount of power in the battery.
When Using Phone
A short, chirp-like sound indicates a low battery. The icon flashes to indicate
that you have approximately five minutes of talk time remaining.
When Charging Battery
Turning Your
i
60
c
Phone On/Off
NOTE: To register for the first time on the Nextel National Network, you
must turn on your
i
60c phone in your home market.
To power the phone on:
Icon
Display abcd
Battery
Strength Low
Battery 11% to
40% 41% to
70% Fully
Charged
Icon
Display efgd
1 flashing bar 1 flashing bar,
1 continuous bar 1 flashing bar,
2 continuous bars 3 continuous bars
Battery
Strength Low
Battery 31% to
60% 61% to
90% Fully
Charged
1
Open the phone cover.
2
For optimal signal strength, extend the antenna.
3
Press and hold pon the keypad until the status light glows red, a tone
briefly sounds, and Powering On displays.
Table of contents
Other Nextel Telephone manuals
