Nexto Di NSB-25 User manual

Changing Bottom Case
Changing
Bottom
Case
NSB-25
1) Changing battery
2)
Changing Bridge PCB
2)
Changing
Bridge
PCB
www.nextodi.com

Guidance on changing Bottom Case NSB25
2. Remove Battery Cover Lock
☞
Usecoinor(
-
) type driver
Use
coin
or
(
)
type
driver

Guidance on changing Bottom Case NSB25
3. Remove Battery Cover
☞
Slide Down
Slide
Down

Guidance on changing Bottom Case NSB25
4. Remove Battery from NSB25
☞
Remove six battery cable from upside to down
Remove
six
battery
cable
from
upside
to
down

Guidance on changing Bottom Case NSB25
5. Remove lower two cables connected to the main PCB

Guidance on changing Bottom Case NSB25
14. Connect two battery power cable to the lower two connector

Guidance on changing Bottom Case NSB25
16. Connect battery connector from lower side to upper side.

Guidance on changing Bottom Case NSB25
17. Second battery

Guidance on changing Bottom Case NSB25
18. Third battery

Guidance on changing Bottom Case NSB25
19. Placement order of three internal batteries

Guidance on changing Bottom Case NSB25
20. Assemble the battery case.
☞
Slide up the cover
Slide
up
the
cover

Guidance on changing Bottom Case NSB25
21. Fix the battery lock screw.

Guidance on changing Bottom Case NSB25
22. Complete

THANK YOU
THANK
YOU
