nextys NPSM120-12 User manual

NPSM120 Series
Instruction Manual
SI000030A03_I.S.NPSM120.doc
www.nextys.com
Page 1/5
NPSM120 Series –Single phase / DC input switching power supply
Main Features:
High efficiency and compact size
Overload 150%
Only 40mm width aluminum enclosure
Up to 60°C operating temperature with no derating
INDEX
Page
Installation Requirements
2
Declaration of Conformity
2
User Instructions
3
Connections
4
Dimensions
4
Distances
4
Mounting
4
Dismounting
5
Input Connections
5
Environment
5
Accessory Device
5

NPSM120 Series
Instruction Manual
SI000030A03_I.S.NPSM120.doc
www.nextys.com
Page 2/5
READ THIS CAREFULLY BEFORE
INSTALLATION!
VOR DER INSTALLATION BITTE
FOLGENDE SICHERHEITSHINWEISE
BEACHTEN
LEGGERE ATTENTAMENTE PRIMA
DELL’INSTALLAZIONE!
A LIRE ATTENTIVEMENT AVANT
L’INSTALLATION!
Before operating, read this document thoroughly
and retain it for future reference.
Non-respect of these instructions may reduce
performances and safety of the devices and
cause danger for people and property.
The products must be installed, operated,
serviced and maintained by qualified personnel
in compliance with applicable standards and
regulations.
Don’t open the device, it does not contain
replaceable components, the tripping of the
internal fuse (if included) is caused by an internal
failure.
Don’t repair or modify the device, if malfunction
or failure should occur during operation, send
unit to the factory for inspection. No responsibility
is assumed by Nextys SA for any consequences
deriving from the use of this material.
Lesen Sie dieses Dokument vor der
Inbetriebnahme sorgfältig durch und bewahren
Sie es zum späteren Nachschlagen auf.
Die Nichtbeachtung dieser Anweisungen kann
die Funktion und Sicherheit der Geräte
beeinträchtigen und birgt Gefahren für Personen
und Eigentum.
Die Geräte müssen von qualifiziertem Personal
unter Einhaltung der geltenden Normen und
Vorschriften installiert, betrieben, gewartet und
instand gehalten werden.
Öffnen Sie das Gerät nicht, es enthält keine
austauschbaren Komponenten, das Auslösen
der internen Sicherung (falls vorhanden) ist stets
auf tiefergehende Fehler im Schaltkreis zurück
zu führen. Reparieren oder modifizieren Sie das
Gerät nicht. Sollte während des Betriebs eine
Fehlfunktion oder ein Defekt auftreten, schicken
Sie das Gerät zur Überprüfung ins Werk.
Nextys SA übernimmt keine Haftung für die
Folgen, die sich aus dem Einsatz dieses Gerätes
ergeben.
Prima dell’installazione, leggere attentamente
questo documento istruzioni e conservarle per
future consultazioni.
L’inosservanza delle presenti istruzioni può
compromettere le caratteristiche e la sicurezza
dell’apparecchio e causare pericolo per le
persone e le cose.
Il prodotto deve essere installato, utilizzato e
riparato da personale qualificato e nel rispetto
delle normative vigenti.
Non aprire il prodotto, esso non contiene
componenti sostituibili, il guasto del fusibile
interno (se previsto) è causato da un guasto
interno. Non tentare di riparare o modificare il
prodotto, se durante il funzionamento si
verificano guasti o anomalie, inviarlo al
produttore per il controllo.
Nextys SA non si assume nessuna
responsabilità per qualunque conseguenza
derivante dall’uso di questo materiale.
Lisez ces instructions avant l'installation,
conservez ce manuel pour référence future.
Défaut de se conformer à ces instructions peut
affecter les caractéristiques et la sécurité du
dispositif de danger et de causer aux personnes
ou aux biens.
Les produits doivent être installés, exploité et
entretenus par personnel qualifié et en conformité
avec les règlements.
N'ouvrez pas le produit, il ne contient aucune
pièce réparable, le déclenchement du fusible
interne (le cas échéant) est causé par un défaut
interne. Ne pas essayer de réparer ou modifier le
produit ; si des défaillances se produisent pendant
le fonctionnement ou les dysfonctionnements, le
retourner au fabricant pour inspection. Nextys SA
n'assume aucune responsabilité des
conséquences éventuelles découlant de
l'utilisation des produits.
CAUTION
ACHTUNG
ATTENZIONE
AVVERTISSEMENT
RISK OF BURNS, EXPLOSION, FIRE,
ELECTRICAL SHOCK, PERSONAL INJURY.
Never carry out work on live parts! Danger of
fatal injury! The product’s enclosure may be hot,
allow time for cooling product before touching it.
Do not allow liquids or foreign objects to enter
into the products.
To avoid sparks, do not connect or disconnect
the device before having previously turned-off
input power and wait for internal capacitors
discharge (minimum 1 minute).
GEFAHR VON VERBRENNUNGEN,
EXPLOSIONEN, FEUER, STROMSCHLAG,
PERSONENSCHÄDEN.
Führen Sie niemals Arbeiten an
spannungsführenden Teilen durch! Gefahr von
tödlichen Verletzungen! Das Gehäuse des
Gerätes kann heiß sein, lassen Sie Zeit zum
Abkühlen des Gerätes, bevor Sie es berühren.
Lassen Sie keine Flüssigkeiten oder
Fremdkörper in die Geräte eindringen.
Um Überschläge zu vermeiden, schließen Sie
das Gerät nicht an oder trennen Sie es nicht
ohne vorher die Eingangsspannung abgeschaltet
zu haben, und warten Sie die Entladung der
internen Kondensatoren ab (mindestens 1
Minute).
RISCHIO USTIONI, ESPLOSIONE, INCENDIO,
SCOSSA, LESIONI GRAVI.
Non effettuare mai operazioni sulle parti sotto
tensione! Pericolo di lesioni letali! Il contenitore
può scottare, lasciar quindi raffreddare il
dispositivo prima di toccarlo. Non far entrare
liquidi o oggetti estranei nel dispositivo.
Per evitare scintille, non collegare o scollegare
l'apparecchiatura prima di avere tolto tensione di
ingresso e prima che sia avvenuta la scarica dei
condensatori interni (min. 1 minuto).
RISQUE DE BRULURES, EXPLOSION,
INCENDIE, ELECTROCUTION, DOMMAGE AUX
PERSONNES.
Ne jamais effectuer des opérations sur les parties
sous tension! Danger de mort! Le récipient peut
produire des brulures, le laisser refroidir avant de
toucher l'appareil. Ne faites pas pénétrer des
liquides ou des corps étrangers dans l'appareil.
Pour éviter des étincelles, ne pas connecter ou
déconnecter l'équipement jusqu'à ce que vous
avez supprimé la tension d'entrée et avant qu'elle
n'ait lieu de décharge des condensateurs internes
(minimum 1 minute).
DECLARATION OF CONFORMITY
NEXTYS SA
Via Luserte Sud 6, 6572 Quartino - Switzerland
Phone: [phone]; Fax: [phone]
E-mail: [e-mail]
This Declaration of Conformity is suitable to the European Standard EN45014 "General criteria for supplier’s declaration of conformity".
We declare under our sole responsibility that the device included in this box, has passed all processing inspections and the final test and it is in conformity with the product requirements,
including all reference codes and supply specifications.
ROHS compliance: the product respects the EC requirements related to ROHS substances, according to “Restriction of Hazardous Substances” as per document 2011/65/UE.
REACH compliance: the product respects the EC requirements related to REACH SVHC directive (EC) 1907/2006.
Note: all the reported information comes from our suppliers, NEXTYS SA has not run any test to evaluate if the specific elements are present.
All indicated devices are designed according to the latest Reference standards, if not expressly indicated through the official documents or files, they have been tested through our internal
pre-compliance testing. Consult directly on www.nextys.com the reference standards applied to each model.
Code Description
NPSM120-12 Single phase switching power supply IN 120 - 240Vac / OUT 12Vdc - 7A
NPSM120-24 Single phase switching power supply IN 120 - 240Vac / OUT 24Vdc - 5A
NPSM120-24P Single phase switching power supply IN 120 - 240Vac / OUT 24Vdc - 5A + ORing circuit
NPSM120-48P Single phase switching power supply IN 120 - 240Vac / OUT 48Vdc - 2.5A + ORing circuit
Certifications and approvals
IND.CONT.EQ. 4WX9
Reference standards
2014/35/EU (Low Voltage Directive)
2014/30/EU (EMC directive)
EN61010-1 (Safety Standard)
EN61010-2-201 (Safety Standard)
UL508 (Certified - IND. CONT. EQ. 4WX9 file no. E356563)
UL61010-1 (Certified - IND. CONT. EQ. 4WX9 file no. E356563)
UL61010-2-201 (Certified - IND. CONT. EQ. 4WX9 file no. E356563)
EN61000-6-2 (Generic immunity standard for industrial environments)
- EN61000-4-2 (Electrostatic discharge immunity test)
- EN61000-4-3 (Radiated, radio-frequency, electromagnetic field immunity test)
- EN61000-4-4 (Electrical fast transient/burst immunity test)
- EN61000-4-5 (Surge immunity test)
- EN61000-4-6 (Immunity to conducted disturbances, induced by radio-frequency fields test)
- EN61000-4-8 (Power frequency magnetic field immunity test)
- EN61000-4-11 (Voltage dips, short interruptions and voltage immunity test)
EN61000-6-4 (Generic emission standard for industrial environments)
- EN55011 (CISPR11 - EMC)

NPSM120 Series
Instruction Manual
SI000030A03_I.S.NPSM120.doc
www.nextys.com
Page 3/5
USER INSTRUCTIONS
1) Description: DIN rail mountable primary switched-mode power supply with 90...264Vac or 110…345Vdc input (UL not evaluated), suitable for single phase main line and DC line.
2) Installation: use DIN-rails according to EN60715. Installation should be made vertically (see Fig.4). For better device stability fix the rail to the wall close to the point where the device is
to be mounted. In order to guarantee sufficient convection, we recommend observing a minimum distance to other modules (see Fig.3).
The device is provided with a thermal protection; a limited air flow can cause the thermal protection tripping.
The SMPS automatically restarts after cooling. To get normal operation reduce the temperature of the air surrounding the power supply, increase the ventilation or reduce the load (see
Fig.8).
3) Connections: the device is equipped with pluggable screw terminals. To avoid sparks, do not connect or disconnect the connectors before having previously turned-off input power and
waited for internal capacitors discharge (minimum 1 minute).
In order to comply with UL certification, use appropriate copper cables of indicated cross section, designed for an operating temperatures of:
60°C for ambient up to 45°C
75°C for ambient up to 60°C
90°C for ambient up to 70°C
Strip the connecting ends of the wires according to the indication and ensure that all strands of a stranded wire enter the terminal connection (see Fig.5).
4) Input protection: the device input is provided with varistors against overvoltage. Input is provided with internal fuses 3.15AT/250Vac, thus an external short circuit/overcurrent protection
must be provided by the end user (see Fig.6).
For operation on a single phase system, a protection fuse on the phase must be provided.
Surge protection: it is strongly recommended to provide external surge arresters (SPD) according to local regulations.
5) AC input connection: the device can be connected to single phase AC lines with Uin 120…240Vac (see Fig.7). Ensure that the PE conductor is properly connected.
Please connect first the PE.
6) DC input connection: connect L terminal to (+) positive pole, N terminal to (-) negative pole and terminal to GND. Rated voltage 110...345Vdc (UL not evaluated).
The device is also suitable for photovoltaic or wind turbine applications (see Fig.7).
7) Output connection: the device is suitable for SELV and PELV circuitry.
Uout can be adjusted with a potentiometer to a wide range (see Fig.1).
Check Uout before connecting the power supply to the load. With output voltage set to the max. value, the continuous [current x voltage] must not exceed the nominal power.
8) Parallel connection and redundancy: power supplies can be connected in parallel to increase power.
Uout must be set uniformly (±100mV) on each power supply and the wiring must be symmetrical to ensure an equal current distribution.
Models with “P” suffix have an integrated ORing circuit.
For redundant connection, use the Models “P” or an external isolating device must be used (see accessory device).
9) Output protection: the device is protected against overload (OL) / short circuit (SC) / overvoltage (OV) / overtemperature (OT).
OL and SC: are controlled by a hiccup mode auto-reset protection with the following behaviour:
OL behaviour: Max. OL = In x 1.5 with constant output voltage. If the current is In x 1.5 the unit enters the OL protection and starts an ON/OFF cycle (hiccup mode).
SC behaviour: the device supplies the indicated short circuit peak current for 30ms if the output current exceeds In x 1.5 the device enters into a controlled ON/OFF cycles (hiccup mode).
The output voltage drops to a voltage value depending on the impedance of the failed load circuit.
Output OV circuit protection: the output is protected against potential OV due to internal malfunction or coming from the load for Uout Unom x 1.2 –1.3, depending on the model.
OT protection: turns off the device if the internal temperature exceeds a safe limit.
The device restarts automatically after cooling down. To recover to normal operation reduce air temperature surrounding the power supply, increase cooling or reduce load (see Fig.8).
10) Feeding DC motors: it is possible to feed DC motors considering that when a motor starts-up under effort its consumption is much higher than the nominal current and it can trigger
overcurrent protection (see accessory device).
NOTE: motors can generate high conducted noise on the DC line. Therefore it is not recommended to feed on the same line motors and equipment sensitive to noise.
11) Operation with Battery: when a battery is connected in parallel to the Output for backup purposes (see accessory device).
12) Environmental: these products are IP20 (according to IEC 60529, not UL evaluated), and therefore chemicals/solvents, cleaning agents and other liquids must not be used.
13) Environment: these power supplies are SMPS for use in applications within a Pollution Degree 2, overvoltage category II environment (overvoltage category III according to EN50178).
Do not use in wet area or subject to moisture. These products are designed for indoor use only.
14) Intended use: these are isolated devices suitable for SELV and PELV circuitry and are designed to be mounted on DIN rail and installed inside a protective enclosure. They are
intended for general use such as in industrial control, communication, and instrumentation equipment.
If the power supply is used in a way not specified in this manual, the protection provided by the equipment may be impaired. Don’t use these devices in applications where malfunction may
cause injury or death.
15) Radio interference: this is an electrical appliance according to EN55032, class A. They may cause radio interference in residential areas.

NPSM120 Series
Instruction Manual
SI000030A03_I.S.NPSM120.doc
www.nextys.com
Page 4/5
Fig.1
Connections
Fig.2
Dimensions
Fig.3
Distances
Just for reference
(1) AC/DC input
(2) DC output (load)
(3) Diagnostic Output
(dry contact, NC output OK)
(4) Green LED: Output OK
(5) Output voltage adjustment
Input AC Line:
L = Line
N = Neutral
= Earth ground
Input DC Line:
L = + Positive DC
N = - Negative DC
= Earth ground
Output:
+ = Positive DC
- = Negative DC
Dry contact = NC
Dimension
W
D
H
mm (inc)
40 (1.57)
110 (4.33)
115 (4.52)
Distance
A
B
mm (inch)
20 (0.8)
50 (2.0)
Fig.4
Mounting / Dismounting Instructions
For DIN rail fastening according to IEC 60715 TH35-7.5(-15).
Mounting as shown in figure, with input terminals on lower side, with suitable cooling and maintaining a proper distance between adjacent devices as specified in the I.S. manual of each
family.
Mounting:
1. Tilt the unit slightly backwards
2. Fit the unit over the top edge of the rail
3. Slide it downward until it hits the stop
4. Press against the bottom for locking
1
2
3
4

NPSM120 Series
Instruction Manual
SI000030A03_I.S.NPSM120.doc
www.nextys.com
Page 5/5
Dismounting:
1. Pull down the slide clamp lever
2. Tilt the unit upward
3. Unhook the unit from the rail
1 & 2
3
Fig.5
Recommended connecting cable
Recommended Tightening torque
MFG
Nm
lbf in
Dinkle
0.51
4.5
ULO
0.51
4.5
Anytek
0.57
5
Würth
0.57
5
Cable size (solid and stranded)
MFG
mm²
AWG
Dinkle
2.5 –0.2
12 –28
ULO
2.5 –0.2
12 –28
Anytek
2.5 –0.34
12 –24
Würth
3.3 –0.2
12 –24
Stripping length
7 - 8mm / 0.28 - 0.32in
Fig.6
Input protection
Fuse 6AT or MCB 6A C curve.
For USA and Canada, use the fuse type closest to the European equivalent type.
Surge protection: it is strongly recommended to provide external surge arresters (SPD) according to local regulations.
Fig.7
Input connections
AC Line
DC Line (UL not evaluated)
Fig.8
Environment
Operating temperature
Derating (UL not evaluated)
- 40°C…70°C
5…95% r.H. non condensing
UL Certified up to 60°C
Overtemperature protection
UL certified up to 2000m
- 2.4W/°C over 60°C
Note:
Data may change without prior notice in order to improve the product
Please refer to the latest version of the "Instruction Manual" for each product by visiting www.nextys.com
See also the products below that can be used in conjunction with NPSM120 units (UL not evaluated) (accessory device)
OR20 20A Active ORing controller
OR50 50A Active ORing controller
DCU20 20A High performance DC UPS
DCW20 960W Combo DC-UPS / DC-DC Converter
BU150U 150J Buffer Module
NUPS12/24 Battery charger and DC UPS Module
NUPS960 40A DC UPS Module
MBC2K 2000W Motor brake controller
NBP30 Sealed Lead acid Battery pack
NCP12 Super Capacitors Module
NDW240 240W Programmable DC/DC Converter
NEF210 DC Overcurrent Protector / Static Switch
