Nexus NEX3031 User manual

RCD protecon module
NEX3031 instrucons
NEX3031PBI-B
above-desk │below-desk │beyond-desk
Full step-by-step mobile friendly
installaon instrucons are available
at nexus.uk or use this QR.
Safety warning
For your safety, this product must be installed in accordance with local
Building Regulaons. If in any doubt, or where required by the law,
consult a competent person who is registered with an electrical self-
cercaon scheme. Further informaon is available online or from
your Local Authority.
Please read carefully and use in accordance with these safety wiring
instrucons. Before commencing any electrical work ensure the
supply is switched o at the mains. Wiring should be in accordance
with the latest edion of the IET regulaons (BS 7671).
To prevent re hazard always use cable of the correct rang & type for
the applicaon.
Warning do not exceed the load rang of this device as stated on the
rear of the product.
Safety advice
What is a safety RCD module?
Your safety RCD module connuously monitors the power supply to
any electrical appliance plugged in to it and cuts o the power within
40 milliseconds if an earth current fault is detected. This is fast enough
to prevent a fatal electric shock. Electrical equipment can become
dangerous if the wiring becomes loose, if they or their power cords
become damaged, or if they get wet. Electrocuon is also possible if
ngers, spillages or other conducve bodies enter the appliance. In all
these cases your safety RCD socket will instantly cut the electricity
before you or a colleague receives a potenally fatal electric shock.
Latching operaon
If the unit looses supply, perhaps in a power cut or when a hazardous
earth fault occurs, the RCD will trip and cut the power supply.
When the supply resumes through the RCD, the RCD will revert to the
original state and supply power without the need for reseng.
DUE TO LATCHING OPERATION, FOR SAFETY THIS PRODUCT
SHOULD NOT BE USED FOR ANY EQUIPMENT THAT WOULD
CAUSE A HAZARD IF RE-ENERGISED WITHOUT SUPERVISION.
Wire idencaon
Note - As from 1st April 2004 new colour codes were introduced.
EARTH = Green/Yellow
NEUTRAL = Black (pre Apr 04) / Blue (aer Apr 04)
LIVE = Red (pre Apr 04) / Brown (aer Apr 04)
Connecng in to the NEX3031
The NEX3031 must be used with a NEX300 series enclosure
or extrusion. The NEX3031 should never be used without an
enclosure, it has not been designed as a standalone product.
This instrucon manual is for the NEX3031 RCD module only
and must be used in conjuncon with your chosen extrusion/
housing instrucons for specic cable restraint, earthing
requirements, and further installaon steps.
Prepare the input cable, which
must be approved to
BS EN 50525-2-31:2011
HO5VV-F - Strip back the
outer sheathing to reveal
44mm for Live and Neutral
cables, 46mm for Earth.
Strip 8mm o each cable to
reveal the conductor.
HO7V-R - Strip 8mm o each
cable to reveal the conductor.
Loosen the terminal
screws and insert the
correct coloured wire
into each terminal and
ghten.
Ensure only bare ends
enter the terminal and
do not over ghten
the terminal screws.
Slide into extrusion
or assemble into a
NEX300 housing.
Ensure end caps
and cover plates
are ed as per
extrusion or housing
instrucons.
Test procedure - TEST BEFORE USE
Ensure power is on to the NEX3001 - press the RESET buon,
the RED indicator should appear.
Press the TEST buon - the RED indicator should disappear,
DO NOT USE IF THE RED INDICATOR REMAINS.
Press the RESET buon - the RCD has now been set for safe use
provided the RED indicator shows in the clear window.
Connued overleaf...
1
2
3
1
2
3
4
!
8mm
36mm 38mm
N E L
36mm
Note: Cover plate removed for clarity

Service condions
This RCD is only suitable for use under the following condions of
service:
An ambient temperature range of -5°C to +40°C, with an
average value not exceeding +35°C over one full day.
An altude not exceeding 2000m above sea level.
An atmosphere not subject to excessive polluon by smoke,
chemical or ammable fumes; salt-laden spray; prolonged
periods of high humidity or other abnormal condions.
Not suitable for exposure to direct radiaon from the sun or
other source of heat likely to raise the temperature above the
designated ambient, nor may it be suitable for subjecon to
excessive vibraon.
Where service condions dier from those prescribed above the
advice of the manufacturer or responsible vendor should be sought.
Technical
Batch code explanaon
yyWxx Manufacturing date code, year of manufacture (yy) and week of
manufacture (Wxx)
Address / Helpline
If you need further technical assistance you can get in touch with our
Technical Helpline on [phone]
email: [email protected]
Environmental protecon
This symbol is known as the “Crossed-out Wheelie Bin
Symbol”. When this symbol is marked on a product or
baery, it means that it should not be disposed of with your
general household waste. Some chemicals contained within
electrical/electronic products or baeries can be harmful
to health and the environment. Only dispose of electrical/
electronic/baery items in separate collecon schemes,
which cater for the recovery and recycling of materials
contained within. Your co-operaon is vital to ensure the
success of these schemes and for the protecon of the
environment.
Luceco PLC
Staord Park 1
Telford TF3 3BD
ENGLAND
(EU) Luceco SE
C/ Bobinadora 1-5
08302 Mataró
SPAIN
Voltage: 220-240V ac
Frequency: 50/60Hz
Rang: 16A
RCD rang: 30mA
Trip speed: 40 ms
Trip contacts: Double pole
RCD type: Latching mechanism,
Type AC
Terminal capacity: 2 x 2.5mm²
1 x 4mm²
ASTA Approved
The ASTA quality mark is evidence that the product has
been independently tested to comply with the relevant
clauses of the applicable standards.
130mm
50mm
42 mm
1
2
3
4
