Nibe AXC 30 User guide

Installer manual
Accessory card
IHB 2113-3
231464
AXC 30
UN

S-series
S1255
4
S-series
F-series
45
F-series

S-series
4Important information
5General
6Common electrical connection
8Shunt controlled additional heat
13Step controlled additional heat
17Extra climate system
22Hot water comfort
27Active cooling in 4-pipe system
32Pool heating
38
Connecting charge pumps in the case of multiple heat
pumps
43Technical data
83Contact information
3AXC 30
S
S-SERIES
Table of Contents

Important information
SAFETY INFORMATION
This manual describes installation and service proced-
ures for implementation by specialists.
The manual must be left with the customer.
This appliance can be used by children
aged from 8 years and above and persons
with reduced physical, sensory or mental
capabilities or lack of experience and
knowledge if they have been given super-
vision or instruction concerning use of the
appliance in a safe way and understand
the hazards involved. Children shall not
play with the appliance. Cleaning and user
maintenance shall not be made by children
without supervision.
This is an original manual. It may not be
translated without the approval of NIBE.
Rights to make any design or technical
modifications are reserved.
©NIBE 2021.
SYMBOLS
NOTE
This symbol indicates danger to person or ma-
chine .
Caution
This symbol indicates important information
about what you should consider when installing
or servicing the installation.
TIP
This symbol indicates tips on how to facilitate
using the product.
MARKING
The CE mark is obligatory for most products
sold in the EU, regardless of where they are
made.
CE
Classification of enclosure of electro-technical
equipment.
IP21
Danger to person or machine.
!
Read the Installer Manual.
AXC 30 S-series | GB4
S
S-series

General
This accessory is used to enable connection and control
of the following accessory functions. One AXC 30 is
required for each function.
In the control module, there are connections to enable
the connection and control of one of the following ac-
cessory functions. One, or more, additional accessory
functions require one AXC 30 each.
• shunt-controlled additional heat
• step-controlled additional heat
• extra climate system
• hot water comfort
• active cooling (4-pipe system)
• pool heating
• connection of several heat pumps.
COMPATIBLE PRODUCTS
• SMO S40
CONTENTS
Cable ties4 x
Heating pipe paste2 x
Insulation tape1 x
AXC module1 x
Aluminium tape2 x
Temperature sensor2 x
COMPONENT LOCATION, AXC MODULE
(AA25)
AA5-X4 AA5-S2
AA5-X2
AA5
AA25-X1
AA5-X9
AA25-FC1
ELECTRICAL COMPONENTS
Accessory cardAA5
DIP switchAA5-S2
Terminal block, inputsAA5-X2
Terminal block, communicationAA5-X4
Terminal block, outputsAA5-X9
AXC moduleAA25
Miniature circuit-breakerAA25-FC1
Terminal block, power supplyAA25-X1
Designations according to standard EN 81346-2.
5AXC 30 S-series | GB
S

Common electrical
connection
NOTE
All electrical connections must be carried out
by an authorised electrician.
Electrical installation and wiring must be carried
out in accordance with the stipulations in force.
The main product must be disconnected from
the power supply when installing AXC 30.
• To prevent interference, sensor cables to external
connections must not be laid close to high voltage
cables.
• The minimum area of communication and sensor
cables to external connections must be 0.5 mm² up
to 50 m, for example EKKX, LiYY or equivalent.
• AXC 30 must be installed via an isolator switch. The
cable area has to be dimensioned based on the fuse
rating used.
• Mark the relevant electrical cabinet with a warning
about external voltage, in those cases where a com-
ponent in the cabinet has a separate supply.
• AXC 30 restarts after a power failure.
Electrical circuit diagrams are at the end of the chapter
for each connection option.
CABLE LOCK
Use a suitable tool to release/lock cables in terminal
blocks.
LEK
1
1
2
2
3
3
1
2
3
3
4
1
2
LEK
1
1
2
2
3
3
1
2
3
3
4
1
2
1
2
MOUNTING
The AXC module (AA25) is a separate, electric control
module and must be mounted on a wall.
Caution
The screw type must be adapted to the surface
on which installation is taking place.
UN
Use all mounting points and mount the module upright,
flat against the wall.
Leave at least 100 mm of free space around the module
to allow access and make cable routing easier during
installation and servicing.
NOTE
The installation must be carried out in such a
way that IP21 is satisfied.
OVERVIEW ACCESSORY BOARD (AA5)
ON
12345678
-X9
-X2
24 20212223 1516171819 1011121314 56789 1
1
N
L
PE
PE
1
2
3
4
5
6
7
8
2
3
4
5
6
7
8
9
234
-X8
-X4
-X10
-X1
AA5-X2 AA5-X9AA5-S2
AA5-X4
CONNECTING COMMUNICATION
AXC 30 contains an accessory board (AA5) that connects
directly to the control module on its joint board (terminal
block AA100-X9).
If more accessories are to be connected, or are already
installed, the boards are connected in series.
AXC 30 S-series | GB6
S

Because there can be different connections for accessor-
ies with accessory board (AA5), you should always read
the instructions in the manual for the accessory that is
to be installed.
+12V
GND
B
A
AA100-X9
7
8
9
10
11
12
AA5-X4
1
2
3
4
5
6
7
8
A
B
GND
A
B
GND
AA5-X4
1
2
3
4
5
6
7
8
A
B
GND
A
B
GND
Accessory 1
Accessory 2
SMO S40
POWER CONNECTION
Connect the power supply cable to terminal block AA25-
X1 as illustrated.
Tightening torque for earth cable: 0.5–0.6 Nm.
AA25-X1
N
L
ExterntProduktNamn
2
1
AA25 External
7AXC 30 S-series | GB
S

Shunt controlled
additional heat
GENERAL
This function enables an external additional heater, e.g.
an electric boiler, wood boiler, pellet boiler, oil boiler,
gas boiler or district heating, to assist with the heating.
The indoor module controls a shunt valve (EM1-QN11)
and a circulation pump (EM1-GP10) via the accessory
board in AXC 30. If the heat pump cannot maintain the
correct supply temperature, at the external supply tem-
perature sensor, (EM1-BT25), the additional heat starts.
When the boiler temperature on the boiler sensor (EM1-
BT52) exceeds the set value, the indoor module trans-
mits a signal to the shunt (EM1-QN11) to open from the
additional heat. The shunt (EM1-QN11) is regulated so
the true supply temperature corresponds with the indoor
module’s theoretical calculated set point value. When
the heating demand drops sufficiently, so that additional
heat is no longer required, the shunt (EM1-QN11) closes
completely.
Factory-set minimum operating time for the boiler is 12
hours.
The function smart energy source can be selected if you
want to prioritise automatically between heat pump
operation and additional heat versus the best price or
environmental impact.
PIPE CONNECTIONS
The external circulation pump (EM1-GP10) is placed on
the supply line to the climate system after the temper-
ature sensor (AA35-BT25).
SHUNT VALVE
The shunt valve (EM1-QN11) must be placed on the
supply line to the climate system after the heat pump
according to the outline diagram.
AB
B
A
• Connect the supply line from the
heat pump to the external heat
source via the T-pipe to port B on
the shunt valve (closes on reduce
signal).
• Connect the supply line to the climate system from
the shunt valve to the common port AB (always open)
• Connect the supply line from the external additional
heat to the shunt valve to port A (opens on increase
signal).
TEMPERATURE SENSOR
• Install the boiler sensor (EM1-BT52) in a suitable loca-
tion in the external additional heat.
•The external supply temperature sensor (AA35-BT25),
connected in the indoor module’s control module,
must be installed on the supply line to the climate
system after the shunt valve (EM1-QN11).
LEK
LEK
E
Install the temperature sensors using cable ties, together
with the heat conducting paste and aluminium tape.
Then insulate with the enclosed insulation tape.
NOTE
To prevent interference, sensor cables to ex-
ternal connections must not be laid close to
high voltage cables.
AXC 30 S-series | GB8
S

SYSTEM DIAGRAM
Caution
This is an outline diagram. Actual installations
must be planned according to applicable
standards.
EXPLANATION
Mixing valve controlled additional heat,
boiler
EM1
AXC moduleAA25
Boiler sensorBT52
External heating medium pumpGP10
Mixing valve, additionQN11
SMO S40AA35
External supply temperature sensorBT25
External return line sensorBT71
Miscellaneous
Non-return valveRM1
OUTLINE DIAGRAM WITH
SHUNT-CONTROLLED ADDITIONAL HEAT
-EM1
-GP10
-AA35-BT25
-RM1
-AA35-BT71
-AA35
-EM1-AA25
-EM1-BT52
-EM1-QN11
-EM1
-EM1
ELECTRICAL CONNECTION
NOTE
Read section "Common electrical connection"
for instructions regarding electrical connection.
CONNECTION OF SENSORS AND EXTERNAL
BLOCKING
Boiler sensor (EM1-BT52)
Connect the sensor to AA5-X2:23-24.
Caution
Sensor cable splicing must fulfil IP54.
24 23 22 21 20 19 18 17 16 15 14 13
AA25
External
BT52
AA5-X2
External blocking (optional)
A contact (NO) can be connected to AA5-X2:21-22 to
block the accessory. When the contact closes, the ac-
cessory is blocked.
24 23 22 21 20 19 18 17 16 15 14 13
AA25
External
External blocking
AA5-X2
External supply temperature sensor (AA35-BT25)
Sensor (BT25) must be connected in the main product.
See the Installer Manual for the main product.
External return line sensor (AA35-BT71)
Sensor (BT71) must be connected in the main product.
See the Installer Manual for the main product.
9AXC 30 S-series | GB
S

Caution
The relay outputs on the accessory board can
have a max load of 2A (230V) in total.
CONNECTION OF THE CIRCULATION PUMP
(EM1-GP10)
Connect the external heating medium pump (GP10) to
AA5-X9:7 (N), AA5-X9:8 (230 V) and X1:PE.
1
2
3
4
5
6
7
8
9
AA5-X9
2
1
1
M
AA25-X1
ExternalAA25
GP10
CONNECTION OF THE SHUNT VALVE
MOTOR (EM1-QN11)
Connect the shunt motor (QN11) to AA5-X9:6 (230V,
open), AA5-X9:5 (N) and AA5-X9:4 (230V, close).
1
2
3
4
5
6
7
8
9
AA25 External
AA5-X9
QN11
Open SH +
N
SH -
Close
Connection of 0-10 V control of shunt motor
(EM1-QN11)
Connect a 2-core cable to AA5-X2:5 (0-10 V) and AA5-
X2:6 (GND).
AA5-X2
0-10V
GND
7654
AA25
External
At 0 V the shunt is closed and at 10 V the shunt is open.
CONNECTION OF THE AUXILIARY RELAY
FOR ADDITIONAL HEATING
Connect the auxiliary relay for switching the additional
heat on and off to AA5-X9:2 (230V) and AA5-X9:3 (N).
L
N
A1 A2
External auxiliary relay
Additional
Heating
1
2
3
4
Additional
heat
External auxiliary relay
AA5-X9
AA25 External
DIP SWITCH
The DIP switch (S2) on the accessory board (AA5) must
be set as follows.
32
1
ON
476
58
AXC 30 S-series | GB10
S

PROGRAM SETTINGS
Program setting of AXC 30 can be performed via the
start guide or directly in the menu system.
Start guide
The start guide appears at first start-up after the heat
pump installation, but can also be found in menu 7.7.
MENU SYSTEM
If you do not make all settings via the start guide or need
to change any of the settings, this can be done in the
menu system.
Menu 7.2.1 - Add/remove accessories
Here, you state which accessories are installed for the
compatible product.
To identify connected accessories automatically, select
"Search for accessories". It is also possible to select ac-
cessories manually from the list.
Menu 7.2.3 - Shunt-contr. add. heat(AXC)
Prioritised add. heat
Setting range: on/off
Setting range: 0 – 2000 DM
Minimum operating time
Setting range: 0 – 48 h
Lowest temperature
Setting range: 5 – 90 °C
Shunt amplification
Setting range: 0.1 –10.0
Shunt waiting time
Setting range: 10 – 300 s
Set when the addition is to start, the minimum run time
and the minimum temperature for external addition with
shunt here. External addition with shunt is for example
a wood/oil/gas/pellet boiler.
You can set shunt valve amplification and shunt valve
waiting time.
Selecting "Prioritised add. heat" uses the heat from the
external additional heat instead of the heat pump. The
shunt valve is regulated as long as heat is available,
otherwise the shunt valve is closed.
See the accessory installation instructions for function
description.
Menu 7.5.3 - Forced control
Here you can force control the various components in
the installation. The most important safety functions
remain active however.
NOTE
Forced control is only intended to be used for
troubleshooting purposes. Using the function
in any other way may cause damage to the
components in your climate system.
Menu 4.6 - Smart Energy Source
Smart Energy Source
Alternative: on/off
Control method
Alternatives: Price per kWh / CO2
If Smart Energy Source™ is activated AXC 30 prioritises
how / to what extent each docked energy source will
be used. Here you can select whether the system will
use the energy source that is cheapest at the time or
the one that is most carbon dioxide neutral at the time.
Caution
Your choices in this menu affect menu 4.7 -
Energy price.
Caution
Also see the Installer Manual for the main
product.
11AXC 30 S-series | GB
S

ELECTRICAL CIRCUIT DIAGRAM
WIRING DIAGRAM SHUNT CONTROL ELSCHEMA SHUNTSTYRD 051055 8
AXC 30 S-series | GB12
S

Step controlled
additional heat
GENERAL
This function enables an external additional heater, e.g.
an electric boiler, to aid with heating.
With AXC 30, three potential-free relays can be used for
additional heat control, which then gives max. 3 linear
or 7 binary steps. Inside the control module, a further
three potential-free relays can be used for additional
heat control, which then provides a further 3 linear or 7
binary steps.
The flow through the additional heat is ensured by the
external circulation pump (EB1-GP10).
PIPE CONNECTIONS
The external circulation pump (EM1-GP10) is placed on
the supply line to the climate system after the temper-
ature sensor (AA35-BT25).
If the climate system’s flow exceeds the maximum re-
commended flow for the electric boiler, a bypass must
be installed so that only a partial flow passes through
the electric boiler.
TEMPERATURE SENSOR
•The external supply temperature sensor (AA35-BT25),
connected in the indoor module’s control module,
must be installed on the supply line to the climate
system after the additional heat.
LEK
LEK
E
Install the temperature sensors using cable ties, together
with the heat conducting paste and aluminium tape.
Then insulate with the enclosed insulation tape.
NOTE
To prevent interference, sensor cables to ex-
ternal connections must not be laid close to
high voltage cables.
SYSTEM DIAGRAM
Caution
This is an outline diagram. Actual installations
must be planned according to applicable
standards.
EXPLANATION
Step controlled additional heatEB1
AXC moduleAA25
External heating medium pumpGP10
SMO S40AA35
External supply temperature sensorBT25
External return line sensorBT71
Miscellaneous
Shut-off valveQM42-43
Trim valveRN1
Non-return valveRM1
OUTLINE DIAGRAM WITH
STEP-CONTROLLED ADDITIONAL HEAT
-EB1
-GP10
-AA35
-BT25
-RN1
-QM42
-QM43 -RM1
-AA35
-AA35-BT71
-EB1-AA25
-EB1
-EB1
13AXC 30 S-series | GB
S

ELECTRICAL CONNECTION
NOTE
Read section "Common electrical connection"
for instructions regarding electrical connection.
CONNECTION OF SENSORS AND EXTERNAL
BLOCKING
External blocking (optional)
A contact (NO) can be connected to AA5-X2:23-24 to
block the accessory. When the contact closes, the ac-
cessory is blocked.
Caution
The relay outputs on the accessory board can
have a max load of 2 A (230 V) in total.
24 23 22 21 20 19 18 17 16 15 14 13
AA25
External
External blocking
AA5-X2
External supply temperature sensor (AA35-BT25)
Sensor (BT25) must be connected in the main product.
See the Installer Manual for the main product.
External return line sensor (AA35-BT71)
Sensor (BT71) must be connected in the main product.
See the Installer Manual for the main product.
Caution
The relay outputs on the accessory board can
have a max load of 2A (230V) in total.
CONNECTING HEATING MEDIUM PUMP
(EB1-GP10)
Connect the external heating medium pump (GP10) to
AA5-X9:7 (N), AA5-X9:8 (230 V) and X1:PE.
1
2
3
4
5
6
7
8
9
AA5-X9
2
1
1
M
AA25-X1
ExternalAA25
GP10
CONNECTION OF RELAYS
Connecting additional step
Connect step 1 to AA5-X9:1 and 2.
Connect step 2 to AA5-X9:3 and 4.
Connect step 3 to AA5-X9:5 and 6.
AA5-X9
ExterntProduktnamn
Steg 1
Steg 2
Steg 3
A2A1
A2
A1
A2A1
1
2
3
4
5
6
7
AA5-X9
AXC30 External
Step 1
Step 3
Step 2
Connection of 0-10 V control of additional heat step
Connect a 2-core cable to AA5-X2:5 (0-10 V) and AA5-
X2:6 (GND).
AA5-X2
0-10V
GND
7654
AA25
External
0 V = 0 steps and 10 V = max. number of set steps.
AXC 30 S-series | GB14
S

DIP SWITCH
The DIP switch (S2) on the accessory board (AA5) must
be set as follows.
32
1
ON
476
58
PROGRAM SETTINGS
Program setting of AXC 30 can be performed via the
start guide or directly in the menu system.
START GUIDE
The start guide appears upon first start-up after the heat
pump installation, but is also found in menu 7.7.
MENU SYSTEM
If you do not make all settings via the start guide or need
to change any of the settings, this can be done in the
menu system.
Menu 7.2.1 - Add/remove accessories
Here, you state which accessories are installed for the
compatible product.
To identify connected accessories automatically, select
"Search for accessories". It is also possible to select ac-
cessories manually from the list.
Menu 7.2.6 - Step-control add. heat(AXC)
Relative DM start additional heat
Setting range: 0 – 2000 DM
Diff. between add heat steps
Setting range: 0 – 1,000 DM
Max step
Setting range
(binary stepping deactivated): 0 – 3
Setting range
(binary stepping activated): 0 – 7
Binary stepping
Setting range: on/off
Make settings for step controlled addition here. Step
controlled addition is for example an external electric
boiler.
It is possible, for example, to select when the additional
heat is to start, to set the maximum number of permit-
ted steps and whether binary stepping is to be used.
When binary stepping is deactivated (off), the settings
refer to linear stepping.
See the accessory installation instructions for function
description.
Menu 7.5.3 - Forced control
Here you can force control the various components in
the installation. The most important safety functions
remain active however.
NOTE
Forced control is only intended to be used for
troubleshooting purposes. Using the function
in any other way may cause damage to the
components in your climate system.
Caution
Also see the Installer Manual for the main
product.
15AXC 30 S-series | GB
S

ELECTRICAL CIRCUIT DIAGRAM
WIR. DIAGRAM STEP CONTROLLED ELSCHEMA STEGSTYRD TILLSATS 051056 8
AXC 30 S-series | GB16
S

Extra climate system
GENERAL
This function is used when SMO S40 is going to control
more than one climate system. It is possible to connect
up to eight different climate systems (heating and/or
cooling systems) that require different supply temperat-
ures, for example where the house has both radiator
systems and underfloor heating systems.
Caution
With underfloor heating systems, the maxim-
um supply temperature is normally set
between 35 and 45 °C.
Check the max floor temperature with your
floor supplier.
Caution
If a room sensor is used in a room with under-
floor heating, it should only have an indicatory
function, not control of the room temperature.
PIPE CONNECTIONS
GENERAL
When connecting extra climate systems, they must be
connected so that they have a lower working temperat-
ure than the climate system 1.
CIRCULATION PUMP
The extra circulation pump (EP21-GP10) is positioned in
the extra climate system according to the outline dia-
gram.
SHUNT VALVE
The shunt valve (EP21-QN25) is located on the supply
line after the heat pump/indoor module, before the first
radiator in the climate system 1. The return line from
the extra climate system is connected to the shunt valve
and to the return line from the climate system 1, see
image and outline diagram.
B
A
AB
• Connect the supply line to the climate
system from the heat pump to port A on
the shunt valve (opens on increase signal)
• Connect the return line from the climate
system to port B on the shunt valve via
the T-pipe (closes on reduce signal).
• Connect the supply line to the climate system to the
common port AB on the shunt valve (always open).
TEMPERATURE SENSOR
• The supply line sensor (EP21-BT2) is installed on the
pipe between the circulation pump (EP21-GP10) and
shunt valve (EP21-QN25).
• The return line sensor (EP21-BT3) is installed on the
pipe from the extra climate system.
LEK
LEK
E
Install the temperature sensors using cable ties, together
with the heat conducting paste and aluminium tape.
Then insulate with the enclosed insulation tape.
NOTE
To prevent interference, sensor cables to ex-
ternal connections must not be laid close to
high voltage cables.
SYSTEM DIAGRAM
Caution
This is an outline diagram. Actual installations
must be planned according to applicable
standards.
EXPLANATION
Climate systemEP21
AXC moduleAA25
Flow temperature sensor, extra climate
system
BT2
Return line sensor, extra climate systemBT3
Circulation pump, extra climate systemGP10
Shunt valveQN25
Non-return valveRM1
SMO S40AA35
External supply temperature sensorBT25
External return line sensorBT71
External heating medium pumpGP10
Non-return valveRM1.2
-EP21-RM1
-EP21-GP10-EP21-BT2
-EP21-AA25
-EP21-BT3
-EP21-QN25
-EP21
-AA35
-GP10
-AA35
-AA35
-BT25
-AA35-BT71
-RM1.2
17AXC 30 S-series | GB
S

ELECTRICAL CONNECTION
NOTE
Read section "Common electrical connection"
for instructions regarding electrical connection.
CONNECTION OF SENSORS AND EXTERNAL
ADJUSTMENT
Supply temperature sensor, extra climate system
(EP21-BT2)
Connect the supply temperature sensor to AA5-X2:23-
24.
24 23 22 21 20 19 18 17 16 15 14 13
AA25
External
BT2
AA5-X2
Return line sensor, extra climate system
(EP21-BT3)
Connect the return line sensor to AA5-X2:21-22.
24 23 22 21 20 19 18 17 16 15 14 13
AA25
External
BT3
AA5-X2
Room sensor, extra climate system (EP21-BT50)
(optional)
Connect the room sensor to AA5-X2:19-20.
24 23 22 21 20 19 18 17 16 15 14 13
AA25
External
BT50
AA5-X2
External supply temperature sensor (AA35-BT25)
Sensor (BT25) must be connected in the main product.
See the Installer Manual for the main product.
External return line sensor (AA35-BT71)
Sensor (BT71) must be connected in the main product.
See the Installer Manual for the main product.
External adjustment (optional)
A potential-free switch can be connected to AA5-X2:17-
18 for external adjustment of the climate system.
24 23 22 21 20 19 18 17 16 15 14 13
AA25
External
AA5-X2
External adjustment
Caution
The relay outputs on the accessory board can
have a max load of 2A (230V) in total.
CONNECTION OF THE CIRCULATION PUMP
(EP21-GP10)
Connect the external heating medium pump (GP10) to
AA5-X9:7 (N), AA5-X9:8 (230 V) and X1:PE.
Connect 0-10V control signal for heating medium pump
(GP10) to AA5-X2:5(0-10V) and AA5-X2:6(GND)
1
2
3
4
5
6
7
8
9
5 4 367891011
AA5-X9
AA5-X2
1
M
2
1
AA25-X1
AA25 External
GP10
Pump speed EP21-GP10
approx. 0 V DC100 %
approx. 5 V DC50 %
approx. 10 V DC0 %
AXC 30 S-series | GB18
S

CONNECTING EXTERNAL HEATING MEDIUM
PUMP (AA35-GP10)
To connect the external heating medium pump (GP10,
see the relevant product’s Installer Manual.
CONNECTION OF THE SHUNT VALVE
MOTOR (EP21-QN25)
Connect the shunt motor (QN25) to AA5-X9:6 (230V,
open), AA5-X9:5 (N) and AA5-X9:4 (230V, close).
1
2
3
4
5
6
7
8
9
AA25 External
AA5-X9
QN25
Open SH +
N
SH -
Close
Connection of 0-10 V control of shunt motor
(EP21-QN25)
Connect a 2-core cable to AA5-X2:7 (0-10 V) and AA5-
X2:8 (GND).
AA5-X2
0-10V
GND
9876
AA25
External
At 0 V the shunt is closed and at 10 V the shunt is open.
DIP SWITCH
Connections in the control module are used to enable
connection and control of the climate system 2. One or
more additional climate systems require one AXC 30
each. The DIP switch (S2) on the accessory board (AA5)
must be set as follows, with each climate system having
a unique setting.
Climate system
5432
ON
12345678
ON
1 2 3 4 5 6 7 8
ON
1 2 3 4 5 6 7 8
ON
1 2 3 4 5 6 7 8
876
ON
12345678
ON
12345678
ON
12345678
19AXC 30 S-series | GB
S

PROGRAM SETTINGS
Activating AXC 30 can be performed via the start guide
or directly in the menu system.
START GUIDE
The start guide appears upon first start-up after heat
pump installation, but is also found in menu 7.7.
MENU SYSTEM
If you do not make all settings via the start guide or need
to change any of the settings, this can be done in the
menu system.
Menu 7.2.1 - Add/remove accessories
Here, you state which accessories are installed for the
compatible product.
To identify connected accessories automatically, select
"Search for accessories". It is also possible to select ac-
cessories manually from the list.
Menu 1.1 - Temperature
You make temperature settings for your installation here.
Menu 1.3 - Room sensor settings
Here, you make your settings for room sensors and
zones. The room sensors are grouped by zone.
Here, you select the zone to which a sensor will belong.
It is possible to connect multiple room sensors to each
zone. Each room sensor can be given a unique name.
The control of heating, cooling, humidity and ventilation
are activated by ticking each option. Which options are
shown depends on which type of sensor is installed. If
control is not activated, the sensor will be the displaying
sensor.
Caution
A slow heating system such as underfloor
heating may be inappropriate for controlling
with room sensors.
Menu 1.30.7 - Own curve
Own curve, heat
Caution
Curve 0 must be selected for own curve to
apply.
You can create your own heating curve here, if there
are special requirements, by setting the desired supply
temperatures for different outdoor temperatures.
Supply temp
Setting range: 5 – 80 °C
Own curve, cooling
Caution
Curve 0 must be selected for own curve to
apply.
You can create your own cooling curve here, if there are
special requirements, by setting the desired supply
temperatures for different outdoor temperatures.
Supply temp
Setting range: -5 – 40 °C
Menu 7.2.4 - Extra climate system (ECS)
Use in heating mode
Setting range: on/off
Use in cooling mode
Setting range: on/off
Shunt amplification
Setting range: 0.1 – 10.0
Shunt waiting time
Setting range: 10 – 300 s
Contr. pump GP10
Setting range: on/off
Control signal
Setting range: PWM / 0-10V*
Manual speed
Setting range: 0 – 100%
Factory setting: 70%
*Factory setting
The shunt amplification and shunt waiting time for the
different extra climate systems that are installed are
also set here.
Menu 7.5.3 - Forced control
Here you can force control the various components in
the installation. The most important safety functions
remain active however.
NOTE
Forced control is only intended to be used for
troubleshooting purposes. Using the function
in any other way may cause damage to the
components in your climate system.
Caution
Also see the Installer Manual for the main
product.
AXC 30 S-series | GB20
S
