Nibe Contura C 720T User manual

www.contura.eu
C 720T
Installation
instructions

66
GB
CERTIFICATE
PRODUCT
Product type Stove lit with solid biofuels
Type designation Contura 720T
Manufacturing number See rating plate on the stove
Intended area of use Heating of rooms in residential buildings
Fuel Wood
MANUFACTURER
Name NIBE AB / Contura
Address Box 134, Skulptörvägen 10
SE-285 23 Markaryd, Sweden
CHECKS
According to AVCP System 3
European standard EN 13240:2001 / A2:2004
Test institute Rein-Ruhr Feuerstätten Prüfstelle, NB 1625,
has checked declared performance and issued test report no. RRF-40 16 4275
PERFORMANCE DECLARATION
No. C720T-CPR-160329-SE-1
DECLARED PERFORMANCE
Essential characteristics Performance Harmonised technical
specification
Reaction to fire A1 WT
Minimum distance to combustible material Rear: 100 mm
Side: 400 mm
Other safety distances according to
the installation instructions
Risk of falling embers Pass
Emissions from combustion CO 0.1%
NOx 103 mg/m3
OGC 77 mg/m3
PM 23 mg/m3
Surface temperatures Pass
Cleaning options Pass
Mechanical durability Pass
Emissions of hazardous substances Pass
Nominal output 5 kW
Efficiency 80%
Flue gas temperature in connector at nominal
output
315°C
EN 13240:2001 / A2:2004
The undersigned is responsible for the manufacture and conformity with the declared performance.
Niklas Gunnarsson, Business area manager NIBE STOVES
Markaryd, March 29, 2016

67
GB
WARNING!
The stove becomes very hot
During operation, certain surfaces of the stove become very
hot and can cause burn injuries if touched. Also, take heed
of the strong heat radiated through the door glass. Placing
flammable material closer than the safe distance indicated
may cause a fire. Smoulder combustion can cause quick gas
ignition with the risk of damage to property and personal
injury.
NOTE:
Report the installation of a stove to your
local authority.
The owner of the house is personally responsible for ensuring
compliance with the mandatory safety requirements and
must have the installation approved by a qualified inspector.
Your local chimney sweep must also be informed about the
installation as this will affect the routines for regular chimney-
sweeping services.
List of Contents
Technical details 68
Prior to installation 68
Connection to chimney 69
Supply of combustion air 70
Installation distances 71
Installing suspension profiles 72
Installing the soapstone 75
Removing the loose parts 77
Adjustment of the base door 78
A warm welcome to Contura.
A warm welcome to the Contura family. We hope you
will get a great deal of pleasure from your new stove.
As a new owner of a Contura stove, you have secured
a product with timeless design and long service life.
Contura also has a combustion process that is both
environmentally friendly and efficient, for the best heat
production.
Read through these installation instructions carefully
before installation. Read how to best light your stove
in the lighting instructions.
CONTENTS

4
3
2
1
68
GB
FACTS
Effect 3-7 kW
Nominal effect 5 kW
Efficiency up to 80%
Model 720T
Height (mm) 1179
Width (mm) 556
Depth (mm) 407
Weight (kg) 210
Type approved in accordance with:
European standard EN-13240
NS 3059 (Norway)
DIN Plus (Germany)
Art. 15a B-VG (Austria)
Clean Air Act. (UK)
Prior to installation
If the insert needs to be put down
to be moved, loose components
should be removed. When the stove is
installed reinstall the components in
reverse order.
1 Fire bars
2 Grate disc
3 Heat deflector
4 Fire bricks
Installation by authorised
technician
This manual contains instructions about
how the stove must be assembled and
installed. To ensure the function and safety
of the stove, we recommend that the
installation is carried out by an authorised
technician. Contact one of our dealers who
can recommend suitable fitters.
Building application
These main instructions may give guidance
which would contravene national building
regulations. Please refer to supplementary
instructions or ask your local authority for
advice regarding building regulations.
Before installing a stove or erecting a
chimney it is necessary for you to make a
building permission application to your
local authority.
Structural support
Check that the wood joists are strong
enough to bear the weight of the stove and
chimney. The stove and chimney can usually
be placed on a normal wooden joist in a
single occupancy house, if the total weight
does not exceed 400 kg.
Floor plate
Due to the risk of falling embers, a
flammable floor must be protected by a
hearth plate. It must extend 300 mm in
front of the stove and 100 mm on each side
of the stove, or have a 200 mm extension
on each side of the opening. The hearth
plate can consist of natural stone, concrete,
metal plate or glass. A painted metal
or glass hearth plate is available as an
accessory for these models.
Important to remember!Technical details

Ø
ca 180 mm
Ø
ca 180 mm
!
4 65
1 32
69
GB
CHIMNEY
Connection to chimney
Rear connection to a masonry chimney
Top connection to the chimney
Make sure that the connector
gasket does not work loose
when the connection pipe
is placed on the connector.
If further sealing material
is required, heat-resistant
sealant may be used.
The back panel must be installed before the stove is rear connected.
The hot air grille must be installed before
chimney top connection.
• The stove meets the requirements for connecting to chimneys
dimensioned for 350°C flue gas temperature.
• The external diameter of the connection sleeve is 150 mm.
• The stove requires a draft in the chimney of at least –12 Pa. The
draft is affected both by the length and area of the chimney, and
by how well sealed it is. The minimum recommended chimney
length is 3.5 m and suitable cross sectional area is 150-200 cm²
(140-160 mm in diameter).
• A flue with sharp bends and horizontal routing reduces the
draught in the chimney. The maximum horizontal flue is 1 m, on the
condition that the vertical flue length is at least 5 m.
• It must be possible to sweep the full length of the flue and the
soot doors must be easily accessible.
• Carefully check that the chimney is sealed and that there is no
leakage around soot doors and flue connections.
In the bag with these installation instruc-
tions are two wing screws for the lid.

!
HK
HK
40 mm
HK
40 mm
HK
40 mm
70
GB
SUPPLY AIR
Supply of combustion air
When a stove is installed in a room, the demand for air supply to the
room increases. Air can be provided indirectly via a vent in the outer
wall or via a duct from the outside that is connected to the connector
on the underneath of the stove. The amount of air needed for
combustion is approx. 15m3/h.
The connector has an external diameter of 67 mm. When duct
routing further than 1 m the pipe diameter must be increased to 100
mm and a correspondingly larger wall vent must be selected.
In hot areas the duct should be insulated with 30 mm mineral wool
covered with a moisture inhibitor (plastic). It is important that the
lead-in between the pipe and the wall (or floor) is sealed using
jointing compound.
A 1 m length of condensation-insulated ducting for combustion air is
available as an accessory.
Through the external wall.
Indirect air supply through the external wall.
Through floor and foundation slab.
Through floor and wall-and-cavity foundation.
In the back and floor plates there are
knockouts that must be removed to
insert the pipe.
Installation variants
Leave a 40 mm gap between
the condensation insulation
and the bottom of the stove.

!
C 720T
71
GB
INSTALLATION DISTANCES
* If the stove is placed on a hearth plate made of glass for example (accessory), the height from the floor is affected by a distance corresponding to the thickness of the hearth plate. Also applies to
separate glass hearth plates (accessory).
** To prevent discolouration of painted non-flammable walls we recommend that the same side distance as to combustible walls is used.
The minimum distance in front of
the stove opening to combustible
parts of the building or interior
decoration must be at least 1 m.
The dimension diagrams only
show the minimum permitted
installation distances for the
stove. When connecting to a steel
flue, also note the safety distance
requirements of the flue. The
safety distance between an un-
insulated flue and a combustible
part of the building should be at
least 300 mm.
Installation distances
A = height from floor to
chimney connection
upwards
B = height from floor to c/c
chimney connection rear
C = height from floor to air
inlet
D = height from floor to lower
edge of hatch
A separate glass hearth
plate (accessory)
increases the connection
height to the chimney by
10 mm.
Permitted area
for combustible
parts of the
building
D 488
556
1179
2100*
126*
Combustible roof
407
211
A 1129*
139
B 1039*
C 420
71
Ø150
Air inlet Ø67
100
361
643
100
707
Combustible wall
900
900
311
593
50**
636
Fire-retardant wall of
brick or concrete
478
200**
700
1100
261
50**
Fire-retardant wall of
brick or concrete
678
400
479
479
311
100
Combustible wall

3
10
10
VANADIUM
No. 7
CHROME
1 2
72
GB
Installing suspension profiles
ASSEMBLY

5
4
10
10
VANADIUM
No. 7
CHROME
73
GB
ASSEMBLY

6
7
74
GB
ASSEMBLY

1 2
3
75
GB
ASSEMBLY
Installing the soapstone

4
76
GB
Final inspection of the installation
It is extremely important that the installation is inspected by an authorised chimney
sweep before the stove is used. Also read the "Lighting instructions" before lighting for
the first time.
ASSEMBLY

1
3
2
77
GB
Removing the loose parts
How to remove the firebricks
Handle the vermiculite with care. Lift the smoke baffle with one hand whilst
removing the sides. The side posts need not be removed when sweeping. Reinstall
in reverse order
How to remove the heat deflector
REMOVAL

78
GB
Adjustment of the base door
ADJUSTMENT

811277 IAV SE-EX C720T-1
2016-05-04
Contura reserves the right to change dimensions and
procedures described in these instructions at any time without
special notice. The current edition can be downloaded from
www.contura.eu
